Furo Systems Fuze User manual

Fuze
Owner’s Manual
EN

1
Your Package Contains
Get to know your Fuze
Fully assembled electric scooter
Set of wireless keys
Charging Adapter
EN

2
Unfolding Your Scooter
Pull out the locking pin around the
folding joint
When the charger
indicates *green* unplug
the charger and close the
rubber flap
Plug the power adapter
into the charging port.
It takes approximately
4hours to fully charge
1
9
43
81
Locate the charging
port and remove the
rubber flap
2
Unfold the scooter until you hear a *click*
and make sure the pin is fully inserted
Straighten out the handlebars The handlebars will automatically
lock out when unfolded
Charging Your Scooter
EN

3
How to Ride
Wear helmets and knee pads at all
times in case of falls and injuries
12
Press and hold the power button to
turn on the scooter
Tap the mode button to toggle
between power levels
Lightly pull on the throttle to
engage the motor
Riding Safety Instructions
Ensure all parts are tightly fitted and secure before you ride
Ensure your speed is below 10kph/6mph when going on bumpy uneven surfaces
Do not accelerate when travelling downhill
Do not use the accelerator when walking along your scooter
Do not hand bags or heavy objects on the handlebar of your Fuze
Do not ride in puddles with water deeper than 2.5 cm/1inches
Do not ride with anyone else on the scooter including children
Do not put your feet on the rear mudguard
EN

4
Getting To Know The On-Board Computer
Speed Indicator
Front Brake
Battery Life
Indicator
Power Level
Speed unit
Throttle
Power Button
Mode Button
Trip Data
Indicator Display Mode
Main Mode Selection
Press and hold the Power button (2-3s) to switch on the Fuze Display.
Tap the Mode button to toggle between the 3levels of power( 1 – 2 – 3)
Tap the power button to cycle through the display modes.
Display Mode Description
TRIP Current Trip Mileage (Long press Mode button to
reset)
ODO Total Mileage
CHA (Unused)
VOL Current Voltage
DST (Unused)
TIME Time Elapsed
EN

5
Changing the settings
To access and change the settings:
Press and hold the Power button (2-3s) to switch on the Fuze Display.
Press both the Power and Mode button together to gain access to the settings.
Tap the power button to cycle through the different settings
Hold the Mode button (1-2s) to select the settings to change
Tap the Mode button to change the settings, and hold mode button to confirm
Hold Mode and Power button together to save and exit the settings page.
Settings Description
P02 Units (miles / km)
P03 Voltage level (48 v)
P04 Automatic shutdown time after inactivity (mins)
P06 Wheel diameter in Inches (10.0 )
P07 Hall sensor number (30)
P09 Zero start (0)
P15 Speed Limit (in chosen units, mph/kph)
P16 ODO settings (0)
EN
Power Button
Mode Button

6
Using The Fuze Anti-Theft System
•Your Fuze comes with an anti-theft
function.
•When the Scooter is turned off,
simply press the lock button and the
anti-theft function will be activated.
•The scooter will sound an alarm
when it vibrates or moves you can
turn off the anti-theft function and
turn off the alarm by pressing the
unlock button.
•The Power Button is not used
If your Fuze is locked,you will be unable to turn it on and will need to press
the unlock button in order you to be able to power it up.
•Vehicle search function:Your Fuze comes with avehicle search function.
When your scoter is turned off, simply press the bell button and it will
start sounding an alarm so you can locate your scooter.This alarm will turn
off on its own within 5s.
•Using your Fuze without your key:You can use your Fuze without your key
by keeping the scooter unlocked.In this mode, the alarm will not activate
and the scooter will not lock and therefore you can switch it back on
without unlocking it.
Additional Key Features
Headlights And Horn
Headlight Button
Horn Button
•Your Fuze is equipped with a Headlight and a
Horn which can easily be activated from the
Dashboard
EN

7
Daily care and Maintenance
Safety Reminder
This electric scooter is aleisure device.But once they're in apublic area, they'll
be seen as vehicles, subjecting to any risks faced by vehicles.For your safety,
please follow instructions in the manual.
Make sure you follow and are aware of traffic laws, regulations or restrictions set
forth by you local government and regulatory agencies.
Others may also pose arisk to your safety by careless or inappropriate driving.
You are exposed to road accidents just as when you are walking or cycling.
The faster you ride the longer your braking time.On smooth surfaces the scooter
may slip, lose balance and may result in afall.Always maintain a safe distance
between others and obstacles.
Respect pedestrians’ Right of Way, try not to startle them and use caution when
approaching them from behind.
Please follow the safety instructions in the manual and any rules or regulation in
your jurisdiction.FuroSystems LTD shall not be liable for any financial losses,
physical injuries, accidents, legal disputes and other conflicts that arise from
actions that violate user instructions.
Do not lend your scooter to anyone who does not know how to use it safely,
please take the time and responsibility to ensure he/she knows how to operate
the vehicle and wears the safety gear.
Check the scooter before every use.When you note loosen parts, low battery
alerts, flat tires, excessive wear, strange sounds, malfunctions and other
abnormal conditions, stop riding immediately.
Use adamp cloth to clean and remove stains from your scooter.If needed, an
abrasive material such as sandpaper can be used to lightly polish the scooter.Do
not use alcohol, kerosene or any other corrosive material to clean your scooter.
When the scooter is not in use keep it indoors in adry and cool environment.
Use original battery packs, use of other brands may result in damage or fire.
Do not touch the battery contacts, do not dismantle or puncture, ensure
contacts are far away from metal objects to avoid ashort-circuit.
Store the battery at about 40%/60%charge, ensure the battery is not left in an
environment above or below -20°C/50°C (e.g. in acar in direct sunlight)
EN

