Friedrich Floating Air Pro-Premiere FPHW091 User manual

1 PB
Service Manual
Floating Air Pro-Premiere
Single Zone
96261401_05
Model Indoor Unit Outdoor Unit Voltage BTU
FPHW091 FPHSW09A1A FPHSR09A1A 115 9k
FPHW091A FPHSW09A1B FPHSR09A1A 115 9k WiFi
FPHW093 FPHFW09A3A FPHSR09A3A 208/230 9k
FPHW093A FPHFW09A3B FPHSR09A3A 208/230 9k WiFi
FRHW093 FRHSW09A3A FRHSR09A3A 208/230 9k
FRHW093A FRHSW09A3B FRHSR09A3A 208/230 9k WiFi
FPHW121 FPHSW12A1A FPHSR12A1A 115 12k
FPHW121A FPHSW12A1B FPHSR12A1A 115 12k WiFi
FPHW123 FPHFW12A3A FPHSR12A3A 208/230 12k
FPHW123A FPHFW12A3B FPHSR12A3A 208/230 12k WiFi
FRHW123 FRHSW12A3A FRHSR12A3A 208/230 12k
FRHW123A FRHSW12A3B FRHSR12A3A 208/230 12k WiFi
FPHW183 FPHFW18A3A FPHSR18A3A 208/230 18k
FPHW183A FPHFW18A3B FPHSR18A3A 208/230 18k WiFi
FPHW243 FPHFW24A3A FPHSR24A3A 208/230 24k
FPHW243A FPHFW24A3B FPHSR24A3A 208/230 24k WiFi
FPHW363 FPHSW36A3A FPHSR36A3A 208/230 36k
FPHW363A FPHSW36A3B FPHSR36A3A 208/230 36k WiFi
FPHW363B FPHSW36A3C FPHSR36A3B 208/230 36k WiFi

2 PB
TABLE OF CONTENTS
Table of Contents
INTRODUCTION‑ 4
Important Safety Information‑ 4
Personal Injury Or Death Hazards‑ 6
Model Identification Guide‑ 8
SPECIFICATIONS‑ 9
Product Specifications 9k and 12k‑ 9
Product Specifications 18k, 24k and 36k‑ 10
Product Dimensions: Indoor Units‑ 11
Capacities and Selection Data‑ 12
Capacities and Selection Data‑ 13
Remote Control‑ 19
Using Sleep during Off‑Timer Function‑ 21
INSTALLATION‑ 25
Installation Dimension Diagram‑ 25
Main Tools For Installation and Maintenance‑ 26
Install Indoor Unit‑ 28
Power and Wiring‑ 36
Leak Check, Evacuation, and Charging (Triple Evacuation)‑ 37
Checklist and Operation Test‑ 39
MAINTENANCE‑ 40
TROUBLESHOOTING‑ 43
Diagnostic Codes‑ 43
Outdoor Unit‑ 43
Outdoor Unit When The Compressor Is In Operation‑ 45
Indoor Unit‑ 46
Led Display‑ 49
Test the jumper terminals‑ 52
Protection Circuit Fault Isolation‑ 53
Compressor Fault Isolation‑ 54
Electric FIlter Board Fault Isolation‑ 54
Electrical Communication Fault ISOLATION‑ 54
Unit does not run‑ 55
Error Code 39‑DC FAN‑ 56
Error Code 39‑PG Fan‑ 57
Error Code 9‑ 58
Error Code 13‑ 59
Error Code 8‑ 59
Error Code 15‑ 60
Error Code 16 Cooling Mode‑ 61
Error Code 16 Heating Mode‑ 61
Error Code 21 Cooling Mode‑ 61
Error Code 11 EEPROM Fault‑ 61
Error Code 20‑ 62
Error Code 33‑ 63
Error Code 34‑ 63
Error Code 14‑ 63
Error Code 1‑ 63
Error Code 2‑ 63
Error Code 6‑ 63
Error Code 19‑ 64
Error Code 36 ‑ 67
Blank Display/Indoor Unit Door Micro Switch‑ 69

