Gastroback Design Mixer Advanced Electronic User manual

Instructions for use
Design Mixer Advanced Electronic
GASTROBACK®
Art.-Nr. 41001 Read all provided instructions before first usage!
Model and attachments are subject to change
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 1

Important Instructions
•WARNING: To avoid injury to persons and damage, always turn the appliance ´Off`, wait for
the motor to stop completely and unplug the appliance, immediately after operation and
before assembling/disassembling or cleaning the appliance. Never use force operating, assembling or
disassembling the appliance.
•WARNING: The blades are very sharp. Pay attention when handling the units. Only touch the
blade assembly housing when handling the blades. Handle with care when cleaning.
•NOTE: Ensure the appliance is properly assembled and the blade is properly attached before
connecting the plug into the power outlet. Never turn the appliance on without the lid or refill lid. Never
turn the appliance on without the blender jug properly placed on the motorblock. Never place
only the holder or the blade only on the motorblock. Never touch the drive gear when the plug is
connected to the power outlet.
•WARNING: If the blade is mounted in the blender jug, the blender jug is positioned on the motorblock,
and the plug is connected to the power outlet, do not insert your fingers, a wooden or plastic spoon or
similar cooking utensils or foreign substances in the blender jug. Always take the blender jug off the
motorblock before pushing the food down with a spoon.
•WARNING: Never combine the blender jug and the holder without the blade. Without the blade the
bottom of the blender jug is open. Liquids could spill and might damage the motorblock.
• Without the blender jug, the unit does not work.
•IMPORTANT: Ensure the blender jug is locked securely onto the motorblock and that
you can not knock the appliance over during operation. The motor will not start and the
screen will turn on before the plug is plugged into the power outlet, the blender jug is
securely locked onto the motorblock and the appliance is switched ´On`.
• As a safety feature, the unit automatically shuts off after operating for 2 minutes. If you want to operate
again, wait 1 minute and then continue.
•WARNING: Do not overfill the blender jug. If necessary, take some food out of the blender jug,
using a wooden or plastic spoon, before starting the appliance again.
•Do not chop extremely hard food, such as nuts with shell or bones to avoid overrunning, spurt out
or that the motor stalls or stucks during operation because the blade is blocked.
•WARNING: Do not operate the appliance when the blender jug has a crack or any part of it
is likely to be damaged. The appliance is likely to be damaged if the appliance was subject to inadmissible
strain (i.e. overheating, mechanical, or electric shock) or if there are any cracks, excessively frayed
parts, distortions or the motor stalls or stucks. In this case, immediately unplug the appliance and
return the entire appliance (including all parts and accessories) to an authorised service centre for
examination and repair.
•WARNING: Do not fill ingredients into the blender jug which exceed a temperature of 60 degrees.
After processing ice cubes slowly heat up the blender jug before processing hot ingredients.
Otherwise the blender jug will crack or get damaged. Use gloves processing hot liquids and do not
fill the blender jug up too high. Ensure not to burn yourself on the blender jug, overrunning, spurt
out or hot steam.
• Never place anything other than food and liquids in the blender whilst the motor is running.
• WARNING: Do not place blender in the freezer with food or liquids. This will freeze and damage
the blade assembly housing, blender jug and motor.
•CAUTION: DO NOT place the appliance in an automatic dishwasher.
•ATTENTION: The circular plastic surround attached to the base of the blender jug in NOT
removable! Same with the plastic surround attached to the blades.
• The appliance is for household only.
2
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 2

Important Safeguards
Save the instructions for further reference. Do not attempt to use this appliance for
any other than the intended use, described in these instructions. Any other use, especially
misuse, can cause severe injury or damage by electric shock, fire or moving mechanical
parts. These instruction is an essential part of the appliance. When passing on the
appliance to a third person, ensure to include these instructions.
Never leave the appliance unattended when in operational mode.
Any operation, repair and technical maintenance of the appliance or any part of it
other than described in these instructions may only be performed at an authorised
service centre. Please contact your vendor.
Safeguards for Daily Operation
• The appliance is designed for normal household quantities. Do not operate or
store the appliance outdoors or in damp or wet areas.
•Do not attempt to operate the appliance using any parts or accessories
not recommended by the manufacturer (i.e. blade, sealing ring). Do not operate
the appliance, when the appliance or any part of it is likely to be damaged, to avoid
risk of fire, electric shock or any other damage or injury to persons. Do not attempt
to open the motor housing or to repair the power cord. Check the entire appliance regularly
for proper operation. The appliance is likely to be damaged if the appliance was subject to
inadmissible strain (i.e. overheating, mechanical, or electric shock) or if there are any
cracks, excessively frayed parts, distortions or the motor stalls or stucks. In this case,
immediately unplug the appliance and return the entire appliance (including all parts
and accessories) to an authorised service centre for examination and repair.
•Do not lift, pull or carry the appliance by the power cord. To move or operate
the appliance, always grasp the motorblock.
• Close supervision is necessary when the appliance is used near young children.
Do not let young children play with any parts of the appliance or the packaging.
The blade is extremely sharp. The appliance is NOT intended for use by children or
infirm persons without supervision. Take care that no one will pull the appliance by
the power cord, especially when young children are near.
• Always place the appliance on a clean, dry and stable surface where it is protected
from inadmissible strain (i.e. mechanical or electric shock, overheating, frost, moisture) and
where young children cannot reach it.
3
Carefully read all provided instructions before you start running the
appliance and pay regard to the warnings mentioned in these
instructions.
!
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 3

