Fuji Electric FRENIC-Multi User manual

High Performance Compact Inverter
User's Manual

Copyright © 2005 Fuji Electric FA Components & Systems Co., Ltd.
All rights reserved.
No part of this publication may be reproduced or copied without prior written permission from Fuji Electric
FA Components & Systems Co., Ltd.
All products and company names mentioned in this manual are trademarks or registered trademarks of their
respective holders.
The information contained herein is subject to change without prior notice for improvement.

i
Preface
This manual provides all the information on the FRENIC-Multi series of inverters including its operating
procedure, operation modes, and selection of peripheral equipment. Carefully read this manual for proper use.
Incorrect handling of the inverter may prevent the inverter and/orrelated equipment from operating correctly,
shorten their lives, or cause problems.
The table below lists the other materials related to the use of the FRENIC-Multi. Read them in conjunction
with this manual as necessary.
Name Material No. Description
Catalog MEH652
Product scope, features, specifications, external
drawings, and options of the product
Instruction Manual INR-SI47-1094-E Acceptance inspection, mounting & wiring of the
inverter, operation using the keypad, running the motor
for a test, troubleshooting, and maintenance and
inspection
The materials are subject to change without notice. Be sure to obtain the latest editions for use.

Japanese Guideline for Suppressing Harmonics by Customers Receiving
High Voltage or Special High Voltage
Refer to this manual, Appendix B for details on this guideline.
Safety precautions
Read this manual and the FRENIC-Multi Instruction Manual (INR-SI47-1094-E) thoroughly before
proceeding with installation, connections (wiring), operation, or maintenance and inspection. Ensure you
have sound knowledge of the product and familiarize yourself with all safety information and precautions
before proceeding to operate the inverter.
Safety precautions are classified into the following two categories in this manual.
Failure to heed the information indicated by this symbol may lead to
dangerous conditions, possibly resulting in death or serious bodily injuries.
Failure to heed the information indicated by this symbol may lead to
dangerous conditions, possibly resulting in minor or light bodily injuries
and/or substantial property damage.
Failure to heed the information contained under the CAUTION title can also result in serious consequences.
These safety precautions are of utmost importance and must be observed at all times.
This product is not designed for use in appliances and machinery on which lives depend. Consult your Fuji
Electric representative before considering the FRENIC-Multi series of inverters for equipment and
machinery related to nuclear power control, aerospace uses, medical uses or transportation. When the
product is to be used with any machinery or equipment on which lives depend or with machinery or
equipment which could cause serious loss or damage should this product malfunction or fail, ensure that
appropriate safety devices and/or equipment are installed.
ii

iii
Precautions for Use
Driving a 400 V
general-purpose
motor
When driving a 400 V general-purpose motor with an inverter using
extremely long wires, damage to the insulation of the motor may occur. Use
an output circuit filter (OFL) if necessary after checking with the motor
manufacturer. Fuji motors do not require the use of output circuit filters
because of their reinforced insulation.
Torque
characteristics and
temperature rise
When the inverter is used to run a general-purpose motor, the temperature
of the motor becomes higher than when it is operated using a commercial
power supply. In the low-speed range, the cooling effect will be weakened,
so decrease the output torque of the motor. If constant torque is required in
the low-speed range, use a Fuji inverter motor or a motor equipped with an
externally powered ventilating fan.
Vibration
When an inverter-driven motor is mounted to a machine, resonance may be
caused by the natural frequencies of the machine system.
Note that operation of a 2-pole motor at 60 Hz or higher may cause
abnormal vibration.
* The use of a rubber coupling or vibration-proof rubber is recommended.
* Use the inverter's jump frequency control feature to skip the resonance
frequency zone(s).
In running
general-
purpose
motors
Noise
When an inverter is used with a general-purpose motor, the motor noise
level is higher than that with a commercial power supply. To reduce noise,
raise carrier frequency of the inverter. Operation at 60 Hz or higher can also
result in higher level of wind roaring sound.
High-speed
motors
If the set frequency is set to 120 Hz or more to drive a high-speed motor,
test-run the combination of the inverter and motor beforehand to check for
safe operation.
Explosion-proof
motors When driving an explosion-proof motor with an inverter, use a combination
of a motor and an inverter that has been approved in advance.
Submersible
motors and pumps
These motors have a higher rated current than general-purpose motors.
Select an inverter whose rated output current is higher than that of the
motor.
These motors differ from general-purpose motors in thermal characteristics.
Set a low value in the thermal time constant of the motor when setting the
electronic thermal overcurrent protection (for motor).
Brake motors
For motors equipped with parallel-connected brakes, their power supply for
brake must be supplied from the inverter’s primary circuit. If the power
supply for brake is connected to the inverter's output circuit by mistake, the
brake will not work.
Do not use inverters for driving motors with series-connected brake coils.
Geared motors If the power transmission mechanism uses an oil-lubricated gearbox or
speed changer/reducer, then continuous motor operation at low speed may
cause poor lubrication. Avoid such operation.
Synchronous
motors It is necessary to take special measures suitable for this motor type. Contact
your Fuji Electric representative for details.
In running
special
motors
Single-phase
motors Single-phase motors are not suitable for inverter-driven variable speed
operation. Use three-phase motors.

