Introduction
PacketMAXTM: Advanced Aggregators are part of Garland Technology’s purpose-built network packet
broker line. These traffic aggregators are designed for high-density filtering, aggregation, replication, and
load balancing to optimize port utilization of existing infrastructure, or as a stand-alone device in L2-L4
filtering applications.
1/2 Rack 1U Chassis Specifications
Max. system throughput:
Support for: SFP( SX, LX and TX) and SFP+ (SR, LR, ER)
Operating Temp: 0 to 40° C or 32 to 104° F
Operating Humidity: 5 to 95%
Dimensions: 17.5” L x 1.72” H x 8.25” W (444.5mm L x 43.68 mm H x 209.55mm W)
Airflow: 50 IF/m
Fixed AC Power (2)
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 4

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
1 Dashboard
The Dashboard of the GAA10G10AC is divided into 2 sections.
System
Packet Broker
1.1 System
The System section of the Dashboard consists of the following.
PS2 Power Supply 2 LED
PS1 Power Supply 1 LED
SYS System LED
Ethernet Interface Upper Left LED
Serial Interface Lower Right LED
1.2 Packet Broker
The Packet Broker Section of the Dashboard consists of the following.
Port 3 thru 11 (odd) Up Arrows Link/Activity LED
Port 4 thru 12 (even) Down Arrows Link/Activity LED
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 5

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
2 System
The following configuration options may be displayed, modified, enabled or disabled under the System
panel.
System Info SNMP
General Export Configuration
Admin Import Configuration
Network Settings Software Upgrade
Date & Time Reboot
Syslog
1. Select System on the Dashboard Menu bar.
The System panel will be displayed. The System configuration options will be displayed on the
left side of the System panel.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 6

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
2.1 System Info
The System Information is displayed by default. The System Information panel displays the following.
Chassis Name
Chassis Model
Chassis Serial Number
MAC Address
Software Version
2.2 General
The following configuration options may be displayed or modified.
Chassis Name
Key Press Timeout
1. Select General.
The panel will display the current configuration.
2. Select Edit Configuration.
3. Enable, disable or modify the desired options.
4. Select Save to save updates.
5. Select Cancel to return to the General System Settings panel.
2.3 Admin
The following configuration options may be displayed, modified, enabled or disabled.
Groups
Users
Local Authentication
TACACS Authentication
1. Select Admin.
The panel will display the current configuration.
The default user is “admin/gtadmin1”. The “admin” user privileges are defined by the default group
“admin”. Changes to the default user “admin” and group “admin” are allowed. However, the “admin”
user or group “admin” may not be deleted.
2.3.1 Groups
The group defines the authorization for a user or group of users. A group may be used for local
or TACACS authorization. In Use “true” means that there is at least one local user assigned to
the group. If a group is used by TACACS, the In Use will indicate “false”.
1. Select Groups + to create a new group.
The Create New Group panel will be displayed.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 7

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
2. Enter the Group Name.
3. Select the privileges for the new group.
4. Select Save to save updates.
5. Select Cancel to return to the Admin Settings panel.
The new group will be displayed on the Admin Settings panel.
6. Edit the group privileges by selecting the pencil.
7. Deleted the group by selecting the Red X. If a group has at least one local user assigned it cannot
be deleted.
2.3.2 Users
Users displayed on the Admin Settings panel are for local authentication only.
1. Select Users + to create a new user.
The Create New User panel will be displayed.
2. Enter the Username.
3. Enter the Password.
4. Select the group the user will be assigned.
5. Select Save to save updates.
6. Select Cancel to return to the Admin Settings panel.
The new local user will be displayed on the Admin Settings panel.
7. Edit the username, password, or assigned group by selecting the pencil.
8. Delete the local user by selecting the Red X.
2.3.3 Authentication
Authentication allows for two options, Local or TACACS. Local or TACACS Authentication may be
enabled or disabled independently and at least one option must be enabled.
1. Select Authentication Settings.
The Authentication Settings panel will be displayed. Local Authentication is enabled by default.
2. Select TACACS Authentication to enable.
3. Enter the TACACS Server IP Address.
4. Enter the TACACS Server Secret Word, optional.
5. Select Save to save updates.
6. Select Cancel to return the Admin Settings panel.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 8

