GE NX-1448E - Security NetworX 48-Zone Fixed User manual

NX-1448E
Fixed English Keypad
User’s Manual

Page 2 NX1448E Icon Keypad
SECURITY SYSTEM NOTES
Installing/Service Company _________________________________
For Service Call __________________________________________
Central Station ___________________________________________
Duress Code ____________________
This system is is not partitioned.
EMERGENCY ACTIVATION KEYS (check if enabled)
Fire Auxiliary Emergency Police
PROGRAMMED FUNCTIONS
Abort Delay (s) Cancel Alarm Forced Arming (s)
Auto Bypass (s) Change Partitions Group Bypass (s)
Auto Instant Chime Quick Arm (s)
Battery Test Communicator Test Re Exit
Siren Test
(s)These features should not be enabled on UL listed systems.
ENTRY / EXIT DELAY TIMES
Exit Delay Time __________ Secondary Exit Delay Time ________
Entry Delay Time _________ Secondary Entry Delay Time _______

NX1448E Icon Keypad Page 3
ZONE DESCRIPTIONS
01 _________________________ 25 _________________________
02 _________________________ 26 _________________________
03 _________________________ 27 _________________________
04 _________________________ 28 _________________________
05 _________________________ 29 _________________________
06 _________________________ 30 _________________________
07 _________________________ 31 _________________________
08 _________________________ 32 _________________________
09 _________________________ 33 _________________________
10 _________________________ 34 _________________________
11 _________________________ 35 _________________________
12 _________________________ 36 _________________________
13 _________________________ 37 _________________________
14 _________________________ 38 _________________________
15 _________________________ 39 _________________________
16 _________________________ 40 _________________________
17 _________________________ 41 _________________________
18 _________________________ 42 _________________________
19 _________________________ 43 _________________________
20 _________________________ 44 _________________________
21 _________________________ 45 _________________________
22 _________________________ 46 _________________________
23 _________________________ 47 _________________________
24 _________________________ 48 _________________________

Page 4 NX1448E Icon Keypad
INTRODUCTION
This manual is furnished to help you understand your security system and
become proficient in its operation. All users of your security system
should read and follow the instructions in this booklet and, if possible,
practice on the keypad control while your professional installer is on site.
Failure to do so could result in the security system not working properly.
Please keep this booklet in an accessible location for the life of the
security system. If you do not understand any part of this manual you
should notify your installing company.
The SECURITY CONTROL can be turned on (ARMED) and off (DISARMED)
by entering a 4 or 6 digit code into the Keypad Control, which is similar to
a telephone keypad. If your Security Control has been so programmed,
you may be able to turn on (ARM) your System by simply pressing the
[STAY] or [EXIT] key. The system must always be disarmed using a 4 or 6
digit code. The LED keypad includes up to 60 icons and a built-in
electronic sounder. These provide specific information relating to the
status of the security system which is described in the booklet.
Understanding what the icons and sounds mean will help you easily
operate your system.
Keep in mind, the level of security you will obtain with this system relates
specifically with two major factors:
1. The quantity, quality and placement of security devices attached
to this system.
2. The knowledge you have of the security system and how that
knowledge is utilized in a weekly test of the complete system.
You should be aware of the following facts when preparing a
safety/security plan for your home/business.
 Your security system is an electronic device and is subject to failure
or malfunction. Do not rely on it as your single source of security.
 Your system should be tested weekly.

NX1448E Icon Keypad Page 5
 Your system will not work without power.
 Warning devices will need to be loud enough, wired correctly, and
properly placed to provide notification of an alarm event.
 Smoke and heat detectors may not detect heat and smoke in all
situations.Use qualified security professionals to install and maintain
your security system.
 It may be possible to arm the security system without the backup
battery connected. Your periodic test should be done with AC Power
removed to verify the battery is connected and adequately charged.
 Care should be taken to plug in and restrain the AC Transformer after
testing.
Please read the following information and instructions carefully
before operating your security control system.

