Design Guide with
Installation
Instructions
monogram.com
Wine Reserve
ZDWT240
and
Beverage Center
ZDBT240

Safety Information
2
CON EN S
Design Guide
The Installation Space ............................. 3
Product Clearances................................... 3
Installation Instructions
Tools, Hard are ..........................................4
Grounding the Product ............................4
Staining Wood Dra er Fronts..............4
Step 1, Remove Packaging .................... 4
Step 2, Leveling ...........................................5
Step 3, Connect Po er ............................ 5
Step 4, Slide Product into Cutout ........5
Step 5, Change the Toekick ...................5
Step 6, Set Temperature Controls ...... 5
BEFORE YOU BEGIN:
Read these instructions completely and carefully.
IMPOR AN – Save these instructions
for local inspector’s use.
IMPOR AN – Observe all governing codes
and ordinances.
Note to Installer – Be sure to leave these
instructions ith the Consumer.
Note to Consumer – Keep these instructions ith
your O ner’s Manual for future reference.
WARNING – This appliance must be properly
grounded. See “Grounding”, page 4.
AVER ISSEMEN –
Cet appareil doit être correctement mise à la terre.
Consulter <<Mise à la terre>>, page 4.
If you received a damaged ine reserve or beverage
center, you should immediately contact your dealer
or builder.
Skill Level – Installation requires basic mechanical skills.
Proper installation is the responsibility of the installer.
Product failure due to improper installation
is not covered under the GE Appliance Warranty.
WARNINGS:
• Use this appliance only for its intended purpose.
• Immediately repair or replace electrical service cords
that become frayed or damaged.
• Unplug the unit before cleaning or making repairs.
• Repairs should be made by a qualified service
technician.
AVER ISSEMEN :
• Il ne faut utiliser cet appareil que pour l’usage pour
lequel il a été construit.
• Il faut réparer ou remplacer immédiatement tout
cordon d’alimentation électrique effiloché ou
endommagé.
• Débrancher le bar ou le réfrigérateur a vin avant
le nettoyage ou toute intervention.
• Les réparations doivent être faites par un technicien
qualifié.
For Monogram local service in your area,
call 1.800.444.1845
For Monogram service in Canada, call
1.800.561.3344
For Monogram Parts and Accessories, call
1.800.626.2002.
www. monogram.com

Design Guide
HE INS ALLA ION SPACE
he cutout depth should be 24″
The cutout dimensions sho n allo for a full door s ing
and access to the pull-out racks hen installed as a
built-in in standard 24″ deep cabinets.
• The ine reserve and beverage center can be
installed freestanding.
• If installing bet een frameless cabinets, a 1/2″ ide
filler strip or side panel may be needed on hinge side.
The filler strip ill act as a spacer bet een the case
and adjacent cabinet door s ing. The idth
of the opening must include the filler panels.
NO E: The door should protrude 1″ beyond the
surrounding cabinets.
Additional Specifications
• A 120 volt 60Hz., 15 or 20 amp po er supply is
required. An individual properly grounded branch
circuit or circuit breaker is recommended. Install a
properly grounded 3-prong electrical receptacle
recessed into the back all as sho n. Electrical must
be located on rear all as sho n. NO E: GFI (ground
fault interrupter) is not recommended.
PRODUC CLEARANCES
The ine reserve and beverage center is factory set
for a 110° door s ing.
When installed in a corner:
• Allo 4″ min. clearance on the hinge side for the 90°
door s ing and to allo racks to slide out.
• Allo 10″ minimum clearance on the hinge side
for a full 110° door s ing.
Choose the location:
• These products may be closed in on the top and three
sides as long as the front is unobstructed for air
circulation and proper access to the door.
• Do not install these products here the temperature ill
go belo 55°F (13°C) or above 90°F (32°C).
• Do not install here it ill be subject to direct sunlight,
heat or moisture.
• These products are not designed to be stacked one
over the other.
Black or Stainless Steel oekick Options
• These products are shipped ith a black toekick
installed. An optional stainless steel toekick is also
supplied ith each product. For shipping purposes,
the stainless steel toekick is secured to the back
or inside the unit.
3
90°Door Swing
10" Minimum
to Wall
110°
21-5/8"
23-5/8"
4" Minimum
to Wall
90°
23-3/4"
34-1/4"
23-3/4"
Locate
Outlet
34-1/2"-35"
24"
23-3/4" Min.
9" Max.
10-1/2"
1-1/2"
34-3/4"
to
NO E:
Handle and
handle
standoff depth
is 1-3/4″
SIDE-BY-SIDE INS ALLA IONS
Increase storage capacity by installing t o Monogram
beverage centers or ine reserves together. Or, for a
complete refreshment center, install any t o of these
units together.
• A side-by-side installation requires at least a 47-1/2″
ide opening. No trim kits required.
• Products must operate from separate, properly
grounded receptacles.
34-1/2"-35"
24"
47-1/2" Min.
1-1/2"
9"
10-1/2"
9"
10-1/2" 14"
15"
Locate
Outlet