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
7. TACACS Test
This option may be used to verify the authentication of a TACACS user and password. The
TACACS Test option will be active only if TACACS Authentication has been enabled.
The TACACS Test panel will appear.
7.1 Enter the Username.
7.2 Enter the Password.
7.3 Select Test.
The GUI will display the results of the authentication of the user and the password entered.
8. TACACS Ping
This option may be used to verify the network connectivity from the unit to the TACACS server.
The TACACS Ping option will be active only if TACACS authentication has been enabled.
The GUI will display the results of the ping test.
2.4 Network Settings
The following configuration options may be displayed, modified, enabled, or disabled. Any change made
to any network setting option could cause network connectivity disruption for about 60 seconds.
DHCP
IP Address
Mask
Gateway
DNS 1
DNS 2
SSL Certificate Loaded
Using Uploaded SSL Certificate
1. Select Network Settings.
The Network Settings panel will be displayed with the current configuration.
2. Select Edit Settings.
The Network Settings panel will appear.
3. Enable, disable or modify the desired options.
4. Enable or disable Using Uploaded SSL Certificate.
This option may be enabled if a SSL cert.pem file and key.pem file have been uploaded
to the unit using the Add SSL Certificate option on the Network Settings panel.
5. Select Save to save updates.
6. Select Cancel to return the Network Settings panel.
7. Add SSL Certificate.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 9

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
Uploading a custom SSL certificate involves two files. The cert.pem file and key.pem file.
The unit will consider these files during the upload. If the files do not match or one of the
files is corrupted the unit will abort the upload. The Result Messages will be displayed
in the GUI. Adding an SSL certificate will cause the GUI to restart. This could take up to
90 seconds. It may be required to refresh or restart the web browser.
8. Select Add SSL Certificate.
The Select Certificate and Select Key File panel will appear.
9. Select Choose File for Select Certificate.
10. Select the desired cert.pem file.
11. Select Open.
12. Select the Choose File for Select Key File.
13. Select the desired key.pem file.
14. Select Open.
15. Select Upload.
16. Select Restart Import to select a different cert.pem or key.pem file.
17. Select Cancel to return to the Network Settings panel.
2.5 Date & Time
The following configuration options may be displayed, modified, enabled or disabled.
Timezone Time
UTC Date
NTP IP Address
NTP Pool
1. Select Date & Time.
The Date & Time Settings panel will be displayed with the current configuration.
2. Select Edit Settings.
The Date & Time Settings panel will be displayed.
3. Enable, disable or modify the desired options.
4. Select Save to save updates.
5. Select Cancel to return the Date & Time Settings panel.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 10

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
2.6 Syslog
The following configuration options may be displayed, modified, enabled or disabled.
Unit ID Syslog Server IP Address
Protocol Protocol Port Number
1. Select Syslog.
The Syslog Configuration panel will be displayed with the current configuration.
2. Select Edit Settings.
3. Enable Syslog Config.
4. Enable, disable or modify the desired options.
5. Select Save to save updates.
6. Select Cancel to return the Syslog Configuration panel.
7. Sys Log Test may be selected to send a test message to the server.
2.7 SNMP
The following configuration options may be displayed, modified, enabled or disabled.
V2 Read/Write V2 read Only V3 MD5/DES V3 SHA/AES
Access Port Access Port Access Port Access Port
Trap Port Trap Port Trap Port Trap Port
Trap IP AddressTrap IP AddressTrap IP AddressTrap IP Address
Community Password Community Password User User
Auth Password Auth Password
Priv Password Priv Password
1. Select SNMP.
The SNMP Configuration panel will be displayed with the current configuration.
2. Select Edit Configuration.
The SNMP Configuration panel will be displayed.
3. Select Enable SNMP Config.
4. Enable, disable or modify the desired options.
5. Select Save to save updates.
6. Select Cancel to return the Syslog Configuration panel.
7. SNMP Test may be selected to send a test trap to the server.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 11

