GE 45411 User manual

45411
Personal Security
Water Leak
Alarm
User’s Manual

Important Safeguards 4
Introduction 4
Installing Batteries 5
Low Battery Indication 5
Installation 6
Warnings 9-10
Specifications 8
Warning 9
Table of Contents

Before connecting or operating the Water Leak
Alarm, please read these instructions carefully and
save this manual for future reference.
This user manual explains in simple steps how to
install, use and care for your new Personal Security
Water Leak Alarm.
If you have any questions or would like additional
information please visit our web site
www.jascoproducts.com or contact our Technical
Support Group at 1-800-654-8483, option 4.

4
Important safeguards
Pre cautions
1. Do not attempt to disassemble the Water Leak Alarm,
unless described in the user’s manual. There are no user
serviceable parts.
2. Handle with Care – Avoid striking or shaking. Improper
use or storage could damage the Water Leak Alarm.
Modifying the device or its internal components can cause a
malfunction and void the Alarm’s warranty.
3. If you feel the Water Leak Alarm is not operating correctly
or as described, please contact Technical Support for
assistance (1-800-654-8483), option 4.
Introduction
The Water Leak Alarm is designed to be used in areas where
there is a potential for damaging water leaks – dishwashers,
washing machines, hot water tanks, bathrooms, air
conditioner condensation drip pans, etc. When mounted
properly it will sound an alarm indicating potential damage
from water leaks.
SENSOR
Indicator Light
Alarm
Siren
Battery Test
Button
Power ON/OFF

5
Installing Batteries
The alarm requires (4) LR44 (or 357) button batteries
(included). Average battery life for typical usage is up to
one year.
1. Make sure alarm ON/OFF switch is set to “OFF” position.
2. Remove the screw securing the battery
compartment cover.
3. Slide cover off the battery compartment door in
direction of arrow.
4. Insert (4) LR44 button batteries noting polarity.
5. Replace battery compartment cover.
6. Secure the battery cover screw.
Low Battery Indicator
GE Personal Security Water
Leak Alarm has a battery test
button. Battery levels can be
checked in either ON or OFF
mode. Once pressed, the light
on front of the alarm will turn
red indicating that the battery
is good. If the battery test
light fails to turn red, replace
all batteries.
Battery Test
Button
Power
ON/OFF

6
Installation
The sensor should be
mounted first. Positioned
the sensor with the
contacts pointing down.
Find a suitable location
where water could
accumulate if a leak were
to occur (e.g. along the
baseboard of wall).
For best results mount both
alarm and sensor to a flat
Surface. The surface must
be smooth and nonporous.
Before mounting, make
sure the mounting surface
is clean and dry. Clean the
mounting surface with a
mixture of 50% Isopropyl
alcohol and 50% water.
Remove protective paper
from double-sided tape.
Once the mounting surface
is ready, position sensor so
that the metal contacts are pointing down, touching the floor
or the area where it can detect water accumulation.
Note: If mounting the sensor to a metal surface, ensure the
sensor’s contacts do not touch the metal surface.
LIQUID

7
Next, stretch the cable vertically and locate a suitable
position with a smooth surface to mount the alarm. Make
sure you can easily access all the controls and the battery
door once the position has been selected. Follow the same
mounting instructions above for mounting the alarm. Position
the back of the alarm unit (after removing protective paper
from the double side tape) up against the smooth nonporous
surface. Apply pressure to secure the alarm unit to the
surface.

8
Specification:
Power Supply: 4 LR44 Batteries
Operating Voltage: 4~6V DC
Operating Current: <40mA (6V DC)
Standby Current: <10uA (6V DC)
Alarm Sound Period: Continuous
Alarm Sound-Level:
Hi>110 dB (6.0V DC)
Low>95 dB (6.0V DC)
(Measured at 30cm)
Low Battery Voltage-Level Indicator: 4~4.7V DC
(Testing Button)
Battery Good: Red LED lights up
Battery Voltage-Level Low: Red LED does not light up
Operating Temperature: 0˚F~40˚F

9
WARNING
Limitations of Alarm Products
This product should be tested periodically to make sure
it is working properly. The product, if used properly, may
reduce the risk of burglary, robbery, or other adverse events.
However, JASCO is not an insurer, this product is neither
insurance nor a guarantee that such an event will be
prevented, and users should protect themselves with proper
insurance. JASCO makes no representation that this product
cannot be compromised or circumvented, that it will provide
an adequate warning, or that it will prevent any personal
injuries, property damage, or other losses. Like any alarm
product, including expensive commercial systems, it may be
bypassed, it is subject to compromise, and it may fail to warn
for a variety of reasons, including, but not limited to: improper
installation or positioning; improper maintenance; tampering;
dead or improperly installed batteries; sensing limitations;
component failures; receivers; intrusions may be outside
of a product’s designed range and certain environmental
conditions may impact performance and audible alarm
signals may be outside of hearing range, muted by doors,
walls, and floors, unheard by deep sleepers or the hearing-
impaired, or overwhelmed by other sounds.

10
GE is a trademark of the General Electric Company
and is used under license to Jasco Products Company
LLC, 10 E. Memorial Road,
Oklahoma City, OK 73114.
45411-1
01/17/11
WARNING
Risk of personal injury
• Prolonged exposure to alarm siren may cause permanent
hearing loss
Battery Warning
• Remove batteries if the Alarm will not be used for
extended periods
• Batteries may leak harmful liquids or ignitable materials or
explode causing injury and product damage
• Do not mix old and new or other battery types
• Replace all batteries at the same time
• Replace fully discharged batteries immediately.
For indoor use only; do not use in wet locations.
This Jasco product comes with a 90 day limited warranty.
Please contact Technical Support at 800-654-8483 option 4
between 7:30 AM—5:00 PM CST or via our website
(www.jascoproducts.com) if the unit should prove defective
within the warranty period.
