FRO­NIUS Selectiva 4120 User manual

Fronius prints on elemental chlorine free paper (ECF) sourced from certified sustainable forests (FSC).
/ Perfect Charging / Perfect Welding / Solar Energy
8 kW 220 V
Selectiva
4120 / 4140 / 4160
8 kW 400 V
Selectiva
2100 / 2120 / 2140
2160 / 2180 / 2200
4060 / 4075 / 4090
4120 / 4140 / 4160
8040 / 8060 / 8075
8090
16 kW 400 V
Selectiva
8120 / 8140 / 8160
8180 / 8210
EN
Operating instructions
Battery charging system
42,0426,0151,EN 032-03022021

Contents
Safety rules 5
General 5
Intended use 5
Environmental conditions 5
Mains connection 5
Dangers from mains current and charging current 6
Danger due to acid, gases and vapours 6
General information regarding the handling of batteries 7
Protecting yourself and others 7
Safety measures in normal operation 7
EMC Device Classifications 7
EMC measures 8
Data protection 8
Maintenance 8
Maintenance and repair 8
Obligations of the operator 8
Safety inspection 8
Markings on the device 9
Disposal 9
Copyright 9
General information 10
Explanation of safety notices 10
Device concept 10
Battery configuration 10
Mains connection 11
Charging lead 11
Warning notices on the device 11
Warning notices inside the device 13
Setup regulations 13
Wall bracket 15
Correct routing of the mains/charging cables 19
Control elements and connections 20
Controls and connections 20
Control panel 21
Charging the battery 23
Charging 23
Interrupting charging 24
Stopping charging 25
Display 27
Overview of display modes 27
Standard mode 27
Menu selection 28
Statistics mode 28
History mode 28
Configuration mode 30
Settings 33
Electrolyte circulation 34
Temperature-controlled charging 34
Equalising charge 35
Delay 36
Calendar 37
Special charges 38
“Opportunity Charge” special function 39
Additional functions 40
General settings 43
Reset settings 45
USB mode 45
Status codes 47
Options 51
Safety 51
3
EN

Electrolyte circulation (not available on the Selectiva 3x220 16 kW variants) 51
External start/stop 53
Charging lights 53
Temperature-controlled charging 53
CAN card 54
Relay board 55
Aquamatic control 56
Charging 56
Charge 50% 56
Charge 80% 56
Charging not complete 56
Charge finish 56
Main charge finished 56
Common error message 56
Common error + warning 56
Signal lamp 56
Immobiliser device 57
Battery cooled down 57
External air pump - electrolyte circulation 57
Wall bracket 57
Floor bracket 57
LED strip 57
IP 23 57
Air filter 57
"Mobile" kit 57
Remote control system 58
Technical data 59
Selectiva 16 kW 220 V 59
Selectiva 8 kW 400 V 61
Selectiva 16 kW 400 V 63
4

Safety rules
General The device has been manufactured in line with the state of the art and according to
recognized safety standards. If used incorrectly or misused, however, it can cause:
- Serious or fatal injury to the operator or third parties
- Damage to the device and other material assets belonging to the operating company
- Inefficient operation of the device
All persons involved in commissioning, operating, maintaining and servicing the device
must:
- Be suitably qualified
- Read and follow these Operating Instructions carefully
The Operating Instructions must always be at hand wherever the device is being used. In
addition to the Operating Instructions, attention must also be paid to any generally
applicable and local regulations regarding accident prevention and environmental protec-
tion.
All safety and danger notices on the device:
- Must be kept in a legible state
- Must not be damaged/marked
- Must not be removed
- Must not be covered, pasted, or painted over
For the location of the safety and danger notices on the device, refer to the section
headed "General information" in the Operating Instructions for your device.
Before switching on the device, rectify any faults that could compromise safety.
This is for your personal safety!
Intended use The device is to be used exclusively for its intended purpose. Any use above and beyond
this purpose is deemed improper. The manufacturer is not liable for any damage, or
unexpected or incorrect results arising out of such misuse.
Proper use also includes:
- Carefully reading and following all Operating Instructions, safety and danger notices
- Performing all stipulated inspection and servicing work
- Following all instructions from the battery and vehicle manufacturers
Proper handling of the device is essential for it to function correctly. Never pull on the
cable when handling the device.
Environmental
conditions
Operation or storage of the device outside the stipulated area will be deemed as not in
accordance with the intended purpose. The manufacturer shall not be held liable for any
damage arising from such usage.
For exact information on permitted environmental conditions, please refer to the "Tech-
nical data" section.
Mains connection Devices with a higher rating may affect the energy quality of the mains due to their cur-
rent consumption.
5
EN