iv
Environ-
mental
conditions
Installation
location
Use the inverter within the ambient temperature range from -10 to +50°C.
The heat sink and braking resistor of the inverter may become hot under
certain operating conditions, so install the inverter on nonflammable
material such as metal.
Ensure that the installation location meets the environmental conditions
specified in Chapter 8, Section 8.4 "Operating Environment and Storage
Environment."
Installing an
MCCB or
RCD/ELCB
Install a recommended molded case circuit breaker (MCCB) or
residual-current-operated protective device (RCD)/earth leakage circuit
breaker (ELCB) (with overcurrent protection) in the primary circuit of each
inverter to protect the wiring. Ensure that the circuit breaker capacity is
equivalent to or lower than the recommended capacity.
Installing an MC
in the secondary
circuit
If a magnetic contactor(MC)is installed in the inverter's output (secondary)
circuit for switching the motor to commercial power or for any other
purpose, ensure that both the inverter and the motor are completely stopped
before you turn the MC on or off.
Remove a surge killer integrated with the magnetic contactor in the
inverter's output (secondary) circuit.
Installing an MC
in the primary
circuit
Do not turn the magnetic contactor (MC) in the primary circuit on or off
more than once an hour as an inverter failure may result.
If frequent starts or stops are required during motor operation, use terminal
[FWD]/[REV] signals or the RUN/STOP key.
Protecting the
motor
The electronic thermal feature of the inverter can protect the motor. The
operation level and the motor type (general-purpose motor, inverter motor)
should be set. For high-speed motors or water-cooled motors, set a small
value for the thermal time constant.
If you connect the motor thermal relay to the motor with a long wire, a
high-frequency current may flow into the wiring stray capacitance. This
may cause the thermal relay to trip at a current lower than the set value. If
this happens, lower the carrier frequency or use the output circuit filter
(OFL).
Discontinuance of
power-factor
correcting
capacitor
Do not connect power-factor correcting capacitors to the inverter’s primary
circuit. (Use the DC reactor to improve the inverter power factor.) Do not
use power-factor correcting capacitors in the inverter’s output (secondary)
circuit. An overcurrent trip will occur, disabling motor operation.
Discontinuance of
surge killer Do not connect a surge killer to the inverter's output (secondary) circuit.
Reducing noise
Use of a filter and shielded wires is typically recommended to satisfy EMC
Directive.
Refer to Appendices, App. A "Advantageous Use of Inverters (Notes on
electrical noise)" for details.
Measures against
surge currents
If an overvoltage trip occurs while the inverter is stopped or operated under
light load, it is assumed that the surge current is generated by open/close of
the phase-advancing capacitor in the power system.
* Connect a DC reactor to the inverter.
Combina-
tion with
peripheral
devices
Megger test When checking the insulation resistance of the inverter, use a 500 V megger
and follow the instructions contained in the FRENIC-Multi Instruction
Manual (INR-SI47-1094-E), Chapter 7, Section 7.5 "Insulation Test."