Page 6 NX1448E Icon Keypad
TABLE OF CONTENTS
GLOSSARY OF TERMS .......................................................................8
ICON KEYPAD DISPLAY ....................................................................9
EMERGENCY ACTIVATION KEYS .....................................................10
UNDERSTANDING THE ICONS & LIGHTS.........................................11
ARMED ICON ................................................................................. 11
BYPASS LIGHT............................................................................... 11
CANCEL LIGHT .............................................................................. 11
CHIME LIGHT ................................................................................ 11
EXIT LIGHT ................................................................................... 11
FIRE ICON .................................................................................... 11
INSTANT ICON .............................................................................. 12
LISTEN-IN ICON ............................................................................ 12
POWER ICON................................................................................. 12
READY / NOT READY ICON .............................................................. 12
SILENCED ICON............................................................................. 12
STAY LIGHT .................................................................................. 12
TAMPER/TROUBLE ICONS ............................................................... 12
ZONE ICON ................................................................................... 12
KEYPAD FUNCTIONS ......................................................................13
ARMING YOUR SYSTEM IN THE “AWAY” MODE................................... 13
ARMING YOUR SYSTEM IN THE “STAY” MODE .................................... 14
USING THE QUICK ARM ................................................................. 15
CHANGING MODES WHILE SYSTEM IS ARMED ................................... 15

NX1448E Icon Keypad Page 7
(Table of Contents continued…)
DISARMING THE SYSTEM................................................................ 15
CANCEL / ABORT FEATURE ............................................................. 16
BYPASSING ZONES ........................................................................ 16
GROUP BYPASS ............................................................................. 16
UNBYPASSING............................................................................... 17
TURNING THE DOOR CHIME ON AND OFF ......................................... 17
CHANGING USER CODES.................................................................17
ASSIGNING USER CODE AUTHORITY LEVELS..................................18
OTHER KEYPAD FUNCTIONS ...........................................................20
SETTING THE KEYPAD TONE............................................................ 20
CHANGE PARTITION – Optional........................................................ 20
VIEW ALARM MEMORY .................................................................... 20
TEST FUNCTION – Optional ............................................................. 21
RESET FUNCTION .......................................................................... 21
SET SYSTEM DATE ......................................................................... 21
SETTING THE SYSTEM CLOCK.......................................................... 22
SETTING THE KEYPAD LIGHTING ..................................................... 23
SERVICE MENU ...............................................................................23
KEYPAD CONTROL TONES (BEEPS) .................................................25
EMERGENCY EVACUATION PLANS...................................................26

Page 8 NX1448E Icon Keypad
GLOSSARY OF TERMS
Abort Delay An option that allows a delay in reporting to the
central station.
Authority Level The level of access an individual has when using
an alarm panel.
Central Station The location where alarm data is sent during an
alarm report.
Chime Feature An option that allows the keypad to sound a
ding-dong whenever an entry/exit door is
opened.
Codes Can be either User Codes (relating to a person)
or Function Codes (a toggle switch to turn
specific functions on/off). NOTE: A system may
have either 99 four-digit codes or 66 six-digit
codes, but not a mixture of the two.
Duress Code An option that allows a special code to be sent to
the central station that indicates the alarm
system is being operated under duress.
Forced Arming An option that allows the system to be turned on
(ARMED) with one or more zones open. A system
that is ready to be “force armed” will flash the
ready icon. (Note: Those zones that are not
ready will not create an alarm.)
Function Code A Function Code is either a four (4) or six (6)
digit code that has been programmed by the
installer to operate a device.
Group Bypass An option that allows the user to bypass multiple
zones with a single operation.
Instant/Delay An option that allows an instant alarm condition
for Entry/Exit doors, or grants a delay to allow
someone to enter/exit the building without an
alarm, or before entering a user code to disarm.
Master Code A master arm/disarm code that can program
other user codes.