3 PB
TABLE OF CONTENTS
COMPONENTS TESTING ‑ 71
Compressor‑ 71
EEV Stepper Coil‑ 72
Fan Motor‑ 73
Printed Circuit Board Diagram Lookup Chart‑ 75
Printed Circuit Board (Indoor)‑ 76
Printed Circuit Board (Outdoor)‑ 78
R‑410A SEALED SYSTEM REPAIR‑ 81
Service Valves Appearance‑ 81
Gas Charging (After Repair)‑ 82
Pumping Down‑ 83
WIRING DIAGRAMS‑ 84
Wiring Diagram Lookup Table‑ 84
Indoor Units‑ 85
Outdoor Units‑ 87
APPENDIX‑ 89
Appendix 1: Reference Sheet of Celsius and Farenheit‑ 89
Appendix 2: Pipe Expanding Method‑ 90
Appendix 3 Resistance Table Of Indoor Coil And Indoor Room Sensor‑ 91
The Resistence Table of Outdoor Coil and Outdoor Air Sensor‑ 91
Resistance Table Of Outdoor Compressor Temperature Sensor‑ 92
LIMITED WARRANTY‑ 93

4 PB
INTRODUCTION
The information in this manual is intended for use by a qualied technician who is familiar with the safety procedures
required for installation and repair, and who is equipped with the proper tools and test instruments required to
service this product.
Installation or repairs made by unqualied persons can result in subjecting the unqualied person making such
repairs as well as the persons being served by the equipment to hazards resulting in injury or electrical shock
which can be serious or even fatal.
Safety warnings have been placed throughout this manual to alert you to potential hazards that may be encountered.
If you install or perform service on equipment, it is your responsibility to read and obey these warnings to guard
against any bodily injury or property damage which may result to you or others.
Important Safety Information
Your safety and the safety of others is very
important.
We have provided many important safety messages in this manual and on your appliance. Always
read and obey all safety messages.
This is a safety Alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol with the word “WARNING”
or “CAUTION”. These words mean:
Indicates a hazard which, if not avoided, can result in severe personal
injury or death and damage to product or other property.
Indicates a hazard which, if not avoided, can result in personal injury
and damage to product or other property.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what will happen if the instructions are not followed.
Indicates property damage can occur if instructions are not followed.
WARNING
NOTICE
CAUTION
WARNING
Refrigeration system
under high pressure
Do not puncture, heat, expose to ame or
incinerate.
Only certied refrigeration technicians
should service this equipment.
R410A systems operate at higher pressures
than R22 equipment. Appropriate safe
service and handling practices must be used.
Only use gauge sets designed for use with
R410A.
Do not use standard R22 gauge sets.

5 PB
Important Safety Information INTRODUCTION
WARNING
Please read this manual thoroughly prior to equipment
installation or operation. It is the installer’s responsibility
to properly apply and install the equipment. Installation
must be in conformance with the NFPA 70-2008 National
Electric Code or current edition, International Mechanic
code 2009 or current edition and any other applicable
local
or national codes.
WARNING
Refrigeration system under high pressure. Do not
puncture, heat, expose to ame or incinerate. Only
certied refrigeration technicians should service this
equipment. R410A systems operate at higher pressures
than R22 equipment. Appropriate safe service and
handling practices must be used. Only use gauge sets
designed for use with R410A. Do not use R22 gauge sets.
Failure to do so can result in property damage, personal
injury, or death.
WARNING
Electrical shock hazard.
Turn OFF electric power before service or
installation.
Unit must be properly grounded.
Unit must have correct fuse or circuit breaker
protection. Unit’s supply circuit must have
the correct wire conductor size. All electrical
connections and wiring must be installed by a
qualied electrician and conform to the National
Electrical Code and all local codes which have
jurisdiction. Failure to do so can result in property
damage, personal injury and/or death.
Your safety and the safety of others are very
important.
We have provided many important safety messages in
this manual and on your appliance. Always read and
obey all safety messages.
This is the safety Alert symbol.
This symbol alerts you to potential
hazards that can kill or hurt you
and others.
All safety messages will follow the
safety alert symbol with the word
“WARNING” or “CAUTION”.
These words mean:
Indicates a hazard which, if not avoided, can result in
severe personal injury or death and damage to product or
other property.
Indicates a hazard which, if not avoided, can result in
personal injury and damage to product or other property. All
safety messages will tell you how to reduce the chance of
injury, and tell you what will happen if the instructions are
not followed.
Indicates property damage can occur if instructions
are not followed.
Indicates property damage can occur if instructions
are not followed.
WARNING
CAUTION
NOTICE
To ensure proper operation, Friedrich requires that all equipment is not operated during active construction phases. This includes
active stages of completing framing, drywalling, spackling, sanding, painting, ooring, and moulding in the equipment’s designated
conditioning space. The use of this equipment during construction could result in premature failure of the components and/or system
and is in violation of our standard warranty guidelines. The operation of newly installed equipment during construction will accelerate
the commencement and/or termination of the warranty period.
CAUTION
DO NOT OPERATE EQUIPMENT DURING ACTIVE
STAGES OF CONSTRUCTION

