FOR-A HVS-6000 User manual

HVS-6000ME
HVS-6000MV
HVS-6000SDI-EX
HVS-6000SDO
HVS-6000IP-8IO
2nd Edition
INSTALLATION
GUIDE

2
Upon Receipt
HVS-6000 optional cards are fully inspected and adjusted prior to shipment. Check your received items
against the packing lists below. Check to ensure no damage has occurred during shipment. If damage
has occurred, or items are missing, inform your supplier immediately.
◆HVS-6000 Option Card Box
ITEM
QTY
REMARKS
HVS-6000ME,
HVS-6000MV,
HVS-6000SDI-EX,
HVS-6000SDO or
HVS-6000IP-8IO
1
LAN cable
1
Operation Manual
1
This manual
◆Required tool
Flathead screwdriver

3
1. Card Installation Slots
◆HVS-6000ME
HVS-6000ME is an M/E/DSK expansion card for HVS-6000. Two cards are installed as standard. In
addition, up to two cards can be added as an option. M/E expansion is provided when installed in the
M/E 3 slot and DSK expansion is provided when installed in the OPTION slot.
◆HVS-6000MV
HVS-6000MV is a Multiview video output expansion card for HVS-6000. One card can be installed as
an option.
By installing the HVS-6000MV, four channels (MV1-MV4) of multi-view video output can be added,
allowing you to monitor input video and composited output video.
◆HVS-6000SDI-EX
HVS-6000SDI-EX is a 12G-SDI input expansion card (installed to I/O slot) for HVS-6000. Up to two
cards can be installed as an option.
◆HVS-6000SDO
HVS-6000SDO is a 12G-SDI output expansion card for HVS-6000. Two cards are installed as standard.
In addition, up to two cards can be added as an option.
◆HVS-6000IP-8IO
HVS-6000IP-8IO is an IP input/output expansion card for HVS-6000. Up to two cards are installed as
an option in the IO slot.
HVS-6000 Front panel HVS-6000 Rear panel
Upper Slots
Slot
Slot label
Installable cards
OUTPUT 1 (Standard)
AUXOUT 1-8
HVS-6000SDO
M/E 1 (Standard)
M/E 1
HVS-6000ME
I/O 1 (Option)
AUXOUT 17-24
EXT INPUT 65-72
HVS-6000SDI-EX, HVS-6000SDO or
HVS-6000IP-8IO
M/E 3 (Option)
M/E 3
HVS-6000ME
M/E 3 slot
(option)
I/O 1 slot (option)
OPTION slot
(option)
‚l^‚d@‚n‚t‚s
M/E 1 EXTINPUT 65~72INPUT49~56INPUT33~40INPUT17~24INPUT1~8AUXOUT1~8 AUXOUT17~24 M/E3 GENLOCK
M/E OUT
1 1 1 1 1 1 1 1
2 2 2 2 2 2 2 2
3 3 3 3 3 3 3 3 4
4 4 4 4 4 4 4 5
5 5 5 5 5 6
6 6 6 6 6 7
7 7 7 7 7 8
8 8 8 8 8
M/E OUT
REF IN TALLY OUT
LAN3
AC100-240V 50/60HzIN
AC100-240V 50/60HzIN
1
2
FAN 9
FAN 1 FAN2 FAN 3 FAN 4
FAN 8FAN7FAN 6FAN5
ALARM
RS-422
1
2
3
4
5
6
RATING Label
AUXOUT25~32 OPTIONEXTINPUT 73~80INPUT 57~64INPUT41~48INPUT25~32INPUT 9~16M/E 2AUXOUT9~16
1 1 1 1 1 1 2
2 2 2 2 2
21
3
3
3 3 3 3 3 4
4 4 4 4 4 5
5 5 5 5 5 6
6 6 6 6 6
7 7 7 7 7 7 8
4
8 8 8 8 8
FAN 10
AC100-240V 50/60HzIN
AC100-240V 50/60HzIN
3
4
CPU
LAN1 LAN2 (MAIN) (SUB)
GPI IN
M/E3 slot
(option)
I/O 1 slot (option)
I/O 2 slot (option)
OPTION slot
(option)
I/O 2 slot (option)
M/E 1 slot
OUTPUT 1 slot
OUTPUT 2 slot
M/E 2 slot
OUTPUT 1 slot
M/E 1 slot
OUTPUT 2 slot
M/E 2 slot