Installation Instructions
4
OOLS REQUIRED
• #2 Phillips scre driver
• Adjustable rench
PAR S SUPPLIED
• Optional stainless steel toekick ith scre s
and spacers
GROUNDING HE WINE CHILLER,
WINE RESERVE AND BEVERAGE
CEN ER
IMPOR AN – Please read carefully.
FOR PERSONAL SAFETY, THIS APPLIANCE MUST BE
PROPERLY GROUNDED.
The po er cord of this appliance is equipped ith
a three-prong (grounding) plug hich mates ith a
standard three-prong (grounding) all receptacle
to minimize the possibility of electric shock hazard
from this appliance.
Have the all outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong all outlet is encountered, it
is your personal responsibility and obligation to have it
replaced ith a properly grounded 3-prong all outlet.
DO NOT, UNDER ANY
CIRCUMSTANCES, CUT
OR REMOVE THE THIRD
(GROUND) PRONG
FROM THE POWER CORD.
DO NOT USE AN ADAPTER PLUG TO CONNECT THE
REFRIGERATOR TO A 2-PRONG OUTLET.
DO NOT USE AN EXTENSION CORD WITH THIS
APPLIANCE.
S EP 1 REMOVE PACKAGING
• Remove corner blocks and foam dra er stops.
• Remove all packing material, tape and protective
plastic coverings.
• Remove stainless steel toekick taped to the back
or inside of the unit.
CAU ION: Small objects are a choke hazard
for children. Remove and discard any parts not used.
MISE EN GARDE : Les petits objets
peuvent étrangler les enfants. Il faut jeter toutes les
piéces qui ne sont pas utilisées.
S AINING WOOD DRAWER FRON S
The dra er fronts are unfinished cherry ood.
During use, oil from hands may accumulate and stain
the ood.
• The dra er fronts may be stained and sealed to
match adjacent cabinetry. The tinted glass ill make
the stained ood appear darker. A true color match
can be seen only hen the door is opened.
• Apply the stain and sealer according to the
manufacturer’s instructions. To avoid unpleasant
odor, keep the door open to ventilate and allo
the stain/sealer to dry completely before using
the product.

5
S EP 2 LEVEL
• Use an adjustable rench to turn the leveling legs and
raise or lo er the product.
• Adjust carefully; the product should be level and plumb
ith cabinetry, and should align ith adjacent toekick
height.
S EP 4 SLIDE PRODUC IN O
HE CU OU
WARNING: Do not apply pressure or push
against the glass door hen moving or installing these
products. Pressure against the glass door ill cause
damage.
AVER ISSEMEN : Ne poussez
jamais et ne mettez jamais de pression sur la porte
en verre quand vous déplacez ou installez ces produits.
Toute pression sur le verre occasionnera des
dommages.
• Carefully slide the unit into the opening. Be careful
not to entangle po er cord.
• Make certain that the door protrudes 1″ beyond
the surrounding cabinets.
• Check again to be sure the unit is level.
S EP 3 CONNEC POWER
• Connect po er cord plug to a properly grounded
receptacle.
• Check to make sure po er is on by opening the door
to see if interior light turns on.
S EP 5 CHANGE HE OEKICK
• The stainless steel toekick is secured to the back
of the product or inside.
• The toekick has a
cutout on the left
and right sides.
Remove
the plug on
the left
side and
reinstall
on the
right side.
If you
choose to
install the
stainless steel toekick,
reinstall the plug on the right side
of that toekick.
• Install original scre s and spacers or scre s and
spacers supplied ith the stainless steel toekick. Install
scre s through the spacer standoff, toekick and into
the base as sho n.
S EP 6 SE EMPERA URE
CON ROLS
• The temperature controls are preset. Refer to the
O ner’s Manual for more information. Allo 24 hours
for temperature to stabilize.
Turn Right to Lower
Turn Left to Raise
Installation Instructions
Move Fill
Plug to
Right Side

6
Notes

7
Notes

Note: While performing installations described in this book,
safety glasses or goggles should be orn.
For Monogram® local service in your area, call
1.800.444.1845.
Note: Product improvement is a continuing endeavor at
General Electric. Therefore, materials, appearance and
specifications are subject to change ithout notice.
Pub. No. 31-46065-1
Part No. 197D6374P001
09-07 JR
Printed in Slovenia