8
Technical Table
Item Specification
Motor Nominal/Peak Power 500W/800W
Top Speed
Locked:25km/h ; Unlocked:40km/h
(can be modified via computer to comply
with local regulations)
Range More than 40km at high pace
Charge Time 4.5hrs
Rider Weight Limit 150kg
Dimensions ( LxHxW )Unfolded : 115x116x41.5 cm
Folded : 115x41.5x23.5 cm
Battery Type Integrated 48V Lithium-ion
Battery Pack Specifications Max input voltage: 54.6v
Internal Battery Management System
Item Weight 17.6 kgs
Max Climbing Angle Approx. 14%
Readouts Distance traveled, current velocity (km/h or
mph), battery autonomy and mode
Riding Modes Eco, Cruise and Sport
Suitable Riding Surfaces Cement, asphalt and dirt roads
Suspension Double, Front and Rear Mechanical (Spring)
Brakes Electronic Regenerative Braking &
Mechanical Disk brakes
Lighting Integrated LED headlight, Rear Brake Light
Tires 10" Pneumatic Tires
EN

9
Warranty
Disclaimer
WARNING!
FuroSystems guarantees each new scooter frame against defects in
workmanship and materials for two years.All original components are also
covered by warranty for aperiod of two years from the date of purchase.This
warranty is expressly limited to the replacement of adefective frame, or
defective parts and is the sole remedy of the warranty. This warranty applies
only to original owners and is not transferable.Claims under this warranty must
be made directly to the place at which you purchased the scooter, and proof of
purchase is required.This warranty does not cover normal wear and tear,
improper assembly or follow-up maintenance, or installation of parts or
accessories.The warranty does not apply to damage or failure due to accident,
misuse, abuse, or neglect.Modification of the frame or components shall void
this warranty.
Under no circumstances, including, but not limited to negligence, shall
FuroSystems or FuroSystems distributor (seller) be liable for any special or
consequential damages that result from the inability to use the materials in this
manual, even if FuroSystems has been advised of the possibility of such
damages.Applicable law may not allow the limitation or exclusion of liability or
incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
As with all mechanical components, kick scooters are subjected to wear and
tear, as well as high stresses.Different materials and components may fatigue in
different ways.If the design life of acomponent has been exceeded, it can
suddenly fail, possibly causing injuries to the rider.Any form of crack, scratches
or change of colouring can indicate that the life of the components has been
reached and should be replaced.
WARNING!
Your scooter must comply with your countries legal requirements when riding
on public roads and in all conditions, including bad weather, night time, dusk or
dawn. Many countries require specific safety devices.It is your responsibility to
familiarize yourself with the laws of the country where you ride and to comply
with all applicable laws including properly equipping yourself and your scooter
as the law requires.
EN

10
Copyright Notice
Trademarks
©Copyright FuroSystems LTD.All rights reserved.
This material provided by FuroSystems LTD is the property of FuroSystems LTD
and is protected by copyright, trademark and other intellectual property laws.
You may view this material and print this material only for personal use,
provided that you maintain all copyright, trademark and other proprietary rights
or notices.You may not otherwise use, reproduce, store, post, broadcast,
transmit, modify, sell or make available to others or the public, content from
this material without the prior written approval of FuroSystems LTD.
FuroSystems®is aregistered trademarks of FuroSystems LTD.
Standards and Conformity
The Fuze is an electric kick scooter developed in accordance with:
•2006/42/EC The Machinery Directive
•2004/108/EC The Electromagnetic Compatibility Directive
•EN 55014-1: 2006+A1: 2009+A2: 2011,EN 55014-2: 1997+A1: 2001+A2: 2008
•EN 61000-3-2: 2014,EN 61000-3-3: 2013
Contact Information
The Fuze is aproduct of FuroSystems LTD aUK registered company,
Registered number:10411786
www.furosystems.com
[e-mail]
