Frizzlife SW10F User manual

(Ver. 03/2022)
OWNER’S MANUAL
Under Sink Water Filtration System
Applicable
Models: SW10F SW15F SW20F

CONTENT
1. BEFORE INSTALLATION
2. PRODUCT INTRODUCTION
3.SAMPLE CONNECTION
5. INSTALLATION STEPS
6. REPLACEMENT FILTER
7. FILTER REPLACEMENT INSTRUCTION
8. MULTI-USAGE
10. FREQUENTLY ASKED QUESTIONS
9. PERFORMANCE DATA
11. LIMITED PRODUCT WARRANTY
01
02
04
4. INSTALLATION TIPS 03
03
07
07
08
08
09
09
12. WARRANTY REGISTRATION 10
If you have problems during the purchase or installation
process, please contact our customer service.
Receive first-hand promiton info and be
the first one getting exclusive benefits.
@Frizzlife
www.frizzlife.com [email protected]
FOLLOW US

Register to activate your warranty with Frizzlife.
Find the Installation Video
1. BEFORE INSTALLATION
Email us your order ID and full name at
[email protected]
Scan the QR code to register
Search “Frizzlife SW10F/15F/20F Installation” on www.youtube.com
Inspect Box
Please take out the system and all the components from the box. Inspect
them carefully according to “Product Introduction”, and make sure nothing in
missing or damaged during shipping. If any parts are cracked or broken,
please do not proceed with installation, and contact Frizzlife for an exchange
or diagnosis.
Do not use it with water that is microbiologically unsafe or of unknown
quality without adequate disinfection.
Technical Parameters
Model No. SW10F SW15F SW20F
Flow Rate
Replacement Period 12-16M
PLC10
4.9×6.1×15 in 4.9×6.1×18.9 in 4.9×6.1×21.1 in
PLC15 PLC20
16-24M 24-36M
Replacement Filter
Dimension
Working Pressure
Operational Temp
Applicable Water Soure
1.5 GPM @ 60 psi
Municipal Water
Min.20psi, Max. 80psi
Min.39ºF,Max 100ºF
Precautions
For cold water use only.
Do not freeze the filter, as this case cause cracking and water leakage.
Do not allow children under 3 years of age to have access to small parts
duringthe installation of this product.
Testing was performed under standard laboratory conditions, actual
performance may vary.
This installation must comply with all applicable state and local regulations.
Please flush water for 15 minutes for the first time usage.
01
04

2. PRODUCT INTRODUCTION
02
SW10F / SW15F / SW20F Filter System
1
PLC10 /PLC15 / PLC20 Filter Cartridge
(Pre-loaded)
2
1/4” Tubing
3
Dedicated Faucet
4
5
Blue Clips
7
Wrench
8
Plumber Tape
9
Blade
10
Mounting Screws
11
61/4” Quick Fitting
3-Way Feed Water Valve
12
6
7
8 9
10
11
3
4
5

3. SAMPLE CONNECTION
4. INSTALLATION TIPS
03
How to cut the tubing?
How to connect/disconnect the tubing?
Feed water valve
Outlet tubing
Dedicated faucet
Existing main faucet
Inlet tubing
Hot Cold Water filter system
Please cut the tubing into two sections in proper length, make sure
cut them squarely and cleanly.
To connect: Please push the tubing into the fitting and make sure it is
fully inserted. Then put the blue lock clip on the fitting, it
will lock the tubing in place.
Please remove the bule lock clip from the fitting, push in
the lock sleeve, and then pull out the tube from the fitting.
If the tubing is not fully inserted, water leakage may occur.
Pulling out the tubing directly will damage the fitting, which
may also cause water leakage.
To disconnect:
Note:

5. INSTALLATION STEPS
Step 1: Mount the system (Optional)
04
Note:
Please always use plumber tape on threaded connection parts
to ensure a watertight seal.
1. Use the screws provided to mount the system
2. Fasten the screws.
(Note: Mount the water filter at least 2
inches higher than the ground for easier
filter replacement)
Step 2: Cut the tubing
1. 1.Please cut the 1/4” tubing into two sections
(1. inlet tubing 2. outlet tubing) in proper length
based on your need.
Please cut the tubing evenly, otherwise may result in water leakage.
0.5 inch
Press
Remove
Remove
blue clip
1. Insert to seal the connection 2. Remove to disconnect
How to drill a hole on my sink (Optional)
Note：Please remember to wear safety glasses to protect your eyes
before proceeding.
Use a 1/2” metal bit to drill. The recommended diameter of the hole
ranges from 1/2” to 1.2”.

05
Step 4: Connect the water supply (COLD WATER ONLY)
1.Shut off the water supply.
2.Remove the feed water hose from the angle valve.
3.Connect the 3-way feed water valve and make sure the rubber
O ring is loaded.
4.Connect the feed water hose.
5.Valve installation complete.
Step 5: Connect the filter system
1. Remove the blue clip from the “Inlet” port,and
connect the other end of inlet tubing to the “Inlet” port.
Please make sure the tubing hits the bottom of the
fitting.
2. Put back and lock the blue clip to seal the connection.
3.Connect the “Outlet” port with the outlet tubing in the
same way.
Step 3: Connect 3-way feed water valve
1.Load the inlet tubing through the nut.
2.Push and squeeze the tubing to the very end.
3.Use a wrench to tighten the nut, please do not over tighten.

06
Step 6: Install the faucet
Step 7: Check for leaks
1.Mount the faucet to your sink top
2.Connect the faucet with the 1/4” quick fitting
3.Connect the other end of outlet tubing from the “Outlet” port into the 1/4”
quick fitting.
1.Turn on all the water supply and check
for leaks.
2.Flush the system for 15 minutes before use.
15 min
Faucet Fixture
Rubber
Rubber
Hand
Fixture
Water Fitting
Note: If the thickness of your counter is over 1.9", please contact us at
[email protected] to claim for longer stem.
Note: If your counter top or granite does no have an existing hole,
please drill one (1/2") before proceeding.

