GE TLE Scalable Series User manual

Critical Power
Installation Guide
Uninterruptible Power Supply
GE Consumer & Industrial SA
General Electric Company
CH – 6595 Riazzino (Locarno)
Switzerland
T +41 (0)91 / 850 51 51
F +41 (0)91 / 850 52 52
www.gecriticalpower.com
imagination at work
TLES_040-120_S1_UPS_GE_Floor_01

Critical Power
Modifications reserved
Page 2/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Model:
TLE Scalable Series 40 - 150 UL S1
TLE Scalable Series 150/40 UL S1
TLE Scalable Series 150/50 UL S1
TLE Scalable Series 150/80 UL S1
TLE Scalable Series 150/100 UL S1
TLE Scalable Series 150/120 UL S1
TLE Scalable Series 150/150 UL S1
Issued by:
Product Document Department
– Riazzino - CH
Approved by:
R & D Department
– Riazzino - CH
Date of issue:
1
2/12/2017
File name:
GE_UPS_
ISG_TLE_SUL_40K_M15_1US_V010
Revision:
1
.0
Identification No.:
8600123208P
Up-dating
Revision Concern Date
COPYRIGHT © 2017 by GE Consumer & Industrial SA
All rights reserved.
The information contained in this publication is intended solely for the purposes indicated.
The present publication and any other documentation supplied with the UPS system is not to be
reproduced, either in part or in its entirety, without the prior written consent of GE.
The illustrations and plans describing the equipment are intended as general reference only and are not
necessarily complete in every detail.
The content of this publication may be subject to modification without prior notice.

Critical Power
Modifications reserved
Page 3/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Dear Customer,
We th
ank you for selecting our products and are
pleased to count you amongst our very valued
customers at GE.
We trust that the use of the TLE Scalable Series 40 - 150
Uninterruptible Power Supply S
ystem, developed and
produced to the highest standards of qual
ity, will give
you complete satisfaction.
Please read carefully the Installation Guide
, which
contains all the necessary information and describes all
you need to know about the installation of the UPS.
Thank you for choosing GE !
START-UP AND COMMISSIONING
A GE GLOBAL SERVICES FIELD ENGINEER must perform start-
up and
commissioning of the UPS.
Please Contact GE. GLOBAL SERVICES at least two weeks prior to schedule
start-up and commissioning at 1-800-637-1738, or by E-
mail at
pqservic[email protected] .
Distributed in the USA by:
Your service contact:
g
GE Consumer & Industrial SA
General Electric Company
CH – 6595 Riazzino (Locarno)
Switzerland
www.gecriticalpower.com
g
GE Energy Connections
Critical Power
3100 Technology – Suite 200
Plano, TX 75074
T: [phone]
E: [email protected]
www.geindustrial.com/products/
critical-power
g
GE Energy Connections
Critical Power
601 Shiloh Road
Plano, TX 75074
24/7 T: [phone]
24/7 F: [phone]
E: [e-mail]

Critical Power
Modifications reserved
Page 4/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Preface
Congratulations on your choice of a TLE Scalable Series 40 - 150 Uninterruptible Power
Supply (UPS).
It will help eliminate load disturbances due to unexpected power problem
.
This
Installation Guide
describes how to prepare the installation site, and it provides
weight and dimensions and procedures for moving, installing and connecting the UPS.
Please refer to the
accompanying User Manual
, which describes the function of the UPS
module, the purpose and location of the switches, the meaning of the system events
related to the front panel indication, and provides procedures for starting and stopping
the equipment.
While every care has been taken to ensure the completeness and accuracy of this manual,
GE assumes no responsibility or liability for any losses or damages resulting from the use
of the information contained in this document.
WARNING!
TLE Scalable Series 40 - 150 is a product that needs to be installed by a licensed and
knowledgeable contractor.
Installation restrictions or additional measures may be needed to prevent disturbances.
We recommend that this manual be kept next to the UPS for future references.
If any problems are encountered with the procedures contained in this manual, please
contact your
Service Center before you proceed.
This document shall not be copied or reproduced without the permission of
GE.
Some of the information contained in this manual may be changed without notice to
reflect technical improvements.
Safety instructions
Read the safety instructions contained on the following pages carefully before the
installation of the UPS, options and battery system.
Pay attention to the
rectangular boxes included in the text:
They contain important information and warning concerning electrical connections and
personnel safety
.
Parallel System version secured with RPA
When included in the text, this symbol refers to operation needed
only for RPA Parallel System.

