Fulleon ASSERTA User manual

2. Fixing Details
25-12384-A
Knockout or drill required cable gland holes, and x required
1. Installation
Dimensions
Midi Sounder/Beacon (230VAC)
5. Sounder Assembly
4. Sounder Settings
ASSERTA
2
3
1
Turn dial clockwise to increase volume.
3. Voltage Select Switch
1. ToneSwitch
OPEN
12345
(Nominal 10dB range)
2. Volume Control
cableglands.
WARNING : Do not remove cover, refer servicing to personnel.
: High voltagepresent within thisequipment.
NOTE : Polar dispersion information available in the technical manual. (Ref:M03-003)
Ingress Protection
Termination
Current Consumption
Operating Temperature
Operation
Operating Voltage Range
Sound Output @ 1m
Construction
Tones
230Vac 50/60Hz
32 see table overleaf
See table overleaf
See table overleaf
-20°C to +70°C
ABS /PC FR plastic
cable
IP66
Continuous
230V AC
1. Plug the two 4 way terminal blocks into the 4 way headers on
the sounder PCB.
2. Plugthe2wayterminal block into thesounderheader on the
PCB.
3. Secure the sounder to the base using the bolts provided.
Operating Voltage Range
Ingress Protection
Termination
Construction
Operating Temperature
Current Consumption
Beacon
Sounder
3. Connection
Fuse
Fuse 32mA Antisurge, 20mm
Rating
30mA
315mA Antisurge, 20mm
ABS /PC FR plastic
-20°C to +70°C
cable
IP66
2.5 Joules
230Vac 50/60Hz
230V AC
NOTE: Ensure that the IP
integrity is maintained during
gland
Hole positions for additional cable entries.
Knock outs for cable entries.
(Top & Bottom)
Rear gland
knock out.
50mm
60mm
151mm
50mm
50mm
Fix base to wall using the two external lugs, or to a suitable
junction box using the positions indicated in the base.
Cut cable to ±130mm. (use the opposite side of the base as a
guide)
NOTE: If the internal holes are being used ensure that the
IP integrity is maintained.
Remove the terminal blocks from the sounder PCB for
cable wiring.
N
L in
Stage 2
N out
Sounder
LL
L in
Common
N in
N
S2
Stage
COM
NOTE: Stage 2 tone selection is achieved by connecting the
S2 to the common terminal.
DO NOT connect AC mainstotheseterminals.
NB: A readily accessible disconnect device must be
incorporated in the mains supply wiring to this unit.
Beacon
L in N out
L L
N
L in
N in
N
Ensure that the correct mains input voltage is selected.
See table overleaf.
0 = Open
1 = Closed
165 132
174
NOTE: 230VAC are seperate products

25-12384-A
