Furo Systems eTura User manual

eTura
Owner’s Manual

1
Your Package Contains
The Basics
1 2
Push the power
button to start The
battery
Press and hold the
power button to start
the bike
3
Select power assist
level
Six Tool SET
#2 Phillips screw driver
2/3/4/5/6 mm Allen Key
Bike Wrench
15 mm / 17 mm
Charger
36V Battery Pack with
USB Charging port and
integrated indicators
2x Battery keys 2x Pedals
Warning Before You Ride!
Always ensure all parts are securely fastened before your ride.All components
must be locked in place.Ensure that all folding levers are secure and that both
wheels are properly mounted on the bike,
Failure to do so may result in serious injury
EN

2
Getting Your Bike Ready For Your First Ride
Remove all the
packaging from your
new eTura
Locate and unfold the
steering stem
Straighten up and lock
the handlebar
Slide the battery
above the rear
wheel
Screw in the right pedal
on the right side
clockwise, and the left
counter-clockwise
Raise and adjust the seat
post
Adjust the height of
the steering stem
12
9
56
4
87
Identify the right and
left pedal marked on
the top
3
Unfold your eTura and
lockout the frame with
the central lever
EN

3
Familiarize Yourself With Your eTura
Get a Grip On The eTura Dashboard
Front Headlight
Rear Brake
Front Brake
Battery Life
Indicator Speedometer
On-Board Computer
Mode And Power Level
Select Button
Indicators
BAFANG
Front motor
Foldable Stem
Adjustable
Handlebar
6 Speed computer
Dashboard
Comfortable Saddle
Removable Lithium Ion
Battery
USB Charging Port
Indicator Lights
Key Lock
All-Terrain Tires
Central Folding
Mechanism
EN

4
Technical Table
Motor Front Hub Motor
Nominal/Peak Power 200W/400W
Pedal Assist Top Speed 25km/h (can be modified via computer to
comply with local regulations)
Range More than 45km at average pace
Charge Time 4.5hrs
Display Backlit LCD with controls
Computer TOPOLOGY SW102.5
Standard Battery Type Lithium-Ion Samsung Cells
Standard Battery Specs 36v 8.7Ah 313Wh
Readouts Distance travelled, current velocity (km/h
or mph), battery autonomy and mode
Pedal Assist 6 Levels
Frame Full carbon foldable in 3 steps
Fork Custom full carbon
Rear deraiilleur One Speed
Brakes Tektro Mini V-Brakes
Tires CST C1762 Black 14*1.75
Total Weight (Inc Battery and Accessories) 12kgs
Maximum Recommended Rider Weight 100kgs
Recommended Rider height 145cm -180cm/4'11 -6'
EN

5
Folding Your eTura
12
34
5 6 7
Identify the seat post and stem
quick release levers.
Shorten the seat post and
steering stem. (Optional)
Press down the red
security lock Pull the release
lever
Fold the stem Press the unlock button
and release the central
lock
Fold the eTura
EN

6
Using The Pre-Installed Indicator Lights
12
3
457
Switch on the indicators by pressing
the white button behind the battery
You can activate the indicators using
the remote on your dashboard
The indicator buttons will flash red when the indicators are activated.
You can hold both left and right buttons to activate the hazard lights
To recharge your indicators
you need to first slide the
indicators out of the battery
Charge the indicators using
any USB charging port with
the cable provided
If the indicator remote is
not working. You need to
replace the internal CR1620
battery by opening up the
remote.
EN

7
Charging Procedure
Open the rubber
charging port
cover
Insert the charging
lead
Plug the charger lead into
the mains
123
45
Charger light will turn red to
indicate charging
Charger light will turn green
when charging is complete
Approx.
4 Hours
The On-Board Computer Systems
What does your screen tell you?
Power Button
Down Button
Up Button
Mode Button
Battery Capacity
Odometer
Speedometer
Power Kevel
EN

8
Power On/Off
Hold down the POWER button and the display will switch on and light up (if the
battery has been switched on…). Hold down the POWER button again and the
display will switch off.
Walk assist mode
Press and hold the DOWN button for 2seconds
and your e-bike motor will start to run at a
uniform speed of 6Km/h.The display will show
“P” on the screen whilst in this “Walk Assist”
mode.
Using The On-Board Computer
Led Backlight
Press UP for 1second to turn on the backlight of the display.Hold UP again for 2
seconds and the light is turned off.
Power assistance selection
Use the UP and DOWN buttons to change the
assistance provided by the Motor.The power
ranges from level 1to level 5
Access the settings
1- Hold MODE button for 3 second to enter the Settings Menu.
2- Navigate through the settings by tapping the MODE button.
3- Use UP and DOWN to chooses settings and hold MODE for 3 seconds to confirm
List of settings
•Unit –switch between kilometers and miles
•Password –allows you to set a password to run the bike (do not forget it!)
•Wheel diameter –change the wheel diameter to calibrate odometer/speedometer
•Speed limit –changes the speed limit of the bicycle
•Other settings –Battery info -settings reset –data clearance
EN