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
2.8 Export Configuration
This option creates a configuration file (exportCfg.json) that may be used to recover a unit. The
exportCfg.json file may be renamed if desired. The exportCfg.json file does not contain Usernames,
Passwords, Groups, or Network Settings.
1. Select Export Configuration.
The Export Configuration panel will be displayed.
2. Select Export.
The exportCfg.json file will be downloaded to the default download destination of the browser.
2.9 Import Configuration
This option allows a previously created configuration file (exportCfg.json) to be uploaded to the unit. The
Chassis Model is the only option that is considered and must match, otherwise, the unit will reject the
exportCfg.json file.
1. Select Import Configuration.
The Import Configuration panel will be displayed.
2. Select Choose File.
3. Select the desired exportCfg.json file.
4. Select Open.
5. Select Upload.
The unit will automatically verify the selected exportCfg.json file.
6. Select Configure.
The unit will import and load the exportCfg.json. An “import done” message will be displayed
when complete. A reboot is not required.
2.10 Software Upgrade
This option allows the unit’s firmware to be upgraded. The existing unit configuration will not be affected
and maintained during the upgrade. It may be required to refresh or restart the web browser after the
firmware upgrade is complete.
1. Select Software Upgrade.
The Update Firmware panel will be displayed.
2. Select Choose File.
3. Select the desired firmware file.
4. Select Open.
The new firmware file will be displayed.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 12

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
5. Select Upload.
The unit will validate the firmware file.
The unit will install the firmware file.
The unit will reboot.
6. After the upgrade is complete. The GUI will refresh to the Login panel.
2.11 Reboot
This option allows the unit to be rebooted. The traffic will be affected for up to 3 minutes.
1. Select Reboot.
The Reboot Device panel will be displayed.
2. Select Reboot.
The unit will present an “Are you sure?” message.
3. Select OK.
A “rebooting” message will be displayed.
A “Session timed out. Go to Login screen” message will be displayed.
4. Select Go.
The Login panel will be displayed.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 13

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
3 Packet Broker
The following configuration options may be displayed, modified, enabled or disabled under the
Packet Broker panel.
Configuration Maps Load Balance Policy
Filter Templates Load Balance Groups
1. Select Packet Broker on the Dashboard menu bar.
The Packet Broker Configurations panel will be displayed.
3.1 Filter Template
Filter templates may be created as a pass all, pass by or deny by. Pass by and deny by templates
may include multiple matching options to filter traffic. The options are considered by the system as (and)
options. Thus, for traffic to pass or be denied it must match all defined options. Once a template is
created it will appear on the Create Config Map panel and may be used to create an ingress or egress
filter. Template options may be modified when applied to a config map. Any option modification made will
not change the original template. It is advisable to rename a filter applied to a config map if the original
template options were modified.
1. Select Filter Templates on the Packet Broker Configurations panel.
The Filter Templates panel will be displayed.
2. Select Create Template.
The Create New Filter Template panel will be displayed.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 14

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
3. Enter the template name. If no name is entered the system will automatically apply a name as follows,
tmplt, tmplt(2), tmplt(3), etc.
4. Enter the description, optional.
5. Select the Template Type, Pass All, Pass By or Deny By.
6. If pass by or deny by was selected in Step 5, the options will be displayed as follows.
Source MAC Address / Source MAC Mask
Destination MAC Address / Destination MAC Mask
Ether Type
Source IP Address / Source IP Mask
Destination IP Address / Destination IP Mask
Inner VLAN ID
Outer VLAN ID
DSCP
IP Protocol
L4 Source Port or Range
L4 Destination Port or Range
7. Select Save Template once all desired option modifications have been completed.
8. The new filter template will appear on the Filter Templates panel.
9. The filter template may be modified by selecting the template name.
10. The filter template may be deleted by selecting the red X.
3.2 Load Balancing Policy
The load balancing policy determines the hashing applied to all load balancing groups, taps in the load
balance mode and the ATLB2 Chained mode. The load balancing policy options are as follows and may
be applied as L3 and/or L4 or L2.
Ipv4 Source MAC Source
Ipv4 Destination MAC Destination
L4 Source Port
L4 Destination Port
1. Select Load Balancing Policy on the Packet Broker Configurations panel.
The Load Balancing Policy panel will be displayed.
2. Select the desired load balancing policy options.
3. Select Save to save updates.
4. Select Cancel to disregard changes.
3.2.1 Load Balancing Group
Load balancing groups are used as an egress option on config maps. The traffic applied to the ports
assigned to a load balancing group will follow the hashing per the load balancing policy. Ports may be
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 15

