Front Runner 200 Series User manual

SSDS103_REV_A03 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
TOYOTA LAND CRUISER 200 SERIES
DECK COMPLETION SET
SSDS103
ENG
1
Thank you for purchasing a Front Runner Deck Completion Set.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.

SSDS103_REV_A03 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
13MM
10MM10MM
8MM8MM
12MM12MM
13MM 3MM
1 2 X Side Deck - 1 Left + 1 Right
2 2 X Large C-Hook
3 2 X M10 D-RIng
4 4 X M5 Nyloc Nut
5 2 X M5 Flat Washer
6 2 X Front Face - 1 Left + 1 Right
7 2 X M5 x 12 Button Head Bolt
8 2 X Front Face 1LH + 1RH With Knockouts
IN THE BOX
FIGURE 1.1
1
2
3
4
5
7
6
6
8
GET ORGANIZED
1

SSDS103_REV_A03 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 3
3
3
If you have chosen to remove the seats,
refer to the left hand side of the image.
Remove the four bolts securing each seat
as shown to remove the seats from the
vehicle. Secure the D-Rings (Item 3) to the
vehicle using the original bolts.
If you have chosen to leave the seats in the
vehicle, refer to the right hand side of the
image. Remove the bolts indicated by item 3
and secure the D-Rings to the vehicle using
the bolts just removed.
Loosen the D-Rings that comes assembled
to the drawer. Reposition the D-Rings to
the drawer as shown.
Place the drawer system into the vehicle,
lining up the front of the drawer with the
edge of the plastic trim as shown. Center
the drawer left to right.
FIT AND SECURE
2
2.1
2.2
2.3

SSDS103_REV_A03 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 4
SSWS003
Vehicle's Rear
Tie Down Ring
D-Ring (item 3)
Fitted in 2.1
Wing Nut
754
6
2
Refer to the fitting instruction of SSWS003
to secure the wing set.
If you have removed the seats to install
the drawer, assemble the front faces
(Item 6 or 8) to the left and right side of the
drawer using item 4, 5 and 7.
Fit the side decks (Item 1) to the drawer.
Refer to 1.1
Loosely secure the front of the drawer to
the vehicle's rear tie down rings using
4 c-hooks and 2 turnbuckles as shown.
(Supplied with the drawer system)
Loosely secure the rear of the drawer to
the vehicle, using 2 large c-hooks and 2
turnbuckles.
Tighten all the turnbuckles making sure
that the drawer system remains centered.
Tighten the Wing nuts.
Ensure that the wing nuts are at the top
as shown (Wing nuts are supplied with the
drawer system)
8
Loremipsum
PREPARATION
2
2.4
2.5
2.6

SSDS103_REV_A03 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 5
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
5Now's the time to visit your favorite Front Runner Dealer in person or online.
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
COMPLETION
4
9
Congratulations! You did it. Take a step back and admire your work!
4RH
FITTING ELECTRICAL SOCKETS
3
Twist the pre cut knock outs to remove.
These cut outs can then be used to fit Front
Runners range of electrical sockets.
(Sold Separately)
ECOM117 - Amp
ECOM118 - USB
ECOM119 - 12/24V
ECOM120 - Merit
ECOM121 - Engel
ECOM124 - Volt
3.1