Critical Power
Modifications reserved
Page 5/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Table of content Page
1IMPORTANT SAFETY INSTRUCTIONS .............................................................................................................................6
2LAYOUT...............................................................................................................................................................................9
2.1 LAYOUT TLE SCALABLE SERIES 40 – 150...........................................................................................................................................................9
3ENVIRONMENT................................................................................................................................................................11
3.1 RECYCLING INSTRUCTIONS.................................................................................................................................................................................. 11
4INSTALLATION.................................................................................................................................................................12
4.1 TRANSPORT................................................................................................................................................................................................................. 12
4.1.1 Dimensions and weights TLE Scalable Series 40 – 150.......................................................................................................................................... 13
4.2 DELIVERY...................................................................................................................................................................................................................... 15
4.3 STORAGE...................................................................................................................................................................................................................... 15
4.3.1 Storage of the UPS.................................................................................................................................................................................................................... 15
4.3.2 Storage of Battery ..................................................................................................................................................................................................................... 15
4.4 PLACE OF INSTALLATION...................................................................................................................................................................................... 16
4.4.1 UPS location ................................................................................................................................................................................................................................. 16
4.4.2 Battery location.......................................................................................................................................................................................................................... 18
4.5 VENTILATION AND COOLING............................................................................................................................................................................... 19
4.6 UNPACKING................................................................................................................................................................................................................ 20
4.7 ELECTRICAL WIRING ............................................................................................................................................................................................... 22
4.7.1 Utility input connection........................................................................................................................................................................................................... 22
4.7.2 Input/output over current protection and wire sizing............................................................................................................................................. 23
4.7.3 Data for Input/output and battery over current protection and wire sizing ............................................................................................... 24
4.7.4 Installation requirements....................................................................................................................................................................................................... 27
4.8 WIRING CONNECTION............................................................................................................................................................................................ 30
4.8.1 TLE Scalable Series 40 - 150 - Power connection with Common Input Utility............................................................................................ 31
4.8.2 TLE Scalable Series 40 - 150 - Power connection with Dual Input Utility...................................................................................................... 33
4.8.3 Battery cabinet connection to TLE Scalable Series 40 - 150 ............................................................................................................................... 35
4.8.4 Use of TLE Scalable Series 40 - 150 in SEM Operation Mode (Super Eco Mode)........................................................................................ 37
4.8.5 Use of TLE Scalable Series 40 - 150 as frequency converter............................................................................................................................... 38
4.9 RPA PARALLEL SYSTEM CONNECTION ............................................................................................................................................................ 39
4.9.1 Power wiring of parallel units.............................................................................................................................................................................................. 39
4.9.2 Parallel control bus connection.......................................................................................................................................................................................... 40
4.9.3 Control bus cable location .................................................................................................................................................................................................... 42
4.10 “EPO - EMERGENCY POWER OFF” COMMAND CONNECTION ............................................................................................................... 44
5CONNECTIVITY INTERFACE ...........................................................................................................................................45
5.1 SERIAL PORT J35µP - RS232 (SUB D, FEMALE 9 PIN)................................................................................................................................. 46
5.2 CUSTOMER INTERFACE BOARD.......................................................................................................................................................................... 47
5.2.1 X1 terminal block - Output signals on voltage-free contacts ............................................................................................................................. 48
5.2.2 X1 terminal block - Programmable input free contacts......................................................................................................................................... 48
5.2.3 X1 terminal block - Gen Set Signalling (GEN ON) ....................................................................................................................................................... 49
5.2.4 X1 terminal block - AUX external Maintenance Bypass......................................................................................................................................... 49
5.2.5 X1 terminal block - SEM/IEMi control signal................................................................................................................................................................. 49
5.3 “3-PH SNMP/WEB PLUG-IN ADAPTER” BOARD ........................................................................................................................................... 50
6OPTIONS...........................................................................................................................................................................51
6.1 TOP CABLE ENTRY/EXIT SIDECAR AND TOP HAT FASCIA ........................................................................................................................ 51
7NOTES...............................................................................................................................................................................53
7.1 NOTES FORM.............................................................................................................................................................................................................. 53