This may affect a number device types in terms of:
- Connection restrictions
-Criteria with regard to the maximum permissible mains impedance *)
-Criteria with regard to the minimum short-circuit power requirement *)
*) at the interface with the public grid
see "Technical data"
In this case, the plant operator or the person using the device should check whether the
device may be connected, where appropriate by discussing the matter with the power
supply company.
IMPORTANT! Ensure that the mains connection is earthed properly
The mains voltage tolerances of the devices may deviate from those specified in the
technical data depending on the mains connection.
Dangers from
mains current
and charging cur-
rent
Anyone working with battery chargers exposes themselves to numerous dangers, e.g.:
- Risk of electrocution from mains current and charging current.
- Hazardous electromagnetic fields, which can risk the lives of those using cardiac
pacemakers.
An electric shock can be fatal. Every electric shock is potentially life threatening. To avoid
electric shocks while using the charger:
- Do not touch any live parts inside or on the outside of the charger.
- Under no circumstances touch the battery poles.
- Do not short-circuit the charging cable or charging terminals.
All cables and leads must be secured, undamaged, insulated and adequately dimen-
sioned. Loose connections, scorched, damaged or inadequately dimensioned cables and
leads must be immediately repaired by authorised personnel.
Danger due to
acid, gases and
vapours
Batteries contain acid which is harmful to the eyes and skin. During charging, gases and
vapours are released that may be harmful to health and are highly explosive in certain
circumstances.
Only use the charger in well-ventilated areas to prevent the accumulation of explosive
gases. Battery rooms are not deemed to be hazardous areas provided that a concentra-
tion of hydrogen of less than 4% can be guaranteed by the use of natural or forced vent-
ilation.
Maintain a distance of at least 0.5 m (19.69 in.) between the battery and charger during
the charging procedure. Possible sources of ignition such as fire and naked flames must
be kept away from the battery.
The battery connection (e.g. charging terminals) must not be disconnected for any
reason during charging.
Do not inhale any of the gases and vapours released under any circumstances - Make
sure the area is well ventilated.
To prevent short circuits, do not place any tools or conductive metals on the battery.
6

Battery acid must not get into the eyes or onto the skin or clothes. Wear protective
goggles and suitable protective clothing. Rinse any acid splashes thoroughly with clean
water and seek medical advice if necessary.
General informa-
tion regarding the
handling of bat-
teries
- Protect batteries from dirt and mechanical damage.
- Store charged batteries in a cool place. Self discharge is kept to a minimum at
approx. +2 °C (35.6 °F).
- Carry out a visual inspection at least once a week or as often as specified by the
battery manufacturer to ensure that the acid (electrolyte) level in the battery is at the
max. mark.
- If any of the following occur, do not start the device (or stop immediately if already in
use) and have the battery checked by an authorised workshop:
- uneven acid levels and/or high water consumption in individual cells caused by
a possible fault.
- overheating of the battery above 55 °C (131 °F).
Protecting your-
self and others
While the charger is in operation, keep all persons, especially children, out of the working
area. If, however, there are people in the vicinity,
- warn them about all the dangers (hazardous acids and gases, danger from mains
and charging current, etc.),
- provide suitable protective equipment.
Before leaving the work area, ensure that people or property cannot come to any harm in
your absence.
Safety measures
in normal opera-
tion
Chargers with a ground conductor must only be operated on a mains supply with a
ground conductor and a socket with a ground conductor contact. If the charger is oper-
ated on a mains supply without a ground conductor or in a socket without a ground con-
ductor contact, this will be deemed gross negligence. The manufacturer shall not be held
liable for any damage arising from such usage.
Only operate the charger in accordance with the degree of protection shown on the rat-
ing plate.
Under no circumstances operate the charger if there is any evidence of damage.
Arrange for the mains cable to be checked regularly by a qualified electrician to ensure
the ground conductor is functioning properly.
Any safety devices and parts that are not functioning properly or are in imperfect condi-
tion must be repaired by a qualified technician before switching on the charger.
Never bypass or disable protection devices.
After installation, an accessible mains plug is required.
EMC Device Clas-
sifications
Devices in emission class A:
- Are only designed for use in industrial settings
- Can cause line-bound and radiated interference in other areas
Devices in emission class B:
- Satisfy the emissions criteria for residential and industrial areas. This is also true for
residential areas in which the energy is supplied from the public low-voltage mains.
7
EN