6. REPLACEMENT FILTER
7. FILTER REPLACEMENT INSTRUCTION
Step 1: Twist the housing clockwise
Step 2: Using the wrench to unscrew
the housing body
Step 3: Take out the old cartridge and
load with new one, then install back in
the same way
Step 4: Flush the new cartridge for 15
minutes before starting to use
The Frizzlife Under Sink Water Filter System requires care and cleaning after a
period of time. It is recommended to change the cartridge according to
corresponding time intervals in the table below. If the system has been work-
ing properly and the filtered water output is slowing down, it may be time to
change the filter cartridge.
12-16M
16-24M
24-36M
System Model No.
SW10F
SW15F
SW20F
PLC10
PLC15
PLC20
Replacement Filter No. Filtration Capacity
07
Note: All the service life of the filter cartridge listed are based on
actual laboratory test and the provided water. The actual service life
of filter cartridge depends on source water quality and daily water
usage.
Note:
With the ATUO Shut off design of the system, you do not need
to shut off the water supply when doing the replacement.
Change

8. MULTI-USAGE
9. PERFORMANCE DATA
The SW10F/SW15F/SW20F system can be connected to your refrigerator / ice
maker by utilizing Frizzlife IMC-1 connection kit (not included).
Simply search “Frizzlife IMC-1”
on Amazon or scan the QR code
below to purchase.
≥50％
≥85％
0.010
99.95％
Substance
Chlorine
Particulate, Class I
Particles 0.5 to ＜1μm
Lead
Cyst
2.0 mg/L ± 10 ％
At least 10,000 particles/ml
0.15 ± 10 ％
Min. 50,000/L
Influent challenge
concentration (mg/L)
Maximum permissible
product water
concentration (mg/L)
08

11. LIMITED PRODUCT WARRANTY
10. FREQUENTLY ASKED QUESTIONS
Q: What should I do if water leaks after installation?
The Frizzlife SW10F/SW15F/SW20F Under Sink Water Filtration System are warranted to
the original purchaser. To be free of defects in material and workmanship by FRIZZLIFE
INC, FRIZZLIFE will replace or repair components of the unit that Frizzlife has deemed to
be broken within the limits of the warranty without charge. The customer is not responsi-
ble for any freight involved with shipping the item back for inspection and shipment of
replacement for items. Frizzlife is not liable for cost of removal, installation, transportation
or any other charges in connection with a warranty claim.
Customer must register their systems with Frizzlife within 90 days of purchase in order to
obtain a warranty. Warranty will discontinue after the unit is removed from the location
where it was originally installed. Warranty begins on the date of delivery of product to
the customer.
09
A: If once installed the system should leak, please shut off water supply firstly. If
the leaking occurs at the thread, please wrap plumber tape on the external thread.
Please contact Frizzlife customer service team for solutions if the water leakage
persists.
Q: Why TDS does not drop after filtration?
A: TDS is not a professional way to test the water quality. TDS means total
dissolved solids, for example if you put a very little salt(NaCl) into the water and test
the TDS, and you will find the result is dramatically high. Same thing, if your water is
full of minerals, the TDS is very high too. The SW10F/SW15F/SW20F doesn't remove any
of the minerals from water, but only stops harmful contaminants like heavy metals
(Lead, Mercury, Cadmium) and over 90% of VOCs and Cysts, and it removes greatly
the chlorine (99%) from water. Therefore, it is the reason why TDS you get is not that
low as you expect.
Q: When should I replace the filter cartridge?
A: The recommend service life of filter is as follows: 12-16 months for SW10F; 16-24
months for SW15F; 24-36 months for SW20F. Please note all the service life of filter
cartridge listed are based on actual laboratory test and the provided water. The actual
service life of filter cartridge depends on feed water quality and daily water usage.
Warrantor: FRIZZLIFE INCSW10F/SW15F/SW20F Under Sink Water Filter System
ONE YEAR LIMITED FRIZZLIFE WARRANTY

12. WARRANTY REGISTRATION
10
As a condition of this Limited Warranty, the owner must ensure that periodic
maintenance of the system is performed as described in the literature enclosed with
the system. Should your unit develop a defect or otherwise fail to perform in
accordance with this warranty, you should contact the retailer from whom the product
was originally purchased.
Owner’s Warranty Responsibility:
1. Frizzlife is not liable for anything that we deem as abuse of the units, including
but not limited to, misuse of product outside of intended use, equipment modifications,
unauthorized repairs, improper installation, damage from freezing, hot water, fire or
other acts of God outside of Frizzlife control.
This warranty will be void if defects occur due to failure to observe the
following conditions:
Incoming water to the the system cannot exceed 100°F.
Do not use outdoors or in a location that is subjected to direct sunlight or freezing.
This warranty will not be effective unless and until the Frizzlife is shown to have
been used in accordance with the installation and maintenance instructions
accompanying the product.
2. Filter Cartridges are considered as disposable items, thus are not covered by
warranty.
3. Customer is responsible for proper operation, which includes complete and
continual leak inspection.
Most of the unit components are made of plastic and eventually can break
or crack from stress.
There are no other warranties which extend beyond what is described above.
150% EXTENDED WARRANTY
1.Email us you order ID and full name at
[email protected] within 90 days.
2.Scan the QR code below to register
If you have any questions, any suggestions, or you need any assistance, please free
to contact us anytime at [email protected].
Your satisfaction is always our top priority!
