Furniture of America CM4230C User manual

EASY
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
Allen Wrench (Included)
Assembly Instructions
Tools Required for Assembly:
Rev.14-11-07
Page 1 of 5
DIFFICULT
ASSEMBLY RATING
2 PERSONS RECOMMENDED
CM4230C

Page 2 of 5

Parts List Hardware List
#1 x 2 pcs
Leg Stand
#2 x 1 pc
Center Stand Support
#3 x 2 pcs
Lower Stand Support
#A x 10 pcs
Flat Bolt 1/4”x5/8”
#B x 4 pcs
Bolt 1/4”x1-1/4”
Before you begin, please read Page 2
of “Assembly and Care Advice”.
And remember, do not tighten until
each step is completed or instructed.
#C x 2 pcs
Allen Screw
MD
#D x 4 pcs
Flat Washer
#4 x 1 pc
Table Frame
Page 3 of 5
Due to the size and/or weight of this product, it is highly recommended that the
assembly should be done near the area of its intended location. Make sure you have
enough space to move around during the assembly. ALWAYS have at least two people
to help with transporting and assembling the product to avoid any potential injury and/or
damage.
#F x 1 pc
Allen Wrench
#5 x 1 pc
Table Top
#G x 2 pcs
Knob
#E x 4 pcs
Leveler

Page 4 of 5
#E x 4 pcs
#A x 4 pcs
#C x 2 pcs
#G x 2 pcs
Turn right (clockwise) to tighten
Turn right (clockwise) to tighten
I. Align the center stand support (#2)
with the 2 leg stands (#1).
II. Insert 2 Allen screws (#C) through
the leg stands (#1) and secure
those screws (#C) using theAllen
wrench (#F) to lock them with the 2
leg stands (#1). Screw 2 knobs (#G)
onto the heads of the Allen screws
(#C) until secured.
III. Align the 2 lower stand supports
(#3) with the 2 leg stands (#1).
IV. Secure 4 flat-head bolts (#A)
through the lower stand supports
(#3) using the Allen wrench (#F) to
lock them with the 2 leg stands (#1).
Align the threaded ends of the 4 levelers (#E) with the pre-drilled
holes on the 2 leg stands (#1) and tighten by hand until secured.
Adjust the levelers according to the
ground level on Step 4.

Page 5 of 5
I. Align the assembled leg
stands (#1) with the pre-
drilled holes on the table
frame (#4).
II. Prepare 4 bolt assemblies
by inserting the flat washer
(#D) onto the bolt (#B).
III. Insert the bolt assemblies
through the assembled leg
stands (#1) and secure
those bolts using the Allen
wrench (#F) to lock them
with the table frame (#4).
I. With the help of another person,
carefully place the table top (#5)
facing down on a protected
surface. Align the brackets of the
assembled table frame (#4) with
the pre-drilled holes on the table
top (#5).
II. Insert 6 flat-head bolts (#A)
through the brackets of the
assembled table frame (#4) and
secure those bolts (#A) using the
Allen wrench (#F) to lock them
with the table top (#5).
III. Carefully place the table in the
upright position. Make sure the
table is rested on a flat surface
and does not feel loose or
wobbly. If it does, double check
that the bolts/screws are secured
and properly tightened.
IV. If necessary, adjust the levelers
(#E) according to the ground
level. To lower or to raise the
levelers (#E), turn the levelers
clockwise or counterclockwise,
respectively.
#B x 4 pcs
#D x 4 pcs
#A x 6 pcs
Turn right (clockwise) to tighten
Turn right (clockwise) to tighten
ASSEMBLY IS COMPLETED