EMC device classification as per the rating plate or technical data.
EMC measures In certain cases, even though a device complies with the standard limit values for emis-
sions, it may affect the application area for which it was designed (e.g. when there is
sensitive equipment at the same location, or if the site where the device is installed is
close to either radio or television receivers).
If this is the case, then the operating company is obliged to take appropriate action to
rectify the situation.
Data protection The user is responsible for the safekeeping of any changes made to the factory settings.
The manufacturer accepts no liability for any deleted personal settings.
Maintenance Before switching on, always check the mains plug and cable as well as charger leads
and charging terminals for any signs of damage.
If the surface of the device housing is dirty, clean with a soft cloth and solvent-free clean-
ing agent only.
Maintenance and
repair
Maintenance and repair work must only be carried out by authorised personnel. Use only
original spare and wearing parts (also applies to standard parts). It is impossible to guar-
antee that bought-in parts are designed and manufactured to meet the demands made
on them, or that they satisfy safety requirements.
Modifications, installations or conversions are only permitted with the approval of the
manufacturer.
Obligations of the
operator
The operator must only allow persons to work with the device who:
- are familiar with the fundamental instructions regarding safety at work and accident
prevention and have been instructed in how to use the device
- have read and understood these operating instructions, especially the section
"safety rules", and have confirmed as much with their signatures
- are trained to produce the required results.
Checks must be carried out at regular intervals to ensure that operators are working in a
safety-conscious manner.
Safety inspection The manufacturer recommends that a safety inspection of the device is performed at
least once every 12 months.
The safety inspection may only be performed by an appropriately qualified electrician
- After any changes have been made
- After any additional parts are installed, or after any conversions
- After repair, care and maintenance are carried out
- At least every twelve months
For safety inspections, follow the appropriate national and international standards and
directives.
Further details on safety inspections can be obtained from your service centre. They will
provide you on request with any documents you may require.
8

Markings on the
device
Devices with the CE marking satisfy the essential requirements of the applicable
guidelines.
Devices displaying the EAC mark of conformity satisfy the requirements of the relevant
standards in Russia, Belarus, Kazakhstan, Armenia and Kyrgyzstan.
Disposal Do not dispose of this device with normal domestic waste! To comply with the European
Directive on Waste Electrical and Electronic Equipment and its implementation as
national law, electrical equipment that has reached the end of its life must be collected
separately and returned to an approved recycling facility. Any device that you no longer
require must either be returned to your dealer or given to one of the approved collection
and recycling facilities in your area. Ignoring this European Directive may have poten-
tially adverse affects on the environment and your health!
Copyright Copyright of these operating instructions remains with the manufacturer.
The text and illustrations are all technically correct at the time of printing. We reserve the
right to make changes. The contents of the operating instructions shall not provide the
basis for any claims whatsoever on the part of the purchaser. If you have any sugges-
tions for improvement, or can point out any mistakes that you have found in the instruc-
tions, we will be most grateful for your comments.
9
EN

