GE Kilsen KFP-CF2 User manual

GE
Security
P/N 501-415103-1-10 • REV 1.0 • ISS 03MAY09
Kilsen KFP-CF Series Installation
Manual

Copyright © 2009 GE Security, Inc.
This document may not be copied in whole or in part or otherwise reproduced without prior
written consent from GE Security, Inc., except where specifically permitted under US and
international copyright law.
Disclaimer The information in this document is subject to change without notice. GE Security, Inc.
(“GE Security”) assumes no responsibility for inaccuracies or
omissions and specifically disclaims
any liabilities, losses, or risks, personal or otherwise, incurred as a consequence, directly or
indirectly, of the use or application of any of the contents of this document. For the latest
documentation, contact your local supplier or visit us online at www.gesecurity.eu.
This publication may contain examples of screen captures and reports used in daily operations.
Examples may include fictitious names of individuals and companies. Any similarity to names
and addresses of actual businesses or persons is entirely coincidental.
Trademarks and patents GE and the GE monogram are trademarks of General Electric Company. CleanMe and the Kilsen
KFP-CF Series name and logo are trademarks of GE Security.
Other trade names used in this document may be trademarks or registered trademarks of the
manufacturers or vendors of the respective products.
Intended use Use this product only for the purpose it was designed for; refer to the data sheet and user
documentation for details. For the latest product information, contact your local supplier or visit
us online at www.gesecurity.eu.
Certification and compliance
European Union directives
2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as
unsorted municipal waste in the European Union. For proper recycling, return this product to
your local supplier upon the purchase of equivalent new equipment, or dispose of it at
designated collection points. For more information see: www.recyclethis.info.
2004/108/EC (EMC directive): Non-European manufacturers must designate an authorized
representative in the Community. Our authorized manufacturing representative is:
GE Security B.V., Kelvinstraat 7,
6003 DH Weert, The Netherlands.
2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union. See the product documentation for specific
battery information. The battery is marked with this symbol, which may include lettering to
indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your
supplier or to a designated collection point. For more information see: www.recyclethis.info.
Contact information For contact information see our Web site: www.gesecurity.eu.

Kilsen KFP-CF Series Installation Manual i
Content
Important information ii
Chapter 1 Introduction 1
Product range 2
Product compatibility 2
Operating modes 2
Chapter 2 Installation 3
Cabinet layout 4
Cabinet installation 6
Connections 8
Chapter 3 Configuration and commissioning 15
The user interface 16
Access levels and passwords 18
Configuration overview 20
Basic configuration 24
Advanced configuration 31
Expansion module configuration 39
Commissioning 42
Chapter 4 Maintenance 45
Fire alarm system maintenance 46
Battery maintenance 47
Chapter 5 Technical specifications 49
Appendix A Configuration presets 59
Operating mode presets 60
Expansion module presets 66
Appendix B Product compliance 69

ii Kilsen KFP-CF Series Installation Manual
Important information
This is the installation manual for the Kilsen KFP-CF series conventional fire control
panels. Read these instructions and all related documentation entirely before
installing or operating this product.
Limitation of liability
Installation in accordance with this manual, applicable codes, and the instructions of
the authority having jurisdiction is mandatory. GE Security shall not under any
circumstances be liable for any incidental or consequential damages arising from
loss of property or other damages or losses owing to the failure of GE Security
products beyond the cost of repair or replacement of any defective products. GE
Security reserves the right to make product improvements and change product
specifications at any time.
While every precaution has been taken during the preparation of this manual to
ensure the accuracy of its contents, GE Security assumes no responsibility for errors
or omissions.

Kilsen KFP-CF Series Installation Manual 1
Chapter 1
Introduction
Summary
This chapter provides an introduction to your control panel and the available
operating modes.
Content
Product range 2
Product compatibility 2
Operating modes 2

Chapter 1: Introduction
2 Kilsen KFP-CF Series Installation Manual
Product range
The KFP-CF series includes the models shown below.
Model Description
KFP-CF2 Two-zone conventional fire alarm control panel
KFP-CF4 Four-zone conventional fire alarm control panel with fire routing
KFP-CF8 Eight-zone conventional fire alarm control panel with fire routing
All models have been designed in accordance with EN 54-2, EN 54-4, BS 5839-1,
NBN S21-100, and NEN 2535 standards. For further details, see “Appendix B
Product compliance” on page 69.
Product compatibility
For details of compatible products, see the compatibility sheet included with your
control panel or consult your local supplier. Compatibility with other products cannot
be guaranteed.
Operating modes
Supported operating modes are shown in the table below. The default operating
mode is EN 54-2.
Table 1: Operating modes
Operating mode Region
EN 54-2 (default) European Union
EN 54-2 Evacuation European Union (Spain)
EN 54-2 Scandinavia European Union (Scandinavia)
BS 5839-1 United Kingdom
NBN S21-100 Belgium
NEN 2535 The Netherlands