6 PB
INTRODUCTION
Personal Injury Or Death Hazards
ELECTRICAL HAZARDS:
• Shutdown and/or disconnect all electrical power to the unit before performing inspections, maintenance, or
service.
• Make sure to follow proper lockout/tag out procedures.
• Always work in the company of a qualied assistant if possible.
• Capacitors, even when disconnected from the electrical power source, retain an electrical charge potential
capable of causing electric shock or electrocution. Wait a few minutes after shutdown to allow the capacitors to
discharge the stored energy.
• Handle, discharge, and test capacitors according to safe, established, standards, and approved procedures.
• Extreme care, proper judgment, and safety procedures must be exercised if it becomes necessary to test or
troubleshoot equipment with the power turned on to the unit.
• Do not spray water on the air conditioning unit while the power is on.
• Electrical component malfunction caused by water could result in electric shock or other electrically unsafe
conditions when the power is restored and the unit is turned on, even after the exterior is dry.
• Use air conditioner on a single dedicated circuit within the specied amperage rating.
• Ensure that the unit is properly grounded.
• Follow all safety precautions and use approved protective safety equipment such as: gloves, goggles, and
clothing. Ensure that properly insulated tools, and testing equipment are are used as well to protect against
equipment damage and reduce the risk of injury.
• Failure to follow proper safety procedures and these warnings can result in serious injury or possibly death.
SAFETY
FIRST
WARNING AVERTISSEMENT ADVERTENCIA
Do not remove, disable
or bypass this unit’s
safety devices. Doing so
may cause re, Doing so
may cause re, injuries,
or death.
Ne pas supprime, désactiver
ou contourner cette l´unité
des dispositifs de sécurité,
faire vous risqueriez de
provoquer le feu, les
blessures ou la mort.
No eliminar, desactivar o
pasar por alto los
dispositivos de seguridad de
la unidad. Si lo hace podría
producirse fuego, lesiones
o muerte.
WARNING
ALWAYS USE INDUSTRY STANDARD PERSONAL
PROTECTIVE EQUIPMENT (PPE)

7PB
• REFRIGERATION SYSTEM REPAIR HAZARDS:
• Use approved standard refrigerant recovering procedures and equipment to relieve high pressure before
opening system for repair. Reference EPA regulations (40 CFR Part 82, Subpart F ) Section 608.
• Do not allow liquid refrigerant to contact skin. Direct contact with liquid refrigerant can result in minor to
moderate injury.
• Be extremely careful when using an oxy-acetylene torch. Direct contact with the torch’s ame or hot surfaces
can cause serious burns.
• Make certain to protect personal and surrounding property with re proof materials and have a re extinguisher
at hand while using a torch.
• Provide adequate ventilation to vent off toxic fumes, and work with a qualied assistant whenever possible.
• Always use a pressure regulator when using dry nitrogen to test the sealed refrigeration system for leaks,
ushing etc.
• MECHANICAL HAZARDS:
• Extreme care, proper judgment and all safety procedures must be followed when testing, troubleshooting,
handling, or working around unit with moving and/or rotating parts.
• Be careful when, handling and working around exposed edges and corners of the sleeve, chassis, and other unit
components especially the sharp ns of the indoor and outdoor coils.
• Use proper and adequate protective aids such as: gloves, clothing, safety glasses etc.
• Failure to follow proper safety procedures and/or these warnings can result in serious injury or death.
• PROPERTY DAMAGE HAZARDS
• FIRE DAMAGE HAZARDS:
• Read the Installation/Operation Manual for the air conditioning unit prior to operating.
• Use air conditioner on a single dedicated circuit within the specied amperage rating.
• Be extremely careful when using acetylene torch and protect surrounding property.
• Failure to follow these instructions can result in re and minor to serious property damage.
• WATER DAMAGE HAZARDS:
• Improper installation, maintenance or servicing of the air conditioner unit can result in water damage to personal
items or property.
• Insure that the unit has a sufcient pitch to the outside to allow water to drain from the unit.
• Do not drill holes in the bottom of the drain pan or the underside of the unit.
• Failure to follow these instructions can result in damage to the unit and/or minor to serious property damage.
INTRODUCTION
Personal Injury Or Death Hazards

8 PB
INTRODUCTION
Model Identication Guide
Figure 101
FP HS W 09
A1A- A
Model Type:
FR- Floating Air Premier
FP - Floating Air Pro
FS- F loating Air Sele ct
Application :
W- Wa llmounted
D- Ducted (Insider)
C- Cassette
R- Remo te Condense r
Function :
HS – H ea t Pump Singl e
HM – Heat Pump Multi
HF – H eat Pump F lex Single and
Multizon e
Coolin g
BTU/HR
Model
Approximate
Introductory
Chara cter:
Voltag e
A- 201 9
B- 202 0
C- 202 1
D- 202 2
1- 115 V olts
3- 230 V olts
MODEL IDENTIFICATION GUIDE
Marketing Suffix :
Letter indicates modification to existing mode l

9 PB
SPECIFICATIONS
Product Specications 9k and 12k
Model No. Units FPHW091/A FPHW121/A FPHW093/A FRHW093/A FPHW123/A FRHW123/A
INDOOR MODEL FPHSW09A1A,
FPHSW09A1B/B
FPHSW12A1A,
FPHSW12A1B/B
FPHFW09A3A,
FPHFW09A3B/B
FRHSW09A3A,
FRHSW09A3B/B
FPHFW12A3A,
FPHFW12A3B/B
FRHSW12A3A,
FRHSW12A3B/B
OUTDOOR MODEL FPHSR09A1A FPHSR12A1A FPHSR09A3A FRHSR09A3A FPHSR12A3A FRHSR12A3A
SPECIFICATIONS
C A PA C I T Y C O O L I N G ( R AT E D ) Btu 9000 12000 9000 9000 12000 12000
C A PA C I T Y C O O L I N G M I N - M A X Btu 3600-10000 4000-13500 3600-10000 3600-10000 4000-13500 4000-13500
COOLING AMPS 6.3 8.3 2.9 10500 4.3 13000
HEATING AMPS 7.0 9.7 3.1 6500 5.0 8000
SENSIBLE HEAT RATIO 76% 77% 76% 3600-10500 77% 4000-14000
CAPACITY HEATING (RATED) @ 47°F Btu 9500 13000 9500 2.3 13000 4.6
C A PA C I T Y H E A T I N G M I N - M A X Btu 3600-10500 4000-14000 3600-10500 3.4 4000-14000 4.8
CAPACITY HEATING (RATED) @ 17°F Btu 5000 7500 5000 76% 7500 77%
COP 3.56 3.46 3.88 28 3.42 25
HSPF 10.00 10.50 10.70 16.1 10.50 15.4
SEER 19.5 22.0 22.5 12.5 22.0 12
EER 12.8 13.0 13.7 Yes 13.0 Yes
MOISTURE REMOVAL Pts/h 1.9 2.5 1.9 1.9 2.5 2.5
A I R F L O W ( H I G H / M E D / L O W / Q U I E T ) CFM 424/382/323/247 424/382/323/247 424/382/323/247 416/384/355/279 424/382/323/247 598/536/446/345
SOUND RATING - INDOOR (HIGH/
MED/LOW/QUIET)
dB-A 39/32/29/26 39/32/29/26 39/32/29/26 39/34/31 39/32/29/26 45/41/39
S O U N D R ATI N G - O U T D O O R dB-A 53 53 53 55 53 55
O P E R A T I N G R A N G E ( H E A T I N G ) °F (-4° – 75°) (-4° – 75°) (-4° – 75°) -13˚-75˚ (-4° – 75°) -13˚-75˚
O P E R AT I N G R A N G E ( C O O L I N G ) °F (5° – 115°) (5° – 115°) (5° – 115°) 0˚-115˚ (5° – 115°) 0˚-115˚
ELECTRICAL DATA
POWER SOURCE V/Hz/
Phase
115V~,60Hz,1P 115V~,60Hz,1P 230V~,208V~,
60Hz,1P
230V~,208V~,
60Hz,1P
230V~,208V~,
60Hz,1P
230V~,208V~,
60Hz,1P
MIN. AMPACIT Y A13.5 16.5 10 10A 10 12A
CO OLING WATTS W700 950 655 559 960 779
HE AT ING WAT TS W780 1100 720 905 1110 856
M A X . T D F U S E / B R E A K E R A 20 25 15 15A 15 15A
POWER AND COMMUNICATION
CABLE Type 4 x 14AWG 600V THHN 4 x 14AWG 600V THHN 4 x 14AWG 600V THHN 4 x 14AWG 600V THHN 4 x 14AWG 600V THHN 4 x 14AWG 600V THHN
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare Flare Flare
LI QUID LINE O.D. in 1/4 1/4 1/4 1/4 1/4 1/4
SUCTION LIN E O.D. in 3/8 3/8 3/8 3/8 3/8 3/8
REFRIGERANT CHARGE oz 33.5 40.9 33.5 25 40.9 25
FACTORY P R ECHA R G E ft. 25 25 25 38.8 25 45.9
M I N . / M A X . L I N E L E N G T H ft 10-50 10-50 10-50 10-50 10-50 10-50
M A X . H E I G H T D I F F E R E N C E ft 33 33 33 33 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in 33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
33 7/8 x 11 3/16
x 8 1/2
38 1/8 X 13 1/8 X
9 15/16
NET WEIGHT lbs 20 20 20 22 20 28.5
OUTDOOR UNIT
W x H x D in 28 1/8 x 19 x 9 7/16 31 7/8 x 23 x 11 28 1/8 x19 x 9 7/16 31 7/8 x 23 x 11 31 7/8 x 23 x 11 31 7/8 x 23 x 11
NET WEIGHT lbs 65 78 59.5 75 72.5 84
Figure 201