General information
Explanation of
safety notices DANGER!
Indicates immediate danger.
▶If not avoided, death or serious injury will result.
WARNING!
Indicates a potentially hazardous situation.
▶If not avoided, death or serious injury may result.
CAUTION!
Indicates a situation where damage or injury could occur.
▶If not avoided, minor injury and/or damage to property may result.
NOTE!
Indicates a risk of flawed results and possible damage to the equipment.
Device concept The three-phase battery charging systems are fitted with intelligent charging technology.
The successful Active Inverter Technology with the revolutionary Ri charging process
adapts itself to the requirements of the battery and only charges the battery with the cur-
rent that it actually needs.
The technology is embedded in a robust industry-standard housing. The exceptionally
compact design complies with all safety standards, requires less installation space and
protects the components to ensure a long service life.
Fitted with a graphical display, an integrated datalogger, new interfaces and additional
options, the device is perfectly equipped for the future.
Battery configur-
ation WARNING!
Danger due to unsuitable batteries being connected to the charger.
Escaping gas, fire or explosion may result in serious injury and damage to property.
▶Never connect a battery to the charger unless it is compatible in terms of its type,
voltage and capacity and corresponds to the charger settings.
10

Mains connection WARNING!
Danger from electrical current.
This may result in serious injuries or death.
▶Before starting work, switch off all the devices and components involved and discon-
nect them from the grid.
▶Secure all the devices and components involved to prevent unintentional restarting.
▶If required, nothing other than a type B residual current circuit breaker should ever
be used for connecting the device to the mains.
WARNING!
Danger due to incorrect operation and incorrectly performed work.
This may result in serious injury and damage to property.
▶All the work and functions described in this document must only be carried out by
trained and qualified personnel.
▶Read and understand this document.
▶Read and understand all the Operating Instructions for the system components,
especially the safety rules.
WARNING!
Danger due to faulty or insufficient power supply.
This may result in serious injury and damage to property.
▶The power supply requirements detailed in "Technical data" must be met.
Charging lead WARNING!
Danger due to trailing charging leads.
This may result in serious injury and damage to property. People may become entangled
in or trip over loose, unwound cables
▶Lay the charging leads so that no one can trip over or become entangled in them.
WARNING!
Danger due to the charging plug being pulled out during the charging process.
This may result in serious injury and damage to property. The sparks caused by this can
ignite the charging gases that build up during the charging process, causing a fire or an
explosion.
▶Once the charging process is complete, wind up the charging leads, or if available,
place them on the cable holder.
Warning notices
on the device
A number of safety symbols can be seen on the charger's rating plate. The safety sym-
bols must not be removed or painted over.
11
EN

Ser.No.: xxxxxxxx
Part No.: 4,010,xxx
UDC nom.
IDC max.
Protective class I
WARNING
Explosive gases. Prevent flames and sparks. Provide adequate ventilation during charge!
Always stop charging before you disconnect the charging cable!
IAC max.
UAC nom.
PAC max.
IP20
xxV
xxxA
xxA
3~ NPE xxxV 50/60Hz
xxxxW
www.fronius.com
xxxxxxxx
Selectiva xxxx
Ladevorgang immer stoppen bevor das Ladekabel abgezogen wird!
Explosive Gase. Flammen und Funken vermeiden.
Während des Ladens für ausreichend Frischluft-Zufuhr sorgen!
Always stop charging before you disconnect the charging cable!
Explosive gases. Prevent flames and sparks.
Provide adequate ventilation during charge!
Toujours arrêter la charge avant de déconnecter le câble de charge!
Gaz explosifs. Éviter les flammes et les étincelles.
Prévoir une ventilation adaptée pendant la charge!
¡Detener siempre la carga antes de desconectar el cable de carga!
Gases explosivos. Evitar llamas y chipas.
¡Mantener una ventilación adecuada durante la carga!
Interrompere sempre la carica prima di scollegare il cavo di carica!
Gas esplosivi. Evitare fiamme libere e scintille.
Predisporre una ventilazione adeguata durante la carica!
WARNUNG - WARNING - ATTENTION
ADVERTENCIA - AVVISO
42,0409,0419
An electric shock can be fatal. The housing must never be opened by anyone
other than a service technician trained by the manufacturer. The device must
be disconnected from the mains before starting any work with the housing
open. A suitable measuring instrument must be used to ensure that electric-
ally charged components (e.g. capacitors) are fully discharged. Ensure that
the device remains disconnected from the mains until all work has been com-
pleted.
Do not use the functions until you have fully read the Operating Instructions.
Possible sources of ignition, such as fire, sparks and naked flames, must be
kept away from the battery.
Risk of explosion! Oxyhydrogen is generated in the battery during charging.
Battery acid is corrosive and must be kept away from eyes, skin and clothes.
Ensure an adequate supply of fresh air during charging.
The charger can cause DC fault currents in the ground conductor. If a fault
current protection device (RCD) is used on the mains side to protect against
electric shock, it must conform to type B.
Do not dispose of the product in domestic waste. Dispose of it according to
the disposal requirements for waste electrical and electronic equipment valid
at the installation site.
12