NX1448E Icon Keypad Page 9
Partitioned System A system divided into multiple areas in which its
own user or users control each area.
Perimeter The outer edge of the protected area.
Quick Arm An option that allows you to turn on (ARM) the
security system by pressing either the [STAY] or
[EXIT] key on the keypad control (for ARMING
only) as programmed by the installing company.
User Code A four (4) or six (6) digit entry code used to arm
or disarm the system.
ICON KEYPAD DISPLAY
Armed
Instant
Ready
FIRE
Power
Service
Enter Code Silenced
Trouble Tamper
12345678910111213141516
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
33 34 35 36 37 38
39 40 41 42 43 44 45 46 47 48
ALARM
Listen-in
Not

Page 10 NX1448E Icon Keypad
EMERGENCY ACTIVATION KEYS
NOTES: You must hold these keys for 2 seconds to activate these
functions. Your system may not be programmed for these activation keys
(see page 1). You should press these keys only in an emergency situation
that requires response by emergency personnel. If your system is
programmed for these functions, the following reports can be sent.
Fire Key – This key can activate the fire alarm when pressed for two
seconds. If your system is connected to a monitoring center, an
emergency report could be sent to that center.
Auxiliary Emergency Key – This key can activate the auxiliary alarm
when pressed for two seconds. If your system is connected to a
monitoring center, an emergency report could be sent to that center.
Police (Panic/Hold-Up) Key - This key can sound a local audible alarm
when pressed for two seconds. If your system is connected to a
monitoring center, an emergency report could be transmitted to that
center. NOTE: Some Panic/Hold-Up alarms are programmed to be silent
at the protected site while reporting an alarm to the monitoring center.
Check with your installing company to determine how your security
system will respond to the Panic/Hold-Up activation.

NX1448E Icon Keypad Page 11
UNDERSTANDING THE ICONS & LIGHTS
ARMED ICON
The armed icon is “on” when the system is armed. The armed icon is
“off” when it is disarmed. The armed icon will flash when there has
been an alarm during the previous arm cycle.
BYPASS LIGHT
The bypass light is “on” when any zone in this keypad’s partition is
bypassed. The zone(s) that is bypassed will also be illuminated. If the
bypass light is “off”, no zones are bypassed.
CANCEL LIGHT
The cancel light will flash during an abort delay time. If a code is
entered followed by the [CANCEL] key while this light is flashing, all
abortable reports will stop the communication process. Note: The abort
feature must be enabled. Entering a code followed by the [CANCEL]
key during or after an alarm report to the central station will cause the
cancel light to come on. It will stay on until the central station has
received the cancel report. Note: The cancel feature must be
enabled.
CHIME LIGHT
The chime light is “on” when the chime feature is “on”; “off” otherwise.
EXIT LIGHT
The exit light is “on” during the exit delay. Please note that the light will
flash during the last 10 seconds of the exit delay as a warning that the
time is running out. (The user may want to disarm the system if the
exit light is flashing in order to prevent an alarm. The user may then re-
arm the system and exit before the delay expires.)
FIRE ICON
A steady fire icon means a fire zone has been faulted. A rapidly flashing
fire icon means that a fire zone is in a trouble condition.

