Chapter 1

Calibration
Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Menu Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Calibrating the Analog Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Calibrating the Analog Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
Alarms Option Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Totalizer/Frequency Option Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12

Calibration 1-1
March 2008
Introduction Calibrating the Model DF868’s analog outputs and inputs is
explained in this chapter. In addition, testing the optional totalizer/
frequency and alarm relay outputs is discussed. The following
specific topics are included:
•calibrating the built-in Slot 0 analog outputs
•calibrating optional Slot 1 through Slot 6 analog outputs
•calibrating optional Slot 1 through Slot 6 analog inputs
•testing optional Slot 1 through Slot 6 alarm relays
•testing optional Slot 1 through Slot 6 totalizer/frequency outputs.
The Model DF868 electronics console includes six expansion slots
for the installation of option cards. These slots are numbered 1-6,
from right to left. In addition, every Model DF868 flowmeter
includes two built-in analog outputs (A and B) at terminal block I/O,
which is designated as Slot 0.
Note: Convention in this manual identifies any expansion slot as Slot
x, where xis a number from 0-6.
See Chapter 1, Installation, of the Startup Guide for a complete
description of the available option cards and the procedures for
wiring them.
Menu Map The Calibration Menu is accessed by pressing the [CAL] key on the
keypad. Use this menu to calibrate and test the Slot 0 analog outputs,
as well as to calibrate and test any option cards that are installed in the
expansion slots. Refer to the menu map in Figure 1-6 on page 1-15 as
a guide in following the calibration instructions.
Note: The same instructions apply to both the 1-Channel and 2-
Channel versions of the Model DF868 flowmeter.
The following discussion assumes that the left screen pane is active.
If the right screen pane is active, only the function key designations
change. That is, replace [F1]-[F4] with [F5]-[F8]. Proceed to the
appropriate sections of this chapter to calibrate and test all of the
installed inputs and/or outputs.
Note: While in the Calibration Menu, if there is no keypad activity
for two minutes, the Model DF868 will automatically reboot
and return to measurement mode.

March 2008
1-2 Calibration
Calibrating the Analog
Outputs
Every Model DF868 flowmeter includes two built-in analog outputs
(A and B) at terminal block I/O, which is designated as Slot 0. Both the
zero-point and full-scale values for each output must be calibrated.
After calibrating the outputs, which have a resolution of 5.0 μA
(0.03% full scale), their linearity should be tested.
Note: The zero point of the analog output may be set for either 0 mA
or 4 mA. However, the calibration procedure always uses the 4
mA point, as the meter will extrapolate this value to obtain the
0 mA point.
Prepare for the calibration procedure by connecting an ammeter to
analog output A of Slot 0, as shown in Figure 1-1 below. Refer to the
menu map in Figure 1-6 on page 1-15.
Figure 1-1: Ammeter Connection (Output A)
Press the [CAL] key to enter the Calibration Program:
CALIBRATION ‰Press [F1] to calibrate Slot 0. (The
option bar will include a slot
listing for each installed option
card.)
Cal
last slot selected
SLOT0 SLOT1 SLOT2 SLOT3
Terminal Block I/O (Slot 0)
B
RTN B
SIG A RTN A SIG
41
+
-
Ammeter

Calibration 1-3
March 2008
Accessing the Calibration
Menu
Figure 1-2: Ammeter Connection (Output A)
1. Press the [CAL] key to enter the Calibration Program.
2. Press [Fx] to calibrate the desired slot. (The option bar will include
a slot listing for each installed option card.)
3. Press [Fx] to select the desired output.
IMPORTANT: The procedure for calibrating all outputs is the same.
However, when calibrating a different output, be sure
to reconnect the ammeter to the appropriate pins on
terminal block I/O. See Figure 1-1 on page 1-2 or
Figure 1-2 above for the correct pin numbers.
Calibrating the Low End of
the Output Range 1. Press [F1] to calibrate the low end of the output range.
2. Press [F1] or [F2] to adjust the ammeter reading UP or DOWN, until
a 4 mA reading is achieved. If you press [F3], Numer, enter the
numeric value and press [ENT].
3. Press [F4] to STORE the setting or press [→] and [F1] to ABORT the
calibration.
Note: If the ammeter reading cannot be adjusted within 5.0 μA of the
4 mA setting, contact the factory for assistance.
Terminal Block (Option Card)
B
RTN
B
SIG
A
RTN
A
SIG
8
1
+
–Ammeter
D
RTN
D
SIG
C
RTN
C
SIG

