FOR-A Diamond CUFF BP User manual

CUFF BP
Blood Pressure Monitoring System Owner’s Manual
Blutdrucküberwachungssystem Bedienungsanleitung
Système de surveillance de la tension artérielle Manuel de l’utilisateur
Sistema per il monitoraggio della
pressione sanguigna Manuale dell'utente
Sistema de supervisión de presión en sangre Manual del propietario
Σύστημα παρακολουθήσης αρτηριακής πίεσης Εγχειρίδιο χρήσης
Bloeddrukbewakingssysteem Handleiding
Tansiyon Ölçüm Sistemi Kullanıcı El Kitabı
Прибор для измерения кровяного давления
Руководство пользователя
Tonometr Příručka vlastníka
Sistema de monitorização de pressão arterial Manual do utilizador
Sistem de monitorizare a tensiunii arteriale Manual de utilizare
ForaCare Suisse AG
0123
Neugasse 55,9000St.
Gallen, Switzerland
www.foracare.ch
Blood PressureMonitoringSystem
CuffBP
IP22
0.8”~1.2”
9.4"~16.9"
24~43cm
2~3cm

EN-1
Safety Information
Read the following Safety Information throughly before using the
device.
• Use this device ONLY for the intended use described in this manual.
• Do NOT use accessories which are not specified by the
manufacturer.
• Do NOT use the device if it is not working properly or damaged.
• Do NOT use under any circumstances on newborns,infants,or
persons who cannot communicate.
• This device does NOT serve as a cure for any symptoms or diseases.
The data measured is for reference only. Always consult your
physician to have the results interpreted.
• Keep the equipment away from hot surfaces.
• Do NOT apply the cuff to areas other than the place directed.
• Proper maintenance and periodically calibration are essential to the
longevity of your device.If you are concerned about your accuracy
of measurement,please contact local customer service for help.
KEEP THESE INSTRUCTIONS IN A SAFE PLACE
Introduction
Intended Use
The Diamond CUFF BP Blood Pressure Monitoring System is
intended to be used to measure the systolic and diastolic blood
pressure and pulse rate by using a non-invasive technique in
which an inflatable cuff is wrapped on the upper arm.
The device also works in unison with iFORA BP app that enables
transmission and sharing capabilities via Bluetooth.
Do not use this system on babies,young children or persons who
cannot express their consent.
Test Principle
Blood pressure is measured non-invasively at the arm based on
oscillometric method.
The reading obtained by single and average mode which use
oscillometic method is for reference only.

EN-2
Product Overview
www.foracare.ch
Blood Pressure Monitoring System
Cuff BP
IP22
0.8”~1.2”
9.4"~16.9"
24~43cm
2~3cm
ForaCare Suisse AG
0123
Neugasse 55, 9000 St.
Gallen, Switzerland
2
4
3
5
6
7
1. Bluetooth LED Indicator 4. Battery Compartment Cover
2. Pressure Cuff 5. Power Button
3. Screen Display 6. Bluetooth Button
Screen Display
1. Systolic Pressure Value 5. Units for Blood Pressure
2. Diastolic Pressure Value 6. Systolic Pressure Symbol
3. IRB (Irregular Rapid Beat)
Symbol
7. Units for Blood Pressure
8. Diastolic Pressure Symbol
4. Low Battery Symbol 9. Pulse Rate
10. Pulse Rate Symbol
Getting Started
Installing the Batteries
Before using the device for the first time,please install four 1.5V
AAA size alkaline batteries.
1. Push down the battery compartment cover to open it.
2. Align the batteries contacts and then insert the batteries into
the battery compartment.

EN-3
3. Close the battery compartment cover.
Installing the APP
With iFORA BP app, you can use your mobile device to track your
blood pressure trends and share the progress across an Android
or iOS mobile device.
Download and install iFORA BP app from Play Store/App Store.
The iFORA BP app icon ( ) is displayed on the Home screen
after the installation is complete.
Pairing with Your Mobile Device
To pair your Diamond CUFF BP with your mobile device, do the
following:
1. Press and hold the Bluetooth button for at least 3 seconds.
3s
““ will appear on the screen during pairing process.
2. On your mobile device,activate the Bluetooth function.Then
search for“DIAMOND CUFF BP“.
3. Tap DIAMOND CUFF BP to start pairing.The Bluetooth LED
indicator will blink during the pairing process.
4. When pairing is complete,the main screen appears on the
mobile device’s screen.

