Frizzlife G Series User manual

OWNER’S MANUAL
Gravity-Fed Water Filter System
G190 - Standard
Applicable Model No.
G210 - Standard
G210 - Scale
G210 - Pro
G210 - Prox

CONTENT
2. Before Installation
3. Installation Guide
4. Filter Replacement Guide
5. Use Tips
6. Maintenance
7. Frequently Asked Questions
8. Limited Product Warranty
9. Warranty Registration
02
02
02
03
04
05
05
1. G-Series Overview
Inspect The Package
Installation Steps
Replacement Filters
Replacement Instruction
Specifications
Precautions
Product Introduction
01
09
09
09
12
12
13
14
16

1. G-Series Overview
01
Register to activate your warranty with Frizzlife.
Scan the QR code to register
Email us your order ID and full name at [email protected]
Find the Installation Video
Search “Frizzlife Gravity-Fed Water Filter System Installation”
on www.youtube.com
Model:
G190-STANDARD
Model:
G210-STANDARD
Model:
G210-SCALE
Model:
G210-PRO
Model:
G210-PROX

2. Before Installation
02
Inspect the Package
NOTE: Do not use with water that is microbiologically unsafe or of unknown quality
without adequate disinfection before or after using of the system.
E-mail: [email protected]
Specifications
Model No. G190 - STANDARD G210 - STANDARD G210 - SCALE G210 - PRO G210 - PROX
Dimension (L*W*H)
System Capacity
CB85 CB85 SC85 HM85 AT85
Filter Life
Replacement Filter
Operational Temperature
Applicable Water Source
Finish
7.48 * 7.48 * 17
inches 8.26*8.26*19 inches
Brushed Nickel
39ºF-100ºF / 4°C-38°C
Municipal Water
Polished Nickel
Up to 6,000 Gallons
1.75 Gallons 2.25 Gallons
Please take out the system and all the components from the box. Inspect them carefully
according to “Product Introduction”, and make sure nothing is missing or damaged
during shipping. If any parts are cracked or broken, please do not proceed with
installation, and contact Frizzlife for an exchange or diagnosis.

1. For cold water use only.
2. Do not allow children under 3 years of age to have access to small parts during
the installation of this product.
3. Testing was performed under standard laboratory conditions, actual performance
may vary.
4. This installation must comply with all applicable state and local regulations.
5. Please flush water for 3-5 minutes for the first time usage.
Precautions
03

Product Introduction
Item G190 - STANDARD G210 - STANDARD G210 - SCALE G210 - PRO G210 - PROX
Upper Chamber
Lower Chamber
Anti-Slip Mat
Washing Funnel
Wrench
Stand*
(Only applicable to G210-Scale/G210-Pro/G210-Prox)
Stainless Steel Spigot
Brass Water Level Spigot
Stand
Lid Knob
Knob rubber washer Lid
Lid Screw
Filter Cartridge
Sealing Rings
(2 pcs)
Knob metal washer
Spigot
Hex Nut
Metal Disc Washer
Flat Rubber Washers
Metal Washer
Rubber Disc Washer Wing Nut
3,4,5 have been
pre-assembled together.
6.7.8 have been
pre-assembled together.
1
3
4
5
2
6
7
17
18
19
20
19
8
9
10
14
15
16
13
12
11
04

Knob Rubber Washer
Knob Metal Washer 3,4,5 have been
pre-assembled together.
2
2
3
4
5
5
1
13
12 14 15
16
20
11
05
Insert the screw into the lid.
Fasten the knob onto the lid with the screw.
Push the metal disc washer and rubber disc washer to the end, close to the spigot, of its thread rod with force.
Insert the well assembled spigot into the lower chamber.
Install the two flat rubber washers, metal washer, and finally fasten the hex nut with the wrench.
Installation Steps
3.Installation Guide
Lid
Lid
Screw
Screw
Knob
Step 1：Lid Knob Assembly
Step 2: Spigot Assembly
Spigot
Hex Nut
Metal Disc Washer Flat Rubber Washers (2 pcs) Metal Washer
Rubber Disc Washer
Wrench
For G190-Standard/ G210-Standard/G210-Scale/G210-Pro :