Kilsen KFP-CF Series Installation Manual 3
Chapter 2
Installation
Summary
This chapter explains how to install your control panel, and how to connect zones, fire
system devices, and the power supply.
WARNING: This product must be installed and maintained by qualified personnel
adhering to the CEN/TS 54-14 standard (or the corresponding national standard) and
any other applicable regulations.
Content
Cabinet layout 4
Cabinet layout for two- and four-zone control panels 4
Cabinet layout for eight-zone control panels 5
Cabinet installation 6
Connections 8
Cabling requirements 8
Overview of fire system connections 9
Connecting zones and zone devices 9
Connecting inputs 10
Connecting outputs 11
Connecting the mains power supply 12
Selecting 115 or 230 VAC operation 13
Connecting the batteries 14
Other connections 14

Chapter 2: Installation
4 Kilsen KFP-CF Series Installation Manual
Cabinet layout
Cabinet layout for two- and four-zone control panels
Figure 1: Cabinet layout for two- and four-zone control panels
1. Seven-segment display
2. Zone and fire system connectors
3. Cable knockouts
4. Mounting screw knockouts
5. Battery area
6. Key connector
7. Alarm counter connector
8. Power supply unit
9. Power supply connector
10. Battery connector
11. Expansion module connector
12. Cable holder
13. Fuse terminal block
Note: The alarm counter and key connectors are only included on selected regional
models.

Chapter 2: Installation
Kilsen KFP-CF Series Installation Manual 5
Cabinet layout for eight-zone control panels
Figure 2: Cabinet layout for eight-zone control panels
1. Seven-segment display
2. Zone and system connectors
3. Cable knockouts
4. Mounting screw knockouts
5. Battery area
6. Power supply unit
7. Key connector
8. Alarm counter connector
9. Fuse terminal block
10. Power supply connector
11. Battery connector
12. Expansion module connector
13. Cable holder
Note: The alarm counter and key connectors are only included on selected regional
models.

Chapter 2: Installation
6 Kilsen KFP-CF Series Installation Manual
Cabinet installation
Before you begin
• Remove the front cover
• Remove cable knockouts from the top, bottom, and rear of the cabinet as
required
Where to install the cabinet
Make sure the installation location is free from construction dust and debris, and
immune to extreme temperature ranges and humidity (see “Chapter 5
Technical specifications” on page 49 for more information on the operating
temperature and relative humidity specifications).
Allow for enough floor and wall space so the panel can be installed and serviced
without any obstructions. The cabinet should be mounted so that the user interface is
at eye level.

Chapter 2: Installation
Kilsen KFP-CF Series Installation Manual 7
Fixing the cabinet to the wall
The requirements for nylon wall plugs and screws are shown in the following table.
Model Screws Wall plugs
Two- and four-zone control
panels
4 x M4, 30 mm 4 x Ø 6 mm
Eight-zone control panel 5 x M4, 30 mm 5 x Ø 6 mm
Figure 3: Mounting hole locations
Fix the control panel cabinet to the wall as follows:
1. Mark drill points on the wall using the template provided in the product packaging
2. Drill all required holes and insert a 6 mm wall plug into each.
3. Insert screw (1) half way and hang the cabinet onto this screw.
4. insert screws (2) and tighten.
5. Insert screws (3) and tighten.
6. Tighten screw (1).

Chapter 2: Installation
8 Kilsen KFP-CF Series Installation Manual
Connections
WARNING: Do not make any control panel or system connections while the control
panel is connected to the mains power supply.
Cabling requirements
Recommended cable
Recommended cables for your fire system are shown in the table below.
WARNING: Failure to use the recommended cable may impact system performance.
Table 2: Recommended cables
Cable Cable description Maximum cable length
Mains cable 3 x 1.5 mm N/A
Zone circuit cable (mixed zone) Twisted-pair (max. 40 Ω/ 500 nF) 2 km
Zone circuit cable (automatic or
manual zones)
Twisted-pair (max. 55 Ω/ 500 nF) 2 km
Securing cables
Use 20 mm cable glands to ensure clean and secure connections at the control panel
cabinet. All cables should be fed through the cable guides in the cabinet housing to
eliminate movement.