• Operate the appliance on a well accessible, stable, level, dry, and suitable large surface.
Do not place the appliance or any part of it on or near hot surfaces (heater, gas burner,
grill, or oven). Do not place the appliance near the edge of the table or counter or
on inclined or wet surfaces or where it can fall. Keep the entire appliance away
from direct sunlight and sharp edges. Ensure the blender jug is locked securely onto
the motorblock and that you can not knock the appliance over during operation to
avoid personal injury.
• Never leave the appliance unattended when the plug is connected to the power
outlet. Always IMMEDIATELY turn the appliance ´Off`, wait for the motor to stop
completely, and then unplug the appliance, if the appliance is not in use (even for
a short break) and before assembling, disassembling or cleaning. Never leave the
appliance unattended when in operational mode.
•Do not leave any food dry on the surfaces of the appliance. Do not immerse
the motor housing or power cord in water or any other liquid. Do not pour or drip
any liquids on the motor housing or power cord. When liquids are spilled on the motor
housing, immediately unplug the appliance and dry the motor housing to avoid risk
of electric shock or fire. Do not attempt to operate the appliance, when liquids are
on or in the motor housing.
•Do not place the motorblock in an automatic dishwasher!
• To avoid damage, do not use any abrasive cleaners, corrosive chemicals
(i.e. disinfectants, bleach) or cleaning pads for operation or cleaning. Do not use
any hard or sharp utensils for operation or cleaning. Always handle the entire
appliance and all parts of it with care and without violence.
•WARNING: The blades are very sharp. Pay attention when handling the blades.
Only touch the blades on the blade assembly and handle with care when cleaning.
•Do not use the appliance if it is damaged or units of the appliance are damaged.
Do not use the appliance if it does not function properly or if it was excessively
loaded. The appliance is likely damaged if the appliance or units of the appliance
show cracks, exorbitant wearing down, alterations or leaks. It is also likely damaged if the
drive wheel of the motorblock moves slowly. Take the appliance for technical
maintenance and repair to an authorised specialised reparation shop.
•WARNING: Do not overfill the blender jug. If necessary, take some food out
of the blender jug, using a wooden or plastic spoon, before starting the appliance again.
•Do not chop extremely hard food, such as nuts with shell, bones to avoid overrunning,
spurt out or that the motor stalls or stucks during operation because the blade is blocked.
• WARNING: Do not fill ingredients into the blender jug which exceed a temperature of 60
degrees. After processing ice cubes slowly heat up the blender jug before processing
hot ingredients. Otherwise the blender jug will crack or get damaged. Use gloves
4
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 4

processing hot liquids and do not fill the blender jug up too high. Ensure not to burn
yourself on the blender jug, on overrunning, spurt out or hot steam. Touch the handle
only for lifting the blender jug.
• The appliance is for household only.
Movable and sharp-edged units – risk of injury
• Always turn the appliance ´Off` (all buttons are deactivated and the LCD timer
screen is switched-off), wait for the motor to stop moving and then pull the plug
before taking the blender jug off the motorblock or taking off the lid. It could take about
3 seconds until the motor has completely stopped. Never leave the appliance ´ON` when
not in use.
•Never put your hands, wooden spoons or other foreign substance (such as hair,
cloth, brush, towels) into the blender jug when the motor is running or the appliance is
connected to the power outlet. Always take the blender jug off the motorblock first
before you push down the food with a spoon or add new ingredients.
•WARNING: The blades are very sharp. Pay attention when handling the units. Only
touch the blade assembly housing when handling the blades. Handle with care when cleaning.
Only store the appliance completely assembled. This way the blades will be out of reach.
•NOTE: Ensure the appliance is properly assembled and that the blade is properly
attached before putting the plug into the power outlet. Never turn the appliance on without
the lid or the refill lid. Never place only the holder or the blade only on the motorblock.
Never touch the drive gear when the plug is connected to the power outlet.
• Always keep one hand on the lid while processing. Using solid ingredients (such as
hard fruits or vegetable), overloading the blender jug or processing with a slow speed,
the motor could stuck, stall or run very slow. In this case turn the appliance ´Off` to avoid
overheating (see ´Trouble shooting`).
•WARNING: If the blade is mounted in the blender jug, the blender jug is positioned on
the motorblock, and the plug is connected to the power outlet, do not insert your fingers, a
wooden or plastic spoon or similar cooking utensils or foreign substances in the blender
jug. Always take the blender jug off the motorblock before pushing the food down with
a spoon.
•Do not chop extremely hard food, such as nuts with shell or bones because the
blade could stall or block. Do not overfill the blender jug to avoid overrunning, spurt
out or that the motor stalls or stucks during operation. If the motor stalls or stucks turn
´Off` the appliance (all buttons are deactivated and the LCD timer screen is
switched-off) to avoid overheating.
5
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 5

