Front Runner SSDS126 User manual

SSDS126_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
front runner
SSDS126
ENG
1
Thank you for purchasing a Front Runner Ford Raptor (2019 - Current) w/Drop-In Bed Liner Deck Completion Set.
Before you start, take a moment to familiarize yourself with the Fitting Instructions and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IMPORTANT WARNING!
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
NOTE: Front Runner will not be responsible for any damage caused by the failure to install the product according to these instructions.
Please call us if you have any questions about the installation of this product.
FORD RANGER RAPTOR (2019-CURRENT)
W/DROP-IN BED LINER DECK COMPLETION SET

SSDS126_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS 2
TOOLS NEEDED
FIGURE 1.1
GET ORGANIZED
1
IN THE BOX
1 1 X Rear Left Deck
2 1 X Front Left Deck
3 1 X Front Right Deck
4 1 X Rear Right Deck
5 1 X Front Plate LH Side
6 1 X Front Plate RH Side
7 1 X Face Plate / Narrow LHS
8 1 X Face Plate / Narrow RHS
9 2 X Carb03
10 2 X Finishing Washer M6
11 2 X M6 x 30 CSK Socket Screw
12 4 X M6 x 16 Button head
13 4 X M6 Nyloc Nut
14 4 X M6 Nut Cap
5mm
1
2
3
10
11
9
4
6
8
5
7
12
14 13

SSDS126_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
3
FIT AND SECURE
2
2.1
2.2
2.3
Secure the three LH / RH Side Wings
(SSWS001) to the drawer system, using
M6x20 Hex Bolts, M6 Spring Washers &
M6x19 Flat Washers.
Secure the D-Rings, using the fasteners
supplied with the drawer system (SSDR010)
as shown. Two on the right and two on the
left hand side.
Secure the Rear Wing Sets as shown, using
M6x20 Hex Bolts, M6 Spring Washers &
M6x19 Flat Washers.
10mm
10mm
10mm

SSDS126_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
4
FIT AND SECURE2
2.4
2.5
2.6
Center the drawer in the load bed.
Position the drawer 230mm from the back of
the cab as shown.
Secure the two Face Plates LH / RH
(Item 5 & 6) to the drawer using four M6x12
Button Head Screws (Item 12).
4mm
230mm
CAB

INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
Be sure to tag us. We love to see our gear in action! #FrontRunnerOutfitters #BornToRoam
Share your adventures on:
FINISH
3
Congratulations! You did it. Take a step back and admire your work!
SSDS126_REV_A01 © 2021 FRONT RUNNER VEHICLE OUTFITTERS
5
FIT AND SECURE
2
2.7
2.8
Secure the Drawer System in position using
the Turnbuckles (supplied with SSDR010)
and Carabiner (Item 9) as shown.
Place the relevant deck sets in place as
shown, making sure that you slide it into
the C-clip of the Side Wings.
12
3
4