10 PB
SPECIFICATIONS
Product Specications 18k, 24k and 36k
Model No. Unit FPHW183/A FPHW243/A FPHW363A FPHW363B
INDOOR MODEL FPHFW18A3A,/ B FPHFW24A3A/B FPHSW36A3A/B FPHSW36A3C
OUTDOOR MODEL FPHSR18A3A FPHSR24A3A FPHSR36A3A FPHSR36A3B
CAPACITY COOLING (RATED) Btu 18000 23500 36000 35000
CAPACITY COOLING MIN - MAX Btu 6500-19500 8000-26500 12000--38000 12000--38000
COOLING AMPS 6.3 8.3 18.5 18.5
HEATING AMPS 7.2 11.1 16 16
SENSIBLE HEAT RATIO 80% 76% 79% 79%
CAPACITY HEATING (RATED) @ 47°F Btu 19000 26000 36000 35000
CAPACITY HEATING MIN - MAX Btu 6500-20000 8000-26500 12000--38000 12000--38000
CAPACITY HEATING (RATED) @ 17°F Btu 11600 14500 18700 18700
COP 3.40 3.05 3.05 2.93
HSPF 11.6 10.5 8.8 8.8
SEER 23.3 21 16.4 16.4
EER 13 12.5 8.6 8.33
MOISTURE REMOVAL Pts/h 3.2 5.1 6.8 6.8
AIRFLOW (HIGH/MED/LOW/QUIET) CFM 618/565/482/382 735/665/559/441 1030/824/706/588 1030/824/706/588
SOUND RATING - INDOOR (HIGH/MED/LOW/QUIET) dB-A 45/41/37/34 47/42/36/33 50/45/40/38 50/45/40/38
SOUND RATING - OUTDOOR dB-A 55 58 60 60
OPERATING RANGE (HEATING) °F -4° – 75° -4° – 75° -4° – 75° -4° – 75°
OPERATING RANGE (COOLING) °F 5° – 115° 5° – 115° 5° – 115° 5° – 115°
ELECTRICAL DATA
POWER SOURCE V/Hz/Phase 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P 230V~,208V~,60Hz,1P
MIN. AMPACITY A 15 20 30 30
COOLING WATTS W 1385 1880 4186 4186
HEATING WATTS W 1638 2500 3459 3459
MAX. TD FUSE/ BREAKER A 20 30 35 35
POWER AND COMMUNICATION CABLE Type 4 x 14AWG, 600V
THHN 4 x 14AWG, 600V THHN 4 x 14AWG, 600V THHN 4 x 14AWG, 600V THHN
REFRIGERATION SYSTEM
REFRIGERANT R410a R410a R410a R410a
COMPRESSOR TYPE Rotary Rotary Rotary Rotary
CONNECTIONS Flare Flare Flare Flare
LIQUID LINE O.D. in 1/4 3/8 3/8 3/8
SUCTION LINE O.D. in 1/2 5/8 5/8 3/4
REFRIGERANT CHARGE . oz 54.7 66.3 81.2 81.2
FACTORY PRECHARGE ft. 25 25 25 25
MIN. / MAX. LINE LENGTH ft 10-66 10-66 10-66 10-66
MAX. HEIGHT DIFFERENCE ft 33 33 33 33
DIMENSIONS & WEIGHT
INDOOR UNIT
W x H x D in 45 3/16 x 13 1/8 x 9 15/16 50 5/8 X 13 5/8 X
10 5/16
50 5/8 X 13 5/8 X
10 5/16
NET WEIGHT lbs 33 33 40 40
SHIPPING WEIGHT lbs 38.5 38.5 48 48
OUTDOOR UNIT
W x H x D in 33 7/8 x 25 9/16 x
12 3/16
34 7/8 x 31 5/16 x
14 3/8
34 7/8 x 31 5/16 x
14 3/8
34 7/8 x 31 5/16 x
14 3/8
NET WEIGHT lbs 99 123.5 141
Figure 202