Page 12 NX1448E Icon Keypad
INSTANT ICON
The instant icon is “on” when there is no delay on your entry/exit
door(s). Any time the instant icon is “on” and the exit delay has expired,
the opening of an entry/exit door will produce an immediate alarm. The
instant icon can be toggled on or off by pressing the [Stay] key while
the system is armed. When the instant icon is “off”, the entry/exit
door(s) is delayed.
LISTEN-IN ICON
Listen-in icon is on when an NX-534 is active in listen-in mode.
POWER ICON
The power icon is on if the primary power is on. The power icon will flash
if the system has a low battery condition.
READY / NOT READY ICON
The ready icon is “on” when the system is ready to arm and “flashes” if
ready to force arm. The not ready icon is on when the system is not
ready to arm because of a zone(s) being faulted.
SILENCED ICON
The silenced icon appears after a code has been entered to silence the
siren but the zone has not been cleared.
STAY LIGHT
The stay light is “on” when all interior (motion detector) zones are
bypassed.
TAMPER/TROUBLE ICONS
The tamper or trouble icon is on when a zone(s) is tampered or in
trouble. Press [r]–[2] and refer to the Service Menu section on page 23
of this manual for further instructions.
ZONE ICON
The zone icons are “off” when everything is normal. A zone icon will be
“on” if the zone has been bypassed. If a zone icon is “flashing”, that
zone is in alarm or has been faulted. If a zone icon is “flashing” rapidly,
it means that the zone is in a trouble condition.

NX1448E Icon Keypad Page 13
Trouble conditions are:
 Tamper  Hardware  Low Battery  Loss of Supervision
(A combination of Alarm/Fault and Tamper/Trouble will produce a rapid
“flashing” light for a short period of time, followed by a slow “flashing”
light.)
KEYPAD FUNCTIONS
ARMING YOUR SYSTEM IN THE “AWAY” MODE
AWAY is used when the user is away from the premise and wants the
interior protected.
Close all protected doors and windows.Step 1
• Ready icon will be on or flashing when all protected zones and
sensors are secure. NOTE: If any zones are bypassed, a sensor
in that zone can be violated without affecting the ready icon.
• The security system will not arm if the not ready icon is on o
r
flashing.
• If the power icon is off, you have no AC power. Restore power i
f
possible. If not, contact your installing company listed on page 1
of this booklet for service.
Step 2 Enter your 4 or 6 digit user code to arm the system.
• The armed icon and exit light will illuminate.
• You may now leave the building.
NOTE: The exit light will flash rapidly for the last 10 seconds of the exit
delay as a warning to the user that the exit time is about to expire. The
user may wish to disarm and rearm the system if more time is needed.

Page 14 NX1448E Icon Keypad
ARMING YOUR SYSTEM IN THE “STAY” MODE
STAY is used when the user is inside the premise and wants protection
around the perimeter.
Close all protected doors and windows.Step 1
• Ready icon must be on or flashing when all protected zones and
sensors are secure. NOTE: If any zones are bypassed, a sensor in
that zone can be violated without affecting the ready icon.
• The security system will not arm if the not ready icon is on or
flashing.
• If the power icon is off, you have no AC power. Restore power if
possible. If not, contact your installing company listed on page 1
of this booklet for service.
Step 2 • Enter your 4 or 6 digit user code.
• If “Auto Bypass” is enabled, all interior zones will be bypassed if
you do not leave through a designated entry/exit door. If Auto
Bypass is enabled, omit Step 3.
• When “Auto Instant” is enabled, if you do not leave through a
designated entry/exit door the instant icon will illuminate
indicating that the entry/exit doors no longer have an entry delay.
If “Auto Instant” is enabled, omit Step 4.
Step 3 • Press the [STAY] key.
• The stay light will illuminate indicating that all interior zones are
bypassed. (All interior devices will bypass automatically, giving
the user freedom of movement within the interior area.)
• The bypass light will illuminate if any zone(s) are bypassed. If any
zone(s) have been bypassed previously by the user, the icon(s)
corresponding to the bypassed zone(s) will illuminate, alerting the
user that a zone(s) may be unprotected and can be faulted
without an alarm.

