Frizzlife PX500-A User manual

Model: PX500-A
Water Filtration System
REVERSE
OSMOSIS
Follow Frizzlife
www.frizzlife.com
OWNER'S MANUAL

CONTENT
1. BEFORE INSTALLATION
2. PRODUCT INTRODUCTION
3. SAMPLE CONNECTION
4. INSTALLATION TIPS
5. INSTALLATION STEPS
6. FIRST TIME USAGE
7. USER INTERFACE
8. REPLACEMENT OF FILTER CARTRIDGE
9. FILTER REPLACEMENT INSTRUCTION
10.HOOK UP TO YOUR REFRIGERATOR/ICE MAKER
11.MINI TANK AVAILABLE NOW
12. MAINTENANCE
13. TROUBLE SHOOTING
14. FREQUENTLY ASKED QUESTIONS
15. LIMITED PRODUCT WARRANTY
1
2
2
3
4
9
9
11
12
13
14
15
16
18
19

1. Before Installation
Model: PX500-A
Search "Frizzlife PX500-A installation" on www.youtube.com
Inspect Box
Open the box and take out the system and all the components. Inspect them carefully
according to "Product Introduction" and make sure nothing is missing or damaged
during shipping. If any parts are cracked or broken, please do not proceed with the
installation and contact Frizzlife for an exchange or diagnosis.
Technical Parameters
Thank you for purchasing Frizzlife PX500-A reverse osmosis undersink filter system with
500G RO membrane. If you have any questions or need any assistance,
please contact: [email protected]
Find the installation video
Register to get 150% warranty
INSTALLATION INSTRUCTION
Model
Min.39ºF,Max.100ºF
110-240VAC
500 gallons
60W
Operating Temp
Rated Power
Rated Voltage
Daily Production Rate
PX500-A
50-60HZ
0.34 gallons/m
@25 C(77 F)
Min.20psi Max. 80psi
Municipal water
CF
Rated Frequency
Flow Rate
Working Pressure
Applicable
Water Source
Rated flow 0.34gallons/m @25 (77 ). Low water temperature will slow down water flow.
Please contact us for reference at: [email protected]
FRIZZLIFE INC. www.frizzlife.com
Page 1
1. Email us your order ID and full name at [email protected].
2. Scan the QR code to register.
1. BEFORE INSTALLATION
2. PRODUCT INTRODUCTION
3. SAMPLE CONNECTION
4. INSTALLATION TIPS
5. INSTALLATION STEPS
6. FIRST TIME USAGE
7. USER INTERFACE
8. REPLACEMENT OF FILTER CARTRIDGE
9. FILTER REPLACEMENT INSTRUCTION
10.HOOK UP TO YOUR REFRIGERATOR/ICE MAKER
11.MINI TANK AVAILABLE NOW
12. MAINTENANCE
13. TROUBLE SHOOTING
14. FREQUENTLY ASKED QUESTIONS
15. LIMITED PRODUCT WARRANTY
1
2
2
3
4
9
9
11
12
13
14
15
16
18
19

2. Product Introduction
3. Sample Connection
Feed water
Drain saddle
Power supply
Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 2
Front Back Accessories:
PX500-A
ASR312-500G
(RO filter)
ASR311
(PP+CB 2-in-1 filter)
Filter life
Power
Flush button
Filter life reset
ASR313A
(Alkaline filter)
Power supply
Connect to water supply
Connect to drain pipe
Connect to drinking faucet
Do not use this plug
Dedicated Faucet
Drain Saddle
Feed Water Valve
Converter Set
1/4” White Tubing
1/4” Red Tubing
3/8” White Tubing
Blade
Plumber Tape
1/4” Quick Fitting
A

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 3
!
4. Installation Tips
How to cut the tubing?
Please cut the tubing into two sections in proper length, make sure cut
them squarely and cleanly.
To connect:
To disconnect:
Note:
please push the tubing into the fitting and make sure it is fully
inserted. Then put the blue lock clip on the fitting, it will lock
the tubing in place.
please remove the blue lock clip from the fitting, push in the
lock sleeve, and then pull out the tube from the fitting.
If the tubing is not fully inserted, water leakage may occur.
Pulling out the tubing directly will damage the fitting,
which may also cause water leakage.
How to drill a hole on my sink (Optional)
How to connect/disconnect the tubing?
0.5 inch.5
Press
Remove
Remove
blue clip
Note：Please remember to wear safety glasses to protect your eyes
before proceeding.
1. Insert to seal the connection
2.Remove to disconnect
Use a 1/2” metal bit to drill. The recommended diameter of the hole
ranges from 1/2” to 1.2” .