Important Safeguards for all Electrical Appliances
• Always operate the appliance near a suitable wall power outlet and connect the appliance
directly to the power outlet. Do not use any extension cords or a multiple desk outlet.
• Ensure that the voltage rating of your mains power supply corresponds to the voltage
requirements of the appliance (220/230 V, 50 Hz, AC). Always connect the appliance
directly to a mains power supply wall socket with protective conductor (earth/ground)
connected properly. The installation of a residual current safety switch with a maximum
rated residual operating current of 30 mA in the supplying electrical circuit is strongly
recommended. If in doubt, contact your local electrician for further information.
•Do not leave the appliance unattended when connected to the power supply.
Always turn the appliance ´Off` (all buttons are deactivated and the LCD timer screen
is switched-off) and IMMEDIATELY unplug the appliance after operation and if it is
not in use (even for a short break) and before cleaning and/or assembling or disassembling.
Always grasp the plug to disconnect the appliance from the power outlet.
• Always handle the power cord with care. Do not pull or strain the power cord.
The power cord may never be knotted or squeezed. Do not let the power cord
hang over the edge of the table or counter. Take care not to entangle in the power
cord. Do not touch the appliance with wet hands to avoid risk of electric shock. Do
not touch the appliance, if it is damp or wet or is touching wet surfaces while connected
to the mains power supply. In this case, immediately unplug the appliance and dry the
appliance (see ‘Care and Cleaning’).
• Ensure that the holder is leak-proof before putting the blender jug on the motorblock.
Always wipe off spilled liquids immediately. Do not immerse the motor or power cord in
any liquids or spill any liquids on it or place the motor on wet surfaces. Never let
any liquids run into the motorblock or underneath it to avoid electric shock. There are
louvre underneath the motorblock. Ensure that no water can run into the louvre.
When liquids are spilled on the motor housing, immediately unplug the appliance
and dry the motor housing to avoid risk of electric shock or fire. Do not attempt
to operate the appliance, when liquids are on or in the motor housing.
6
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 6

Get to know your blender
Inner measuring lid
Kinetix blades
Mount of the jug
1-5: different speed controls for continuous
operation
1: MIX
2: CHOP
3: BLEND
4: LIQUIFY
5: PUREE
LCD timer screen: counts up on speed settings
and down for pre-programmed settings
Control panel with illuminated buttons,
´POWER` button, ´STOP` button,
5 speed control buttons, ´ICE-CRUSH` button,
´PULSE` button, ´SMOOTHIE` button and
LCD timer screen
7
Motorblock with drive coupling
´PULSE` button: for interval operation
´ICE-CRUSH` button: pre-programmed
(30 seconds) for crushing ice
´POWER` button: to get the appliance
into the operational mode or to turn it ´Off`
Unique ring pull design ensures the lid
is easy to remove yet sealed tight during
operation
1,5 litre heat and coldresistent glass jug
´STOP` button: to stop or interrupt the
operation and to get the appliance into
the operational mode
´SMOOTHIE` button: pre-programmed
(40 seconds) for making smoothies
Cord storage and sturdy non-skid feet
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 7

Blender for superior requirements
The secret to the Kinetix Blade System is the
continuous movement created inside the jug.
It allows the blender to combine the functions
of a blender with a mini food processor for
the ultimate in versatility. Now you can use
your blender to not only crush ice to a snow
consistency and create super smooth frappés
and smoothies, but to also process nuts,
vegetables and herbs into evenly chopped
pieces and perfect purees, and mince meat
and fish for delicious homemade meals.
Combined with a powerful 1.200 watt motor
and heavy duty commercial grade components,
the blender is built for durability, reliability
and professional results superior to all other
blenders.
8
The jug has been designed with dual ribs which
assist the extra wide blades by creating
movement of ingredients. Food is forced
through the blades, up the sides of the jug, then
mixed back down through the blades in a
continuous circular movement ensuring perfectly
blended results.
1. Unique jug design
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:03 Seite 8