13
12
14
15
20
16
11
06
Push the metal disc washer and rubber disc washer to the end, close to the spigot, of its thread rod with force.
Insert the well assembled spigot into the lower chamber.
Install the one flat rubber washer, metal washer, and finally fasten the hex nut with the wrench.
Twist the water level tube onto the spigot.
Water Level Tube
For G210-Prox :
Hex Nut
Flat Rubber Washer
Metal Washer
Wrench
Spigot
Metal Disc Washer
Rubber Disc Washer

8
8
7
6
7
7
19
07
Unscrew the wing nut from the filter cartridge.
Take out the two sealing rings from the filter cartridge
Attach the washing funnel onto the filter cartridge.
Flush the filter cartridge for 3-5 mins.
Sealing Rings
Sealing Ring
Sealing Ring
Step 3：Flush the Filter Cartridge
Wing Nut
Washing Funnel
Push one sealing ring to the end of the thread rob.
Insert the threaded rod of the cartridge into the hole in the upper chamber.
Fasten the threaded rod of the cartridge with the other sealing ring and the wing nut.
Step 4：Install the Filter Cartridge
Wing Nut
Filter Cartridge

NOTE: The G Series Gravity-Fed Systems also come with non-slip mat, which is
convenient for users to use on the table or on the stand, improving stability,
safety and aesthetics.
Upper Chamber
Lower Chamber
Stand
9
2
10
18
08
For G210-Scale /G210-Pro /G210-Prox:
Place the upper chamber into the lower chamber.
Put the lid on the upper chamber.
Please put the lower chamber onto the stand provided.
Lid
Step 5: Upper and Lower Chamber Assembly

NOTE: All the service life of the filter cartridge listed are based on actual laboratory
test and the provided water. The actual service life of filter cartridge depends on
source water quality and daily water usage.
Model No. G190 - STANDARD G210 - STANDARD G210 - SCALE G210 - PRO G210 - PROX
The Frizzlife Stainless Steel Gravity-Fed Water Filter System requires care and cleaning
after a period of time. It is recommended to change the cartridge according to corre-
sponding time intervals in the table below.
Replacement Filter No.
Filter Life Up to 6,000 Gallons
CB85 CB85 SC85 HM85 AT85
09
Replacement Filters
Replacement Instruction
4. Filter Replacement Guide
Empty the water inside the upper and lower chambers.
Fill the upper chamber with water, pour out the first bucket of water in the lower chamber. Repeat the step again.
After 2-3 times of flushing, you can drink water from Frizzlife Gravity-Fed Water Filter System.
Step 1:
Step 6: Flush the Filter System

9
7
8
6
7
19
10
Sealing Rings
Wing Nut
Filter Cartridge
Washing Funnel
Unscrew the wing nut and sealing ring from the bottom of the upper chamber
Take out the old cartridge.
Unscrew the wing nut from the new cartridge.
Take out the two sealing rings from the new cartridge
Attach the washing funnel onto the new cartridge.
Flush the new cartridge for 3-5 mins.
Step 2：Remove the old cartridge
Step 3: Flush the new cartridge.
Sealing Ring
8 Wing Nut
Upper Chamber
Old
New

6
7
8
7
11
Push one sealing ring to the end of the thread rob.
Insert the threaded rod of the cartridge into the hole in the upper chamber.
Fasten the threaded rod of the cartridge with the other sealing ring and the wing nut.
Place the upper chamber into the lower chamber.
Step 4: Install the new cartridge
Wing Nut
Sealing Ring
Sealing Ring
Filter Cartridge
New

12
5. Use Tips
For G210 - Prox :
1. Please ensure the spigot is in the closed position during the flushing and filtration
process.
2. Do not fill the upper chamber if the lower chamber is completely full, as this will cause
the lower chamber to overflow.
3. If you plan to leave the system unused for more than 3 days, please empty both upper
and lower chambers, remove all filtration elements, and allow the components to dry.
4. Do not use with water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after using of the system.
1. The red ball in the water level tube indicates the water level in the lower chamber.
Please add water into the upper chamber according to the height of the floating ball.
2. Do not add water if the red ball is at the highest level.
1. Remove the filter cartridge, spigots and other attached components first.
2. Then clean the chambers with water and dish soap.
3. Please do not use the steel wool, and abrasive cleaner, or a corrosive liquid such as
gasoline or acetone.
The Gravity-Fed System should be cleaned once a month:
6. Maintenance