11 PB
SPECIFICATIONS
Product Dimensions: Indoor Units
Model Width Height Depth
FPHSW09A1A,
FPHSW09A1B/B 33 7/8 “(Inches) 11 3/16 “(Inches) 8 1/2 “(Inches)
FPHFW09A3A,
FPHFW09A3B/B 33 7/8 “(Inches) 11 3/16 “(Inches) 8 1/2 “(Inches)
FPHSW12A1A,
FPHSW12A1B/B 33 7/8 “(Inches) 11 3/16 “(Inches) 8 1/2 “(Inches)
FPHFW12A3A,
FPHFW12A3B/B 33 7/8 “(Inches) 11 3/16 “(Inches) 8 1/2 “(Inches)
FPHFW18A3A,
FPHFW18A3B/B 45 3/16 “(Inches) 13 1/8 “(Inches) 9 15/16 “(Inches)
FPHFW24A3A,
FPHFW24A3B/B 45 3/16 “(Inches) 13 1/8 “(Inches) 9 15/16 “(Inches)
FPHSW36A3A,
FPHSW36A3B,
FPHSW36A3C/B/C
50 5/8 “(Inches) 13 5/8 “(Inches) 10 5/16 “(Inches)
Figure 203

12 PB
SPECIFICATIONS
Capacities and Selection Data
Capacity characteristic charts
The following charts show the characteristics of outdoor unit capacity, which corresponds with the operating
ambient temperature of outdoor unit. This data is obtained with Free-Spin of the Condenser and not in a testing mode
Conditions:
1- Pipe length / height difference : 25 ft. (7.6m) / 0 ft. (0m)
2- Compressor at rated inverter frequenc y
3- Indoor fan speed at high fan speed
4- Capacity loss due to frost accumulation and defrost operation is not included.

13 PB
SPECIFICATIONS
Capacities and Selection Data
Floating Air Pro / Premier Cooling Extended Capacity (By System Model)
System Model Outdoor Air
Temp. (°F DB)
Indoor Air Temp. °F DB / °F WB
80 /67
Cooling BTUs Heating BTUs Power
kBtu/h kW
FPHW091/A
32 9.56 6.69 0.26
41 10.09 7.06 0.36
50 10.35 7.24 0.47
59 10.96 7.67 0.50
67 11.18 7.83 0.59
77 11.57 8.10 0.70
82 11.90 8.33 0.81
87 11.78 8.25 1.00
95 11.63 8.14 1.02
104 11.08 7.76 1.02
115 9.94 6.96 1.00
FPHW121/A
32 10.76 7.53 0.27
41 11.29 7.90 0.36
50 11.93 8.35 0.42
59 12.17 8.52 0.59
67 12.44 8.71 0.78
77 12.68 8.88 1.01
82 13.25 9.28 1.07
87 12.98 9.08 1.16
95 12.55 8.79 1.25
104 11.90 8.33 1.24
115 10.53 7.37 1.18
FPHW093/A
32 8.54 5.97 0.26
41 8.72 6.10 0.36
50 9.15 6.41 0.47
59 9.53 6.67 0.60
67 9.89 6.92 0.69
77 10.21 7.14 0.80
82 10.37 7.25 0.90
87 10.28 7.19 0.91
95 10.11 7.08 0.92
104 9.85 6.89 0.89
115 9.26 6.48 0.88

14 PB
SPECIFICATIONS
Capacities and Selection Data
Floating Air Pro / Premier Cooling Extended Capacity (By System Model)
System Model Outdoor Air
Temp. (°F DB)
Indoor Air Temp. °F DB / °F WB
80 /67
Cooling BTUs Heating BTUs Power
kBtu/h kW
FPHW123/A
32 10.66 7.46 0.35
41 11.39 7.97 0.54
50 12.09 8.46 0.65
59 12.73 8.91 0.76
67 13.13 9.19 0.86
77 13.62 9.54 0.95
82 14.07 9.85 1.09
87 13.85 9.69 1.15
95 13.25 9.27 1.22
104 12.15 8.50 1.19
115 9.81 6.87 1.10
FPHW183/A
32 16.78 11.75 0.97
41 17.75 12.43 1.09
50 18.40 12.88 1.22
59 18.62 13.03 1.30
67 19.03 13.32 1.35
77 19.31 13.52 1.41
82 19.55 13.69 1.60
87 19.26 13.48 1.91
95 18.57 13.00 1.91
104 17.27 12.09 2.11
115 15.80 11.06 2.11
FPHW243/A
32 22.14 15.50 1.09
41 25.05 17.54 1.47
50 26.49 18.55 1.72
59 27.28 19.10 1.93
67 27.51 19.26 2.13
77 27.72 19.40 2.35
82 28.08 19.66 2.52
87 27.35 19.15 2.72
95 26.47 18.53 3.02
104 22.76 15.93 2.89
115 18.34 12.84 2.60

