GE NetworX Series Installation manual

NetworX™Series
NX-216E Zone Expander Module
Installation and Startup

© 2009 GE Security
All rights reserved.
These instructions do not purport to cover all details or variations in equipment nor to provide every
possible contingency to be met during installation, operation, and maintenance. If further information is
desired or if particular problems arise that are not covered sufficiently for the purchaser’s purpose, the
matter should be referred to GE Security.
This document contains proprietary information of GE Security and is furnished to its customer solely to
assist that customer in the installation, testing, operations, and/or maintenance of the equipment
described. This document shall not be reproduced in whole or in part nor shall its contents be disclosed
to any third party without the written approval of GE Security.
Please refer to the current GE Security product catalog for detailed warranty information.
Main 800-727-2339 Technical Support 888-437-3287
Outside the US 903-845-6941 Sales & Literature 800-547-2556
Main Fax [phone]
Web: www.gesecurity.com
SAFETY SYMBOL LEGEND
Warning
Indicates a procedure, practice, condition, or statement that, if not strictly
observed, could result in personal injury.
* This symbol indicates electrical warnings and cautions.
Caution
Indicates a procedure, practice, condition, or statement that, if not strictly
observed, could result in damage to or destruction of equipment or property.
** This symbol indicates general warnings and cautions.

Note
Indicates an essential or important procedure, instruction, condition, or
statement.

Tip
Indicates a user tip. Provides helpful information that is not normally defined
in regular use, but from an experienced user.

TABLE OF CONTENTS
I. GENERAL DESCRIPTION.............................................................................................................................4
II. ORDERING INFORMATION.........................................................................................................................4
III. BOARD INSTALLATION ...............................................................................................................................4
IV. WIRING.............................................................................................................................................................5
V. TERMINAL DESCRIPTION...........................................................................................................................5
VI. DIP SWITCH SETTINGS (6 POSITION)......................................................................................................6
VII. ENROLLING THE EXPANDER ....................................................................................................................7
VIII. DEFAULT ZONE CONFIGURATIONS........................................................................................................7
IX. ZONE CONFIGURATION AND PARTITION .............................................................................................9
X. PROGRAMMING WORKSHEETS..............................................................................................................10
XI. SPECIFICATIONS .........................................................................................................................................16
UNDERWRITERS LABORATORIES INFORMATION
The NX-216E is UL approved and listed in accordance with the following UL Standards (US & Canada):
UL365 Police Station Connected Burglar Alarm Units & Systems
UL609 Local Burglar Alarm Units & Systems
UL985 Household Fire Warning Systems
UL1023 Household Burglar Alarm Systems
UL1610 Central Station Burglar Alarm Units
NX-216E Zone Expander 3