v
Control circuit
wiring length When using remote control, limit the wiring length between the inverter and operator panel to 20 m or less and use twisted pair or shielded wire.
Wiring length
between inverter
and motor
If long wiring is used between the inverter and the motor, the inverter may
overheat or trip due to overcurrent because a higher harmonics current
flows into the stray capacitance between each phase wire. Ensure that the
wiring is shorter than 50 m. If this length must be exceeded, lower the
carrier frequency or install an output circuit filter (OFL).
Wire size Select wires with a sufficient capacity by referring to the current value or
recommended wire size.
Wire type Do not share one multi-core cable in order to connect several inverters with
motors.
Wiring
Grounding Securely ground the inverter using the grounding terminal.
Driving
general-purpose
motor
Select an inverter according to the applicable motor ratings listed in the
standard specifications table for the inverter.
When high starting torque is required or quick acceleration or deceleration
is required, select an inverter with one rank larger capacity than the
standard. Refer to Chapter 7, Section 7.1 "Selecting Motors and Inverters"
for details.
Selecting
inverter
capacity
Driving special
motors Select an inverter that meets the following condition: Inverter rated current > Motor rated current
Transpor-
tation and
storage
When transporting or storing inverters, follow the procedures and select locations that meet the
environmental conditions listed in the FRENIC-Multi Instruction Manual (INR-SI47-1094-E),
Chapter 1, Section 1.3 "Transportation" and Section 1.4 "Storage Environment."

vi
How this manual is organized
This manual contains Chapters 1 through 9,Appendices and Glossary.
Part 1 General Information
Chapter 1 INTRODUCTION TO FRENIC-Multi
This chapter describes the features and control system of the FRENIC-Multi series, and the recommended
configuration for the inverter and peripheral equipment.
Chapter 2 PARTS NAMES AND FUNCTIONS
This chapter contains external views of the FRENIC-Multi series and an overview of terminal blocks,
including a description of the LED display and keys on the keypad.
Chapter 3 OPERATION USING THE KEYPAD
This chapter describes inverter operation using the keypad. The inverter features three operation modes
(Running, Programming and Alarm modes) which enable you to run and stop the motor, monitor running
status, set function code data, display running information required for maintenance, and display alarm data.
Part 2 Driving the Motor
Chapter 4 BLOCK DIAGRAMS FOR CONTROL LOGIC
This chapter describes the main block diagrams for the control logic of the FRENIC-Multi series of inverters.
Chapter 5 RUNNING THROUGH RS-485 COMMUNICATION
This chapter describes an overview of inverter operation through the RS-485 communications facility. Refer
to the RS-485 Communication User's Manual (MEH448b) or RS-485 Communications Card "OPC-E1-RS"
Installation Manual (INR-SI47-1089) for details.
Part 3 Peripheral Equipment and Options
Chapter 6 SELECTING PERIPHERAL EQUIPMENT
This chapter describes how to use a range of peripheral equipment and options, FRENIC-Multi's
configuration with them, and requirements and precautions for selecting wires and crimp terminals.
Part 4 Selecting Optimal Inverter Model
Chapter 7 SELECTING OPTIMAL MOTOR AND INVERTER CAPACITIES
This chapter provides you with information about the inverter output torque characteristics, selection
procedure, and equations for calculating capacities to help you select optimal motor and inverter models. It
also helps you select braking resistors.

Part 5 Specifications and Troubleshooting
Chapter 8 SPECIFICATIONS
This chapter describes specifications of the output ratings, control system, and terminal functions for the
FRENIC-Multi series of inverters. It also provides descriptions of the operating and storage environment,
external dimensions, examples of basic connection diagrams, and details of the protective functions.
Chapter 9 FUNCTION CODES
This chapter contains overview lists of seven groups of function codes available for the FRENIC-Multi series
of inverters and details of each function code.
Appendices
Glossary
Icons
The following icons are used throughout this manual.
This icon indicates information which, if not heeded, can result in the inverter not operating to
full efficiency, as well as information concerning incorrect operations and settings which can
result in accidents.
This icon indicates information that can prove handy when performing certain settings o
r
operations.
This icon indicates a reference to more detailed information.
vii