15 PB
SPECIFICATIONS
Capacities and Selection Data
Floating Air Pro / Premier Cooling Extended Capacity (By System Model)
System Model Outdoor Air
Temp. (°F DB)
Indoor Air Temp. °F DB / °F WB
80 /67
Cooling BTUs Heating BTUs Power
kBtu/h kW
FPHW363/A/B
32 29.25 20.48 1.09
41 32.72 22.90 1.45
50 33.50 23.45 2.20
59 33.88 23.72 2.46
67 35.27 24.69 2.63
77 36.36 25.45 3.52
82 37.89 26.52 3.59
87 37.20 26.04 3.69
95 32.91 23.04 3.90
104 29.64 20.75 3.65
115 23.63 16.54 3.13
FRHW093/A
32 7.60 5.32 0.21
41 8.41 5.89 0.28
50 9.73 6.81 0.40
59 11.23 7.86 0.50
67 12.94 9.06 0.69
77 14.12 9.89 0.89
82 14.48 10.13 1.04
87 14.27 9.99 1.07
95 13.56 9.49 1.16
104 12.67 8.87 1.25
115 11.62 8.13 1.40
FPHW123/A
32 13.76 9.63 0.33
41 14.12 9.88 0.47
50 14.60 10.22 0.50
59 14.92 10.44 0.70
67 15.38 10.77 0.84
77 15.50 10.85 1.09
82 15.89 11.12 1.15
87 15.73 11.01 1.17
95 15.19 10.64 1.27
104 14.44 10.11 1.38
115 13.31 9.32 1.32

16 PB
SPECIFICATIONS
Capacities and Selection Data
Floating Air Pro / Premier Cooling Extended Capacity (By System Model)
System Model Outdoor Air
Temp. (°F DB)
Indoor Air Temp. °F DB / °F WB
80 /67
Cooling BTUs Heating BTUs Power
kBtu/h kW
FPHW091/A
-5 -7 4.95 1.14
5 3 5.45 1.07
14 12 7.08 1.17
17 15 8.93 1.30
23 19 9.67 1.30
32 28 9.65 1.19
35 33 9.89 1.03
47 43 10.54 0.94
59 50 9.86 0.82
FPHW121/A
-5 -7 6.40 1.22
5 3 8.12 1.30
14 12 9.76 1.49
17 15 12.13 1.63
23 19 12.95 1.68
32 28 13.07 1.48
35 33 14.00 1.43
47 43 15.50 1.45
59 50 12.73 0.91
FPHW093/A
-5 -7 4.95 1.14
5 3 6.20 1.20
14 12 7.29 1.27
17 15 8.59 1.34
23 19 9.33 1.38
32 28 9.85 1.34
35 33 10.23 1.19
47 43 11.65 1.11
59 50 10.78 0.80
FPHW123/A
-5 -7 8.67 1.29
5 3 10.18 1.34
14 12 11.40 1.44
17 15 12.10 1.48
23 19 12.72 1.54
32 28 13.46 1.56
35 33 13.94 1.51
47 43 14.19 1.31
59 50 14.01 1.10

17 PB
SPECIFICATIONS
Capacities and Selection Data
Floating Air Pro / Premier Cooling Extended Capacity (By System Model)
System Model Outdoor Air
Temp. (°F DB)
Indoor Air Temp. °F DB / °F WB
80 /67
Cooling BTUs Heating BTUs Power
kBtu/h kW
FPHW183/A
-5 -7 8.57 1.17
5 3 10.90 1.27
14 12 13.90 1.28
17 15 15.43 1.49
23 19 16.74 1.60
32 28 18.24 1.65
35 33 20.92 1.80
47 43 21.27 1.81
59 50 20.73 1.77
FPHW243/A
-5 -7 11.57 2.35
5 3 15.61 2.62
14 12 17.08 2.61
17 15 19.55 2.79
23 19 19.31 2.76
32 28 20.88 2.57
35 33 21.64 2.54
47 43 26.78 2.52
59 50 26.68 2.50
FPHW363/A
-5 -7 15.93 3.02
5 3 19.21 3.12
14 12 21.01 3.07
17 15 21.32 3.15
23 19 25.92 3.45
32 28 27.41 3.61
35 33 33.11 3.80
47 43 38.07 3.90
59 50 34.61 2.74
FRHW093/A
-5 -7 5.25 1.08
5 3 7.76 1.22
14 12 9.82 1.41
17 15 11.08 1.45
23 19 11.77 1.45
32 28 11.87 1.21
35 33 11.92 1.12
47 43 12.05 1.06
59 50 11.81 0.86

