Front Runner BPTH007 User manual

BPTH007_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
toyota hilux REVO (2016 -CURRENT)
Rock SlideRs
BPTH007
ENG
1
45 min
IMPORTANT WARNING!
Thank you for purchasing Front Runner Rock Sliders.
Before you start, take a moment to familiarize yourself with this Fitting Intruction and the components received.
Refer to Page 2 for a list of all the components, quantities and tools required.
READ ME !
IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR VEHICLE. IMPROPER ATTACHMENT COULD
RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT
RUNNER PRODUCTS TO YOUR VEHICLE. CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR AND
DAMAGE. THEREFORE YOU MUST READ AND UNDERSTAND ALL OF THE INSTRUCTIONS AND PRECAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO
INSTALLATION OR USE. IF YOU DO NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT THOROUGHLY
FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

BPTH007_REV_A00 2 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS
8
9
1
46
47
7
4
5
5
4
7
6
4
2
2
4
3
4
6
TOOLS NEEDED
17MM 17MM
12MM
1 1 X Rock Sliders (1LH & 1RH)
2 3 X M10x130 Hex Bolt
3 2 X M10x150 Hex Bolt
4 11 X M10x30x3 Flat Washer
5 5 X Bolt Plate (Not Welded)
6 6 X M10 Spring Washer
7 5 X M10 Nyloc
8 1 X Bolt Plate (Welded)
9 1 X M10x120 Hex Bolt
IN THE BOX
FIGURE 1.1
REAR OF VEHICLE
FRONT OF VEHICLE
GET ORGANIZED
1
Here is what you are looking at for BPTH007

BPTH007_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 3
FRONT
REAR
FIT AND SECURE
2
You will secure the rock sliders by bolting
through the existing holes in the chassis.
See diagram 1.1 for placement of the
fasteners.
For the left hand rock slider you will need
to use the welded bolt plate (item 8) to
secure the rock slider at the rear mounting
piont between the chassis and the tank.
See diagram 1.1 for placement of the
fasteners
Loosen the cable bracket before fitting
the left rock sliders. Refit the cable bracket
after the rock slider has been secured.
Remove the side steps on both sides
of the vehile.
2.1
2.2
2.3
17MM
12MM
17MM
Lift the rock sliders into position as
shown using the vehicles jack.

BPTH007_REV_A00 © COPYRIGHT 2016 FRONT RUNNER VEHICLE OUTFITTERS 4
COMPLETION
3
INSTALL OTHER VEHICLE AND RACK ACCESSORIES
4
Now's the time to visit your favorite Front Runner Dealer in person or online.
9
3.1
Congratulations. You did it. Take a step back and admire your work!