I. GENERAL DESCRIPTION
The NX-216E is a microprocessor-controlled 16-zone expander for the NetworX control panels (refer to
Compatibility chart on the back of this manual). Up to five NX-216E zone expander modules can be added to the
NX-8 or NX-8-CF control panels with a maximum zone count of 48 zones. Up to twenty-three expanders can be
added to the NX-8E and NX-8E-CF controls with a maximum zone count of 192 zones. Each expander has an
optional tamper switch and power isolator making it ideal for use in a remote location.
II. ORDERING INFORMATION
PART # DESCRIPTION PART # DESCRIPTION
NX-216E 16 Zone Expander NX-320E Remote Power Supply
NX-8 NX-8V2 Control Panel only (48 zones) NX-408E # 8 Zone Wireless Expansion Module
(UL LISTED PART #60-904)
NX-8-KIT NX-8V2 Control, NX-108E LED Keypad, &
16.5V 40VA Transformer NX-416E # 16 Zone Wireless Expansion Module (UL LISTED PART #60-904)
NX-8E NX-8E Control Panel only (192 zones) NX-448E # 48 Zone Wireless Expansion Module
(UL LISTED PART #60-904)
NX-8E-KIT NX-8E Control, NX-108E LED Keypad, &
16.5V 40VA Transformer NX-508E Eight Output Module
NX-003 Household Fire and Burglar Enclosure NX-870E Fire Supervision Module
NX-003C Commercial Burglar Enclosure
#These wireless devices are UL listed for residential applications only.
Please refer to the GE Security product catalog for warranty details.
III. BOARD INSTALLATION
Inside the can, several 2-holed insertion points have been constructed. This
allows for either vertical or horizontal placementof the modules. Notice that each
insertion point has two sizes of holes -a larger hole and a smaller hole.
Diagram 1: The black plastic PCB guides are grooved on one edge where the
PC board will be seated. The end with the half-moon protrusion fits into the
larger hole. The smaller hole is for the screw.
Diagram 2: Place the first black plastic PCB guide in the top insertion point,
grooved edge downward. The half-moon protrusion will be in the large hole. It
does not require force. Insert one of the provided screw into the smaller hole
(from inside the can) to secure it in place. A screwdriver should reach through
the notch that runs thelength of the guide to tighten thescrew. The second PBC
guide shouldbepositionedoppositethe first (groovededge up)andplaced inthe
lower insertion point, using the same procedures described above. Once
mounted, screw it in securely.
Diagram 3: The PC Board should slide freely in the grooves of both guides.
NX-216E Zone Expander
4

IV. WIRING
Any unused zones must have the EOL resistor across it (unless all eight are
disabled by dip switch 6).
Figure IV—1
V. TERMINAL DESCRIPTION
POS Connect to the KP POS terminal of the NetworX controlpanel (refertoCompatibility charton theback
of this manual). Current draw is 30 mA.
COM Connect to the KP COM terminal of the control panel.
DATA Connect to the KP DATA terminal of thecontrolpanel. (Seethe wiring diagramfor wirespecifications)
TAM Connect as shown on diagram. IF NOT USED, CONNECT TO A COM TERMINAL.
AUX Can be used to power devices directly from the NX-216E. Power is coming from the control panel
therefore the current draw of these devices must be added to the total current draw of the NX-216E.
This output is current limited to 100 mA.
Z9 Connect to one side of zone 9 loop. Connect the other side to COM terminal. Open or short causes
alarm. (See wiring diagram for examples)
COM Common (-) terminal for zones 9 & 10.
Z10 Connect to one side of zone 10 loop. Connect the other side to COM terminal. Open or short causes
alarm. (See wiring diagram for examples).
Z11—Z24 Connect as described for Z9 & Z10.
NX-216E Zone Expander 5

VI. DIP SWITCH SETTINGS (6 position)
The first thing that must be decided is the starting zone ofthis particularzoneexpander. The startingzonemust be
on a boundary of eight (8) zones. The sixteen (16) zones for this module will move out from this starting position.
To set the starting zone, set the dip switch according to the table below:
THE POSITION OF ALL SWITCHES IS ONLY UPDATED WHEN THE NX-216E IS POWERED UP.
BEFORE YOU CHANGE THE POSITION OFTHESE SWITCHES YOU MUSTPOWER DOWN THE EXPANDER.
Starting Zone # Expander # Switch 1 Switch 2 Switch 3 Switch 4 Switch 5
9 22 OFF OFF OFF OFF OFF
9 23 ON OFF OFF
OFF OFF
17 16 OFF ON OFF
OFF OFF
25 17 ON ON OFF
OFF OFF
33 18 OFF OFF ON OFF OFF
41 19 ON OFF ON OFF OFF
49 20 OFF ON ON OFF OFF
57 21 ON ON ON
OFF OFF
65 96 OFF OFF OFF ON OFF
73 97 ON OFF OFF ON OFF
81 98 OFF ON OFF ON OFF
89 99 ON ON OFF
ON OFF
97 100 OFF OFF ON ON OFF
105 101 ON OFF ON ON OFF
113 102 OFF ON ON ON OFF
121 103 ON ON ON ON OFF
129 104 OFF OFF OFF OFF ON
137 105 ON OFF OFF
OFF ON
145 106 OFF ON OFF
OFF ON
153 107 ON ON OFF
OFF ON
161 108 OFF OFF ON OFF ON
169 109 ON OFF ON OFF ON
177 110 OFF ON ON OFF ON
185 111 ON ON ON
OFF ON
Dip switch 6 - Dip switch6 is usedtodisable the secondblockof eight (8) zoneson this zoneexpander. Thiscan
be done if only an eight- (8) zone expander is required in a particular expander location. To disable the second
group of eight (8) zones on this expander, turn dip switch 6 on.
NX-216E Zone Expander
6

