Front Runner PRO UNDER RACK TABLE bracket User manual

ENG
45 min
PRO UNDER RACK
TABLE bracket
TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 1
IMPORTANT WARNING!
Thank you for purchasing a Front Runner Pro Under Rack Table Bracket.
Before you start, take a moment to familiarize yourself with this Fitting Instruction and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE.
IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH.
YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND DAMAGE.
THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO INSTALLATION OR USE.
IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES,
YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.
TBRA016
READ ME !

TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 2
IN THE BOX
FIGURE 1.1
1 2 X Table Slide - 1 Left + 1 Right
2 2 X T-Slot Rubber
3 6 X M8x16 Hex Bolt
4 6 X M8x19 Flat Washer
5 8 X M8 Nyloc Nut
6 6 X M8 Nut Cap
7 2 X M6 Nyloc Nut
8 2 X Uni Screw Cap
9 2 X M6x12x1ss Flat Washer
10 2 X M6x12 Button Head Bolt
11 2 X M8x20 Button Head Bolt
12 2 X M8 Flat Washer
13 1 X Latch
IN THE BOX TOOLS NEEDED
IN THE BOX
13MM
10MM
13MM
10
6
2
13
12
11
9
8
7
1
3
4
1
5
6
If you wish to mount your table at the rear of your rack, please refer to Section 2.
If your rack is mounted using a foot rail system and you wish to side mount your table, please refer to Section 3.
1GET ORGANIZED
Here is what you are looking at for TBRA016
5mm
4mm

TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
3
MOUNTING THE TABLE AT THE REAR OF THE RACK
2
2.2
2.3
2.4
2.1
2.1
2.2
2.3
Working underneath and from the rear of
the rack, slide two M8x16 bolts (item 3)
into the second and fourth slats of the rack
through the machined slots.
Loosely secure the table slides (item1) to
the rack using items 4 and 5 as shown.
Cut the T-slot rubber (item 2) to
suite the width of your rack and insert
into the rear T-slot of the first slat by
pinching/squeezing the sides of the rubber
together and pushing/rolling the rubber
into the T-slot as shown.
13MM
Depending on the width of your table, space
the two table slides either 750mm or
550mm apart. Tighten all the nyloc nuts
and place a M8 nut cap (item 6) over each
nyloc nut. See diagram 2.1
4th
2th Rear of Rack
(Shown Upside Down)
6
4
5
1
3
750mm or 550mm
2

TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
4
11
12
13
Push Up To Open
MOUNTING THE TABLE AT THE REAR OF THE RACK
2
2.2
2.3
2.4
2.1
2.4
2.5
2.6
Inserta M8 nyloc nut (item 6) dome side
down into the "U" channel of the rack
through the gap in the corner as shown.
Slide the nyloc nut to the center of the rack.
Open the latch by pushing on the
latch release and slide the table into
position. Check that the table has no
forward/backward movement when the
latch is closed. If it does, loosen the nyloc
nuts (item 6) from diagram 2.1 and adjust
so that the table has no movment in the
slides when the latch is colsed.
A small padlock can be used through the
hole in the latch release should you wish
to lock the table.
Place the latch (item 13) onto the rack,
lining up the mounting hole in the latch
with the nyloc nut in diagram 2.4. Secure
the latch in position using the M8x20
button head and M8 flat washer
(item 11 and 12)
Slide nut down T-Slot
5MM

TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
5
750mm or 550mm
6
4
1
5
3
Underside Shown
SIDE MOUNTING WITH FOOT RAIL
3
2.2
2.3
2.4
2.1
3.1
3.2
3.3
Insert three M8x16 bolts (item 3) into the
slat as shown through the machined slots.
Loosely secure the table slides (item 1)
to the rack using the M8 nyloc nuts and
M8x19 flat washers items 4 and 5 as
shown.
Working on the side of the rack that the
table will exit, insert a M8 nyloc nut
(item 6) dome side down into the T-Slot
of the rack through the gap in the
corner as shown. Slide the nyloc nut down
the T-Slot and center the nut
between the two table slides.
13MM
Space the table slides 250mm away from
the edge of the rack as shown.
The table slides are slotted left to right to
enable adjustment. Space the two table
slides 750mm or 550mm apart and
tighten all the nyloc nuts. place a M8 nut
cap (item 6) over each nyloc nut.
250mm
Slide nut down "U" Channel

TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
5
10
8
9
7
13
Push Up To Open
SIDE MOUNTING WITH FOOT RAIL
3
2.2
2.3
2.4
2.1
3.4
3.5
3.6
Place the latch (item 13) into the rack,
lining up the mounting hole in the latch
with the nyloc nut inserted in diagram
2.3. Secure the latch in position using the
M8x20 Button head bolt and M8 flat washer
(items 11 and 12)
Open the latch by pushing on the
latch release and slide the table into
position. Check that the table has no
forward/backward movement when the
latch is closed. If it does, loosen the nyloc
nuts (item 6) from diagram 3.1 and adjust
so that the table has no movement in the
slides when the latch is closed.
A small padlock can be used through the
hole in the latch release should you wish
to lock the table.
5MM
10MM
Fasten items 7,8,9 and 10 as shown.
12
11
4MM

COMPLETION
4
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
5
Now's the time to visit your favorite Front Runner Dealer in person or online.
9
4.1
Congratulations. You did it. Take a step back and admire your work!
TBRA016_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
5
9
4.2
Congratulations. You did it. Take a step back and admire your work!
