Garland INT10G12 V2 Series User manual

User Guide
RegenTAP: Dual Breakout | INT10G12XXV2 | 4.22.1
This document describes the front panel, LED indications, interfaces, rear panel, supported media types
and installation procedure for the INT10G12XXV2. The unit supports two taps in a single chassis. LFP
and Fail Mode (open) are supported on the network ports of both taps.
Front Panel
LED Indications
PS2 Power Supply 2 LED
PS1 Power Supply 1 LED
SYS System LED
Port 1 L/A1 Link/Activity LED
Port 2 L/A2 Link/Activity LED
BP N/A
Up Arrows SFP Ports 3-11 Link/Activity LEDs
Down Arrows SFP Ports 2-12 Link/Activity LEDs
Interfaces
Tap 1
Port 1 Network Port
Port 2 Network Port
Port 3 Monitor Port Ingress Port 1
Port 4 Monitor Port Ingress Port 1
Port 5 Monitor Port Ingress Port 2
Port 6 Monitor Port Ingress Port 2
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 1

User Guide
RegenTAP: Dual Breakout | INT10G12XXV2 | 4.22.1
Tap 2
Port 7 Network Port
Port 8 Network Port
Port 9 Monitor Port Ingress Port 7
Port 10 Monitor Port Ingress Port 7
Port 11 Monitor Port Ingress Port 8
Port 12 Monitor Port Ingress Port 8
Rear Panel
PS 1 Fan 1 Fan 2 PS 2
Media Types
Tap 1/Tap 2 Speed
Copper
SM Fiber
MM Fiber
1G
SFP+T
N/A
N/A
1G
N/A
SFPSX 1G
SFPLX 1G
10G
SFP+T
SFP+SR10G
SFP+LR10G
* The SFP+T will support 1G and 10G copper applications. The port speed in the INT10G12XXV2 is
determined by the speed or advertised speed of the device connected to a particular port.
* 1G copper and 1G fiber SFPs cannot be used together.
* The INT10G12XXV2 supports 2 taps. Port 3 and port 9 are monitor ports for tap 1 and tap 2.
They also have a second functionality of determining the port speeds for tap 1 and tap 2.
Therefore, SFPs must be inserted into port 3 for tap 1 and port 9 for tap 2 before power is
applied to the unit.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 2

User Guide
RegenTAP: Dual Breakout | INT10G12XXV2 | 4.22.1
Tap 1 Tap 2
Port 1 Network Port Port 7 Network Port
Port 2 Network Port Port 8 Network Port
Port 3 Speed Control and Monitor Port Port 9 Speed Control and Monitor Port
Port 4 Monitor Port Port 10 Monitor Port
Port 5 Monitor Port Port 11 Monitor Port
Port 6 Monitor Port Port 12 Monitor Port
Installation Procedure
1. Insert the SFPs into the INT10G12XXV2 based on the speed and application per the Media Types
table. Verify the correct SFPs are inserted into port 3 for tap 1 and port 9 for tap 2.
2. Connect power cables to PS1 and PS2 on the rear panel and plug into available power sources.
3. Verify that the PS1 LED and PS2 LED on the front panel are illuminated.
4. Verify that the SYS LED on the front panel is illuminated.
5. Connect the network ports of tap 1 and/or tap 2 to the desired sources.
6. Verify the link LEDs are illuminated indicating link.
7. Verify the activity LEDs are flashing indicating traffic.
8. Connect the monitor ports of tap 1 and/or tap 2 to the desired source.
9. Verify the link LEDs are illuminated indicating link.
10. Verify the activity LEDs are flashing indicating traffic.