5. Installation Steps
Precautions:
Fig.1 Fig.2
Please cut the 3/8" white tubing in proper length, make sure cut them squarely
and cleanly. (Fig.1)
Put one end of the tubing into boiled water for 5 seconds to soften itself.(Fig.2)
Load the 3/8" tubing through the nut. (Fig.3)
Connect the end of 3/8" tubing that has been softened into the 3-way feed
water valve. Make sure push and squeeze the tubing to the very end.(Fig.4)
Use a wrench to tighten the nut, please do not over tighten. (Fig.5)
Step 1: Cut and Soften the 3/8" white tubing
Step 2: Connect three-way feed water valve (3/8" or 1/2")
!
Note: If the cold water pipe is 1/2", please connect one part of converter
to the angle valve and connect another part of converter to the pipe
before proceeding to the next step. (see Fig.6)
Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 4
Do not use with water that is microbiologically unsafe or of unknown quality without
adequate disinfection.
Testing was performed under standard laboratory conditions, actual performance may
vary.
For cold water use only.
This filter must be protected from freezing, which can cause cracking of the filter and
water leakage.
Do not allow children under 3 years of age to have access to small partsduring
installation.
The installation must comply with all applicable state and local regulations.

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 5
Fig.3 Fig.4 Fig.5 Fig.6
Fig.7 Fig.8Fig.9
Shut off the water supply. (Fig.7)
Disconnect the cold water pipe from angle valve.
Twist the feed water valve onto the angle valve and make sure the O ring is
loaded. (Fig.8)
Connect cold water pipe onto the feed water valve. (Fig.9) Valve installation
complete.
Connect the other end of 3/8" tubing into "Supply" port on the back of the system,
make sure to insert the tubing about 0.8 inch to the end of the fitting. ( Fig.11)
Put the lock clip on the fitting to secure the connection. (Fig.12)
Step 3: Connect the water supply (COLD WATER ONLY)
Except " DO NOT USE" one, remove all other three plugs by pressing the
fitting sleeves. (Fig. 10)
Step 4: Connect the "SUPPLY" water tubing

Fig.13 Fig.14 Fig.15
Fig.16 Fig.17
Disassemble the drain saddle, and peal off the black sticker and stick to saddle
valve (Fig.13)
Choose a spot on the drain pipe that is convenient for installing the drain saddle.
It is recommended to install the drain saddle on the vertical drain pipe. (Fig.14)
Drill a 1/4" hole in the drain pipe. Make sure not to penetrate the opposite side
of the pipe. (Fig.15 )
Mount the drain saddle and tighten the screws with a screw driver (Fig.16)
Insert the 1/4" red tubing to the drain saddle about 1.4", and lock the fitting
with a blue clip (Fig.17)
Step 5：Install the drain saddle
Fig.10 Fig.11 Fig.12
Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 6

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 7
Fig.18
Fig.20
Fig.19
Insert the other end of 1/4" red tubing into the "Waste" port on the back of the
system.（Fig.18, Fig.19）
Step 6: Connect the "WASTE" water tubing
!
Note: If your counter top or granite does not have an existing hole, please drill
one (1/2") before proceeding.
!
Note: Please make sure the tubings are fully inserted,
otherwise may result in water leakage.
Cut the 1/4" white tubing in proper length, and insert one end into the “Filtered”
port on the back of the system. (Fig.20)
Step 7: Connect the "FILTERED" water tubing
Follow the steps below and mount the faucet onto the sink top.
(Fig.21, Fig.22, Fig.23)
Mount the rubber and fasten the hand fixture underneath (Fig.24, Fig.25, Fig.26)
Connect the other end of 1/4" white tubing from the "FILTERED" port into the
1/4" quick fitting. (Fig.27, Fig.28, Fig.29)
Step 8: Install the drinking faucet
!
Note: If the thickness of your counter is over 1.5” (3.85cm), please contact us at
[email protected] to claim for longer stem.