viii
CONTENTS
Part 1 General Information
Chapter 1 INTRODUCTION TO FRENIC-Multi
1.1 Features.....................................................................................................................................................1-1
1.2 Control System ....................................................................................................................................... 1-11
1.3 Recommended Configuration.................................................................................................................1-13
Chapter 2 PARTS NAMES AND FUNCTIONS
2.1 External View and Allocation of Terminal Blocks....................................................................................2-1
2.2 LED Monitor, Keys and LED Indicators on the Keypad..........................................................................2-2
Chapter 3 OPERATION USING THE KEYPAD
3.1 Overview of Operation Modes .................................................................................................................3-1
3.2 Running Mode..........................................................................................................................................3-3
3.2.1 Monitoring the running status.............................................................................................................3-3
3.2.2 Setting up frequency and PID process commands..............................................................................3-4
3.2.3 Running/stopping the motor................................................................................................................3-9
3.2.4 Jogging Operation...............................................................................................................................3-9
3.3 Programming Mode................................................................................................................................3-10
3.3.1 Setting up basic function codes quickly -- Menu #0 "Quick Setup" --..............................................3-12
3.3.2 Setting up function codes -- Menu #1 "Data Setting" --...................................................................3-16
3.3.3 Checking changed function codes -- Menu #2 "Data Checking" -- ..................................................3-17
3.3.4 Monitoring the running status -- Menu #3 "Drive Monitoring" -- ...................................................3-18
3.3.5 Checking I/O signal status -- Menu #4 "I/O Checking" -- ...............................................................3-21
3.3.6 Reading maintenance information -- Menu #5 "Maintenance Information" -- ................................3-26
3.3.7 Reading alarm information -- Menu #6 "Alarm Information" --......................................................3-29
3.4 Alarm Mode............................................................................................................................................3-32
3.4.1 Releasing the alarm and switching to Running mode .......................................................................3-32
3.4.2 Displaying the alarm history.............................................................................................................3-32
3.4.3 Displaying the status of inverter at the time of alarm .......................................................................3-32
3.4.4 Switching to Programming mode......................................................................................................3-32
Part 2 Driving the Motor
Chapter 4 BLOCK DIAGRAMS FOR CONTROL LOGIC
4.1 Symbols Used in Block Diagrams and their Meanings ............................................................................4-1
4.2 Drive Frequency Command Block ...........................................................................................................4-2
4.3 Drive Command Block.............................................................................................................................4-6
4.4 Control Block............................................................................................................................................4-8
4.5 PID Process Control Block.....................................................................................................................4-12
4.6 PID Dancer Control Block......................................................................................................................4-16
4.7 FM Output Selector ................................................................................................................................4-19

ix
Chapter 5 RUNNING THROUGH RS-485 COMMUNICATION (OPTION)
5.1 Overview on RS-485 Communication......................................................................................................5-1
5.1.1 RS-485 common specifications (standard and optional).....................................................................5-2
5.1.2 RJ-45 connector pin assignment for standard RS-485 communications port......................................5-3
5.1.3 Pin assignment for optional RS-485 Communications Card...............................................................5-4
5.1.4 Cable for RS-485 communications port..............................................................................................5-4
5.1.5 Communications support devices........................................................................................................5-5
5.2 Overview of FRENIC Loader...................................................................................................................5-6
5.2.1 Specifications......................................................................................................................................5-6
5.2.2 Connection..........................................................................................................................................5-7
5.2.3 Function overview...............................................................................................................................5-7
5.2.3.1 Setting of function code ..............................................................................................................5-7
5.2.3.2 Multi-monitor..............................................................................................................................5-8
5.2.3.3 Running status monitor ...............................................................................................................5-9
5.2.3.4 Test-running ..............................................................................................................................5-10
5.2.3.5 Real-time trace—Displaying running status of an inverter in waveforms ................................ 5-11
Part 3 Peripheral Equipment and Options
Chapter 6 SELECTING PERIPHERAL EQUIPMENT
6.1 Configuring the FRENIC-Multi................................................................................................................6-1
6.2 Selecting Wires and Crimp Terminals.......................................................................................................6-2
6.2.1 Recommended wires...........................................................................................................................6-4
6.3 Peripheral Equipment ...............................................................................................................................6-8
6.4 Selecting Options....................................................................................................................................6-14
6.4.1 Peripheral equipment options............................................................................................................6-14
6.4.2 Options for operation and communications ......................................................................................6-23
6.4.3 Meter options ....................................................................................................................................6-26
Part 4 Selecting Optimal Inverter Model
Chapter 7 SELECTING OPTIMAL MOTOR AND INVERTER CAPACITIES
7.1 Selecting Motors and Inverters.................................................................................................................7-1
7.1.1 Motor output torque characteristics.....................................................................................................7-1
7.1.2 Selection procedure.............................................................................................................................7-4
7.1.3 Equations for selections ......................................................................................................................7-7
7.1.3.1 Load torque during constant speed running ................................................................................7-7
7.1.3.2 Acceleration and deceleration time calculation...........................................................................7-8
7.1.3.3 Heat energy calculation of braking resistor............................................................................... 7-11
7.1.3.4 Calculating the RMS rating of the motor..................................................................................7-12
7.2 Selecting a Braking Resistor...................................................................................................................7-13
7.2.1 Selection procedure...........................................................................................................................7-13
7.2.2 Notes on selection.............................................................................................................................7-13