Warning notices
inside the device WARNING!
Danger from electrical current.
This may result in serious injuries or death.
▶The housing must never be opened by anyone other than a service technician
trained by the manufacturer.
▶Before starting work, switch off all the devices and components involved and discon-
nect them from the grid.
▶Secure all the devices and components involved to prevent unintentional restarting.
▶After opening the device, use a suitable measuring instrument to check that electric-
ally charged components (such as capacitors) have been discharged.
▶Use an easily legible and understandable warning sign to ensure that the device is
not reconnected to the mains supply before all the work has been completed.
(4)
(5)
(+)
(-)
(1)
(2)
(3)
RCS 3.0 Lights
1
2
3
4
12V
GREEN
YELLOW
RED
BLUE
Temp. Sensor
Ext. Start/Stop
WARNING Hazardous Voltage
Kondensator Entladezeit < 3 min.
Capacitor discharge time < 3 min.
Décharge de condensateur < 3 min.
Condensador tiempo de descarga < 3 min.
Condensatore tempo di scaricamento < 3 min.
Risk of Electric Shock!
Do not operate at circuits
more than 250 V to ground!
0... 30V DC/4A
0... 250V AC/4A
Use Copper Conductors Only!
C Common
NC Normally Closed
NO Normally Opened
LLine
NNeutral Wire
max. 1A
AC Output!
42,0409,0008
C NC NO C NC NO C NC NO L/C NC NO N
WARNING!
  
Setup regulations WARNING!
Danger from devices falling or toppling over.
May result in serious injuries or death.
▶Set up all system components in a stable position. When using a floor bracket or
wall bracket, always ensure that all fastening elements are firmly seated.
▶Devices weighing more than 25 kg (55.12 lb.) must be carried by at least 2 persons.
▶When mounted on a shelf, the load capacity of the shelf must at least correspond to
the weight of the device.
13
EN

The device has been tested according to degree of protection IP20. This means:
- Protection against the penetration of solid foreign bodies with a diameter of more
than 12.5 mm (0.49 in.)
- No protection against water.
The device can be set up and operated in dry, closed rooms in accordance with degree
of protection IP20. Avoid exposure to moisture.
The permissible operating position of the
device is horizontal.
The ambient air surrounding the device must be kept free from battery acid vapors.
Mounting the device directly above the battery to be charged should therefore be
avoided.
Cooling air
The device must be set up so that cooling air can flow through the housing openings
provided unhindered. There must always be a minimum distance of 0.2 m (7.874 in.)
from the air inlet and outlet openings. The ambient air must be free from
- excessive dust exposure,
- electrically conductive particles (carbon black or metal chips),
- heat sources.
The cooling air flows in and out as indicated by the arrows in the following illustrations.
NOTE!
Air inlet and outlet openings must not be blocked or even partially covered.
16 kW: 60 cm (1 ft. 11.62 in.)
8 kW: 30 cm (11.81 in.)
The setup of several devices one behind the other should be staggered.
The setup of several devices one behind the other should be staggered, otherwise a
minimum distance of:
14