Chapter 2: Installation
Kilsen KFP-CF Series Installation Manual 9
Overview of fire system connections
Figure 4: Overview of fire system connections
Connecting zones and zone devices
Connecting zones
Connect zone wires as shown in Figure 4 above. Line resistance is shown in the table
below.
Zone type Line resistance
Mixed (automatic and manual) Max. 40 Ω
Automatic Max. 55 Ω
Manual Max. 55 Ω
Note: The default zone detection settings for each operating mode can be found in
Appendix A “Configuration presets” on page 59. To change the zone detection setting,
see “Advanced configuration” on page 31.
Terminating zones
Each zone circuit requires a 4.7 kΩend-of-line resistor for termination. If a zone is not
used, the 4.7 kΩend-of-line resistor must be installed across the unused zone
terminals.
Note: For BS 5839-1 the default zone configuration is active end-of-line and an active
end-of-line module must be installed instead of an end-of-line resistor. Unused zones
must be terminated with an active end-of-line module or configured as passive end-
of-line and terminated with a 4.7 kΩend-of-line resistor as described above.

Chapter 2: Installation
10 Kilsen KFP-CF Series Installation Manual
Connecting detectors
Connect detectors as shown in Figure 4 on page 9. Each zone circuit can support up
to 20 detectors.
Connecting manual call points
Connect manual call points in parallel, as shown in Figure 4 on page 9. Each zone
circuit can support up to 32 manual call points.
Manual call points must have a resistance installed in series with the normally open
(NO) contact to avoid a short-circuit and to allow the control panel to identify the
origin of the alarm (automatic or manual).
The resistance required will depend on the zone type as shown below.
Zone type Manual call point resistance
Mixed 100 Ωper 2 W
Manual 100 Ωto 470 Ωper 2 W
Note: The default zone detection settings for each operating mode can be found in
Appendix A “Configuration presets” on page 59. To change the zone detection setting,
see “Advanced configuration” on page 31.
Connecting inputs
Input functionality
Each control panel has two inputs, marked INPUT1 and INPUT2. These circuits are
connected as normally open and activated when closed.
The function of INPUT1 is defined by the panel operating mode. See Table 3 below.
Table 3: Input functionality for inputs 1 and 2
Operating mode INPUT1 INPUT2
EN 54-2 Remote reset Delays off
EN 54-2 Evacuation Remote reset Delays off
EN 54-2 Scandinavia Extended fire routing delay Delays off
BS 5839-1 Class change Delays off
NBN S21-100 Remote reset Delays off
NEN 2535 Fire routing inhibit delay Delays off
Note: INPUT1 is not used in two-zone control panels operating EN 54-2 Scandinavia mode.
Connecting inputs
Connect input switches to INPUT1 and INPUT2, as shown in Figure 4 on page 9. The
circuit should have a maximum resistance of 100 Ω(including any cable resistance).

Chapter 2: Installation
Kilsen KFP-CF Series Installation Manual 11
Connecting outputs
Output functionality
Control panels have the following outputs:
• Two-zone control panels have two outputs, marked OUT1 and OUT2.
• Four- and eight-zone control panels have four outputs, marked OUT1, OUT2,
OUT3, and OUT4.
The function of each output is defined by the panel operating mode. See Table 4
below. All outputs are overload protected.
Table 4: Output functionality for outputs 1 to 4
Operating mode OUT1 OUT2 OUT3 OUT4
EN 54-2 Sounders Sounders Sounders Fire routing
EN 54-2 Evacuation Sounders Sounders Sounders Sounders
EN 54-2 Scandinavia Sounders Sounders Sounders Fire routing
BS 5839-1 Sounders Sounders Sounders Sounders
NBN S21-100 Evacuation
sounders
Evacuation
sounders
Warning
sounders
Warning
sounders
NEN 2535 Sounders Sounders Fire routing
(automatic)
Fire routing
(manual)
Output termination
All outputs require a 15 kΩend-of-line resistor for termination. If an output is not
used, the 15 kΩend-of-line resistor must be installed across the unused output
terminals.
Output polarity
All outputs are polarity sensitive. Observe polarity or install a 1N4007 diode to avoid
inverted activation issues.
Connecting the sounders
Depending on the operating mode, up to four sounder circuits can be connected. See
Table 4 above.
The sounder outputs are powered and supply −15 VDC in standby and +24 VDC
(nominal value) in alarm.
The maximum current consumption for each sounder circuit is shown below.
Two- and four-zone control panels 250 mA
Eight-zone control panel 500 mA
The sounder outputs are supervised for short circuit and open circuit.