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 8
!
Note: It is important to turn on the water supply first then connect the power
supply!
Turn on the angle valve and 3-way feed water valve. Check for leaks. (Fig.30)
Insert the DC head of the power adapter into the "POWER" port on the back of
the system. (Fig.31)
Step 9: Connect the power cord
Fig.26
Fig.21 Fig.22 Fig.23 Fig.24
Fig.25
Fig.29
Fig.27 Fig.28
Fig.30 Fig.31

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 9
6. First time usage
Fig.32
Fig.34
Fig.33
!
Note: Please fully open the drinking faucet when dispensing water. Otherwise, it
may cause system to malfunction（Fig.32, Fig.33）
!
Note: When the system keeps producing water continuously for 30 minutes, the
system will enter into protection status and all the components stop working.
The indicators will flash in red. In this condition, please unplug the power for
10 seconds and then power on again.
The system will automatically flush for 30 seconds after the power supply is
plugged
Before first use or after filter replacement, please flush the filter system by
turning on the faucet for 20 min.
7. User Interface
×√
FLUSH RESET
PPC RO TC-A

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 10
!
Note: If the filter is expired, the buzzer will keep beeping when producing water
to remind users of replacing filter. Filter life may vary depending on source
water quality and water usage.
When the system is powered on, you will hear a beep. All indicators will be
on for 3 seconds, and then the system will automatically flush for 30 seconds.
After flushing, if there is no water production, it will turn into standby status.
The power indicator will always light in blue when the system is plugged in.
Power-on
When the system is producing water, the power indicator will flash in blue.
Water production
A. Flushing when powered on: when powered on, the system will be
automatically flushed for 30 seconds.
B. Flushing when cumulative water production reaches 10 minutes:
If the cumulative water production reaches 10 minutes, after returning
into standby status, it will be automatically flushed for 10 seconds.
Automatic flushing
When the system keeps producing water continuously for 30 minutes, the
system will enter into protection status and all the components stop working.
The indicators will flash in red. In this condition, please unplug the power for
10 seconds then power on again.
Long-time operation reminder
Different colors suggest different remaining lifespan:
A. Indicator constant lit in blue: the filter is normally working
B. Indicator flashed in red: the filter lifetime is about to be expired
(remaining lifespan <5%)
C. Indicator constant lit in red:the filter is expired
Filter life indicator
C. Flushing when constant water production: if the system constantly
keeps producing water for 10 minutes, it will be automatically
flushed for 15 seconds.

Position
Recommended
Replacement Period
6 months or cumulative water
production for 30 hours
(around 450-500gal)
one year or cumulative water
production for 60 hours
(around 900-1000gal)
Two years or cumulative
water production for 120
hours(around 1800-2000gal)
Model Number
ASR311
ASR312-500G
Filter
PP+CB 2-in-1 filter
RO membrane
1st stage
2nd stage
ASR313-A
Alkaline filter 3rd stage
The replacement filer cartridges are: PP+CB 2-in-1 filter ，RO membrane and post
carbon filter
Please replace filter cartridges regularly according to the recommended replacement
period shown below.
8. Replacement of Filter Cartridge
!
When the system is in standby status, press the "Flush" button, the system will
start flushing. Press the "Flush" button again to stop.
Note: When the system is being flushed, the indicator will flash in blue.
Manual flushing
Reset button
Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 11
Select filter: when the system is powered on, long press the "Reset" for 3
seconds, the buzzer will beep and you can start to select the filter you want to
change. Press "Reset"button to change between the filters and the selected
filter lifetime indicator will flash.
Reset: after selecting the filter, long press "Reset" button for 3 seconds. You
will hear a beep. The selected filter's indicator will return to blue light once
the filter is changed and sucessfully reset. If you do not operate within 10
seconds, it will automatically exit this mode and resume normal display.
Revocation of reset: select the wrong-operated filter, long press "Reset" and
"Flush" buttons for 3 seconds. The buzzer will beep for 3 times. The filter
indicator will return to the color status before reset. (Note: the reset can be
revoked within 5 minutes. If the system is powered off after the reset, the
revocation will be invalid.).
A.
B.
C.

