Garmin GPSMAP 4010 Operating manual

Printing agPSMaP®4000/5000 SerieS FluSh Mount teMPlate in adobe acrobat
Notes:
(A) Youmustprintthetemplateon11˝x17˝paper.Thisisnormallyselectedinthe‘PrinterProperties’,andwilldifferbymanufacturer.
• Ifyourprinterisnotcapableofprintingon11˝x17˝paper,oryoudonothave11˝x17˝paper,youmustprintthistemplateatanoffice
servicesstoreorsimilarlocationthathastheabilitytoprinton11˝x17˝paper.
(B) Youmustsetthe‘PageScaling’settingto‘None’.
(C)Select‘Auto-RotateandCenter’tomakesurethetemplateprintsinthecorrectorientation.
Important Information:
• Beforecuttingthemountingsurface,measuretheprintouttomakesureitprintedatthecorrectsize.Boththelengthandwidth
measurementsarenotedonthetemplate.Verify both the length and width measurements before cutting.
• WhencuttingtheFlushMounttemplate,cutinside the line,thensandand/orlethemountingsurfacetoensureagoodt.
A
B
C
Adobe Acrobat Print Dialog Box
Printing a Flush Mount Template.1 1 3/23/2007 4:58:23 PM

GPSMAP®4010/4210
FLUSH MOUNT TEMPLATE
Unit dimensions: 13 3/8in. (340.4 mm) W ×8 15/16 in. (226.9 mm) H
Dimensions de l’appareil : 340,4 mm ×226,9 mm (l x H)
Dimensioni unità: L 340,4 mm ×A 226,9 mm
Geräteabmessungen: Breite 340,4 mm ×Höhe 226,9 mm
Dimensiones de la unidad: 340,4 mm ancho ×226,9 mm alto
Enhetsmått: 340,4 mm B ×226,9 mm H
Enhedens mål: 340,4 mm B ×226,9 mm H
Mål på enheten: 340,4 mm B ×226,9 mm H
3
/
8
in. (9.5 mm)
Recommended clearance for SD card door
Débattement recommandé pour le cache de la carte SD
Spazio libero consigliato per lo sportello della scheda SD
Empfohlener Abstand für SD-Speicherkartenabdeckung
Se recomienda despejar la puerta de la tarjeta SD
Rekommenderat utrymme för SD-kortlucka
Anbefalet fri plads til SD-kortlåg
Anbefalt klaring for SD-kortdekselet
121/4in. (312 mm)
85/16 in. (211 mm)
March 2009 190-00779-05 Rev. C Printed in Taiwan
1/2 in.
13 mm
1/2in.
13 mm
Recommended clearance for sun cover handle
Espace de sécurité recommandé pour manipuler le pare-soleil
Spazio libero consigliato per la maniglia della copertura di
protezione dai raggi solari
Empfohlener Abstand für Griff des Sonnenschutzes
Se recomienda despejar el mango de la cubierta para el sol
Rekommenderat utrymme för solskyddshandtag
Anbefalet plads til soldækslets håndtag
Anbefalt klaring for håndtaket på soldekselet
1
/
8
in. (3.175 mm)
