Frizzlife DW10F User manual

(Ver. 03/2022)
OWNER’S MANUAL
Direct Connect Under Sink Water Filtration System
          

CONTENT
1. BEFORE INSTALLATION
2. PRODUCT INTRODUCTION
3.SAMPLE CONNECTION
5. INSTALLATION STEPS
6. REPLACEMENT FILTER
7. FILTER REPLACEMENT INSTRUCTION
8. MULTI-USAGE
10. FREQUENTLY ASKED QUESTIONS
9. PERFORMANCE DATA
11. LIMITED PRODUCT WARRANTY
01
02
04
4. INSTALLATION TIPS 03
03
07
07
08
08
09
09
12. WARRANTY REGISTRATION 10
If you have problems during the purchase or installation
process, please contact our customer service.
Receive first-hand promiton info and be
the first one getting exclusive benefits.
@Frizzlife
www.frizzlife.com [email protected]
FOLLOW US

Register to activate your warranty with Frizzlife.
Find the Installation Video
1. BEFORE INSTALLATION
Email us your order ID and full name at
[email protected]
Scan the QR code to register
Search “Frizzlife DW10F/DW15F/DW20F Installation” on www.youtube.com
Inspect Box
Please take out the system and all the components from the box. Inspect
them carefully according to “Product Introduction”, and make sure nothing in
missing or damaged during shipping. If any parts are cracked or broken,
please do not proceed with installation, and contact Frizzlife for an exchange
or diagnosis.
Do not use it with water that is microbiologically unsafe or of unknown
quality without adequate disinfection.
Technical Parameters
Model No. DW10F DW15F DW20F
Flow Rate
Replacement Period 3-6M, 12-18M
SED10R, CB10R
4.9×9.9×15 in 4.9×9.9×19 in 4.9×9.9×21 in
SED15R, CB15R SED20R, CB20R
4-8M, 16-24M 6-12M, 24-36M
Replacement Filter
Dimension
Working Pressure
Operational Temp
Applicable Water Soure
1.5 GPM @ 60 psi
Municipal Water
Min.20psi, Max. 80psi
Min.39ºF,Max 100ºF
Precautions
For cold water use only.
Do not freeze the filter, as this case cause cracking and water leakage.
Do not allow children under 3 years of age to have access to small parts
duringthe installation of this product.
Testing was performed under standard laboratory conditions, actual
performance may vary.
This installation must comply with all applicable state and local regulations.
Please flush water for 15 minutes for the first time usage.
01

2. PRODUCT INTRODUCTION
02
DW10F/DW15F/DW20F Filter System
with Filters Loaded
1
21/4” Tubing
3
Dedicated Faucet
4
5
Blue Clips
7Wrench
8Plumber Tape
9Blade
10 Mounting Screws
6
1/4” Quick Fitting
3-Way Feed Water Valve
1
5
6
7 8
9
10
2
3
4

3. SAMPLE CONNECTION
4. INSTALLATION TIPS
03
How to cut the tubing?
How to connect/disconnect the tubing?
Feed water valve
Outlet tubing
Dedicated faucet
Existing main faucet
Inlet tubing
Hot Cold Water filter system
Please cut the tubing into two sections in proper length, make sure
cut them squarely and cleanly.
To connect: Please push the tubing into the fitting and make sure it is
fully inserted. Then put the blue lock clip on the fitting, it
will lock the tubing in place.
Please remove the bule lock clip from the fitting, push in
the lock sleeve, and then pull out the tube from the fitting.
If the tubing is not fully inserted, water leakage may occur.
Pulling out the tubing directly will damage the fitting, which
may also cause water leakage.
To disconnect:
Note:

5. INSTALLATION STEPS
Step 1: Mount the system (onto a wooden plate)
04
Note:
Please always use plumber tape on threaded connection parts
to ensure a watertight seal.
1. Find the proper place to mount up the system.
2. Srew off the cartridges.
4. Scew back the cartridges.
3. Mount up the filter heads using the provided
screws.
Step 2: Cut the tubing
1. 1.Please cut the 1/4” tubing into two sections
(1. inlet tubing 2. outlet tubing) in proper length
based on your need.
Please cut the tubing evenly, otherwise may result in water leakage.
0.5 inch
Press
Remove
Remove
blue clip
1. Insert to seal the connection 2. Remove to disconnect
How to drill a hole on my sink (Optional)
Note：Please remember to wear safety glasses to protect your eyes
before proceeding.
Note: Leave at least 2 inches higher than the ground for easier filter
replacement.
Use a 1/2” metal bit to drill. The recommended diameter of the hole
ranges from 1/2” to 1.2”.

05
Step 4: Connect the water supply (COLD WATER ONLY)
1.Shut off the water supply.
2.Remove the feed water hose from the angle valve.
3.Connect the 3-way feed water valve and make sure the rubber
O ring is loaded.
4.Connect the feed water hose.
5.Valve installation complete.
Step 5: Connect the filter system
1. Remove the blue clip from the “Inlet”
port,and connect the other end of inlet
tubing to the “Inlet” port. Please make
sure the tubing hits the bottom of the
fitting.
2. Put back and lock the blue clip to seal
the connection.
3.Connect the “Outlet” port with the outlet
tubing in the same way.
Step 3: Connect 3-way feed water valve
1.Load the inlet tubing through the nut.
2.Push and squeeze the tubing to the very end.
3.Use a wrench to tighten the nut, please do not over tighten.
Note: If your water valve is 1/2", please contact us to claim the
1/2" to 3/8" converter set.