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 12
!
Note: All the service life of the filter cartridge listed are based on actual laboratory
test and the provided water. The actual service life of filter cartridge depends
on source water quality and daily water usage.
Fig.35 Fig.36
Fig.38
Long press the "Reset" button for 3 seconds, the buzzer will beep and you can start
to select the filter you want to change. Press "Flush"button to change between the
filters and the selected filter lifetime indicator will flash. After selecting the filter,
long press "Reset" button for 3 seconds. You will hear a beep. The selected filter's
indicator will turn into blue light, which means the filter is successfully reset. If you
do not operate within 10 seconds, it will automatically exit this mode and resume
normal display.
9. Filter Replacement Instruction
Step 1: Cut off the power and turn on the water faucet to release water pressure
Step 2: Reset the filter lifetime
Fig.37
Fig.39
Cut off the water supply and power before replacement. (Fig.35, Fig.36)
Unscrew the cartridge needs to be replaced counter clockwise.（Fig.39）
Screw the new cartridge clockwise into the system.
Turn on the water faucet to release water pressure.（Fig.37)
Remove the front cover of the filter.（Fig.38)
Connect the power code and turn on the water supply.（Fig.40)
Fig.40
A
3 TC-A

! Note for TDS
Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 13
Step 3: Flush the filter
Turn on the faucet to discharge the filtered water after replacement. If you replace
the RO membrane, please do not use the water in the first 20 minutes. If you
replace CP filter cartridges, please do not use the water in the first 10 minutes.
TDS result of Alkaline Series RO systems will be higher than universal RO systems
due to remineralized post filter.
TDS means total dissolved solids including particles and elements such as Lead, Calcium,
potassium,sodium,etc. Most of the bottled water from supermarket also has HIGH TDS,
since the water has health-benefiting minerals inside.
What is TDS:
Why TDS is ineffective in testing remineralized RO water?
The first two stages of the system are able to eliminate more than 99.99% of all substances
from your tap water, removing more than 94% of TDS value. The pure water then goes
through the 3rd alkaline stage of the system which restores essential minerals, adjusts
pH level and further polishes the water taste, serving customers with optimal water
solution. However, the essential elements such as calcium and magnesium may raise the
TDS value of the water again.
10.Hook Up to Your Refrigerator/Ice Maker
The PX500-A system can be connected with
your refrigerator/Ice-maker by utilizing an
extra IMC-1 ice maker connection kit
(not included). Simply search “Frizzlife
IMC-1” or Asin# “B07R7NH55L” on
Amazon, or scan the QR code to purchase.

Drain Saddle
Feed Water
Adapter
Frizzlife Mini Water Tank
MWT3
The mini water tank is not included in the
package.If you consider the initial lag of
the water outflow to be undesirable,
please search "Frizzlife MWT3" on
Amazon or frizzlife.com to purchase.
Pure Water
Output Faucet
Sample
Kitchen Faucet
Frizzlife RO System
Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 14
11.Mini Tank Available Now!
Frizzlife now offer a perfect solution
-- Frizzlife MWT3 mini water tank --
if you are encountering the following problems of tankless RO systems:
Simply search “Frizzlife MWT3” on Amazon,
or frizzlife.com, or scan the QR code to purchase.
1.If you consider the lagging outflow to be undesirable.
2.If you are encountering the constant on and off issue of the system pump
due to unstable/lack of water pressure.
!
Note: That since the tankless RO system produces instant fresh pure
water to the faucet, there would be approximately 0.5-1 second
of time lag for water outflow.

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 15
If you don't use the system for a long time:
Please replace the filter cartridge regularly according to the filter life indicator.
Keep the drain water pipe unobstructed to avoid damage to the filter or internal
components.
Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection.
12. Maintenance
When the drain pipe is blocked, do not use the system (please turn off the power) to
avoid the waste water from soaking the floor.
Check the system and water pipe fittings regularly for water leakage to avoid any
property damage.
Regularly check whether the power supply and wires are damaged or loose to avoid
major accidents caused by electric leakage.
The testing was performed under standard laboratory conditions, acual perfor-
mance may vary depending on the source water quality and water usage. In case of
premature blockage and failure of the filters , it is recommended to replace the filter
in accordance with actual usage.
A. If the system has not been used for more than 2 days, please turn on the
faucet and discharge the filtered water at least 5 minutes before usage.
B. If the system will not be used for more than 1 week, please seal the filter
cartridges and store them in the refrigerator but do not put them in the
freezer. Discharge filtered water for at least 10 minutes before next time
usage.
C. If the system will not be used for a long time, please cut off the water supply,
cut off the power and turn on the handle of the faucet to release the internal
pressure and avoid damage to the system.
Clean the system with clear water if necesary. Do not drench the system!
Wipe only. Do not apply steel wool, abrasive cleaner or corrosive liquid to the filter
to avoid damage to the filter system.