4
Lower Slots
Slot
Slot label
Installable cards
OUTPUT 2 (Standard)
AUXOUT 9-16
HVS-6000SDO
M/E 2 (Standard)
M/E 2
HVS-6000ME
I/O 2 (Option)
AUXOUT 25-32
EXT INPUT 73-80
HVS-6000SDI-EX, HVS-6000SDO or
HVS-6000IP-8IO
OPTION (Option)
OPTION
HVS-6000ME or HVS-6000MV

5
2. Procedure for Initial Installation / Replacement
Follow the steps below to prepare installation or replacement.
For the slot position, see Sec. 1. "Card Installation Slot".
The following procedure shows how to install an HVS-6000SDO into the I/O 1 slot.
(1) Turn OFF the power switches on the front of the
HVS-6000.
(2) Verify that the POWER indicator is lit orange, and then
disconnect the power cord from the rear panel.
When replacing cards, disconnect all connected
BNC cables.
(3) Completely loosen the four fixing screws on both sides
of the front panel, and then remove the front panel.
(4) Disconnect all LAN cables from LAN ports on the
all cards.
(5) Turn the knob of the LAN cable fixing bracket
upright to release the LAN cable bundle.
(6) Loosen the four fixing screws at the four corners of the
front card unit, and pull the front card unit straight out
toward you.
Do not remove the screws completely at once, but
keep them slightly engaged and pull them out little by
little so that the front card unit does not pop out all the
way to the front.
IMPORTANT
Be careful when working on the front card unit, as the connectors are easily damaged while removing
the card unit.
5
4
I/O 1 Slot
LAN cable
fixing bracket
4
Front card unit
HVS-6000
DIGITAL V IDEOSW ITCHER
POWE R 1
POWER
ON
OFF
OFF
ON POWER
ALARM
ALARM
POWE R 2
HVS
1
3
3
3
3

6
(7) Completely release the fixing screw on the blank
panel or the installed HVS-6000SDO and pull out
the blank panel or the card.
(8) Insert the HVS-6000SDO so that it fits into the
upper and lower rails of the I/O 1 slot.
Push it in all the way.
* Confirm the card direction before insertion.
Upper slot Lower slot
(9) Fasten the fixing screw of the new HVS-6000SDO installed in Step (8).
(10) Connect one end of the supplied LAN cable to an
available port on the hub.
(11) Re-install the front card unit removed in (6).
(12) Re-connect the LAN cables disconnected in (4).
Each card has two LAN ports.
Plug LAN cables to the following ports.
MU_CPU card (Bottom-left): Top and bottom
LAN ports
Card on the upper slot: Top LAN ports
Card on the lower slot: Bottom LAN ports
(13) Gather the LAN cables behind the LAN cable fixing bracket. Turn the LAN cable fixing bracket
sideways and secure the LAN cables.
(14) Re-install the front panel.
(15) Re-plug the power cords on the back of the HVS-6000 and turn on the power switches on the front.
(16) Open the [SETUP > STATUS > VERSION > MU IN/OUT] menu in the OU and check card versions.
(See Sec. 2-1. “Version Check.”)
A card installation is now complete.
8
7
OPT INPUT 2
slot
Fixing screw
Front
Place the connector
downward
Front
Place the connector
upward
12
13
10
Hub
LAN cable
fixing bracket
MU_CPU card
12

7
2-1. Version Check
◆HVS-6000SDI-EX / HVS-6000SDO / HVS-6000IP-8IO
Open the [SETUP > STATUS > VERSION > MU IN/OUT] menu in the OU and refer to the
table below to check whether the card version is displayed (the card is properly recognized)
under card installed slots.
Card slot
Card
OUTPUT 1 (Standard)
AUXOUT 1
OUTPUT 2 (Standard)
AUXOUT 2
I/O 1 (Option)
IN/OUT 1
I/O 2 (Option)
IN/OUT 2
◆HVS-6000ME / HVS-6000MV
Open the [SETUP > STATUS > VERSION > MU M/E] menu refer to the table below to check
whether the card version is displayed (the card is properly recognized) on card installed slots.
Card slot
Card
M/E 1 (Standard)
M/E 1
M/E 2 (Standard)
M/E 2
M/E 3 (Option)
M/E 3
OPTION (Option)
OPT

FOR-A COMPANY LIMITED
3-8-1 Ebisu, Shibuya-ku, Tokyo 150-0013, Japan
Tel: [phone] Fax: [phone]
https://www.for-a.com/