VII. ENROLLING THE EXPANDER
The NetworX control panels have the ability to automatically findand storeinmemory the presence of all keypads,
zone expanders, wireless receivers and any other module connected to the data terminal. (Refer to Compatibility
chart on the back of this manual). This allows these modules to be supervised by the control panel. To enroll the
modules enter the Program Mode of the controlpanel (refertothe installationmanual forthespecific controlpanel).
When the Program Mode is exited, it will automatically enroll the devices. The enrolling process takes about 12
seconds, during which time the “Service” LED will illuminate. User codes will not be accepted during the enrolling
process. Once a module is enrolled, if it is not detected by the control, the “Service” LED will illuminate.
VIII. DEFAULT ZONE CONFIGURATIONS
Zones can be programmed to be one of thirty different zone configurations (zone types). Configurations # 17
through 20 can be used for wireless or hardwired zones using European double EOL configuration. The default
zoneconfigurationsarelisted below. These zoneconfigurations canbecustomized byprogramming locations110
to 169.
 All Fire Zones are pre-programmed for UL systems.
 Zone Types 21-30 are applicable to the NX-8E control panels ONLY.
 The expander zones will not follow the Fast Loop Response.
DATA DESCRIPTION OF DEFAULT CONFIGURATION
1 DAY ZONE - Instant when system is armed trouble zone when system is disarmed.
2 24-HOUR AUDIBLE - Creates an instant yelping siren alarm regardless of the armed state of the
panel.
3 ENTRY/EXIT DELAY 1 - A trip will start entry delay 1. The lack of a trip during exit delay will enable
the Automatic Bypass or Instant mode if so programmed.
4 FOLLOWER WITH AUTO-BYPASS DISABLED - This zone will be instant when the system is
armed and no entry or exit delays are being timed. It is delayed during entry and exit delay times.
This zone will not bypass in Stay Mode, nor automatically bypass even if enabled in Segment 1 /
Location 23.
5 INTERIOR FOLLOWER WITH AUTO- BYPASS ENABLED - This zone will be instant when the
system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay
times. This zone will bypass in Stay Mode, and automatically bypass if enabled in Segment 1 of
Location 23.
6 INSTANT - This zone creates an instant alarm whenever it is tripped and the Armed LED is on.
7 24-HOUR SILENT - Creates an instant silent alarm regardless of the armed state of the control
panel. It will not display on the keypad.
8 FIRE - This zone will illuminate the Fire LED and sound the temporal siren each time the zone is
shorted. It will also rapidly flash the Fire LED indicating a trouble if the zone is open.
9 ENTRY/EXIT DELAY 2 - A trip will start entry delay 2. The lack of a trip during exit delay will enable
the Automatic Bypass or Instant mode if so programmed.
10 24-HOUR SILENT SUPERVISED - Creates an instant silent alarm regardless of the armed state of
the control panel. It will display on the keypad.
11 KEYSWITCH ZONE - This zone type will arm and disarm the partition or partitions of the control
panel that resides in each time the zone is shorted. Keyswitch arming will report as user #99.
12 INTERIOR FOLLOWER WITH "CROSS ZONE" ENABLED - This zone will be Instant when the
system is armed and no entry or exit delay is being timed. It is delayed during entry and exit delay
times. If a "Cross Zone" is not being timed it will start a "Cross Zone" timer. If a "Cross Zone" is being
timed it will create an Instant alarm. This zone will bypass in Stay Mode and automatically bypass
when enabled in Segment 1 of Location 23.
13 INSTANT ENTRY GUARD - This zone creates an instant alarm whenever it is tripped and the Stay
LED is off. It will start an entry delay time 2 if it is tripped and the system is armed and the Stay LED
is on.
NX-216E Zone Expander 7