9
Conventional Blades
The stainless steel ice-crushing blades are extra wide, reaching ingredients all the
way to the sides of the blender jug. Combined with an additional set of dual blades,
all ingredients are completely and evenly processed every time.
KINETIX Blade System
KINETIX BladesConventional Blades
2. Patented* extra wide blades - KINETIX Blade System
3. Continuous blending action
The Kinetix Blade System ensures there are no spaces for food to get caught or
trapped. The patented* extra wide blades are contoured to the base of the blender
jug meaning food can never jam or escape the high speed blades. There are no
dead zones, so food is 100% blended with no over or under blended ingredients.
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 9

Assembling and disassembling the appliance
Disassembling the blender jug
1. Always turn the appliance ´Off` (all buttons are deactivated and
the LCD timer screen is switched-off), wait until the motor stops and
unplug the appliance before assembling/disassembling.
Always completely assemble your appliance before you put the
plug into the power outlet.
2. Remove the blender jug from the motor base by grasping the
handle and lifting the jug in an upward direction.
3. Take the lid off the blender jug and empty the blender jug
(picture A).
4. Take the clear refill lid and twist it anticlockwise to take it out.
NOTE: The refill lid has two small guiding pins that fit in the
matching gaps of the lid. Pull the inner lid up to remove it (picture B).
5. Remove the blade assembly housing by upturning the
blender jug and twisting the Blade Removal System clockwise to
unlock (picture C and D), then lift upwards and away from the
base of the blender jug.
ATTENTION: The circular plastic surround attached to the base
of the blender jug is not removable.
ATTENTION: The circular plastic surround attached to the
blades is not removable.
WARNING: The blades are very sharp. Pay attention handling it
and if possible only hold on to the blade assembly housing.
6. Remove the silicon seal from the blade assembly housing for
cleaning (picture E).
7. Clean the units with a soft sponge in warm soapy water and dry
them off afterwards. Pay attention not cutting yourself handling
the blade. Do not use abrasive cleaners, cleaning pads, corrosive
chemicals (disinfectants, bleach) or any sharp or hard objects
(i.e. metal scouring pads) for cleaning, for this could damage the
surfaces. Always handle the entire appliance with care and
without violence.
10
A
C
D
E
B
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 10

Assembling the blender jug
Ensure that the blender jug and all units are clean before you
assemble the appliance.
1. To reassemble the blender jug, replace the silicon seal onto the
blade assembly housing (picture A). Ensure the sealing ring is
in proper position. The sealing ring has to be clean and show no
crustifications, crinkles, cracks or look porous.
2. Hold on to the blade assembly housing with your right hand
and with your left hand hold on to the handle of the blender
jug. Upturn the blender jug and insert the blade assembly housing
into the jug base (picture B and C). Twist the Blade Removal
System anticlockwise until firmly locked into position.
WARNING: The blades are very sharp. Pay attention handling it
and if possible only hold on to the blade assembly housing.
NOTE: The blade assembly housing has two small guiding pins
that fit in the matching gaps of the base of the blender jug. The
blade assembly housing is in the right position if it seats solidly onto
the base of the blender jug and when you can twist it anticlockwise.
NOTE: Ensure the blade assembly housing is securely locked onto
the jug base.
The blade assembly housing and the sealing ring should be properly connected to
seal the bottom of the blender jug. Otherwise ingredients will run right into the
motorblock. IMPORTANT: Do not tighten them with force or too tight to avoid
damaging the appliance or the sealing ring. Ensure the sealing ring is in position
and did not fall into the blender jug when assembling.
ATTENTION: Ensure the blender jug is leak-proof before putting the blender jug on
the motorblock. Always wipe off spilled liquids immediately. Never let any liquids run
into the motorblock or underneath it to avoid electric shock. When liquids are spilled on
the motor housing, immediately unplug the appliance and dry the motor housing to avoid
risk of electric shock or fire. Do not attempt to operate the appliance, when liquids
are on or in the motor housing.
ATTENTION: Never place the holder or the blade only on the motorblock. Never touch
the drive gear when the plug is connected to the power outlet. Without the blade
assembly housing the bottom of the blender jug is open. Spilled liquids might run
right into the motor.
11
A
C
B
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 11

ATTENTION: When liquids are spilled on the motor housing,
immediately unplug the appliance and dry the motor housing
to avoid risk of electric shock or fire. Do not attempt to operate
the appliance, when liquids are on or in the motor housing.
3. Place the proper assembled blender jug onto the motorblock.
Turn the blender jug until it locks onto the motorblock. The handle
of the blender jug should be positioned to the right hand side of
the appliance in order to see the measuring scale (picture A).
The screen will turn on as soon as the plug is plugged into the
power outlet, the blender jug is securely locked onto the motorblock
and the appliance is switched ´On` by pressing the power button.
4. Place the clear refill lid onto the opening of the blender lid.
NOTE: The refill lid has two small guiding pins that fit in the matching
gaps of the lid. Twist it clockwise 1/4 of a turn until firmly locked
into position (picture B). You can hear it click when the refill lid
is in proper position.
5. Load the blender jug with ingredients, pick a speed on the control panel and start
processing.
ATTENTION: Always ensure the motorblock is turned off when placing the blender jug
on the motorblock to avoid personal injury.
ATTENTION: Never try to sharpen the blade. Replace the blade if it is blunt. Please
contact our service department for the replacement part.
Operating
Before first use
WARNING: The blade is very sharp. Pay attention when handling the blade. Only touch
the blade on the blade assembly housing. Do not leave young children play with the
appliance or any part of it or the packing material.
After unpacking, remove all promotional and packing materials as well as any foreign objects.
Before first use and after a long period of storage, clean the appliance and all its units
with a damp soft cloth and warm soapy water (see ‘Care and Cleaning’). The blender
jug is dishwasher safe.
WARNING: The lid, refill lid and blade assembly housing are not dishwasher safe. Ensure
to remove the blade assembly housing and take the lid off the blender jug before placing
the blender jug into the dishwasher.
NOTE: When using your blender for the first time, you may notice an odour coming
from the motor. This is normal and will dissipate with use.
12
A
B
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 12

General Tips
Place the blender jug on a suitable, stable, dry, and clean working surface. (see:
‘Safeguards for Daily Operation’). Always wipe off spilled liquids immediately. Never
let any liquids run into the motorblock or underneath it to avoid electric shock. When
liquids are spilled on the motor housing, immediately unplug the appliance and dry
the motor housing to avoid risk of electric shock or fire. Do not attempt to operate the
appliance, when liquids are on or in the motor housing.
WARNING: If the blade is mounted in the blender jug, the blender jug is positioned on the
motorblock, and the plug is connected to the power outlet, do not insert your fingers, a
wooden or plastic spoon or similar cooking utensils or foreign substances in the blender
jug. Always turn the appliance ´Off` and wait for the motor to stop before taking the
blender jug off the motorblock, removing the lid, checking the food, pushing the food
down with a spoon or filling in more ingredients. Use cutlery made of wood, rubber or
plastic only. Never use force when trying to push the food down or trying to remove food
that blocks the blade.
The Design Mixer Advanced Electronic can not replace all of your kitchen appliances. The
mixer can not be used for: beating the white of eggs or juicing fruits and vegetable. Also
it is not possible to use it for stirring very firm batter or dough or for chopping very hard
ingredients such as nuts with shell, bones or alike.
IMPORTANT: Do not leave any food dry on the surfaces of the appliance. Always
clean the appliance right after use (see ´Care and Cleaning`).
Tips for operation
• Use Low speeds (1-3 – Mix, Chop and Blend) for drink or cocktail making and emulsions
such as mayonnaise, dressings, marinades and foods that require mixing until just
combined, such as batters.
• Use High speeds (4-5 – Puree and Liquify) for pureeing soups and aerating liquids.
Use ‘PULSE’ for foods that only require short bursts of power such as chopping nuts.
• Use ‘ICE CRUSH’ for ice crushing. The maximum amount of ice cubes the blender
can blend at any one time is 1 standard ice try or 250g.
• Use ‘SMOOTHIE’ for drink making using both liquid and solid ingredients.
• Ensure all foods are cut into cubes (approx. 2-3cm squares) where appropriate to
achieve an even result.
• IMPORTANT: Do not overload the motor with food that is oversized or too hard.
Turn the appliance ´Off` as soon as the motor stalls or stucks to avoid overheating of
the motor (see ´Trouble shooting`). Fill liquid ingredients into the blender jug first
unless it is described different in the recipe. Prepare your food before you fill it into
the blender jug. Do not overfill the blender jug.
13
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 13