NX1448E Icon Keypad Page 15
Step 4 • To toggle from a “delayed entry” mode to an “Instant” mode,
press the [STAY] key again.
• The instant icon will illuminate indicating that the entry/exit doors
have no entry delay.
USING THE QUICK ARM (Optional, see page 1)
The Quick Arm feature may be used if it is enabled. Quick Arm will allow
the user to arm the security system in the AWAY mode by pressing the
[EXIT] key, or arm in the STAY mode by pressing the [STAY] key. This
feature is used for ARMING ONLY, and will not disarm the security system.
This is ideal for a maid or baby sitter code, etc.
CHANGING MODES WHILE SYSTEM IS ARMED
 Pressing the [STAY] key will turn on/off (toggle) a delay on entry/exit
doors and turn on/off (toggle) the instant icon.
 (Optional) Press the [BYPASS] key at this time to turn on/off (toggle)
all designated interior zones.
 (Optional) When armed, pressing the [EXIT] key will start the exit
delay, enabling you to leave the building.
IMPORTANT!
The instant icon needs to be off at this time if you plan on re-entering
the building; otherwise you will create an alarm. You may restore an
entry delay by pressing the [STAY] key again.
DISARMING THE SYSTEM
When you enter the protected area through one of the designated
Entry/Exit doors, the keypad control will sound a continuous tone for the
duration of the entry delay time, or until you enter a valid code. The
armed icon will go off and the tone will stop. The security system is now
DISARMED. If a valid code is not entered before the end of the entry
delay, an alarm will occur. (NOTE: If the armed icon is flashing during
the entry delay, the alarm system has been activated in your

Page 16 NX1448E Icon Keypad
absence. Leave the building immediately and call your alarm
company and/or the police from a safe location.)
CANCEL / ABORT FEATURE (Optional, see page 1)
The cancel light will flash during an abort delay time. If a code is entered
followed by the [CANCEL] key while this light is flashing, all abortable
reports will stop the communication process. Entering a code followed by
the [CANCEL] key during or after an alarm report to the central station
will cause the cancel light to come on. It will stay on until the central
station has received the cancel report.
BYPASSING ZONES
If you wish to bypass one or more zones, this must be done while the
system is in the disarmed state. The following steps are used for
bypassing zones:
Step 1 Press the [BYPASS] key.
Step 2 Enter user code, if required (optional). The bypass light flashes.
Step 3 Enter 1 or 2 digits indicating the zone you wish to bypass, i.e.
press the [1] key for zone 1, press [1]-[2] for zone 12.
Step 4 Press the [BYPASS] key again.
Step 5 The corresponding zone icon will illuminate indicating the zone
has been bypassed. Repeat steps 3 and 4 for any other zone(s)
that need to be bypassed.
Step 6 Press the [BYPASS] key again -or- press the [#] key to exit
the Bypass Mode. The bypass light will stop flashing upon
exiting the Bypass Mode.
GROUP BYPASS
By pressing the [BYPASS] key, followed by the [0] key, then the
[BYPASS] key again, all zones that are designated as group bypass zones
will be bypassed. Press the [BYPASS] key again -or- press the [#] key to
exit group bypassing.

NX1448E Icon Keypad Page 17
UNBYPASSING
To manually unbypass zones, perform the bypassing procedure on a zone
that is already bypassed. The corresponding icon for that zone will go off
when unbypassed. NOTE: All zones will automatically be unbypassed
each time the system is disarmed.
TURNING THE DOOR CHIME ON AND OFF
The door chime is turned on or off by pressing the [CHIME] key while the
system is in the disarmed state. If the chime is on the chime light will be
illuminated. If the chime is off, the chime light will be off. Each press of
the [CHIME] key will toggle the chime feature on/off and produce a
momentary ding-dong sound.
ADDING AND CHANGING USER CODES
Your system must be Disarmed to change user codes.
Step 1 Press [r]-[5]
Step 2 The Enter Code icon will display. Enter a [“Master
Arm/Disarm” Code].
NFor partitioned systems, someone changing the code of
another person must have access to all or more
partitions than the user being changed.
Step 3 The Ready icon will flash.
Step 4 Enter the 2-digit “user number”.
(Always enter 2 digits such as [0]-[3] for user 3.)
Step 5 The instant icon will flash and zone icons will illuminate specifying
the first digit of the “user code”.