EN-4
Note:
• If the device is left idle for 3 minutes,it will turn off automatically.
• The Bluetooth pairing process is only required when user needs to
pair this device to a Bluetooth receiver for the first time,or when
user needs to pair this device to another new Bluetooth receiver.
Testing Your Blood Pressure
Before Measument
• Avoid caffeine,tea, alcohol and tobacco for at least 30 minutes
before measurement.
• Wait 30 minutes after exercising or bathing before
measurement.
• Sit or lie down for at least 10 minutes before measurement.
• Do not measure when feeling anxious or tense.
• Take a 5-10 minute break between measurements.This
break can be longer if necessary, depending on your physical
conditions.
• Keep the records for your doctor as reference.
• Blood pressure varies between each arm. Always measure your
blood pressure on the same arm.
Fitting the Cuff
1. Assemble the cuff.
The smooth surface should be inside the cuff loop and the
metal D-ring should not touch your skin.
Note:
• Before using the cuff, be sure the cuff size fits with your upper
arm circumference.
2. Stretch your left (right) arm in front of you with your palm
facing up.Slide and place the cuff onto your arm with the
artery mark region (in red) toward the lower arm.
Wrap and tighten the cuff above your elbow.The red line on
the edge of the cuff should be approximately 2 to 3 cm (0.8 to
1.2 inches) above your elbow.
0.8”~1.2”9.4"~16.9"
2~3cm25~35cm
3. Leave a little free space between the arm and the cuff.You
should be able to fit 2 fingers between them.
4. Press the hook material firmly against the pile material.The
top and bottom edges of the cuff should be tightened evenly
around your upper arm.
Proper Measurement Position
1. Sit down for at least 10 minutes before measuring.
2. Place your elbow on a flat surface.Relax your hand with the
palm facing up.
3. Make sure the cuff is about the same height as the location of
your heart.

EN-5
Important!
If the cuff is relatively lower (higher) than the heart, the
obtained blood pressure value could be higher (lower) than
the actual value.A 15 cm difference in height may result in an
error around 10 mmHg.
4. Press the Power button.
The device will turn on and the cuff will begin to inflate
automatically. Remain still and do not talk or move during the
measurement.
Measuring Blood Pressure
This device provides you different ways to measure your blood
pressure.
When the device detects an irregular heart beat, the IRB symbol
is shown as“ ”instead of“ ”. If the problem still persists,
please consult your doctor.
Important!
Always apply the pressure cuff before turning on the device.
A. Single Measurement
Perform an individual blood pressure measurement.
1. Press the Power button. All the LCD symbols will appear.Then
the cuff will begin to inflate automatically.
Note:
• When the device is connected to your mobile device (via
Bluetooth),you can also initiate the measurement by tapping
.
• The cuff will begin inflate automatically.
2. The heart symbol“ ”will flash when a pulse is detected
during the inflation.

EN-6
After the measurement,the monitor displays the systolic
pressure,diastolic pressure and pulse rate.
3. Press the Power button to turn the device off.
Note:
• If the device is left idle for 3 minutes,it will turn off automatically.
B. Average Measurement (via APP)
Automatically performs three (3) consecutive blood pressure
measurements and displays the average result in the end.
This function is only available when your Diamond CUFF BP is
connected to your mobile device.
1. Press the Bluetooth button.The“ “ icon will appear on the
display, indicating that the device is ready to transmit data.
Important!
Be sure the device is properly connected to your mobile
device via Bluetooth.
ForaCareSuisse AG
CH-9000St. Gallen
www.foracare.ch
BloodPressure Monitoring System
CuffBP
IP22
0.8”~1.2”
9.4"~16.9"
24~43cm
2~3cm
2. Launch iFORA BP app.The main screen appears on the
mobile device’s screen.
3. Set Average Mode to ON and tap .Then the
cuff will begin to inflate automatically.
4. After the first measurement is complete, the device and
iFORA BP app will start counting down before the second
measurement begins.The device will take three (3)
measurements consecutively with an interval of 20 seconds.
Note:

EN-7
When the difference between the first and second systolic
pressure is more than 15mmHg, the time interval for third
measurement will be 40 seconds.
5. After taken three measurements,the test result is displayed
on the screen. Press the Power button to turn the device off.
Reviewing Test Results
Your device stores the 200 most recent blood pressure test
results along with respective dates and times in the memory. To
recall the memory, you have to connect your Diamond CUFF BP
to your mobile device.Once connected,the measured data is
automatically imported to iFORA BP app.
Appendix
Maintenance
Changing Battery
When the battery is low,one of the following screen will appear:
• the“ “ icon appears with display messages:
This indicates the device is functional and the result remains
accurate,but it is time to change the batteries.
• the“ “ icon appears with E-b:
This indicates the power is not enough for a measurement.You
must change the batteries immediately.
To change the batteries, do the following:
1. Push down the battery compartment cover to open it.
2. Remove the old batteries and replace with four 1.5V AAA size
alkaline batteries.
3. Close the battery compartment cover.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
Note:
• When the“ “ icon appears on the screen,
it indicates that you need to synchronize with your mobile
device in order to adjust the date and time settings.In addition, this
measurement will not be stored in meter memory.
• Replacing the batteries does not affect the test results stored in
memory.However, if you did not synchronize with your mobile
device after the battery replacement, the measured data will not be
stored in the memory.
• Keep away these batteries from small children. If swallowed,
promptly seek medical assistance.
• Batteries may leak chemicals if unused for a long time. Remove the
batteries if you are not going to use the device for an extended
period.
• Properly dispose of the used batteries according to your local
environmental regulations.

EN-8
Caring for Your Device
• To clean the device exterior, wipe it with a cloth moistened
with tap water or a mild cleaning agent,then dry the device
with a soft dry cloth. Do NOT flush with water.
• Do NOT use organic solvents to clean the device.
• Do NOT wash or iron the pressure cuff.
Device Storage
• Storage condition: -25°C to 70°C, within 10%~95% relative
humidity.
• Always store or transport the device in its original storage case.
• Avoid dropping and heavy impact.
• Avoid direct sunlight and high humidity.
Troubleshooting
If you follow the recommended action but the problem persists,
or error messages other than the ones below appear, please call
your local customer service.
Error Message
Error Message Cause What To Do
Inflation or
pressure error.
Please contact local customer
service for help.
Blood Pressure
measurement
error.
Refit cuff tightly and correctly.
Relax and repeat the
measurement. If the error still
remains,please contact local
customer service for help.
Battery is too low. Replace the batteries.
Problem with the
device.
Please contact local customer
service for help.
Blood Pressure Measurement
Symptom Cause What To Do
Nothing is displayed
after pressing the
Power button.
Batteries exhausted. Replace the
batteries.
Batteries incorrectly
installed or no
battery is installed.
Check that the
batteries are
correctly installed.
The heart rate is
higher/lower than
user’s average.
Movement during
measurement.
Repeat
measurement.
Measurement taken
just after exercise.
Rest at least
30 minutes
before repeating
measurement.
The result is higher/
lower than user’s
average measurement.
May not be in correct
position while
measuring.
Adjust to the
correct position to
measure.
Blood pressure
naturally varies from
time to time.
Keep in mind for
next measurement.