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 16
Please reinstall the system according
to the instruction or contact customer
service team.
Pipes or filters are not
installed properly.
Please contact customer service team.
Other components are
damaged
Please contact customer service team.The O rings are missed.
Water leakage
13. Trouble Shooting
Fault Solution
Please check if the adapter is
connected properly.
Please open the valves.
Please replace the filter cartridge or
contact customer service team.
Please check the pipelines and make
sure the connection is correct.
Possible Cause
The system is not connected
to the power adapter or the
connection is loose.
Cold water valve, 3-way feed
water valve or the faucet is off.
Lifetime of the filter cartridge
is expired.
Connection of pipeline is
incorrect.
No water
out of
faucet
Please replace the filter according to
the instruction.
Please contact customer service team.
Please check PE pipes.
Filter is blocked.
Please replace the filter according to
the instruction.
Lifetime of the filter cartridge
is expired.
Please discharge water for 5 minutes
before usage.
The system has been off work
for more than 2 days.
Please ensure the water source is
municipally treated water or has been
properly disinfected prior use.
Quality of feed water is too bad.
Water pressure is low, or water
supply is insufficient.
PE pipes are bent.
Low water
flow
Filtered water
in poor quality

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 17
Please contact customer service team.
Electronic controller or
display panel is damaged.
Unchanged filter
lifetime indicator
Please contact customer service team.
The circuit board is boken.
Please contact customer service team.The high pressure switch
is broken.
Please check if the “FILTERED” tubing and
“WASTE” tubing were in the right place.
Filter is blocked.
Please disconnect the power and wait for
water supply recovery.
Feed water is cut off.
Check the system, water pipe fittings and
connections, or contact customer service
team.
The “FILTERED water”
tubing is mistakenly inserted
into “WASTE” port.
Please contact customer service team.
Check the system, water pipe fittings and
connections, or contact customer service
team.
Leakage detection system
is abnormal.
System is leaking.
System is
unstoppable for
a long time after
turning off the
faucet
Examination
indicator lights
or flashes in red,
or the beezer
keeps beeping
Please operate the button according to
the instruction.
Please contact customer service team.
The button is misoperated.
Please check if the adapter is
connected properly.
Please contact customer service team.
The system is not connected
to the power adapter or the
connection is loose.
The panel is damaged or it’ s
cable is loose.
The button is damaged.
Button failure
Indicators on
user interface
disappear

Model: PX500-A
FRIZZLIFE INC. www.frizzlife.com
Page 18
Why TDS is higher at the beginning, but back to normal range after about
one minute?
Why there are many white bubbles in the water?
Why out TDS value of PX500-A is higher than normal RO system?
14. Frequently Asked Questions
Q:
Q:
Q:
Normally for the first time use of the RO system, the water seems to have
white bubbles in it, which is normal and totally drinkable. It is because when
the pump is pressurizing the water, it will pressurize the air at the same time.
It will make the air molecules smaller, thus the solubility further increases.
The air can’ t be released at that time because of the pressure in the RO
system.However, when you turn on the tap to get a cup of water, the pressure
of air is released. So you will see a huge number of bubbles in the water. It
looks cloudy and white, but they are just bubbles. After you put the water
still for a while, all bubbles will be gone, the water is totally good for drinking.
Osmosis is a natural phenomenon happens in all RO system, no matter if you
have a conventional RO system or tankless RO system. When the RO system
starts to work, pressure from the pump overcomes natural osmotic pressure,
forcing feed water through the RO membrane that removes the impurities.
When the RO system stops working, the pump stops offering pressure as
well. At that time, because of different concentrations, a small fraction of
ions will enter into pure water and cause TDS to rise by a small amount.
However, even if the TDS reading is a little high at the beginning, the quality
water is still unbeatable by any other filtration methods including carbon,
KDF, ceramic, UF, UV, etc.. The water is totally good to drink and you don’ t
have to wait for about 1 minute to get the water, since the whole system will
not release any harmful substances to the water. The TDS removing rate for
PX500-A is about 94-95%, if your incoming TDS is high, the outlet TDS will
be high too.
The first two stages of the system are able to eliminate more than 99.99% of
all substances from your tap water, removing more than 94% of TDS value.
The pure water then goes through the 3rd remineralized stage of the system
which restores essential minerals, adjusts pH level and further polishes the
water taste, serving customers with optimal water solution. However, the
essential elements such as calcium and magnesium may raise the TDS value
of the water again.
If you consider the remineralized water to be undesirable, please contact us
for an exchange of the last alkaline filter to universal post carbon filter.