13
A：TDS is not a professional way to test the water quality. TDS means total dissolved
solids, for example if you put a very little salt(NaCl) into the water and test the TDS, and
you will find the result is dramatically high. Same thing, if your water is full of minerals,
the TDS is very high too. The Frizzlife Gravity-Fed System doesn't remove any of the
minerals from water, but only stops harmful contaminants like heavy metals (Lead,
Mercury, Cadmium) and over 90% of VOCs and Cysts, and it removes greatly the chlorine
(99%) from water. Therefore, it is the reason why TDS you get is not that low as you
expect.
1. Please empty the remaining water inside the chamber.
2. Please seal the filter cartridge and store it in the refrigerator, but do not put it in the
freezer.
3. Before the next use, please re-flush the filter cartridge and the system.
How to store the filter:
7. Frequently Asked Questions
Q: Why TDS does not drop after filtration?
A：After the lower chamber is filled up with filtered water, the water inside may spill out.
Please pay attention to the water level
Q: Why does water leak between the upper chamber and the lower chamber?

14
A：Please make sure the new cartridge has been fully flushed for 3-5 mins before
starting to use.
Q: My filtered water has an unexpected taste, what can I do?
A：It is normal. Since the system is gravity fed, as the water level in the upper chamber
goes down, the pressure that forces the water goes down decreases as well. Therefore,
the filtration speed will naturally slow down.
Q: Why does the upper chamber still contain water after
filtration?
8. Limited Product Warranty
The Frizzlife Gravity-Fed Water Filter System are warranted to the original purchaser.
To be free of defects in material and workmanship by FRIZZLIFE INC, FRIZZLIFE will
replace or repair components of the unit that Frizzlife has deemed to be broken within
the limits of the warranty without charge. The customer is not responsible for any
freight involved with shipping the item back for inspection and shipment of replace-
ment for items. Frizzlife is not liable for cost of removal, installation, transportation or
any other charges in connection with a warranty claim.
Warrantor: FRIZZLIFE INCFrizzlife Gravity-Fed Water Filter System
ONE YEAR LIMITED FRIZZLIFE WARRANTY

15
Customer must register their systems with Frizzlife within 90 days of purchase in
order to obtain a warranty. Warranty will discontinue after the unit is removed from
the location where it was originally installed. Warranty begins on the date of delivery
of product to the customer.
As a condition of this Limited Warranty, the owner must ensure that periodic
maintenance of the system is performed as described in the literature enclosed
with the system. Should your unit develop a defect or otherwise fail to perform in
accordance with this warranty, you should contact the retailer from whom the
product was originally purchased.nally installed. Warranty begins on the date of
delivery of product to the customer.
Owner’s Warranty Responsibility:
1. Frizzlife is not liable for anything that we deem as abuse of the units, including but
not limited to, misuse of product outside of intended use, equipment modifications,
unauthorized repairs,
improper installation, damage from freezing, hot water, fire or other acts of God
outside of Frizzlife control. Warranty begins on the date of delivery of product to the
customer.

16
Do not use outdoors or in a location that is subjected to direct sunlight or freezing.
This warranty will not be effective unless and until the Frizzlife is shown to have
been used in accordance with the installation and maintenance instructions
accompanying the product.
Incoming water to the the system cannot exceed 100°F.
2. Filter Cartridges are considered as disposable items, thus are not covered by warranty.
3. Customer is responsible for proper operation, which includes complete and continual
leak inspection.
There are no other warranties which extend beyond what is described above.
9. Warranty Registration
150% EXTENDED WARRANTY
1. Email us you order ID and full name at [e-mail]
within 90 days.
2. Scan the QR code below to register
If you have any questions, any suggestions, or you need any assistance, please free
to contact us anytime at [email protected].
Your satisfaction is always our top priority!
This warranty will be void if defects occur due to failure to observe the following conditions:
