Fri-Jado GO Combi User guide

Mounting instruction
How to mount the handshower
EN (Original Instruction) Revision 12/2022, SW: 0.3.37
GO Combi

2
GO Combi

3
GO Combi
GO Combi mounting instruction, revision 12/2022, SW: 0.3.37
General information 4
Target group....................................................................................... 4
Technical changes............................................................................... 4
More documentation.......................................................................... 4
Warranty ............................................................................................ 4
Permissions......................................................................................... 4
Safety information 5
Before replacement 6
Tools ............................................................................................. 6
Spare parts ......................................................................................... 6
Oven overview 7
Mounting the handshower 8
Mounting the holder for the handshower........................................... 8
Mounting the handshower ................................................................. 9
Table of contents

4
GO Combi
General information
Target group
This document is aimed at service technicians who have been trained in installing and servicing the
oven. The oven must only be installed and serviced by qualified service technicians.
Technical changes
This document is subject to changes without notice.
More documentation
You find more documentation about the oven at our website.
Warranty
You find more information about warranty at our website.
Permissions
Log in as “Technician” (576021) to have the necessary rights to be able to change the oven setup,
use the test functions, update software, etc.
The hand shower kit is designed to fit the Fri-Jado GO with water filters. If the handshower kit is
to be mounted without a water filter or with a reverse osmosis system, you must contact your local
plumber for installation.
You can connect the handshower to either filtered or unfiltered water.

5
GO Combi
GO Combi mounting instruction, revision 12/2022, SW: 0.3.37
Safety information
Read this document before using, installing or servicing the product.
Installation and operation must comply with local regulations and accepted
codes of good practice.
Read the safety instructions in the user manual, installation manual and
service manual before you perform any work on the oven.
All maintenance and repair must be carried out by qualified installation and
service technicians only. Installation and/or service by others than qualified
service technicians may result in injury to the operator and/or damage to the
oven.

6
GO Combi
Before replacement
• Make sure the required tools are available.
• Unpack the spare parts and check if all parts are available.
• Make sure the working area is tidied up, clean and safe to prevent personal injury and damage
to the equipment.
Tools
• Power drill
• 3.3 mm drill
• Threader, M4
• Vacuum cleaner
• Allen screwdriver
• Scissors
• Flat screwdriver
Spare parts
• 103574, hand shower kit

7
GO Combi
GO Combi mounting instruction, revision 12/2022, SW: 0.3.37
Oven overview
Pos. Description Pos. Description
1 Inlet, solenoid valve (filtered water) 6 Water filter system
2 Inlet, solenoid valve (unfiltered water) 7 Water inlet hose, 1500 mm
3 Fittings 8 Ball valve
4 Hose, 1500 mm 9 Hose for handshower
5 Hose, 1500 mm - -
Table 1
4
1
6
5
8
9
2
7
3

8
GO Combi
Mounting the handshower
Mounting the holder for the handshower
1. Locate the two markings on the lower right-hand side of the oven.
2. Drill two holes at the markings using a 3.3 mm drill.
3. Thread the two holes as M4.
4. Remove any swarfs from inside the control panel with a vacuum cleaner.

9
GO Combi
GO Combi mounting instruction, revision 12/2022, SW: 0.3.37
5. Fasten the holder to the right-hand side of the oven using two screws and an Allen
key.
IMPORTANT! Make sure that you turn the holder correctly.
Mounting the handshower
1. Click the three hose clips into the oven base frame.
2. Cut 50 mm of the hose for the hand shower.
1

10
GO Combi
3. Take apart the hoses and the T-fittings on the non-filtered side of the water filter.
Use a flat screw driver for the clips.
4. Twist the blue plastic lock on the filter head and remove the T-fitting.
5. Use the piece of hose that you have cut off to connect the handshower, ball valve
and elbow fitting.
6. Connect T-fitting from the handshower kit and the T-fitting from the water filter to
the elbow fitting with metal clips.
7. Mount the handshower in the holder.
8. Fasten the handshower hose in the three clips on the oven base frame.
9. Mount the handshower fittings in the water connection on the water filter.
10. Mount the water inlet hose on the T-fitting pointing backwards.
11. Mount the water connection hose to the T-fitting pointing towards the ground
12. See also “Oven overview” on page 7 for a more schematical overview.

11
GO Combi
GO Combi mounting instruction, revision 12/2022, SW: 0.3.37
This page is intentionally left empty.