EN-9
Reference Values
Blood Pressure
Human blood pressure naturally increases after reaching middle
age.This symptom is a result of continuous ageing of the blood
vessels.Further causes include diabetes,lack of exercise and
cholesterol (LDL) adhering to the blood vessels. Rising blood
pressure accelerates hardening of the arteries,and the body
becomes more susceptible to apoplexy and coronary infarction.
Definitions and Classification of blood pressure levels according to
2007 ESH-ESC Practice Guidelines for the Management of Arterial
Hypertension:
Category Systolic Diastolic
Optimal < 120 mmHg and < 80 mmHg
Normal 120 –129 mmHg and/or 80 –84 mmHg
High normal 130 –139 mmHg and/or 85 –89 mmHg
Grade 1 hypertension 140 –159 mmHg and/or 90 –99 mmHg
Grade 2 hypertension 160 –179 mmHg and/or 100 –109 mmHg
Grade 3 hypertension t180 mmHg and/or t110 mmHg
Isolated systolic
hypertension
t140 mmHg and < 90 mmHg
Isolated systolic hypertension should be graded (1,2, 3) according
to systolic blood pressure values in the ranges indicated,provided
that diastolic values are < 90 mmHg.
Source: The European Society of Hypertension and European Society
of Cardiology Task Force Members. 2007 ESH-ESC Practice Guidelines
for the Management of Arterial Hypertension.J Hypertens 2007; 25:
1751-1762.
Symbol Information
Symbol Referent
Read instructions before use
Manufacturer
Serial number
Caution, consult accompanying documents
Type BF Equipment
Collection for electrical and electronic equipment
Temperature limitation
Humidity limitation
Model number

EN-10
Specifications
System performance
Power Source Four 1.5V AAA alkaline batteries
Dimensions (w/o cuff) 145 (L) x 64.5 mm (W) x 29.6 mm (H)
Weight (w/o cuff) 240g (without batteries)
Cuff Size 24-43 cm (9.4 - 16.9 inches)
Memory Maximum 200 memory records
Power Saving Automatic power off if system is idle
for 3 minutes
Operating Conditions Temperature: 5°C ~ 40°C
Humidity:15% ~ 93%
Storage Conditions Temperature: -25°C ~ 70°C
Humidity:10% ~ 95%
Blood pressure measurement performance
Measurement unit mmHg
Systolic Measurement Range 50 ~ 250 mmHg
Diastolic Measurement
Range 30 ~ 180 mmHg
Pulse Rate Measurement
Range 40 -199 beats / minute
Accuracy of Pressure ±3 mmHg or ±2% of reading
Accuracy of Pulse Rate ±4% of reading
Reference to standards:ANSI/AAMI SP10, IEC 80601-2-30, BS EN ISO
81060-1:2012, ISO 81060-2, MEDDEV 2.7.1, IEC 60601-1, IEC 60601-1-2,
EN 1060 -1/-3/-4, EN 301 489-17, EN 300 328.
WARRANTY TERMS AND
CONDITIONS
With respect to disposable products, ForaCare Suisse warrants
to the original purchaser that,at time of delivery,each standard
product manufactured by ForaCare Suisse shall be free of defects
in material and workmanship and,when used for the purposes
and indications described on the labeling,is fit for the purposes
and indications described on the labeling.All warranties for a
product shall expire as of the product expiration date,or if none,
after one (1) year from the date of shipment from ForaCare
Suisse.ForaCare Suisse warranty hereunder shall not apply if:
(i) a product is not used in accordance with its instructions or
if it is used for a purpose not indicated on the labeling; (ii) any
repairs,alterations or other work has been performed by Buyer or
others on such item, other than work performed with ForaCare
Suisse’s authorisation and according to its approved procedures;
or (iii) the alleged defect is a result of abuse,misuse, improper
maintenance,accident or the negligence of any party other than
ForaCare Suisse.The warranty set forth herein is conditioned
upon proper storage, installation, use and maintenance in
accordance with applicable written recommendations of
ForaCare Suisse.The warranty furnished hereunder does not
extend to damage to items purchased hereunder resulting in
whole or in part from the use of components, accessories, parts
or supplies not furnished by ForaCare Suisse.

CUFF BP
Blood Pressure Monitoring System
Blutdrucküberwachungssystem
Système de surveillance de la tension artérielle
Sistema per il monitoraggio della pressione sanguigna
Sistema de supervisión de presión en sangre
Bloeddrukbewakingssysteem
Tansiyon Ölçüm Sistemi
Tonometr
Sistema de monitorização de pressão arterial
Sistem de monitorizare a tensiunii arteriale
ForaCare Suisse AG
Neugasse 55, 9000 St. Gallen, Switzerland
www.foracare.ch FORA P80
ver 2.0 2019/01 311-3140100-013
Para autotest/
For self-testing/Zur Selbstmessung/
Pour l'auto-test/Per test autodiagnostici/
/Kendi kendine ölçüm için/
/
Para auto-diagnóstico/Pentru autotestare