9
Give Your eTura Love And Attention
Pre-Ride Checks
Maintain Pressure
2.4-3.1 bar / 35-45 psi
Lubricate chain
every 3 months
Ensure battery
is not drained when not in use
Check the brakes by making sure
the levers cannot be pulled all the
way
Ensure that the seat tube is not
over extended
Make sure the stem is securely
locked up
Check that the central folding
mechanism is locked out and that the
lever cannot be turned
12
34
EN

10
Safety Instructions
CAUTION!
Only use the provided battery charger.
Only charge the eTura indoors, in awell ventilated and dry location (i.e. keep
out of the rain and avoid extreme temperature fluctuations).
For ultimate charging, charge at temperatures between 0°C and 50°C.
Place charger on ahard surface and ensure it is not covered.Never place on
carpet or another textile surface.
Always keep the plug and charger connector free of dirt and moisture,
especially while charging.
Do not use the charger or charger plug when damaged.If in doubt about the
condition of your charger, please contact FuroSystems.
Never charge the battery in direct sunlight.Keep away from windows or open
doors.
When the eTura isn't used for along period, please make sure the battery is
either connected to the charger or the battery gets afull charge cycle every 6
months
Ensuring Battery Health
•Please charge at least every 6 months
•Never store the eTura for more than one month with a drained battery
The strength & stiffness of carbon fibre composite frames & components can be
adversely affected by high temperatures. Do not keep the bike in poorly
ventilated areas, where it is exposed to radiant heat sources.
EN

11
Warranty
Disclaimer
WARNING!
FuroSystems guarantees each new bicycle frame against defects in
workmanship and materials for two years.All original components are also
covered by warranty for aperiod of two years from the date of purchase.This
warranty is expressly limited to the replacement of adefective frame, or
defective parts and is the sole remedy of the warranty. This warranty applies
only to original owners and is not transferable.Claims under this warranty must
be made directly to the place at which you purchased the bike, and proof of
purchase is required.This warranty does not cover normal wear and tear,
improper assembly or follow-up maintenance, or installation of parts or
accessories.The warranty does not apply to damage or failure due to accident,
misuse, abuse, or neglect.Modification of the frame or components shall void
this warranty.
Under no circumstances, including, but not limited to negligence, shall
FuroSystems or FuroSystems distributor (seller) be liable for any special or
consequential damages that result from the inability to use the materials in this
manual, even if FuroSystems has been advised of the possibility of such
damages.Applicable law may not allow the limitation or exclusion of liability or
incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
As with all mechanical components, bicycles are subjected to wear and tear, as
well as high stresses.Different materials and components may fatigue in
different ways.If the design life of acomponent has been exceeded, it can
suddenly fail, possibly causing injuries to the rider.Any form of crack, scratches
or change of colouring can indicate that the life of the components has been
reached and should be replaced.
WARNING!
Cycling is an inherently dangerous activity.The likelihood of accidents is greatly
increased if your Quick Release Skewer (or any part) is incorrectly installed.
Incorrect installation or damage to the Quick Release Skewer could cause an
accident resulting in injury or death.
EN

12
WARNING!
Your bicycle must comply with your countries legal requirements when riding on
public roads and in all conditions, including bad weather, night time, dusk or
dawn. Many countries require specific safety devices.It is your responsibility to
familiarize yourself with the laws of the country where you ride and to comply
with all applicable laws including properly equipping yourself and your bike as
the law requires
WARNING!
Inspection and maintenance are important to the safety and longevity of your
bicycle.Regularly check brakes, tyres, steering and rims.Any part of apoorly
maintained bike can break or malfunction leading to an accident resulting in
serious injury or death.
WARNING!
Riding in the city is hazardous.Failure to wear ahelmet when riding may result
in serious injury or death.
WARNING!
Please note all the product specific demands for third party products you add to
the bike.Child and baggage carriers add weight and raise the centre of gravity
making balance and cornering more difficult.If you lose control, you and your
child passenger can be severely injured or killed.
WARNING!
Failure to confirm compatibility, properly install, operate and maintain any
component or accessory can result in serious injury or death.Do not modify
your bike frame or components in any way.Modifications can cause damage
leading to an accident that can result in severe injury or death.Incompatible
accessories or improper mounting of accessories can adversely affect the
performance of your bicycle and may be unsafe
EN

13
Copyright Notice
Trademarks
©Copyright FuroSystems LTD.All rights reserved.
This material provided by FuroSystems LTD is the property of FuroSystems LTD
and is protected by copyright, trademark and other intellectual property laws.
You may view this material and print this material only for personal use,
provided that you maintain all copyright, trademark and other proprietary rights
or notices.You may not otherwise use, reproduce, store, post, broadcast,
transmit, modify, sell or make available to others or the public, content from
this material without the prior written approval of FuroSystems LTD.
FuroSystems®is aregistered trademarks of FuroSystems LTD.
Standards and Conformity
The eTura is an electric power assisted cycle developed in accordance with:
•2006/42/EC The Machinery Directive
•2004/108/EC The Electromagnetic Compatibility Directive
and is in conformity with the applicable requirements of the following
documents:
•EN 15194:2009+A1Cycles -Electrically power assisted cycles -EPAC Bicycles
Contact Information
The eTura is aproduct of FuroSystems LTD aUK registered company,
Registered number:10411786
www.furosystems.com
[e-mail]
EN