- 8 kW: Minimum distance 30 cm (11.81 in.)
- 16 kW: Minimum distance 60 cm (1 ft. 23.62 in.)
must be observed.
Wall bracket WARNING!
Danger due to incorrect operation and incorrectly performed work.
This may result in serious injury and damage to property.
▶All the work and functions described in this document must only be carried out by
trained and qualified personnel.
▶Read and understand this document.
▶Read and understand all the Operating Instructions for the system components,
especially the safety rules.
▶Different wall plugs and screws are required depending on the supporting surface.
Wall plugs and screws are therefore not included in the scope of supply. The
installer is responsible for selecting the correct wall plugs and screws.
WARNING!
Danger from machines falling or toppling over.
This may result in serious injury and damage to property.
▶Ensure that all screw connections are secure.
▶Only use with a Fronius Selectiva 8/16 kW charger.
▶Ensure the device is level when mounting.
1
15
EN

3
1
2
32
62
62
2
633 (24.92)
mm (in.)
13
(.51)
180 (7.09)
193 (7.6)
595,5 (23.44) 179 (7.05)
453 (17.83) 344 (13.54)
109
(4.29)
8 kW (400 V)
16

8 kW 220 V
392 (15.43)
502 (19.76)
647 (25.47)
267 (10.51)
247 (9.72)
241 (9.49)
585 (23.03)
20
(.79)
110
(4.33)
mm (in.)
16 kW 400 V
392 (15.43)
502 (19.76)
647 (25.47)
267 (10.51)
247 (9.72)
241 (9.49)
585 (23.03)
20
(.79)
110
(4.33)
mm (in.)
17
EN

342 (13.46)
418 (16.46)
494 (19.45)
500 (19.69)
492 (19.37)
450 (17.72)
400 (15.75)
300 (11.81)
200 (7.87)
20 (.79)
8.3
(.79)
6
(.24)
7 (.28)
8.5
(.33)
6(.24)
25
(.98)
76 (2.99)
60
(2.36)
mm (in.)
Drilling template
Weight of wall bracket:
- 8 kW 400 V: 1.8 kg (3.97 lb.)
- 8 kW 220 V: 3.15 kg (6.49 lb.)
- 16 kW 400 V: 3.15 kg (6.49 lb.)
18

Correct routing of
the mains/char-
ging cables
CAUTION!
Danger due to overheating as a result of incorrectly laid mains/charging cables.
Risk of damage to the components.
▶Lay the mains/charging cable without a loop.
▶Do not cover the mains/charging cable.
▶Charging cables longer than 5 m (16 ft. 4.85 in.) must be laid individually (no bund-
ling).
▶For charging cables longer than 5 m (16 ft. 4.85 in.), a maximum ambient temperat-
ure of 30 °C (86 °F) must not be exceeded.
▶The mains/charging cable may only be replaced by a qualified electrician.
▶Charging cables longer than 5 m (16 ft. 4.85 in.) can have an increased surface tem-
perature (be aware of hot surfaces).
19
EN

Control elements and connections
Controls and
connections
(5)
(4)
(3)
(2)
(8)
(6)
(7)
(1)
(9)
(11)
(10)
(12)
No. Function
(1) USB port
The USB port allows a USB flash
drive to be used to update the
device and also to log the charging
parameters while charging is in
progress. The maximum supply
current is 0.5 A.
(2) Position for the remote control
system or charging lights
options.
(3) Position for the external start/
stop option or temperature-con-
trolled charging option.
No. Function
(4) (-) Charging lead
(5) (+) Charging lead
(6) Positions for the relay-related options.
(e.g. Aquamatic control)
More information can be found in the "Options" chapter.
(7) Position for the internal electrolyte circulation option.
Compressed air outlet
(8) Position for the internal electrolyte circulation option.
Air intake with air filter
20
