Front Runner RRAC105 User manual

ENG
15 min
Rotopax Mounting Plate
RRAC105_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 1
IMPORTANT WARNING!
Thank you for purchasing a Front Runner Rotopax Mounting Plate.
Before you start, take a moment to familiarize yourself with this Fitting Instruction and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE.
IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH.
YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND DAMAGE.
THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO INSTALLATION OR USE.
IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES,
YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
RRAC105
READ ME !

RRAC105_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 2
IN THE BOX
FIGURE 1.1
1 1 X RotoPax Mounting Plate
2 6 X M8 Nut Cap
3 6 X M8 Nyloc Nut
4 6 X M8x16x1.6ss Flat Washer
5 6 X M8x16 Hex Bolt
IN THE BOX TOOLS NEEDED
IN THE BOX
13MM
2
3
4
1
5
2
3
4
5
1GET ORGANIZED
Here is what you are looking at for RRAC105

RRAC105_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
3
FIT AND SECURE
2
2.2
2.3
2.4
2.1
2.1
2.2
2.3
Fit 2 RotoPax RX-PM Pack mounts to the
Rotopax mounting plate (item1).
Fasteners are supplied with the
RotoPax RX-PM Pack mounts.
Place the Rotopax over the RotoPax RX-PM
Pack mounts and tighten.
13MM
13MM
Slide 2 M8x16 hex bolts (item 5) into each of
the 2nd, 3rd and 4th slats t-slot. Place the
Rotopax mounting plate (item 1) over the
bolts. Move the mounting plate into the
desired position by using the Rotopax
tank before securing it with items 3 and 4.
Finnish it of by placing a M8 nut cap
(item 2) over each of the 6 nyloc
nuts (item 3).
RotoPax RX-PM Pack mounts
1
2nd
3rd
4th
2
1
5
4
3
Rotopax

COMPLETION
3
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
9
3.1
Congratulations. You did it. Take a step back and admire your work!