x
Part 5 Specifications and Troubleshooting
Chapter 8 SPECIFICATIONS
8.1 Standard Models.......................................................................................................................................8-1
8.1.1 Three-phase 200 V series....................................................................................................................8-1
8.1.2 Three-phase 400 V series....................................................................................................................8-2
8.1.3 Single-phase 200 V series ...................................................................................................................8-3
8.2 Common Specifications............................................................................................................................8-4
8.3 Terminal Specifications ............................................................................................................................8-8
8.3.1 Terminal functions ..............................................................................................................................8-8
8.3.2 Terminal arrangement diagram and screw specifications..................................................................8-19
8.3.2.1 Main circuit terminals ...............................................................................................................8-19
8.3.2.2 Control circuit terminals............................................................................................................8-20
8.4 Operating Environment and Storage Environment.................................................................................8-21
8.4.1 Operating environment......................................................................................................................8-21
8.4.2 Storage environment .........................................................................................................................8-22
8.4.2.1 Temporary storage.....................................................................................................................8-22
8.4.2.2 Long-term storage.....................................................................................................................8-22
8.5 External Dimensions...............................................................................................................................8-23
8.5.1 Standard models................................................................................................................................8-23
8.5.2 Standard keypad................................................................................................................................8-26
8.6 Connection Diagrams .............................................................................................................................8-27
8.6.1 Running the inverter with keypad.....................................................................................................8-27
8.6.2 Running the inverter by terminal commands....................................................................................8-28
8.7 Protective Functions ...............................................................................................................................8-30
Chapter 9 FUNCTION CODES
9.1 Function Code Tables ...............................................................................................................................9-1
9.2 Overview of Function Codes..................................................................................................................9-15
9.2.1 F codes (Fundamental functions)......................................................................................................9-15
9.2.2 E codes (Extension terminal functions).............................................................................................9-44
9.2.3 C codes (Control functions) ..............................................................................................................9-71
9.2.4 P codes (Motor 1 parameters) ...........................................................................................................9-78
9.2.5 H codes (High performance functions).............................................................................................9-81
9.2.6 A codes (Motor 2 parameters).........................................................................................................9-103
9.2.7 J codes (Application functions).......................................................................................................9-105
9.2.8 y codes (Link functions)..................................................................................................................9-120

xi
Appendices
App.A Advantageous Use of Inverters (Notes on electrical noise)................................................................... A-1
A.1 Effect of inverters on other devices.......................................................................................................A-1
A.2 Noise...................................................................................................................................................... A-2
A.3 Noise prevention.................................................................................................................................... A-4
App.B Japanese Guideline for Suppressing Harmonics by Customers Receiving High Voltage
or Special High Voltage....................................................................................................................... A-12
B.1 Application to general-purpose inverters............................................................................................. A-12
B.2 Compliance to the harmonic suppression for customers receiving high voltage or
special high voltage........................................................................................................................................... A-13
App.C Effect on Insulation of General-purpose Motors Driven with 400 V Class Inverters.......................... A-17
C.1 Generating mechanism of surge voltages............................................................................................ A-17
C.2 Effect of surge voltages....................................................................................................................... A-18
C.3 Countermeasures against surge voltages ............................................................................................. A-18
C.4 Regarding existing equipment............................................................................................................. A-19
App.D Inverter Generating Loss..................................................................................................................... A-20
App.E Conversion from SI Units.................................................................................................................... A-21
App.F Allowable Current of Insulated Wires................................................................................................. A-23
App.G Replacement Information .................................................................................................................... A-25
G.1 External dimensions comparison tables............................................................................................... A-25
G.2 Terminal arrangements and symbols................................................................................................... A-28
G.3 Function codes..................................................................................................................................... A-31
Glossary