March 2008
1-4 Calibration
Calibrating the High End
of the Output Range 1. Press [F2] to calibrate the high end of the output range.
2. Press [F1] or [F2] to adjust the ammeter reading UP or DOWN, until
a 20 mA reading is achieved. If you press [F3], Numer, enter the
numeric value and press [ENT].
3. Press [F4] to STORE the setting or press [→] and [F1] to ABORT the
calibration.
Note: If the ammeter reading cannot be adjusted within 5.0 μA of the
20 mA setting, contact the factory for assistance.
Testing the Analog Output
Linearity 1. Press [F3] to TEST the linearity of the currently selected analog
output.
2. Check the ammeter reading at the 50% output level.
3. Then, enter a different output level (0-100%) and press [ENT].
4. Check the ammeter reading at this setting. Press [ENT] when done.
Table 1-1 below lists the expected ammeter readings at various %
Full Scale settings, for both 4-20 mA and 0-20 mA scales. Refer to
this table to verify the accuracy of the ammeter readings taken above.
If the linearity test readings are not within 5 μA of the values listed in
Table 1-1 above, check the accuracy and wiring of the ammeter.
Then, repeat the low and high end calibrations. If the analog output
still does not pass the linearity test, contact the factory for assistance.
Table 1-1: Expected Ammeter Readings
% Full Scale 4-20 mA Scale* 0-20 mA Scale*
0% 4.000 0.000
10% 5.600 2.000
20% 7.200 4.000
30% 8.800 6.000
40% 10.400 8.000
50% 12.000 10.000
60% 13.600 12.000
70% 15.200 14.000
80% 16.800 16.000
90% 18.400 18.000
100% 20.000 20.000
* All ammeter readings should be ±0.005 mA

Calibration 1-5
March 2008
Procedure Options You have completed calibration of the analog output. Do one of the
following:
•To calibrate or test another output, press [F4] (EXIT) and return to
Step 3 in Accessing the Calibration Menu on page 1-3.
•To calibrate/test additional slots, press [F4] (EXIT) twice and
proceed to the appropriate section.
•To leave the Calibration Menu, press [F4](EXIT) three times.

March 2008
1-6 Calibration
Calibrating the Analog
Inputs
Analog inputs may be added to the Model DF868 flowmeter by
installing an Analog Inputs Option Card in one (or more) of the six
expansion slots. The option card contains two analog inputs, which
are designated as A and B. Each of the inputs must be calibrated at
both the zero-point and full-scale values. After calibrating the inputs,
their linearity should be tested.
Calibration of the analog inputs requires the use of a calibrated
current source. If an independent calibrated current source is not
available, one of the Slot 0 analog outputs may be used for the
calibration. During the analog input calibration, the Slot 0 analog
output will supply the low reference, high reference, 4 mA and 20
mA signals at the appropriate times.
Note: If a Slot 0 analog output will be used to calibrate the analog
inputs, make sure that the Slot 0 analog output calibration
procedure has already been completed.
Connect the Slot X analog output(s) (or an independent calibrated
current source) to the analog input(s) on the option card, as shown in
Figure 1-3 below. Refer to the menu map in Figure 1-6 on page 1-15
as a guide.
Figure 1-3: Analog Input Calibration Connections
Analog Input Option Card
A
INLO
A
RTN
A
+24V
A
INHI
8
1
B
INLO
B
RTN
B
+24
B
INHI B
RTN B SIG A RTN A SIG
Terminal Block I/O (Slot 0)
41

Calibration 1-7
March 2008
Calibrating the Analog
Inputs (cont.)
For this discussion, assume that the option card has been installed in
Slot x.
Note: The zero point of the analog input may be set for either 0 mA
or 4 mA. However, the calibration procedure always uses the 4
mA point, as the meter will extrapolate this value to obtain the
0 mA point.
Accessing the Calibration
Menu 1. Press the [CAL] key to enter the Calibration Program.
2. Press [Fx] to calibrate the desired slot. (The option bar will include
a slot listing for each installed option card.)
3. Press [F1] to select the desired input.
The procedure for calibrating Input A is identical to that for calibrating
Input B. However, when calibrating Input B, be sure a calibrated
current source is connected to the appropriate pins on the terminal
block. See Figure 1-3 on page 1-6 for the correct pin numbers.
4. Press [F1]-[F4] to select the reference point to be calibrated.
Do one of the following:
•If you selected [F1] (aLOW), proceed to aLOW Option on the next
page.
•If you selected [F2] (aHIGH),proceed to aHIGH Option on the next
page.
•If you selected [F3] (4 mA), proceed to 4 mA Option on the next
page.
•If you selected [F4] (20 mA),proceed to 20 mA Option on the next
page.

March 2008
1-8 Calibration
aLOW Option = [F1] 1. Enter the low reference value and press the [ENT] key.
2. Press [F1] to store the current low reference value or press [F2] to
cancel the entry. In either case, the ANALOG INPUT prompt will
reappear.
3. Press [F2] to proceed to the next section.
aHIGH Option = [F2] 1. Enter the high reference value and press the [ENT] key.
2. Press [F1] to store the current high reference value or press [F2] to
cancel the entry. In either case, the ANALOG INPUT prompt will
reappear.
3. Proceed to Procedure Options below.
4 mA Option = [F3] 1. Connect the 4 mA current source to the currently selected analog
input, as shown in Figure 1-3 on page 1-6.
2. Press [F1] to store the current 4 mA value or press [F2] to cancel the
entry. In either case, the ANALOG INPUT prompt reappears.
3. Press [F4] to proceed to the next section.
20 mA Option = [F4] 1. Connect the 20 mA current source to the currently selected analog
input, as shown in Figure 1-3 on page 1-6.
2. Press [F1] to store the current 20 mA value or press [F2] to cancel
the entry. In either case, the ANALOG INPUT prompt reappears.
3. Proceed to Procedure Options below.
Procedure Options You have completed calibration of the analog input. Do one of the
following:
•To calibrate another input, return to Step 3 in Accessing the
Calibration Menu on the previous page.
•To calibrate/test additional slots, press [F4] (EXIT) and proceed to
the appropriate section.
•To leave the Calibration Menu, press [F4] (EXIT) twice.