• Do not put more than 2 cups of warm ingredients into the blender before blending
commences. After the blending process has begun and the blades are turning you may
slowly add another 11/2 cups of ingredients through the opening in the lid if desired.
• Thick mixtures puree more efficiently if the blender is 1/4 to 1/2 full.
• When using several ingredients, place liquid ingredients in the blender jug before
solid ingredients, unless specified in the recipe.
• When blending thick or dry mixtures it may be necessary to stop the blender and
scrape down the sides of the blender jug with a plastic or rubber spatula, once or
twice during blending. Do not use metal utensils as they may damage the blades or
blender jug. WARNING: If the blender jug is positioned on the motorblock, and the plug is
connected to the power outlet, do not insert your fingers, a wooden or plastic spoon
or similar cooking utensils or foreign substances in the blender jug. Always take the
blender jug off the motorblock before pushing the food down with a spoon.
• Process ingredients a few seconds only. Permanently check on the consistency of
the food in between the operation to avoid getting food which is too fine and slushy.
Pick the speed for your needs: mixing (MIX 1-5) for permanent operation, ´ICE-CRUSH`
button, ´PULSE` button (for interval operation) or the ´SMOOTHIE` button.
• Do not operate a heavy mixture for more than 30 seconds.
• For normal blending tasks, for example, mayonnaise, dressings etc., do not operate
for longer than 1 minute at one time without turning off the blender and stirring the
ingredients, and then continue blending.
• Do not operate the blender without having the blender lid in position. To add additional
ingredients whilst blending, remove the refill lid and place ingredients through the
opening in the lid.
• Do not fill the blender jug above the 'MAX' line. When the blender jug is filled at
or near the 'MAX' line, place one hand on the blender lid to avoid displacement of
the lid during operation.
• Do not place any objects, other than food or liquid, into the blender whilst the
motor is running.
• Do not use the blender jug to store food.
• The blender will not knead dough or mash potatoes.
• Do not remove the blender jug while the blender is operating. Always make sure
the blender is ´Off` by pressing the ‘Power’ button and unplug the power cord from
the power outlet.
• Do not overload the blender with more than the specified quantity of ingredients
as doing so could cause the motor to stall. Turn the blender is ´Off` by pressing the
14
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 14

‘Power’ button on the control panel and unplug the cord. Remove a portion of the
mixture from the blender jug before continuing.
• Do not place hot or boiling ingredients into the blender; allow to cool before placing
into the blender jug.
Speedcontrol
It is possible to process food with all kind of texture using the speedcontrol. The
control panel has therefore different marks. You find some ideas and proposals on how
to use the different speed.
Pulse Interval operation: ideal for processing nuts (i. e. almonds),
for mincing boiled meat or fish.
Ice-Crush For crushing ice.
Smoothie For preparing milk-shakes, smoothies and Frappés
1 To combine milkpowder, juice and gelatin or preparing eggs
MIX for omelettes.
2 Used for grinding hard and solid seeds such as beans, cafe,
CHOP chickpea, or grinding sugar to make icing sugar, and for mincing
meat or fish.
3 For preparing Frappé-ice, shakes, yogurt, ice cream
BLEND
4 For mixing harder ingredients
LIQUIFY
5 For onions, thick sauces, etc. It does not get a sauce foamy.
PUREE For mashing fruit and vegetable.
The length of mixing time depends on your personal preferences, the consistency of
the ingredients and the recipe.
Interval-function: The Pulse button is a touch sensitive button which keeps the motor
running only for the time you press the button down and which should be pressed
in short intervals only. One interval takes 1 second.
Timer-function: The Ice-Crush and the ´SMOOTHIE` button are pre-programmed
cycles which automatically adjust the blending time and speeds to optimise blending
results. The LCD timer screen will start counting downwards in one second increments
until ‘00’ is displayed. When ‘00’ seconds is reached, the blender will automatically cease
to operate. The ´ICE-CRUSH` button is pre-programmed for 30 seconds and the
´SMOOTHIE` button for 40 seconds.
15
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 15

Mixing: The 5 speed buttons are for permanent operation. The motor only stops
when pressing the ´Off`-button or after 2 minutes of permanent operation. Note: As
a safety feature, the unit automatically shuts off after operating for 2 minutes. If you want to
operate again, unplug the appliance, wait 1 minute and plug in again.
Suggested uses for your blender
Food Preparation & Usage Quantity Function Time
Mayonnaise Mix the egg yolk and vinegar. 125 g 1 / MIX 60 seconds
Add the oil
Use: dressings
Whipped cream Add sugar or vanilla if desired 200 g 1 / MIX 60 seconds
Use: topping
Lean meat/ Trim excess fat and sinew, 250 g 2 / CHOP 10-20 seconds
poultry cut into 2cm cubes
Use: mince
Fish/ Remove skin and bones 300 g 2 / CHOP 10-15 seconds
seafood and cut into 2cm cubes
Use: mince
Raw vegetable Peel and cut into 200 g 2 / CHOP 10-30 seconds
1.5-2cm cubes
Use: stuffing, filling, puree, soup
Nuts Remove skin 200 g 2 / CHOP 10-30 seconds
Use: cakes, toppings, pastes
Bread or biscuit Cut bread into 2cm pieces, 100 g 2 / CHOP 10-30 seconds
crumbs break up biscuits
Use: cheesecake
Herbs/spices Whole or halve 1 cup 2 / CHOP 20-30 seconds
Use: pastes, sauces
Smoothie Milk, whole fresh fruits, max. Smoothie / or 20-30 seconds
yogurt, ice cream 800 ml 3 / BLEND
Use: milkshake, frappé
Fresh fruit Whole, chopped berries 250 g 2 / CHOP 30 seconds
Use: dessert sauce
Dried fruit Chopped dry fruit 300 g 2 / CHOP 30 seconds
Use: fruit mince
Ice Crush 250 g Ice-Crush 10-20 seconds
Use: mixed drinks, cocktails, slurpies 2 / CHOP
16
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 16