06
Step 6: Install the faucet
Step 7: Check for leaks
1.Mount the faucet to your sink top
2.Connect the faucet with the 1/4” quick fitting
3.Connect the other end of outlet tubing from the “Outlet” port into the 1/4”
quick fitting.
1.Turn on all the water supply and check
for leaks.
2.Flush the system for 15 minutes before use.
15 min
Faucet Fixture
Rubber
Rubber
Hand
Fixture
Water Fitting
Note: If the thickness of your counter is over 1.9", please contact us at
[email protected] to claim for longer stem.
Note: If your counter top or granite does no have an existing hole,
please drill one (1/2") before proceeding.

6. REPLACEMENT FILTER
7. FILTER REPLACEMENT INSTRUCTION
Step 1: Twist the cartridge housing(s) clockwise
Step 2: Using the wrench to unscrew
the housing body
Step 3: Take out the old cartridge and
load with new one, then install back in
the same way
Step 4: Flush the new cartridge for 15
minutes before starting to use
The Frizzlife Under Sink Water Filter System requires care and cleaning after a
period of time. It is recommended to change the cartridge according to
corresponding time intervals in the table below. If the system has been work-
ing properly and the filtered water output is slowing down, it may be time to
change the filter cartridge.
3-6M, 12-18M
4-8M, 16-24M
6-12M, 24-36M
System Model No.
DW10F
DW15F
DW20F
SED10R, CB10R
SED15R, CB15R
SED20R, CB20R
Replacement Filter No. Filtration Capacity
07
Note: All the service life of the filter cartridge listed are based on
actual laboratory test and the provided water. The actual service life
of filter cartridge depends on source water quality and daily water
usage.
Note:
With the ATUO Shut off design of the system, you do not need
to shut off the water supply when doing the replacement.
Change

8. MULTI-USAGE
9. PERFORMANCE DATA
The DW-F Series system can be connected to your refrigerator / ice maker by
utilizing Frizzlife IMC-1 connection kit (not included).
Simply search “Frizzlife IMC-1”
on Amazon or scan the QR code
below to purchase.
≥50％
≥85％
0.010
99.95％
Substance
Chlorine
Particulate, Class I
Particles 0.5 to ＜1μm
Lead
Cyst
2.0 mg/L ± 10 ％
At least 10,000 particles/ml
0.15 ± 10 ％
Min. 50,000/L
Influent challenge
concentration (mg/L)
Maximum permissible
product water
concentration (mg/L)
08

11. LIMITED PRODUCT WARRANTY
10. FREQUENTLY ASKED QUESTIONS
Q: What should I do if water leaks after installation?
The Frizzlife DW10F/DW15F/DW20F Under Sink Water Filtration System are warranted to
the original purchaser. To be free of defects in material and workmanship by FRIZZLIFE
INC, FRIZZLIFE will replace or repair components of the unit that Frizzlife has deemed to
be broken within the limits of the warranty without charge. The customer is not responsi-
ble for any freight involved with shipping the item back for inspection and shipment of
replacement for items. Frizzlife is not liable for cost of removal, installation, transportation
or any other charges in connection with a warranty claim.
Customer must register their systems with Frizzlife within 90 days of purchase in order to
obtain a warranty. Warranty will discontinue after the unit is removed from the location
where it was originally installed. Warranty begins on the date of delivery of product to
the customer.
09
A: If once installed the system should leak, please shut off water supply firstly. If
the leaking occurs at the thread, please wrap plumber tape on the external thread.
Please contact Frizzlife customer service team for solutions if the water leakage
persists.
Q: Why TDS does not drop after filtration?
A: TDS is not a professional way to test the water quality. TDS means total
dissolved solids, for example if you put a very little salt(NaCl) into the water and test
the TDS, and you will find the result is dramatically high. Same thing, if your water is
full of minerals, the TDS is very high too. The DW Series doesn't remove any
of the minerals from water, but only stops harmful contaminants like heavy metals
(Lead, Mercury, Cadmium) and over 90% of VOCs and Cysts, and it removes greatly
the chlorine (99%) from water. Therefore, it is the reason why TDS you get is not that
low as you expect.
Warrantor: FRIZZLIFE INCDW10F/DW15F/DW20F Under Sink Water Filter System
ONE YEAR LIMITED FRIZZLIFE WARRANTY
As a condition of this Limited Warranty, the owner must ensure that periodic
maintenance of the system is performed as described in the literature enclosed with
the system. Should your unit develop a defect or otherwise fail to perform in
accordance with this warranty, you should contact the retailer from whom the product
was originally purchased.
Owner’s Warranty Responsibility:

12. WARRANTY REGISTRATION
10
1. Frizzlife is not liable for anything that we deem as abuse of the units, including
but not limited to, misuse of product outside of intended use, equipment modifications,
unauthorized repairs, improper installation, damage from freezing, hot water, fire or
other acts of God outside of Frizzlife control.
This warranty will be void if defects occur due to failure to observe the
following conditions:
Incoming water to the the system cannot exceed 100°F.
Do not use outdoors or in a location that is subjected to direct sunlight or freezing.
This warranty will not be effective unless and until the Frizzlife is shown to have
been used in accordance with the installation and maintenance instructions
accompanying the product.
2. Filter Cartridges are considered as disposable items, thus are not covered by
warranty.
3. Customer is responsible for proper operation, which includes complete and
continual leak inspection.
Most of the unit components are made of plastic and eventually can break
or crack from stress.
There are no other warranties which extend beyond what is described above.
150% EXTENDED WARRANTY
1.Email us you order ID and full name at
[email protected] within 90 days.
2.Scan the QR code below to register
If you have any questions, any suggestions, or you need any assistance, please free
to contact us anytime at [email protected].
Your satisfaction is always our top priority!