Critical Power
Modifications reserved
Page 6/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
1IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions for models TLE Scalable Series 40 - 150that should be
followed during installation and maintenance of the UPS and battery.
GENERAL
- Move the UPS in an upright position in its original package to the final destination room.
To lift the cabinets, use a forklift or lifting belts with spreader bars.
- Check for sufficient floor and elevator loading capacity.
- Check the integrity of the UPS equipment carefully.
If you notice visible damage, do not install or start the UPS.
Contact the nearest Service Center immediately.
- WARNING! RISK OF ELECTRICAL SHOCK:
Do not remove covers, there are no user serviceable parts inside.
- After switching off takes 5 minutes for the DC capacitors to discharge because a lethally high voltage
remains at the terminals of the electrolytic capacitors.
- UPS’s and battery system require a 12 months periodic maintenance to operate reliably and safely.
This should be performed by qualified service personnel. The UPS contains its own energy source (battery).
- The field-wiring outlets may be electrically live, even when the UPS is disconnected from the utility.
- Dangerous voltages may be present during battery operation.
- The battery must be disconnected during maintenance or service work.
- This UPS contains potentially hazardous voltages.
- Be aware that the inverter can restart automatically after the utility voltage is restored.
- End user must follow applicable regional occupational safety codes/regulations during installation,
operation and equipment maintenance. This may require additional field marking or labeling defining
appropriate level of PPE (Personal Protection Equipment) to reduce the risk of Arc-flash related injuries.
Contact our Technical Support for product specific information.
INSTALLATION
- This UPS must be installed and connected only by trained personnel.
- Verify accurately during Commissioning and Maintenance of the UPS, for the following:
Damaged components, squeezed wires and cables, or not correctly inserted plugs.
- After removing the sidewalls of the UPS, make sure that all earth connections when reassembling, are
correctly reattached.
- This UPS is intended for use in a controlled indoor environment free of conductive contaminants and
protected against animals intrusion.
- WARNING! HIGH EARTH LEAKAGE CURRENT:
Earth connection is essential before connecting to AC input!
- Switching OFF the unit does not isolate the UPS from the utility.
- Do not install the UPS in an excessively humid environment or near water.
- Avoid spilling liquids on or dropping any foreign object into the UPS.
- The unit must be placed in a sufficiently ventilated area; the ambient temperature should not exceed 104°F
(40°C).
- Optimal battery life is obtained if the ambient temperature does not exceed 77°F (25°C).
- It is important that air can move freely around and through the unit. Do not block the air vents.
- Avoid locations in direct sunlight or near heat sources.
STORAGE
-Store the UPS in a dry location; storage temperature must be within -13°F (-25°C) to 131°F (55°C).
-The optimal temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed the range -
4°F (-20°C) to 104°F (40°C).
- If the unit is stored for a period exceeding 3 months, the battery must be recharged periodically (time
depending on storage temperature).
BATTERY
- The battery-voltage is dangerous for person’s safety.
- When replacing the battery, use the same cells number, voltage (V), capacity (Ah).
All the battery used, shall be of the same manufacturer and date of production.
- Proper disposal or recycling of the battery is required.
Refer to your local codes for disposal requirements.
- Never dispose of battery in a fire: they may explode.
- Do not open or mutilate battery: their contents (electrolyte) may be extremely toxic.
If exposed to electrolyte, wash immediately with plenty of water.
- Avoid charging in a sealed container.
- Never short-circuit the batteries.
When working with batteries, remove watches, rings or other metal objects, and only use insulated tools.
- In case of air shipment, the cables +/- going to the battery fuses/terminals shall be disconnected and isolated.

Critical Power
Modifications reserved
Page 7/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Safety instructions when working with battery
EXTERNAL BATTERY MUST BE INSTALLED AND CONNECTED TO THE UPS BY
QUALIFIED SERVICE PERSONNEL.
INSTALLATION PERSONNEL MUST READ THIS ENTIRE SECTION BEFORE HANDLING
THE UPS AND BATTERY.
DANGER!
Full voltage and current are always present at the battery terminals.
The battery used in this system can provide dangerous voltages, extremely high currents and a risk
of electric shock.
If the terminals are shorted together or to ground they may cause severe injury.
You must be extremely careful to avoid electric shock and burns caused by contacting battery
terminals or shorting terminals during battery installation.
Do not touch uninsulated battery terminals.
A qualified service person, who is familiar with battery systems and required precautions, must
install and service the battery.
The installation must conform to national and local codes.
Keep unauthorized personnel away from the battery.
The qualified service person must take these precautions:
1Wear protective clothing, such as rubber gloves and boots and protective eye wear.
Batteries contain caustic acids and toxic materials and can rupture or leak if mistreated.
Remove rings and metal wristwatches or other metal objects and jewellery.
Do not carry metal objects in your pockets where the objects can fall into the battery cabinet.
High energy through conductive materials could cause severe burns.
2Tools must have insulated handles and must be insulated so that they will not short battery
terminals.
Do not allow a tool to short between individual or separate battery terminals or to the cabinet
or rack.
Do not lay tools or metal parts on top of the battery, and do not lay them where they could fall
onto the battery or into the cabinet.
3Disconnect charging source prior to connecting or disconnecting battery terminals.
Install the battery as shown on the drawing provided with the battery.
When connecting cables, never allow a cable to short across a battery’s terminals, the string of
battery, or to the cabinet or rack.
4Align the cables on the battery terminals so that the cable lug will not contact any part of the
cabinet or rack, even if the battery is moved.
Keep the cable away from any sharp metal edges.
5Install the battery cables in such a way that the UPS or battery cabinet doors cannot pinch them.
6Do not connect the battery terminal to Ground.
If any battery terminal is inadvertently grounded, remove the source of the ground.
Contacting any part of a grounded battery can cause a risk of electric shock.
7Determine if battery is inadvertently grounded. If inadvertently grounded, remove source from
ground. Contact with any part of a grounded battery can result in electrical shock.
The likelihood of such shock can be reduced if such grounds are removed during installation and
maintenance.
8To reduce the risk of fire or electric shock, install the battery in a temperature and humidity
controlled indoor area, free of contaminants.
9Battery system chassis ground (earth) must be connected to the UPS chassis ground (earth).
If you use conduits, this ground conductor must be routed in the same conduit as the battery
conductors.
10 Where conductors may be exposed to physical damage, protect the conductors in accordance
with all applicable codes.
11 If you are replacing the battery or repairing battery connections, shut OFF the UPS and remove
the battery fuses.