Directions for use
• The mixer proceeds fast and reliable when you add the ingredients one after the
other in small portions.
• The mixer processes within seconds. Avoid processing food longer then necessary.
• Always ensure the lid is closed before starting the motor to avoid spilling.
• You can add ingredients during the operation through the refill aperture. Never
place your face or hands over the opening.
• If the motor slows down use the next faster speed.
• Always clean the appliance right after use.
If ingredients get stucked on the walls of the blender jug turn the appliance off, take the
blender jug off the motorblock, open the lid and push the food down carefully using a
spatula. Take care of the blade.
ATTENTION: Open the refill aperture when mixing hot food and cover it with a
kitchen towel. This way excess pressure and steam can escape.
Production steps
WARNING: Ensure the blender jug is locked securely onto the motorblock
and that you can not knock the appliance over during operation to avoid
personal injury.
Connected the plug to the power outlet. Press the ‘Power’ button on the far left of
the control panel to turn the blender on. The ‘Power’ button will illuminate and
flash. The LCD timer screen will illuminate with ‘00’ displayed. The LCD timer
screen shows the running time of the motor.
1. If the appliance is properly assembled and securely locked onto the motorblock fill
the ingredients into the blender jug. Do not fill the blender jug above the ‘MAX’ line.
When the blender jug is filled at or near the ‘MAX’ line place one hand on the blender
lid to avoid displacement of the lid during operation.
IMPORTANT: Cooked food should cool down before processing. Food with hard texture
should be cut in pieces of 2 cm size before filling them into the blender jug. Fill liquids
in first. Do not overload the blender jug to avoid spilling or overloading the motor.
2. Place the lid on the blender jug and press the lid down to seal the top of the
blender jug. Close the opening of the lid with the refill lid.
NOTE: The refill lid has two small guiding pins that fit in the matching gaps of the lid. Twist
it clockwise 1/4 of a turn until firmly locked into position. You can hear it click when
the refill lid is in proper position.
17
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 17

NOTE: The blender features a patented assist lid. This allows the lid to fit tightly
onto the blender jug, avoiding displacement during operation. The ring pull
design allows the user to easily remove the lid with a simple leverage action.
WARNING: Never take the blender jug off the motorblock, the lid of the blender jug
or place a spoon or other foreign substance into the blender jug while the motor is running.
Always turn the appliance ´Off` first and wait for the motor to stop moving. Now you
can take the blender jug off the motorblock remove the lid and check on the ingredients.
WARNING: Do not fill ingredients into the blender jug which exceed a temperature of
60 degrees. After processing ice cubes slowly heat up the blender jug before processing hot
ingredients. Otherwise the blender jug will crack or gets damaged. Use gloves processing
hot liquids. Ensure not to burn yourself on the blender jug, overrunning, spurt out or hot steam.
ATTENTION: If you are working with hot ingredients first take off the refill lid and
cover the opening with a towel to release excess pressure and steam.
IMPORTANT: Ensure the blender jug is properly locked on the motorblock and
stands securely. The unit does not work if the blender jug is not in proper position
on the motorblock.
3. Place one hand on top of the lid. Press the ‘Power’ button on the far left of the control
panel to turn the blender ´ON`. The ‘Power’ button will illuminate and flash. The LCD
timer screen will illuminate with ‘00’ displayed.
4. Select the required speed (1 to 5) by pressing the corresponding speed button. The
blender will start to operate and the selected speed button will illuminate. The ‘Power’
button will illuminate and cease to flash. The ‘STOP’ button will illuminate and flash.
The LCD timer screen will start counting upwards in one second increments until
120 seconds is reached.
Note: Using the pre-programmed functions such as the ´Ice-crush` or the ´SMOOTHIE`
button the screen will start counting downwards in one second increments until ‘00’
is displayed. When ‘00’ seconds is reached, the blender will automatically cease to
operate. The ´ICE-CRUSH` button is pre-programmed for 30 seconds and the
´SMOOTHIE` button for 40 seconds.
Important: The maximum amount of ice cubes the blender can blend at any one
time is 1 standard ice tray or 250g.
Note: The Pulse button is a touch sensitive button which keeps the motor running only
for the time you press the button down and which should be pressed in short
intervals only. One interval takes 1 second.
Note: The speed can be changed at any time during the blending process. Each time a new
speed is selected its button will illuminate and the previous speed button illumination will go
out. The number of seconds on the LCD timer screen is not interrupted and will continue to
count upwards to 120 seconds unless interrupted. If changing to a pre-programme function
18
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 18

