Ge D30 series User manual

D30 Line Distance Protection

System

UR Series Instruction Manual

D30 revision: 7.2x

Manual P/N: 1601-0116-AA5 (GEK-119556D)

GE Grid Solutions

650 Markland Street

Markham, Ontario

Canada L6C 0M1

Tel: +1 905 927 7070 Fax: +1 905 927 5098

Internet: http://www.GEGridSolutions.com

GE Multilin's Quality Management

System is registered to ISO

9001:2008

QMI # 005094

UL # A3775

*1601-0116-AA5*

837767A2.CDR

Grid Solutions

LISTED

52TL

IND.CONT. EQ.

E83849

D30 Line Distance Protection System UR Series Instruction Manual revision 7.2x.

FlexLogic, FlexElement, FlexCurve, FlexAnalog, FlexInteger, FlexState, EnerVista,

CyberSentry, HardFiber, Multilin, and GE Multilin are trademarks or registered

trademarks of GE Multilin Inc.

The contents of this manual are the property of GE Multilin Inc. This

documentation is furnished on license and may not be reproduced in whole or in

part without the permission of GE Multilin. The content of this manual is for

informational use only and is subject to change without notice.

Part number: 1601-0116-AA5 (August 2017)

ADDENDUM

This addendum explains firmware differences in the instruction manual for the D30.

PHASE DISTANCE FAULT TYPE CHARACTERISTICS

Phase distance fault type characteristics were slightly changed between minor version 7.21 and 7.24 firmware releases to

allow phase distance operation during some unusual cases, where spurious I_0 can be present during fault. This adden-

dum explains the difference in the firmware implementation for the following releases.

a) FIRMWARE 7.21

For phase distance following fault-type characteristic are applied.

FLGAB= ~(AG OR BG) OR I0< max(0.02 pu, I2/16, I1/16)

FLGBC= ~(BG OR CG) OR I0< max(0.02 pu, I2/16, I1/16)

FLGCA= ~(CG OR AG) OR I0< max(0.02 pu, I2/16, I1/16)

where

"~" means inverse operation

I0 is the zero sequence current magnitude

I2 is the negative sequence current magnitude

AG, BG, CG are ground distance single-line-to-ground (SLG) fault-type signatures, explained in the Fault-Type Characteris-

tic section in the Theory of Operation chapter

This means that fault-type characteristic for the phase distance is confirmed, if there is no SLG fault in the corresponding

loop or if zero-sequence current is relatively small, which is true for phase-to-phase or three-phase fault. Phase distance

fault type supervision is suppressed during open pole conditions.

b) FIRMWARE 7.24 AND 7.25

Version 7.24 added additional angle between I_1 and I_2 along with I_1 and I_2 level detectors. I_1 phasor is obtained by

subtracting pre-fault positive sequence current I1mem from the fault positive sequence current.

θ12=ang(I1)-ang(I2), limit angle 45°

PKP_I0= I0>max(0.02 pu, I2/16, I1/16)

PKP_I2= I2>max(0.02 pu, I0/16, I1/16)

PKP_I1= abs(I1(k)- I1mem )>0.05pu

FLG 3P= PKP_I1 & NOT PKP_I2

For the ABC, rotation phase distance fault type characteristics applied are as follows:

FLGAB= ~(FLG5A OR FLG5B) OR [abs(θ12+60°)<45° AND (PKP_I0 OR PKP_I2)] OR PS_3P

FLGBC= ~(FLG5B OR FLG5C) OR [abs(θ12+180°)<45° AND (PKP_I0 OR PKP_I2)] OR PS_3P

FLGCA= ~(FLG5C OR FLG5A) OR [abs(θ12+300°)<45° AND (PKP_I0 OR PKP_I2)] OR PS_3P

This means that the first check is if the ground elements fault-type comparator, explained in the Fault-Type Characteristic

section in the Theory of Operation chapter, does not operate in the corresponding distance loop. Second, the angle

between (I_1 - I_1mem) and I_2 is checked to be within 45° in the corresponding phase distance loop. I_1mem is the pre-

fault positive sequence current, which is updated with the actual I_1 phasor of two cycles before fault. Upon 50DD asser-

tion, I_1mem stops updating and is sealed-in for 500 ms. In case any phase distance zone is picked-up after this 500 ms

seal-in timer expires, I_1mem continues to be held until either all phase distance zones drop out or for three seconds after

any zone is still picked up. After that, I_1mem is updated again. Lastly, condition for the three-phase fault is checked.

Phase distance fault type supervision is suppressed during open pole conditions.

c) FIRMWARE 7.26

In order to improve phase distance fault type supervision especially during complex faults and to give user flexibility to dis-

able fault type supervision, following is applicable in this release.

Fault type supervision is designed to ensure dependability of the phase distance operation. It uses first voltages and then

currents to ensure giving permission to phase distance for any fault. First the SLG fault type is determined by detecting one

phase voltage depressed while two others are not by using the following equation.

SLG= (VA_LOW & NOT VB_LOW & NOT VC_LOW) OR (NOT VA_LOW & VB_LOW & NOT VC_LOW) OR

ADDENDUM

(NOT VA_LOW & NOT VB_LOW & VC_LOW)

where

VA_LOW = |V_A + V_0| < 0.98 *VBC/√3, similarly for B and C phases

Additionally multi-phase fault is determined if at least 2 phases are below 85% of the nominal:

M-PH= (VA < 0.85pu & VB < 0.85pu) OR (VB < 0.85pu & VC < 0.85pu) OR ( VC< 0.85pu & VA < 0.85pu)

Permission is always granted to phase distance by setting FLGAB, FLGBC and FLGCA flags to logic '1', unless following

condition is satisfied:

PKP_I0 & PKP_I2 & SLG & NOT M-PH,

meaning that if there are negative- and zero-sequence currents present in the fault signal, voltage signatures indicate pres-

ence of the SLG fault and not multi-phase fault. If at least one of these conditions is not satisfied, permission to be contin-

ued granted to all phase distance loop.

But in case this condition is satisfied, angles between I_0 and I_2 are additionally checked to still grant permission to the

phase distance loops, shown below for the ABC rotation.

If abs[ang(I_0)-ang(I_2)+120°] <70°, then FLGAB=1,

If abs[ang(I_0)-ang(I_2)+240°] <70°, then FLGCA=1,

If abs[ang(I_0)-ang(I_2)] <70°, then FLGBC=1,

Phase distance fault type supervision is suppressed during open pole conditions and for delta connected VTs.

Fault type supervision is applied to phase distance zone1 to zone 3 only with an option to disable fault type supervision by

setting phase distance zone 5 Voltage level setting to non-zero-value (regardless zone 5 is enabled or not). G60 and L60

relays are not employing fault type supervision for the phase distance in all zones.