Critical Power
Modifications reserved
Page 8/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Safety symbols and warnings
Safety warnings
The text of this manual contains some warnings to avoid risk to the persons and to avoid damages to
the UPS system and the supplied critical loads.
The non-observance of the warnings reminding hazardous situations could result in human injury and
equipment damages.
Please pay attention to the meaning of the following warnings and symbols.
Throughout this manual, the following symbols are defined:
WARNING, if instruction is not followed injury or serious equipment damage may
occur!
CAUTION, internal parts have dangerous voltage present.
Risk of electric shock!
PE (Earth) – GND (Ground)
PROTECTIVE GROUNDING TERMINAL:
A terminal which must be connected to earth ground prior to making any other
connection to the equipment.
A terminal to which or from which an alternating (sine wave) current or voltage
may be applied or supplied.
A terminal to which or from which a direct current or voltage may be applied or
supplied.
This symbol indicated the word “phase”.
This symbol indicates the principal on/off switch in the on position.
This symbol indicates the principal on/off switch in the off position.

Critical Power
Modifications reserved
Page 9/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
2LAYOUT
2.1 LAYOUT TLE SCALABLE Series 40 – 150
Fig. 2.1-1 TLE Scalable Series 40 - 150 - General view
Fig. 2.1-2 Control panel
Fig. 2.1-3 Q1 - UPS Output switch
Fig. 2.1-4 Connectivity Slots
TLES_040-120_S1_UPS_GE_02
TLES_UL_040-150_S1_Switch Q1_01
Q1
0 OFF
I ON
J35µP - RS232
CI SNMP
CONN2 CONN3
CONN4
TLES_040-120_S1_UPS connectivity_02
EPO
EPO
-
+
XA

Critical Power
Modifications reserved
Page 10/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Fig. 2.1-5 TLE Scalable Series 40 & 50
General view with open door
Fig. 2.1-6 TLE Scalable Series 80 & 100
General view with open door
Fig. 2.1-7 TLE Scalable Series 120 & 150
General view with open door
Fig. 2.1-8 TLE Scalable Series 40 - 150 - General front view without protection panels
1
Opening for bottom cables
entry (*)
2
Bus bars for Utility Input
connection
3
Bus bars for Load Output
connection
4
Bus bars for
external Battery
connection
CI
Customer Interface Board
(see Fig. 2.1-4)
CR
Connectivity Slots
J35µP
Serial port
RS232 for IMV
protocol
Q1
UPS Output switch
RPA
RPA board (Redundant
Parallel Architecture) for
Parallel System (option)
SNMP
3-ph SNMP/WEB plug-in
adapter (see Fig. 2.1-4)
XA
Terminals for EPO
(Emergency Power Off) and
24Vdc connection
*
)R
emove this panel or provide
means to capture metal filings
from cutting conduit entry holes
TLES_UL_040-050_S1_UPS_03
EPO
EPO
-
+
XA
Q1
I ON
0 OFF
POWER MODULE 1
TLES_UL_080-100_S1_UPS_03
EPO
EPO
-
+
XA
Q1
I ON
0 OFF
POWER MODULE 1
POWER MODULE 2
TLES_UL_120-150_S1_UPS_03
EPO
EPO
-
+
XA
Q1
I ON
0 OFF
POWER MODULE 1
POWER MODULE 2
POWER MODULE 3
TLES_UL_040-150_S1_UPS_04
EPO
EPO
-
+
XA
CR
J35
µP
RPA
XA
4Q1 31
2
Q1
POWER MODULE 2
POWER MODULE 1
POWER MODULE 3