the LCD timer screen resets to the pre-programmed function time selected.
ATTENTION: If the motor slows down or stucks turn the appliance off
immediately to avoid overheating (see ´Trouble shooting`).
5. Turn the appliance ´Off` when the operation is finished. Note: Operate the
blender only for the appropriate amount of time required – do not over process.
To stop blending at any time, press the ´STOP` button or the selected speed button. The
selected speedcontrol button and ´STOP` button illumination will go out and the
´POWER` button starts flashing. The appliance is set into the operational mode.
Note: The ´Power’ button can also be pressed, but this will also turn the appliance
´Off` and all illuminations will go out.
Important: The blender will automatically stop blending after 120 seconds (2 minutes)
and the function button and ‘STOP’ button illumination will go out. The ‘POWER’ button
will illuminate and flash. This is a safety feature.
6. As soon as the motor stops moving you can take the blender jug off the motorblock
holding on to the handle. Take off the lid to check the consistency of the food or to push
down the food from the sides of the blender jug. You can fill in more ingredients
through the refill aperture. Turn the refill lid anticlockwise and lift it. After adding the
ingredients close the refill aperture, place the blender jug on the motorblock and make sure
it is securely locked. Turn ´On` the appliance. Process until the food has the favoured texture.
7. Turn the appliance ´Off` as soon as you are done with operating and take the
blender jug off the motorblock. You can pour out liquid foods.
IMPORTANT: Do not leave any food dry on the surfaces of the appliance. Always
clean the appliance right after use (see Care and Cleaning).
Care and Cleaning
WARNING: To avoid injury to persons and damage, always turn the appliance ´Off`,
wait for the motor to stop completely and unplug the appliance, immediately after
operation and before assembling/disassembling or cleaning the appliance.
WARNING: Ware oven gloves if processing hot food. Ensure not to get burned on
spilled over liquids or steam.
ATTENTION: Do not use abrasive cleaners, cleaning pads, corrosive chemicals
(disinfectants, bleach) or any sharp or hard objects (i.e. metal scouring pads) for cleaning,
for this could damage the surfaces. Always handle the entire appliance with care and
without violence.
19
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 19

Cleaning the blender jug
1. Empty the blender jug and rise it with warm water.
2. Replace the blender jug on the motorblock and ensure it is securely locked into position.
3. Fill the blender jug with warm soapy water. The waterlevel should be high enough
to cover the blade with water but not too high to avoid run over liquids. Close the lid
and turn ´On` the motor on “5”. Let the motor run for a few seconds.
4. Turn the motor ´Off`, wait for the blade to stop moving and take the blender jug
off the motorblock.
5. Pull the plug out of the power outlet.
6. Take the lid off the blender jug and pour out the water. Stubborn residues you can
remove using a nylon washing brush or sponge.
WARNING: Pay attention not to cut yourself cleaning around the blade or
cleaning the blade.
IMPORTANT: The blender jug should be clean now. For the case that there are
stubborn residues on the blender jug or the blade, disassemble the blender jug and
clean the single unit (see ´Assembling and disassembling the appliance`). Soak the
units in warm soapy water.
7. Clean the lid and the refill lid with soapy water.
8. Rinse the blender jug, the lid, and the refill lid with clear water and dry the
units thoroughly and carefully with a cloth or leave all parts dry naturally where they
are out of reach of young children.
Note: The blender jug is dishwasher safe.
Note: The lid, refill lid and blade assembly housing are not dishwasher safe. Ensure
to remove the blade assembly housing and take the lid off the blender jug before placing
the blender jug into the dishwasher.
Disassembling the blender jug and removing stubborn residues
WARNING: The blade is very sharp! Do not touch the blade. To handle the blade,
always hold on to the blade assembly housing.
1. Take the blender jug off the motorblock and hold it over the sink. Remove the holder
turning it 1/4 of a turn clockwise. Take the holder off the blender jug and remove the blade.
ATTENTION: The blender jug might be connected really tight to the holder. Do not
use force unscrewing it.
2. Rinse all units in warm soapy water. Soak stubborn residues for a few minutes and then
remove them using a nylon washing brush or sponge. Do not cut yourself. Beware
20
41001_DesignMixerAdvancedElectronic_Manual_englisch.qxp 03.01.2008 12:04 Seite 20