Chapter 2: Installation
12 Kilsen KFP-CF Series Installation Manual
Connecting fire routing equipment
Connect fire routing equipment as shown in the table below.
Operating mode Fire routing (automatic) Fire routing (manual)
EN 54-2
EN 54-2 Scandinavia
OUT4 OUT4
NEN 2535 OUT3 OUT4
The fire routing outputs are supervised for short circuit and open circuit.
Note: Fire routing in EN 54-2 operating modes makes no distinction between
automatic and manual alarms.
Connecting the mains power supply
WARNING: Connect the mains power supply before connecting the batteries.
The control panel can be operated at 110 VAC / 60 Hz or 240 VAC / 50 Hz
(+10%/−15%).
Mains power should be sourced directly from a separate circuit breaker in the
building electrical supply distribution board. This circuit should be clearly marked,
have a bipolar disconnect device, and only be used for fire detection equipment.
Feed all mains cables through the appropriate cable knockouts and connect them to
the fuse terminal block as shown in Figure 5 below.
Keep mains cables separate from other cabling to avoid potential short circuits and
interference. Always secure mains cables to the cabinet to prevent movement.
Figure 5: Connecting the mains power supply
1. Mains fuse
2. Live
3. Earth
4. Neutral
For fuse specifications, see Chapter 5 “Technical specifications” on page 49.

Chapter 2: Installation
Kilsen KFP-CF Series Installation Manual 13
Selecting 115 or 230 VAC operation
WARNING: An incorrect power setting can destroy the power supply.
Power switching for 115 or 230 VAC operation is automatic for two- and four-zone
control panels and no configuration is required.
For eight-zone control panels, the default power setting is 230 VAC. For 115 VAC
operation, use a small screwdriver to change the power setting switch, located on the
side of the power supply unit, as shown in Figure 6 below.
WARNING: Always disconnect the control panel from the mains supply before
changing the power setting.
Figure 6: Selecting 115 or 230 VAC operation

Chapter 2: Installation
14 Kilsen KFP-CF Series Installation Manual
Connecting the batteries
The control panel requires two 12 V, 7.2 or 12 Ah rechargeable, sealed, lead-acid
batteries (see “Compatible batteries” on page 47).
Batteries must be installed in series, at the base of the control panel cabinet. Use the
battery lead and bridge provided and connect batteries to the BATT connector on the
control panel PCB, as shown below. Polarity must be observed.
Note: If the control panel indicates a Supply Fault, then the batteries may need to be
replaced. See “Battery maintenance” on page 47.
Figure 7: Connecting the batteries
Caution: No other equipment may be connected to the BATT connector.
Other connections
Connecting auxiliary equipment
Connect the auxiliary equipment to 24 AUX as shown in Figure 4 on page 9. The
24 VDC auxiliary output is supervised for short circuit and voltage output.
Connecting alarm and fault relays
Connect the alarm and fault equipment to the ALARM and FAULT relays.
Each potential-free relay output will be activated in an alarm or fault situation
respectively. The fault relay output is powered when there is no fault.
The maximum contact rating for each relay circuit is 2 A / 30 VDC.

Kilsen KFP-CF Series Installation Manual 15
Chapter 3
Configuration and
commissioning
Summary
This chapter includes information on how to configure and commission the control
panel. Configuration is divided in basic configuration and advanced configuration
options.
Content
The user interface 16
User interface for two- and four-zone
control panels 16
User interface for eight-zone control
panels 17
Access levels and passwords 18
Configuration overview 20
Configuration controls 20
Common configuration tasks 22
Basic configuration 24
The basic configuration menu 24
Basic default configuration 25
Operating mode 26
Sounder delay 27
Fire routing delay 28
Extended fire routing delay 29
Add an expansion module 30
Advanced configuration 31
The advanced configuration
menu 31
Sounder operation during a zone
test 32
Sounder re-sound 33
Sounder synchronization 33
Zone configuration 34
Zone delay 35
Zone type 36
Changing access level passwords 37
Auxiliary 24 V reset 38
Configuration, software, and PCB
identification 38
Expansion module configuration 39
Add an expansion module 39
Expansion module configuration 39
Commissioning 42
Before commissioning the control
panel 42
Commissioning the control panel 42
Functional tests 44
Response times 44

Chapter 3: Configuration and commissioning
16 Kilsen KFP-CF Series Installation Manual
The user interface
User interface for two- and four-zone control panels
Figure 8: User interface for two- and four-zone control panels
1. Zone buttons and LEDs (Z1, Z2, etc.)
2. Supply LED
3. General Fault LED
4. General Fire Alarm LEDs
5. Sounder Fault/Disable/Test button
and LED
6. Sounder Delay button and LED
7. Network Fault LED
8. Service Detector LED
9. Expansion I/O Fault/Disabled LED
10. General Disable button and LED
11. General Test button and LED
12. Configuration controls
13. Reset button and LED
14. Panel Silence button and LED
15. Sounder Start/Stop button and LED
16. System Fault LED
17. Out of Service LED
18. Earth Fault LED
19. Supply Fault LED
20. Fire Routing Delay button and LED
21. Fire Routing Start and
Fault/Disable/Test button and LEDs
Note: Two-zone control panels do not include fire routing.