Critical Power
Modifications reserved
Page 11/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
3ENVIRONMENT
3.1 RECYCLING INSTRUCTIONS
NOTE !
This product has been designed to respect the
environment, using materials and components respecting
eco-design rules.
It does not contain CFCs (Carbon Fluor Clorid) or HCFCs
(Halogen Carbon Fluor Clorid).
PACKING MATERIAL RECYCLING
GE, in compliance with environment protection, uses only
environmentally friendly material.
UPS packing materials must be recycled in compliance with
all applicable regulations.
RECYCLING AT THE END OF SERVICE LIFE !
GE
, in compliance with environment protection
recommends to the User that the UPS equipment, at the
end of its service life, must be recovered conforming to
the local applicable regulations.
WARNING !
Leads contained in the batteries is a dangerous substance
for the environment, therefore it must be correctly
recycled by specialized companies!

Critical Power
Modifications reserved
Page 12/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
4INSTALLATION
4.1 TRANSPORT
The UPS is packaged on a pallet suitable for handling with a forklift.
The UPS must be moved in
upright position.
Do not tilt cabinets
more than +/- 10° during handling.
Move the UPS in its original package to the final destination site
.
Do not stack other packages on top: This could damage the UPS.
Forklift
Fig. 4.1-1 Position of the forklift when moving the unpacked UPS
Forklift
The UPS may be lifted with a forklift in
upright position.
Take note of the
center of gravity
marked on the package
.
Crane
Fig. 4.1-2 Position of the carrying belts when moving the unpacked UPS
WARNING !
Check for sufficient floor and
elevator loading capacity.
Transport UPS only in upright
position.
Do not stack other package on top
of the UPS.
Crane
If the UPS has to be lifted by crane, use
suitable carrying belts taking note of the
center of gravity
marked on the
package.
Take all necessary precautions to
avoid damage to the cabinet while
hoisting the UPS.
WARNING !
When loading / unloading and when
moving the UPS, it is forbidden:
When loading / unloading and when
moving the UPS, pay attention to:

Critical Power
Modifications reserved
Page 13/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
4.1.1 Dimensions and weights TLE Scalable Series 40 – 150
Fig. 4.1.1-1 Standard UPS
Fig. 4.1.1
-2 UPS with options
“Top Cable Entry” & “Top Hat Fascia”
Dimensions and weights TLE Scalable Series 40 & 50
Dimensions
(W x D
x H)
Standard UPS 23.62 x 34.06 x 64.17 inches
600 x 865 x 1630 mm
UPS with options
“TCE” & “THF”
27.56 x 34.06 x 75.00 inches
700 x 865 x 1905 mm
Weight
Standard UPS 849 lbs / 385 kg
UPS with options
“TCE” & “THF” 959 lbs / 435 kg
Floor
loading
Standard UPS 152 lbs/sq.ft / 742 kg/m2
UPS with options
“TCE” & “THF” 172 lbs/sq.ft / 838 kg/m2
Dimensions and weights TLE Scalable Series 80 & 100
Dimensions
(W x D x H)
Standard UPS 23.62 x 34.06 x 64.17 inches
600 x 865 x 1630 mm
UPS with options
“TCE” & “THF”
27.56 x 34.06 x 75.00 inches
700 x 865 x 1905 mm
Weight
Standard UPS 992 lbs / 450 kg
UPS with options
“TCE” & “THF” 1102 lbs / 500 kg
Floor
loading
Standard UPS 178 lbs/sq.ft / 867 kg/m2
UPS with options
“TCE” & “THF” 198 lbs/sq.ft / 964 kg/m2
Dimensions and weights TLE Scalable Series 120 & 150
Dimensions
(W x D x H)
Standard UPS 23.62 x 34.06 x 64.17 inches
600 x 865 x 1630 mm
UPS with options
“TCE” & “THF”
27.56 x 34.06 x 75.00 inches
700 x 865 x 1905 mm
Weight
Standard UPS 1147 lbs / 520 kg
UPS with options
“TCE” & “THF” 1257 lbs / 570 kg
Floor
loading
Standard UPS 205 lbs/sq.ft / 1002 kg/m2
UPS with options
“TCE” & “THF” 225 lbs/sq.ft / 1098 kg/m2
34.06"
865mm 23.62"
600mm
TLES_UL_040-150 _S1_UPS dimensions_GE_01
64.17" / 1630mm
TLES_UL_040-150_S1_UPS+TCE+FCL_Dimensions_GE_01
64.17" / 1630mm
34.06"
865mm 23.62"
600mm
75.00" / 1905mm
27.56" / 700mm
10.83"
275mm
3.94"
100mm