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
added or removed from load balancing groups as desired. However, if ports are added or removed from
a load balancing group that is used in a config map, the config map load balancing group will be also
modified, the reverse is also applied. Previously created load balancing groups will appear on the Create
Config Map panel.
1. Select Load Balancing Groups on the Packet Broker Configurations panel.
The Load Balancing Groups panel will be displayed.
2. Select Create Group.
The Create New Load Balance Group panel will be displayed.
3. Enter the name. If no name is entered the system will automatically apply a name as follows,
lbg, lbg(2), lbg(3), etc.
4. Enter the description, optional.
5. Add ports by placing the cursor on the desired port. Select with the left mouse button. Drag the port to
the New L.B. Group panel and release. Repeat for all desired ports. Ports may be added in any
combination.
6. Remove a port by placing the cursor on the port in the New L.B. Group panel and double press the left
mouse button.
7. Select Save to save updates.
8. Select Cancel to return to the Load Balancing Groups panel.
The load balancing group will be displayed on the Load Balancing Groups panel. The assigned
ports will also be displayed.
9. Edit the load balancing group by selecting the Edit for the desired group.
10. Deleted the load balancing group by selecting the red X. Load balancing groups may not be
deleted if used on a config map.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 16

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
3.3 Config Map
Config maps are unidirectional connections between ingress port(s) to egress port(s) and/or a load
balancing group.
1. Select Create Config Map on the Packet Broker Configurations panel.
The Create Config Map panel will be displayed. Any previously created load balancing groups
or filter templates will be displayed along with the new options. Any port shaded gray can be
used for a config map, any port shaded black may not be used.
2. Select the Name pencil icon to apply a name, optional. If no name is entered the system will
automatically apply a name to the config maps as follows, map, map(1), map(2) etc.
3. Place the cursor in the Name panel and enter the name.
4. Select the Check to apply.
5. Select the Description pencil to apply a description, optional.
6. Place the cursor in the Description panel and enter the description, optional.
7. Select the Check to apply updates.
3.3.1 Ingress
1. Add an ingress port by placing the cursor on the desired port. Select with the left mouse button. Drag
the port to the Ingress panel and release. Ports may be added in any combination. If multiple ports are
added, then the traffic from all ingress ports will be aggregated.
Figure 1 Ingress
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 17

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
2. Remove a port by selecting the red X.
3.3.2 Filters
1. Add filters by placing the cursor on the desired filter template. A previously created filter
template or the new filter template option may be selected. Select with the left mouse button. Drag the
filter template to the Filter panel and release. The filter template will become an actual filter once
the config map is saved.
Filters may be added in any combination. If multiple filters are added, then the top filter is the
highest priority. The filters are considered from top to bottom. A filter may be selected
and moved up or down depending on priority preference.
Figure 2 Filter
Figure 3 Filter System Considerations
2. Filter templates may be modified by selecting the green filter icon for the desired template.
The Edit Filter panel will be displayed.
Any option modification made will not change the original template. It is advisable to rename a
filter if the original filter template options were modified.
3. Enter the filter name, optional. If no name is entered the system will automatically apply a name to the
filter as follows, iFlt, iFlt(2), iFlt(3) etc.
4. Select Accept once all desired options have been modified.
5. Remove a Filter Template by selecting the red X.
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 18

Aggregator
PacketMAX™ Advanced Aggregator | GAA10G10AC | 1.19.2
3.3.3 Egress
1. Add an egress port by placing the cursor on the desired port. Select with the left mouse button. Drag
the port to the Egress panel and release. Repeat for all desired ports. If multiple ports are added, then
100% of the traffic will be sent to each port.
Figure 4 Egress Port(s)
2. Add a load balancing group by placing the cursor on a previously created load balancing group or new
load balancing group. Select with the left mouse button. Drag the load balancing group to the Egress
panel and release. Ports may be added or removed from any load balancing group. If ports are added
or removed from a previously created load balancing group, the origional load balancing group will
also be modified.
Figure 5 Egress Load Balancing Group
3. One load balancing group plus separate port(s) may be applied. The traffic applied to the ports
assigned to the load balancing group will follow the hashing per the load balancing policy. 100% of
the traffic will be sent to each of the separate port(s).
Figure 6 Egress Load Balancing Group and Port(s)
Garland Technology | 716.242.8500 | garlandtechnology.com/support
Copyright © 2022 Garland Technology, LLC. All rights reserved. 19