18 PB
SPECIFICATIONS
Capacities and Selection Data
Floating Air Pro / Premier Cooling Extended Capacity (By System Model)
System Model Outdoor Air
Temp. (°F DB)
Indoor Air Temp. °F DB / °F WB
80 /67
Cooling BTUs Heating BTUs Power
kBtu/h kW
FRHW123/A
-5 -7 8.56 1.46
5 3 10.78 1.60
14 12 11.96 1.80
17 15 11.90 1.56
23 19 13.03 1.48
32 28 15.07 1.61
35 33 15.22 1.66
47 43 17.21 1.51
59 50 16.45 1.17

19 PB
OPERATION
Remote Control
Figure 301
Remote Control Operation and Function
Remote conller 1

 



POWER








 















 







 





 
 


 
$   
  
.� 
y    
•  ,
 






   a·   
  *   
        
    
  

•    a  
   
 
-1-

20 PB
OPERATION
Remote Technical Parameters
Remote receiver distance (front of the air conditioner): 26ft.
Remote receiver angle: Less than 60 degrees.
Temperature control accuracy: ±2.4°F.
Time Response: Less than 1 second.
Display Functions
Remote
Current control functions on the remote controller (See unit’s “Installation and Operating Manual”)
Display of the indoor unit displays set temperature or indoor temperature.
Indoor unit
Running LED lit during operation, ashing when in defrost.
Timer LED lit when the timer mode is active.
Sleep LED lit when the sleep mode is activated and turns off after 10 seconds.
Compressor LED lit when compressor is running.
Remote control receiver receives signals from the remote control.
Displays error codes if present. An error code is displayed according to the signal from the indoor CPU. The error code will
ash for 5 seconds while displayed.
Indoor Unit Operation
Manual Operation “ON/OFF” Button:
When pressing the manual operation “ON/OFF” button after system is idle or in stand-by mode, the previous settings will be
restored from last operation: Mode, Temperature, and Fan Speed. The air ow directional setting does not restore. When rst
powered, pressing the manual operation “ON/OFF” button will force the system would operate in “auto” mode and will enter
stand-by mode by pressing the button again. Pressing and holding the manual operation “ON/OFF” button for 5 seconds will
engage Test Mode and will beep 1 time. It will operate in cooling mode with the indoor fan speed set to high-speed and will
ignore indoor temperature for 5 minutes. If the manual operation “ON/OFF” button is pressed again or a signal is received
from the remote control, test mode will exit. If exited from the remote control the system will operate with the corresponding
mode selected on the remote control.
I-Feel Function
The I-Feel function is set by the remote control. The room temperature value interpreted by the system will use the
temperature on the remote control instead of the temperature reported by the ambient air sensor in the indoor unit. The
remote control will automatically transmit a temperature signal every 10 minutes. The remote control will transmit a signal
every 2 minutes if the temperature setpoint selected exceeds 2°F. If the indoor unit does not receive a signal from the remote
in 30 minutes, the selected temperature setpoint will depend on the ambient air sensor of the indoor unit.
Timer Function
Max Timer range is 24 hours.
Timer ON/OFF can be cycled anytime.
Timer accuracy is ±1 minute.
The Timer can be adjusted by 1 min increments.
Timer On-OFF operational times can overlap.
Sleep Function
Sleep mode can only be used in Cooling, Heating and Dry mode.
If Sleep mode is selected in Cooling mode, the room temperature setting will increase 2.5°F every hour for 8 hours. Room
temperature will not rise more than 2.5°F per hour. Temperature rise will cease at 79°F. Room temperature will not rise
above 79°F.
If Sleep mode is selected in Heating mode, room temperature will be decreased by 2.5°F per hour for 3 hours but will not
decrease more than 2.5°F per hour or 8°F for the duration of the mode.
In either mode, the indoor fan run in the LOW speed. Last user settings (air direction and temperature) can be used, or
adjusted by user. The Running indicator will ash, then the unit will turn off all the light indicators except the Sleep. After 5
minutes, the Sleep indicator will turn off. All indicators will be standby unless the temperature or Time setting is adjusted.
After setting these, the indicators will turn off after 10 seconds.