Critical Power
Modifications reserved
Page 14/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Battery cabinets
Fig. 4.1.1-3 Battery cabinet
UPS
Battery table
Battery
capacity
Autonomy
time
Dimensions
(W x D x H)
Weights
Floor
loading
TLE Scalable Series 150/40
*)
Ah HR
*)
min.
29.80 x 29.50 x 75.00 inches
757 x 750 x 1905 mm
40.00 x 29.50 x 75.00 inches
1016 x 750 x 1905 mm
*)
Lbs / kg
*)
lbs/sq.ft /
kg/m2
TLE Scalable Series 150/50
TLE Scalable Series 150/80
TLE Scalable Series 150/100
TLE Scalable Series 150/120
TLE Scalable Series 150/150
*) For this and further information please consult the “Installation, Operation & Maintenance Manual”
of the “Battery cabinet”.
NOTE !
The weight of each single piece is marked outside the package!
TLES_UL_040-150_S1_Battery cabinet_Dimensions_01US
Battery
cabinet
Width
Height
Depht
right side view front view

Critical Power
Modifications reserved
Page 15/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
4.2 DELIVERY
When delivered, inspect the package integrity and the physical condition of the cabinets carefully.
In case of any damage sustained during transport, immediately inform the carrier and contact your
local Service Center.
A detailed report of the damage is necessary for any insurance claim.
NOTE !
A damaged UPS must never be installed or connected to Utility or Battery!
4.3 STORAGE
4.3.1 Storage of the UPS
The equipment is carefully packed for transport and
storage so that it is in a perfect condition when eventually
installed.
Never leave an UPS
outside the building and do not store
the UPS one on top of the other.
We recommend to store the UPS in its original package in
adry, dust-
free room, away from chemical substances,
and with a temperature range not exceeding -13°F (-25°C)
to 131°F (55°C).
In case the battery is included please refer to Section 4.3.2.
Some important functions of the UPS, such as the customized functions, are defined by parameters
stored in a RAM memory.
A small backup Battery located on the Control Unit board supplies the RAM.
If the storage time of the UPS exceeds 1 year, these functions should be verified by an authorized
Service Center before putting the UPS into operation.
4.3.2 Storage of Battery
When the delivery includes a maintenance free Battery, keep in mind that they are subject to self-
discharge and therefore you must recharge the Battery.
The storage time without Battery recharge depends on the temperature of the storage site.
The optimal temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed the
range -4°F (-20°C) to 104°F (40°C).
Recharge stored maintenance free Battery every:
6 months when the storage temperature is 68°F (20°C)
3 months when the storage temperature is 86°F (30°C)
2 months when the storage temperature is 95°F (35°C)

Critical Power
Modifications reserved
Page 16/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
4.4 PLACE OF INSTALLATION
4.4.1 UPS location
NOTE !
UPS installation and connection must be performed by QUALIFIED SERVICE
PERSONNEL only.
If optional cabinets and accessories are included with the UPS, please refer to those
accompanying manuals for installation and operating instructions.
It is important to have a clean, dust-free environment provided with proper ventilation and air-
conditioning to keep the ambient temperature within the specified operating range.
The recommended air inlet temperature is from 68°F (20°C) to 77°F (25°C) (max. 104°F / 40°C).
Refer to Section 4.5.
Check for sufficient floor load capacity before installing the UPS and the Battery.
Refer to Section 4.1.1.
For Battery installation follow the local codes and the recommendation of the battery supplier.
NOTE !
Temperature is very important for valve-regulated batteries (maintenance free).
Operation at temperatures higher than 77°F (25°C) will reduce battery life.
The TLE Scalable Series 40 - 150UPS can radiate radio frequency energy.
Although some RFI (Radio Frequency Interference) filtering is inherent to the UPS there is no guarantee that
the UPS will not influence sensitive devices such as cameras and monitors that are positioned close by.
If interference is expected, the UPS should be moved away from the sensitive equipment.
Positioning of the UPS TLE Scalable Series 40 - 150
Fig. 4.4.1-1 TLE Scalable Series 40 - 150 – Positioning of the UPS
Clearance around the front of the unit
should be sufficient to enable free passage
of personnel with the doors fully open, and
to allow sufficient airflow to the door vents.
Check section 110-26(A) of the NEC code
for specific requirements.
To guarantee proper cooling and exhausted
air exchange, IT IS MANDATORY to maintain
the following minimum distances:
Rear side: 2” (50mm)
Top of the UPS: 20” (500mm)
A single-phase power outlet (120Vac) should
be provided near the UPS for connection of
power tools, test equipment or connectivity
devices.
This outlet must be grounded.
Min.
20" / 500mm
TLES_UL_040-150_S1_UPS disposition_GE_01
Min.
2" / 50mm

