FRO­NIUS FlexTrack 45 User manual

FlexTrack 45
8,045,565
Operating instructions
Spare parts list
Welding carriage
EN
/ Perfect Welding / Solar Energy / Perfect Charging
42,0426,0205,EN V03-03032015

3
These operating instructions will help you familiarise yourself with the device. It is in
your interest to read these instructions carefully and to observe the directions contained
in them. This will prevent faults and incorrect operation or possible damage to installed
components.
Please also obey the safety rules; doing so will ensure greater safety when using the
product. Careful handling of the entire system will repay you with years of safe and reli-
able operation. These are essential prerequisites for excellent results.
Dear reader,
Introduction

4

5
Contents
General information 7
About this document........................................................................................................................................ 9
Function of this document .......................................................................................................................... 9
Explanation of safety symbols.................................................................................................................... 9
Qualied technicians .................................................................................................................................. 9
Copyright.................................................................................................................................................... 9
General.......................................................................................................................................................... 10
Principle.................................................................................................................................................... 10
Device concept and applications.............................................................................................................. 10
Safety 13
Operational reliability and tips for the user .................................................................................................... 15
Proper use................................................................................................................................................ 15
Foreseeable misuse................................................................................................................................. 15
Conversions or modications ................................................................................................................... 15
Duty to instruct ......................................................................................................................................... 15
Operating instructions .............................................................................................................................. 16
Personal protective equipment................................................................................................................. 16
Local regulations ...................................................................................................................................... 16
Spare parts, wearing parts and auxiliary materials .................................................................................. 16
Transportation and storage ...................................................................................................................... 17
Description of the welding carriage 19
Scope of supply............................................................................................................................................. 21
Basic conguration................................................................................................................................... 21
Accessories and options .......................................................................................................................... 22
Welding carriage components....................................................................................................................... 23
Conguration: welding carriage with oscillation unit................................................................................. 23
Conguration: welding carriage without oscillation unit............................................................................ 24
Operating elements and connections............................................................................................................ 25
Connections ............................................................................................................................................. 25
Control box operating elements ............................................................................................................... 26
Welding carriage operating elements....................................................................................................... 26
Remote control elements ......................................................................................................................... 27
Rails and bridges........................................................................................................................................... 29
Weights of rails and bridges..................................................................................................................... 29
Fittings...................................................................................................................................................... 29
Rigid rails.................................................................................................................................................. 30
Flexible rails ............................................................................................................................................. 30
Bridge types ............................................................................................................................................. 31
Structure of a bridge................................................................................................................................. 31
Conguration: rail and guide rings ........................................................................................................... 32
Welding position and weld seam tracking ..................................................................................................... 34
Possible welding positions ....................................................................................................................... 34
Commissioning 37
Preparing the welding carriage...................................................................................................................... 39
Installing the welding carriage with oscillation unit................................................................................... 39
Replacing oscillation unit with adjustment unit......................................................................................... 40
Preparing and installing rails ......................................................................................................................... 41
Number of bridges required ..................................................................................................................... 41
Installing the bridges ................................................................................................................................ 41
Straight rails ............................................................................................................................................. 42

6
Installing the contact cams....................................................................................................................... 42
Securing the rail structure ........................................................................................................................ 43
Closed ring rail ......................................................................................................................................... 43
Closed ring rail ......................................................................................................................................... 44
Rigid ring segments ................................................................................................................................. 45
Flexible ring segments ............................................................................................................................. 47
Commissioning the welding carriage............................................................................................................. 48
Placing the welding carriage on a straight rail.......................................................................................... 48
Placing the welding carriage on a ring rail ............................................................................................... 49
Regulating the pressure rollers ................................................................................................................ 50
Disengaging the welding carriage ............................................................................................................ 51
Operation 53
Creating and saving welding programs ......................................................................................................... 55
Switching on system components............................................................................................................ 55
Setting the welding carriage parameters.................................................................................................. 55
Selecting additional functions................................................................................................................... 56
Saving a program..................................................................................................................................... 57
Loading a welding program...................................................................................................................... 58
Changing the units of measurement ........................................................................................................ 58
Work procedure............................................................................................................................................. 59
Working with or without oscillation ........................................................................................................... 59
Performing a test run................................................................................................................................ 59
Starting the welding process .................................................................................................................... 60
Maintenance and disposal 61
Troubleshooting............................................................................................................................................. 63
General..................................................................................................................................................... 63
Basic requirements for the system to work .............................................................................................. 63
Event codes ............................................................................................................................................. 63
Error codes............................................................................................................................................... 63
Maintenance.................................................................................................................................................. 64
Maintenance personnel............................................................................................................................ 64
Maintenance record ................................................................................................................................. 64
Recommended lubricants ........................................................................................................................ 64
Maintenance intervals and procedures .................................................................................................... 65
Technical data 67
Technical data ............................................................................................................................................... 69
FlexTrack 45 welding carriage ................................................................................................................. 69
Control box............................................................................................................................................... 69
Oscillation unit.......................................................................................................................................... 69
Dimensions............................................................................................................................................... 69
Rating plates ............................................................................................................................................ 70
Weights of rails and bridges..................................................................................................................... 71
Ring rail settings table.............................................................................................................................. 72
Flexible rail segments settings table ........................................................................................................ 73
Spare parts, circuit diagram 75
Spare parts.................................................................................................................................................... 77
Spare parts, wearing parts and auxiliary materials .................................................................................. 77
Ordering details........................................................................................................................................ 77
Circuit diagram .............................................................................................................................................. 85