Calibration 1-9
March 2008
Calibrating the RTD
Inputs
Calibrating an RTD option card involves a slightly different
procedure than for other analog input cards. However, you access the
card in the same manner.
Accessing the Calibration
Menu 1. Press the [CAL] key to enter the Calibration Program.
2. Press [Fx] to calibrate the desired slot. (The option bar will include
a slot listing for each installed option card.)
3. Press [F1] to select Input A, or [F2] to select Input B.
4. Press [F1]-[F2] to select the reference point to be calibrated.
Do one of the following:
•If you selected [F1] (LOW), proceed to step 5.
•If you selected [F2] (HIGH), proceed to step 8.
LOW Option = [F1] 5. Enter the low reference value and press the [ENT] key.
6. Press [F1] to STORE the low reference value or [F2] to ABORT the
calibration. In either case, the screen returns to the ANALOG INPUT
prompt.
7. Press [F2] to proceed to the next section.
HIGH Option = [F2] 8. Enter the high reference value and press the [ENT] key.
9. Press [F1] to STORE the current high reference value or press [F2] to
ABORT the entry. In either case, the ANALOG INPUT prompt will
reappear.
10.Proceed to Procedure Options below.
Procedure Options You have completed calibration of the RTD input. Do one of the
following:
•To calibrate another input, press [EXIT].
•To calibrate additional slots, press [EXIT] and then [F4] (EXIT) and
proceed to the appropriate section.
•To leave the Calibration Menu, press [F4] (EXIT) twice.

March 2008
1-10 Calibration
Alarms Option Card Alarm relays may be added to the Model DF868 by installing an
Alarms Option Card in one (or more) of the six expansion slots. Each
option card includes three alarm relays, which are designated as A, B,
and C. To test the alarm relays, connect an ohmmeter to the option
card terminal block as shown in Figure 1-4 below. Refer to the menu
map in Figure 1-6 on page 1-15 as a guide.
Figure 1-4: Typical Ohmmeter Connections
For this discussion, assume that the option card has been installed in
Slot x.
Accessing the Calibration
Menu 1. Press the [CAL] key to enter the Calibration Program.
2. Press [Fx] to select Slot x. (The option bar will include a slot listing
for each installed option card.)
3. Press [F1]-[F3] to select alarm relay A, B or C, respectively.
Terminal Block (Option Card)
A
NC
B
NO
A
NO
A
COM
9
1
+
–Ohmmeter
C
NO
C
NC
B
COM
B
NC
C
COM

Calibration 1-11
March 2008
Testing the Alarm Relays
(cont.)
Note: The procedure for testing Alarm Relay A is identical to that for
testing Alarm Relays B and C. However, make sure that the
ohmmeter is connected to the desired normally-open or
normally-closed contact of the currently selected relay. See
Figure 1-4 on page 1-10 for the correct pin numbers on the
option card terminal block.
4. Pressing [F1] (CLOSE) should yield an ohmmeter reading of about
zero. Pressing [F2] (OPEN) should yield an infinite ohmmeter
reading.
5. Press [F3] to EXIT.
6. Repeat the above procedure until both the normally-open and
normally-closed contacts for all three alarm relays have been
tested. Then, proceed to Procedure Options below.
Procedure Options You have completed testing the alarm relays. Do one of the following:
•To calibrate/test additional slots, press [F4] (EXIT) and proceed to
the appropriate section.
•To leave the Calibration Menu, press [EXIT] twice.

March 2008
1-12 Calibration
Totalizer/Frequency
Option Card
Totalizer/Frequency outputs may be added to the Model DF868 by
installing a Totalizer/Frequency Option Card in one (or more) of the
six expansion slots. Each option card includes four outputs, which are
designated as A, B, C and D. To test the outputs, connect a frequency
counter to the card’s terminal block as shown in Figure 1-5 below.
Refer to the menu map in Figure 1-6 on page 1-15 as a guide.
Figure 1-5: Frequency Counter Connections
For this discussion, assume that the option card has been installed in
Slot x.
Accessing the Calibration
Menu 1. Press the [CAL] key to enter the Calibration Program.
2. Press [Fx] to select Slot x. (The option bar will include a slot listing
for each installed option card.)
3. Press [F1]-[F4] to select output A, B, C or D, respectively.
Entering Frequency 4. Enter a new frequency in the range of 1-10,000 Hz and press the
[ENT] key. Verify that the frequency counter reads the correct
value.
Terminal Block (Option Card)
B
COM
B
NO
A
COM
A
NO
8
1
Frequency
D
COM
D
NO
C
COM
C
NO
Counter
COM
IN