Critical Power
Modifications reserved
Page 17/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
TLE Scalable Series 40 - 150 Opening for input and output cable connections
Fig. 4.4.1-2 TLE Scalable Series 40 - 150
Opening on the bottom of the cabinet for input and output cable connections
TLE Scalable Series 40 - 150
provided an opening on the
bottom of the cabinet for the
connection of input and output
cables.
Pay attention to the position of
this opening when choosing the
placement of the UPS.
Fixing of the UPS cabinet TLE Scalable Series 40 – 150 on the floor
The UPS cabinet is free standing and normally
does not require to be bolted to the floor.
The UPS cabinet can be fixed however to the
floor by bolting it with the supporting blocks to
the floor.
Fig. 4.4.1-3 Fixing of the UPS cabinet on the floor
Fig. 4.4.1-4 TLE Scalable Series 40 - 150 – UPS cabinet floor fixing points
FRONTAL SIDE
Utility input
Load output
Battery
20.67"
525mm
1.48"
37.5mm
1.48"
37.5mm
8.27"
210mm
22.15"
562.5mm
3.64"
92.5mm
23.63"
600mm
34.06"
865mm
TLES_UL_040-150_S1_UPS view bottom_01US
TLES_040-120_S1_UPS fixing_GE_02
FRONTAL SIDE
21.85"
555mm
0.89"
22.5mm
0.89"
22.5mm
28.94"
735mm
3.47"
88mm
23.63"
600mm
34.06"
865mm
1.65"
42mm
TLES_UL_040-150_S1_UPS fixing_01
Ø 0.53"
13.5mm

Critical Power
Modifications reserved
Page 18/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
Fig. 4.4.1-5 TLE Scalable Series 40 - 150 – RPA Parallel System disposition
In case of parallel system, try to
place the UPS modules in sequence
of their numbers
(marked on the
packing).
If the units are positioned “
side by
side
”, the side panels must be
mounted on all units.
4.4.2 Battery location
Batteries require a well-ventilated room with controlled temperature to obtain reliable operation.
The Battery can be installed immediately adjacent to the UPS (left or right side) or remotely from the
UPS.
If the Battery is installed remotely from the UPS, a wall mounted DC disconnect device must be installed
within line-of-site to both the UPS and the Battery.
The optimal room temperature for Battery storage is 68°F (20°C) to 77°F (25°C) and shall never exceed
the range -4°F (-20°C) to 104°F (40°C).
The life of valve-regulated batteries will be reduced by 50% for each additional 18°F (10°C) that the
battery ambient temperature is above 77°F (25°C).
The Battery System associated with larger UPS is usually either rack mounted or installed in multiple
Battery Cabinets.
Installation and assembly must be made according to the local standards and Battery System
manufacturer‘s recommendations.
The Battery Circuit Breaker or Battery Fuse Box must be mounted as near as possible to the Battery.
WARNING !
Battery installation and connection must be performed by QUALIFIED PERSONNEL
ONLY.
Read all safety instructions before proceeding with the installation (see Section 1).
Battery discharging and/or charging activities may cause the emission of
hydrogen gas; therefore, the room requires proper ventilation and fresh air.
Comply with the UL1778-CSAC22.2no170.3 UPS safety standard, ANSI/IEEE P1184
Guide for Batteries for Uninterruptible Power Supply Systems and applicable codes
and governmental regulations.
TLES_040-120_S1_RPA disposition_01GB
UPS 6
UPS 5
UPS 4
UPS 3
UPS 2
UPS 1

