Fri-Jado MCC 60 Original operating manual

9124721 Instruction front doors MCC Page 1
9124721 Service Instruction
Installation front doors MCC (2nd version)
The technician, working on the unit will be fully responsible for abiding the locally prevailing safety rules and
regulations.
 Technicalactivitiesmustbeperformedbyqualiedandauthorizedpersonsonly.
Before working on any electrical part, or dismantling the unit by means of
using a screwdriver or any other tool, ALWAYS REMOVE THE POWER
PLUG from the main outlet.

Page 2
9124721 Instruction front doors MCC
Door set
MCC 60 9380369
MCC 90 9380370
MCC 120 9380371
MCC 150 9380372

9124721 Instruction front doors MCC Page 3
Depending on variant:
With standard under frame:
Remove front under frame panel (two screws, one on each bottom corner).
Drop-In:
Raise the unit at least 30cm from tabletop level in order to access the screws for the child- guard.
Be careful to support the unit such that no components or connections underneath the base of the
unit are damaged while doing so.
Step 1.
Remove Child guard:
Refer service manual chapter replacement
and adjustment
a. Remove front panel.
b. Loosen mounting screws
(3x depending on unit length) of child guard.
Screwed from underneath.
c. Remove Child guard
d. Position under beam on place of child guard
e. Fasten mounting screws.
Top
Bottom

Page 4
9124721 Instruction front doors MCC
A
B
Step 2.
a. Remove side glass both sides:
b. Slide the double glass pane towards the
front along the top (A) and bottom (B)
guiding rails.
c. The side pane can be removed from the unit
once it has slid entirety past the top guide.
CAUTION:
Once past the top guide, the glass pane might fall if not properly held.
Hence do not leave it standing upright without being supported by both guide rails or
holding it.
Step 3.
a. Remove white (or black) stud, both sides.
(Black stud is screwed in)
Step 5.
a. Remove side glass holder,
left and right.
Step 4.
a. Remove top air guide or assy. air box
(which is applicable depending on version).
Step 6.
a. Remove or loosen back cover(s)
left and right (sliding door stopper).
 Bothxedwiththreescrews.

9124721 Instruction front doors MCC Page 5
Step 7.
a. Remove top column cover by removing
last screw. (one each side)
Step 8.
a. Place new (longer) top column cover(s)/
window support (two screws).
b. Mount screws in new top column cover
Step 9.
a. Replace white (or black) stud removed
earlier.
Step 11.
a. Place top front beaminsideproles.
 Slidethebeamintothefrontoftheprole.
Step 12.
a. Fasten the top front beam
insideproleswithscrews.
(both sides)
Step 10.
a. Replace side glass holder
removed earlier.

Page 6
9124721 Instruction front doors MCC
Step 14.
a. Place a door on the lower beam, let it stick
out of the unit.
CAUTION:
Be careful not to touch the top beam
with the glass door.
Step 15.
a. Place hinge pin into bearing
Step 16.
a. Place distance ring on hinge
pin.
Step 17.
a. Fasten hinge pin
loosely, making sure
the door is kept
in place
Step 13.
a. Check placing bearing(s) in door, one in
the top,
one at the bottom.
 Makesuretheangeofthebearingsits
opposite of the glass.
Flange
TOP Side
Bottom Side

9124721 Instruction front doors MCC Page 7
Step 18.
a. Place top hinge pin into top bearing.
b. Place distance ring on top hinge pin.
c. Fasten top hinge pin, tighten tight !
Step 19.
a. Fasten lower hinge
pin, tighten tight !
Step 20.
Repeat step 14 till 19 for each front door, depending on MCC variation.
Replace removed sliding doors covers in reverse order.
 Replacetopairguideorassyairbox,inreverseorder.Ifthisdoesnottanymorepleaseorder:
Fri-Jado B.V.
Blauwhekken 2
4751 XD Oud Gastel
The Netherlands
Tel: [phone]
Top air guide Assy air box
MCC 60 9382062 N.A.
MCC 90 9382061 9380002
MCC 120 9382063 9380098
MCC 150 9382124 9380137