DATA DESCRIPTION OF DEFAULT CONFIGURATION
14 ENTRY/EXIT DELAY 1 WITH GROUP BYPASS ENABLED - A trip will start entry delay 1. This
zone will bypass when the "Group Bypass" command is entered at the keypad. The lack of a trip
during exit delay will enable the Automatic Bypass or Instant mode if so programmed.
15 INTERIOR FOLLOWER WITH GROUP BYPASS ENABLED - This zone will be instant when the
system is armed and no entry or exit delays are being timed. It is delayed during entry/exit delay
times. This zone will bypass when the "Group Bypass" command is entered at the keypad. This zone
will bypass in Stay Mode and automatically bypass even if enabled in Segment 1 / Location 23.
16 INSTANT WITH GROUP BYPASS ENABLED - This zone creates an instant alarm whenever it is
tripped and the Armed LED is on. This zone will bypass when the "Group Bypass" command is
entered at the keypad.
17 ENTRY/EXIT DELAY 1 WITH TAMPER ENABLED - A trip will start entry delay 1. The lack of a trip
during exit delay will enable the Automatic Bypass or Instant mode if so programmed. This
configuration group can be used to enable tamper on a wireless transmitter.
18 INTERIOR FOLLOWER WITH TAMPER AND AUTO-BYPASS ENABLED - This zone will be
instant when the system is armed and no entry or exit delay is being timed. It is delayed during entry
and exit delay times. This zone will bypass in Stay Mode and automatically bypass if enabled in
Segment 1 / Location 23. This configuration group can be used to enable tamper on a wireless
transmitter.
19 INSTANT WITH TAMPER ENABLED - This zone creates an instant alarm whenever it is tripped and
the Armed LED is on. This configuration group can be used to enable tamper on a wireless
transmitter.
20 ENTRY/EXIT DELAY 2 WITH TAMPER ENABLED - A trip will start entry delay 2. The lack of a trip
during exit delay will enable the Automatic Bypass or Instant mode if so programmed. This
configuration group can be used to enable tamper on a wireless transmitter.
Zone Types 21-30 are applicable to the NX8-E control panels ONLY
21 GAS DETECTION- Creates an instant alarm regardless of the armed state of the control panel. It will
display on the keypad and activate the keypad sounder.
22 LOW TEMP DETECTION- Creates an instant silent alarm regardless of the armed state of the
control panel. It will display on the keypad and activate the keypad sounder.
23 HIGH TEMP DETECTION- Creates an instant silent alarm regardless of the armed state of the
control panel. It will display on the keypad and activate the keypad sounder.
24 MANUAL FIRE - This zone will illuminate the Fire LED and sound the temporal siren each time the
zone is shorted. It will also rapidly flash the Fire LED indicating a trouble if the zone is open.
25 CHIME ONLY - Creates no alarm regardless of the armed state of the control panel. It will chime
anytime it is faulted and will display on the keypad. Local only.
26 INTERIOR FOLLOWER DELAY 2 - This zone will be instant when the system is armed and no entry
or exit delay is being timed. It is delayed during entry and exit delay 2 times. This zone will
automatically bypass if enabled in Segment 1 of Location 23.
27 INTERIOR FOLLOWER FORCE ARMABLE - This zone will be instant when the system is armed
and no entry or exit delay is being timed. It is delayed during entry and exit delay 1 times. This zone
will automatically bypass if enabled in Segment 1 of Location 23.
28 ENTRY/EXIT FORCE ARMABLE DELAY 2 - A trip will start entry delay 2. The lack of a trip during
exit delay will enable the Automatic Bypass or Instant mode if so programmed.
29 INTERIOR FOLLOWER WITH ACTIVITY SUPERVISION ENABLED - This zone will be instant
when the system is armed and no entry or exit delay is being timed. It is delayed during entry and exit
delay times. It will send a report if the zone activity time is reached without a change of state. Refer
to Location 40 / Segment 11. This zone will automatically bypass if enabled in Segment 1 of Location
23.
30 ENTRY/EXIT WITH ACTIVITY SUPERVISION ENABLED- A trip will start entry delay 1. It will send a
report if the zone activity time is reached without a change of state. Refer to Location 40 / Segment
11. The lack of a trip during exit delay will enable the Automatic Bypass or Instant mode if so
programmed.
NX-216E Zone Expander
8