Critical Power
Modifications reserved
Page 19/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
4.5 VENTILATION AND COOLING
Fig. 4.5-1 Installation on plain floor Fig. 4.5-2 Installation on raised floor
The heat produced by the UPS is transferred to the environment by its ventilation.
A suitable ventilation or cooling system must be installed to extract the heat from the UPS room.
NOTE !
Do not put anything on the top of the cabinet.
20” (500mm) of air clearance MUST BE LEFT from the top of the UPS for a sufficient
exhausted air exchange, proper cooling, service access and safety.
Air filtering systems could be required when the UPS operates in a dirty environment.
In order to prevent overheating of the UPS, the available air intake flow rate must exceed the total air
exhaust flow rate requirement of the UPS system.
Contact your Dealer or the nearest Service Center for appropriate solutions.
The below table indicates the heat dissipation at full Load at PF = 0.9/1and charged Battery, up to 3280
ft (1000 m) altitude, for cooling air 77°F (25°C) to 86°F (30°C).
UPS model
Losses
Cooling air flow
VFI
SEM (Super Eco Mode)
VFI
PF = 0.9
PF = 1
PF = 0.9
PF = 1
PF = 0.9
PF = 1
TLE Scalable Series 150/40
6005 BTU/hr
1760 kW
6142 BTU/hr
1800 kW
1841 BTU/hr
540 kW
1911 BTU/hr
560 kW
872 CFM
513 m
3
/h
892 CFM
525 m
3
/h
TLE Scalable Series 150/50
7507 BTU/hr
2200 kW
7677 BTU/hr
2250 kW
1962 BTU/hr
575 kW
2047 BTU/hr
600 kW
1090 CFM
642 m
3
/h
1115 CFM
656 m
3
/h
TLE Scalable Series 150/80
11738 BTU/hr
3440 kW
12011 BTU/hr
3520 kW
3139 BTU/hr
920 kW
3276 BTU/hr
960 kW
1705 CFM
1003 m
3
/h
1744 CFM
1027 m
3
/h
TLE Scalable Series 150/100
15013 BTU/hr
4400 kW
15355 BTU/hr
4500 kW
3583 BTU/hr
1050 kW
3753 BTU/hr
1000 kW
2180 CFM
1283 m
3
/h
2230 CFM
1313 m
3
/h
TLE Scalable Series 150/120
18016 BTU/hr
5280 kW
18426 BTU/hr
5400 kW
4299 BTU/hr
1260 kW
4504 BTU/hr
1320 kW
2616 CFM
1540 m
3
/h
2676 CFM
1575 m
3
/h
TLE Scalable Series 150/150
22520 BTU/hr
6600 kW
23544 BTU/hr
6900 kW
5374 BTU/hr
1575 kW
5630 BTU/hr
1650 kW
3271 CFM
1925 m
3
/h
3419 CFM
2013 m
3
/h
NOTE !
The ventilation and cooling system shall be rated as for operation in VFI mode.
TLES_UL_040-150_S1_UPS ventilation_Plain floor_01US
Air Extraction
Air Intake
Air Intake
TLES_UL_040-150_S1_UPS ventilation_Raised floor_01US
Air Extraction

Critical Power
Modifications reserved
Page 20/53
GE_UPS_ISG_TLE_SUL_40K_M15_1US_V010.docx
Installation Guide TLE Scalable Series 40 - 150 UL S1
4.6 UNPACKING
Move the equipment in it’s original packing, wooden case, until the place of installation and remove the
packing and the transport sockets only just before installing the UPS.
Be aware of the heavy weight of the UPS, pay attention when moving the UPS cabinet.
White color =without any anomaly
Red color =anomaly evidence
The package of the TLE Scalable Series 40 - 150
is equipped with ShockWatch (indicator for
shock), and TiltWatch (indicator for overthrow)
on the outside.
These devices indicate an eventual shock or
overthrow during transport.
Whenever these devices show a possible
anomaly, the UPS shall not be commissioned.
Please contact your “GE Service Center”.
Fig. 4.6-1 ShockWatch device
Fig. 4.6-2 TiltWatch device
NOTE !
Be aware of the heavy weight of the UPS, pay attention when moving the UPS
cabinet.
Take care not to damage the UPS when moving by forklift.
A damaged UPS must never be installed or connected to Utility or Battery!
In case of any damage sustained during the transport, immediately inform the
shipping agent!
A detailed report of the damage is necessary for any indemnity claim.
Included in the delivery you can find the following parts:
•An accessories bag.
•Air inlet grids, which must be mounted on the bottom of the cabinet UPS with the screws included.
•Control Bus cables for inter-connecting the UPS modules (only For the RPA system).
•The documentation includes the “Installation Guide & User Manual”and the “UPS Safety Rules”.
PACKING MATERIAL RECYCLING
GE, in compliance with environment protection, use only environmentally
friendly material.
UPS packing materials must be recycled in compliance with all applicable
regulations.