Page 18 NX1448E Icon Keypad
 When all icons are all illuminated = code is blank; when all
icons are off = “0”.
 Use the [•] and [–] keys to view the next digit or enter new
4- or 6-digit “user code”.
 While using the [•] and [–] keys, you can change any digit
by entering a new digit. This will advance you to the next
digit.
To delete a user code, enter [r]-[r]-[r]-[r] for a 4-digit code,
or [r]-[r]-[r]-[r]-[r]-[r] for a 6-digit code.
Step 6 The ready icon will flash indicating you are back at Step 2 above.
If the code is rejected, the sounder will beep 3 times.
Step 7 If another “user code” needs to be programmed, return to Step
4.
Step 8 Press the [#] key while the ready icon is flashing to exit the User
Code Programming Mode.
ASSIGNING USER CODE AUTHORITY LEVELS
Assign authority levels to users by following the steps below. Assign user
codes before assigning authority levels.
Step 1 Press [r]-[6]-[“Master Arm/Disarm Code”].
NSomeone changing the authority of another person can
only add or remove partition authorization for
partitions to which they have access.
Step 2 The ready icon will flash.
Step 3 Enter the 2 digit “user number” to be assigned authority (The
ready icon is constant and the instant icon will flash).
Step 4 Icons illuminated indicate the authority levels assigned to this
code. An explanation of the icons is listed in the following table.
You may toggle (turn on/off) the authority level by pressing the
number for that authority level.

NX1448E Icon Keypad Page 19
ICON AUTHORITY LEVELS IF ICON 8 IS OFF
1 Reserved (Note: Do not change if on.)
2 Arm Only
3 Arm Only After Closing Time
4 Master Arm/Disarm (can program other codes)
5 Arm/Disarm
6 Bypass Zones
7 Open / Close Reporting
8 If this icon is on, this code is programmed as a
function code. Do not change! Press [#] - [#] to exit.
Step 5 Press the [r] key. The ready icon is on constant and instant icon
is on constant. This moves you to the partition enable. (The user
has access in partitions that are illuminated.)
Step 6 The illuminated numbers indicate each partition where the user
has access. To change any of the partitions where the user has
access, press numbers corresponding to areas where you want to
give the user access or deny access. (Example: If zone icon #2
is lit, then the user is assigned access to partition #2. By
pressing the [2] key, the icon will go off, denying access to
partition #2. Refer to the following chart.
ICON PARTITIONS ASSIGNED
1 Partition 1
2 Partition 2
3 Partition 3
4 Partition 4
5 Partition 5
6 Partition 6
7 Partition 7
8 Partition 8

Page 20 NX1448E Icon Keypad
Step 7 When the partitions are assigned, press the [r] key. This returns
you to Step 2 previously mentioned. At this point you may enter
another user number to assign authority level. Repeat Steps 3 -
7 until you have assigned authority levels to all user numbers.
Step 8 Press the [#] key to exit the Assigning Authority Level Program.
OTHER KEYPAD FUNCTIONS
SETTING THE KEYPAD TONE
Step 1 Press [r]-[0]. Keypad is now in the “Adjust Tone” mode.
Step 2 Pressing the [•] key will make the keypad sounder go to higher
tones, pressing the [–] key will make the keypad sounder go to
lower tones.
Step 3 When the desired tone is reached, press the [#] key to set this
tone and exit from the “Adjust Tone” mode.
CHANGE PARTITION – Optional
Step 1 Press [r]-[1].
Step 2 Press a NUMBER key between 1 and 8 to change partitions
momentarily.
Step 3 If no other key is pressed, it will go back to its standard
partition in ten seconds.
Step 4 If another key is pressed, the system will remain in the new
partition until no keys have been pressed for 60 seconds.
VIEW ALARM MEMORY
Step 1 Press [r]-[3]. The zone(s) that created the last alarm will be
displayed along with the alarm icon flashing on the keypad.