IX. ZONE CONFIGURATION AND PARTITION
Theprogrammingfor allzone informationisperformed inthe NetworXcontrolpanels (referto Compatibilitycharton
the back of this manual). For instructions on accessingandprogramming thecontrol panel aswell aschangingthe
characteristics of a configuration group, refer to the installation manual for the corresponding control panel. The
following programming information is taken from the NX-8 Installation Manual.
LOCATION 25 CONFIGURATION GROUP ZONES 1-8
(8 segments, numerical data) Location 25 containsthe ConfigurationGroup(Zone type)forzones 1-9. Segment1
is for zone 1; Segment 8 is for zone 8. Default configurations are found in the table on page 7.
LOCATION 26 PARTITION SELECT ZONES 1-8
(8 segments, feature selection data) Location 26 is used to select the partition(s) that zones 1-8 reside in. A zone
mayresidein any combinationofthe 8 partitions. If a burglary zone resides in more than 1 partition, it will only
be active when all partitions are armed. A zone that resides in more than 1 partition will be reported to its
lowest partition. Location28 has 8segments. Segment 1correspondsto zone 1andSegment 8 correspondsto
zone 8.
Segments 1 - 8:
1 = Partition # 1 3 = Partition # 3 5 = Partition # 5 7 = Partition # 7
2 = Partition # 2 4 = Partition # 4 6 = Partition # 6 8 = Partition # 8
LOCATIONS 27 – 36;
LOCATIONS 170 – 205 (Available on NX-8E only)
These locations contain the Configuration Group and Partition Select for Zones 9 – 192. Use the instructions
associated with Location 25 and 26 to program the remaining locations. Worksheets for these locations are
included for your convenience.
NX-216E Zone Expander 9

X. PROGRAMMING WORKSHEETS
LOC DESCRIPTION DEFAULT DATA
27 ZONES 9 - 16 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
28 ZONES 9 - 16 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 9 10 11 12 13 14 15 16
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
29 ZONES 17 – 24 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
30 ZONES 17 – 24 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 17 18 19 20 21 22 23 24
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
31 ZONES 25 – 32 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
32 ZONES 25 – 32 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 25 26 27 28 29 30 31 32
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
33 ZONES 33 – 40 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
34 ZONES 33 – 40 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 33 34 35 36 37 38 39 40
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NX-216E Zone Expander
10

LOC DESCRIPTION DEFAULT DATA
35 ZONES 41 – 48 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
36 ZONES 41 – 48 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 41 42 43 44 45 46 47 48
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NOTE: THE FOLLOWING LOCATIONS ARE ONLY AVAILABLE ON THE NX8-E PANELS
170 ZONES 49 – 56 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
171 ZONES 49 – 56 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 49 50 51 52 53 54 55 56
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
172 ZONES 57 – 64 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
173 ZONES 57 – 64 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 57 58 59 60 61 62 63 64
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
174 ZONES 65 – 72 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
175 ZONES 65 – 72 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 65 66 67 68 69 70 71 72
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NX-216E Zone Expander 11

LOC DESCRIPTION DEFAULT DATA
176 ZONES 73 – 80 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
177 ZONES 73 – 80 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 73 74 75 76 77 78 79 80
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
178 ZONES 81 – 88 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
179 ZONES 81 – 88 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 81 82 83 84 85 86 87 88
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
180 ZONES 89 – 96 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
181 ZONES 89 – 96 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 89 90 91 92 93 94 95 96
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
182 ZONES 97 – 104 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
183 ZONES 97 – 104 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 97 98 99 100 101 102 103 104
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NX-216E Zone Expander
12

LOC DESCRIPTION DEFAULT DATA
184 ZONES 105 – 112 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
185 ZONES 105 – 112 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 105 106 107 108 109 110 111 112
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
186 ZONES 113 – 120 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
187 ZONES 113 – 120 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 113 114 115 116 117 118 119 120
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
188 ZONES 121 – 128 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
189 ZONES 121 – 128 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 121 122 123 124 125 126 127 128
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
190 ZONES 129 – 136 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
191 ZONES 129 – 136 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 129 130 131 132 133 134 135 136
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NX-216E Zone Expander 13

LOC DESCRIPTION DEFAULT DATA
192 ZONES 137 – 144 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
193 ZONES 137 – 144 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 137 138 139 140 141 142 143 144
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
194 ZONES 145 – 152 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
195 ZONES 145 – 152 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 145 146 147 148 149 150 151 152
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
196 ZONES 153 – 160 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
197 ZONES 153 – 160 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 153 154 155 156 157 158 159 160
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
1
2
3
4
5 5
6 6
7 7
8 8
ZONES 161 – 168 CONFIGURATION GROUP
198 6-6-6-6-6-6-6-6
ZONES 161 – 168 PARTITION SELECT
199
1 2 3 4 5 6 7 8
Segment
Zone 161 162 163 164 165 166 167 168
1 1
2
3
4
5
6
7
8
2
3
4
5
6
7
8
1
2
3
1
4
5
6
7
8
2
3
4
5
6
7
8
1 1 1
2
3
4
5
6
2
3
4
5
6
7
8
2
3
4
5
6
7
8 7 8
1
2
3
4
5
6
7
8
NX-216E Zone Expander
14

LOC DESCRIPTION DEFAULT DATA
200 ZONES 169 – 176 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
201 ZONES 169 – 176 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 169 170 171 172 173 174 175 176
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
202 ZONES 177 – 184 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
203 ZONES 177 – 184 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 177 178 179 180 181 182 183 184
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
204 ZONES 185 – 192 CONFIGURATION GROUP 6-6-6-6-6-6-6-6
205 ZONES 185 – 192 PARTITION SELECT
Segment 1 2 3 4 5 6 7 8
Zone 185 186 187 188 189 190 191 192
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
NX-216E Zone Expander 15

XI. SPECIFICATIONS
OPERATING POWER 12VDC Supplied from NetworX control panel or NX-320E
AUXILIARY POWER Supplied from NetworX control or NX-320E
Current limited to 100mA
CURRENT DRAW 30mA
LOOP RESISTANCE 300 Ohms Maximum
LOOP RESPONSE Selectable 50mS or 500mS
OPERATING TEMPERATURE 32 to 120 degrees F
DIMENSIONS 6.0" Wide
2.125" High
1.0" Deep
SHIPPING WEIGHT 2 lbs.
COMPATIBLE CONTROL PANELS:
NETWORX PANEL MAX NX-216E MODULES MAX ZONE COUNT
NX-8 5 48
NX-8E 23 192
Main 800-727-2339 Technical Support 888-437-3287
Outside the US 903-845-6941 Sales & Literature 800-547-2556
Main Fax [phone] Web: www.ge-security.com
INX216EIM Rev F (January 2009)
