GeoVision GV-R1352 User manual

June 15, 2011
1
GV- R1352 Card Reader
The GV-R1352 is a card reader designed to recognize identification cards. Featured with the
Wiegand and RS-485 outputs, the unit can be connected to any standard access control
panel. GV-R1352 comes with a weather sealed and IP66 compliant housing for outdoor use.
1. Packing List
1. GV-R1352 Card Reader x 1
2. Screw x 3
3. Screw Anchor x 2
4. Security Torx
5. GV-R1352 Software CD x 1
6. GV-R1352 Installation Guide
Front View
2. Electric Wire
Wire Color Function
Red DC 12V
Black GND
Yellow Beeper
Orange Green LED
Light Red Red LED
Green Wiegand Data 0
White Wiegand Data 1
Blue RS-485 +
Light Blue RS-485 -
Gray N/A
Purple N/A
Brown N/A
Rear View

June 15, 2011
2
3. LED Indicator and Beeper
In standby mode, the LED is blue. When a card is read, the LED flashes green and the
beeper beeps once.
GV-R1352 comes with the external control wires of Green LED, Red LED and Beeper. When
these control wires are connected to GV-AS Controller, the status of LED and Beeper can be
defined by GV-AS Controller. For details on how to configure the settings, refer to
6.Configuring the Beeper and LED Indicator later in this installation guide.
4. Connecting GV-R1352 to GV-AS Controller
GV-R1352 is compatible with GV-AS100/110/120/400 Controllers, but the connection
between GV-R1352 and the controller varies with different controller models. The following
diagrams illustrate how to connect GV-R1352 to GV-AS400 Controller through Wiegand or
RS-485 interface.
4.1 Connecting through Wiegand Interface
Up to eight GV-R1352 readers can be connected to GV-AS400 Controller through the
controller’s Wiegand interface.
Wiegand A
Wire Color
Function
Black GND
Green Wiegand Data 0
White Wiegand Data 1
Red DC 12V

June 15, 2011
3
4.2 Connecting through RS-485 Interface
Up to eight GV-R1352 readers can be connected together to the RS-485 interface on GV-
AS400 Controller. When multiple readers are connected to the same RS-485 interface, you
need to specify each reader an ID so that the controller can distinguish one reader from
another. You will need to:
1. Connect GV-R1352 readers to a computer to access the GV-RK1352 Config AP.
2. Define the ID number of each GV-R1352 reader on the GV-RK1352 Config AP.
3. Wire GV-R1352 readers to GV-AS Controller.
Note: If only one GV-R1352 reader is connected to GV-AS Controller through RS-485
interface, you can skip steps 1 and 2, and the default ID number for the reader will be 0.
4.2.1 Connecting GV-R1352 to a Computer to Access GV-RK1352 Config AP
Using the GV-RK1352 Config AP included in the software CD, you can define the ID
numbers of multiple readers connected through RS-485 interface.
To start the GV-RK1352 Config AP, you have to connect GV-R1352 to a computer through
GV-COM, GV-Hub or GV-NET/IO Card V3.1.
Wire Color
Function
Blue RS-485 +
Light Blue RS-485 -
Note: GV-R1352 is not compatible with GV-NET Card and GV-NET/IO Card of versions
earlier than V3.

June 15, 2011
4
4.2.2 Defining ID Numbers of Readers
After GV-R1352 readers are connected to a computer, follow the steps below to define the ID
number of each GV-R1352 reader:
1. Insert the software CD and the Install Program window will pop up automatically.
2. Select Install GeoVision USB Devices Driver.
3. In the GeoVision USB Driver Installer window that appears, select Install.
4. Go back to the Install Program window, and select Run GV-RK1352 Config Utility. This
dialog box appears.
5. Type the barcode number of GV-R1352 in the Serial ID box. The barcode number is on
the rear panel of GV-R1352.
6. Select the COM port that is connected to GV-R1352 and click Open COM. The red
square next to the COM port box should change to blue to indicate the COM port is
correct.

June 15, 2011
5
Note: If the COM port is incorrect, an “Error opening serial port”message will appear.
To verify the COM port that is connected to GV-R1352, go to Windows Device Manager. In
the Ports (COM & LPT) field, you should see the entry for Prolific USB-to-Serial Comm
Port. The COM port showing in the entry indicates the COM number currently in use.
7. Select an ID number for the reader. The ID number ranges from 0 to 7.
8. Click Setup GO. The settings are sent to GV-R1352.
Note: If you select the wrong COM port of GV-R1352, a “Fail. Please check Serial ID and
comport” message will appear when you click the Setup GO button. Go to Windows
Device Manager to find out the COM port of GV-R1352.

June 15, 2011
6
4.2.3 Wiring GV-R1352 to GV-AS Controller
After defining the ID number of the readers, you can connect the wires of GV-R1352 to GV-
AS Controller. Here we use GV-AS400 Controller as example to illustrate the wiring.
 Connecting four or less readers to GV-AS400 Controller:
Wire Color
Function
Black GND
Light Blue RS-485 -
Blue RS-485 +
Red DC 12V
 Connecting five or more readers to GV-AS400 Controller:
For readers five to eight, connect the RS-485 cable to the RS-485 interface on GV-
AS400 Controller and then connect the 12V power output and GND of the reader to a
10V to 13V DC power output on the GV-AS Power Board.
Wire Color
Function
Black GND
Light Blue RS-485 -
Blue RS-485 +
Red DC 12V

June 15, 2011
7
5. Defining Readers on GV-AS Controller Web Interface
This section explains how to define readers on the Web interface of GV-AS Controller using
GV-AS400 Controller as an example. Since GV-AS400 Controller can control up to four
doors, you need to specify which door each reader controls.
1. On the GV-AS400 Web interface, click Extend Reader. This dialog box appears.
2. Select the ID number of the reader and type its barcode number. The ID number should
be the same with the one you configure through the GV-RK1352 Config AP.
3. Select a door/gate for the reader from the Function drop-down list. Click Submit.

June 15, 2011
8
6. Configuring the Beeper and LED Indicator
You can configure the settings of the LED and the beeper by enabling the GV-AS Controller
to externally control the LED and Beeper. You will have to:
1. Set up the Beeper and LED settings of the reader by using the GV-RK1352 Config AP.
2. Wire the Beeper, Red LED and Green LED from GV-R1352 to GV-AS Controller.
3. Specify the Beeper and LED settings for each door through the Web interface of GV-AS
Controller.
6.1 Setting up Beeper and LED on GV-RK1352 Config AP
To enable the external controls of the Beeper and LED, start the GV-RK1352 Config AP
according to the instructions in Accessing the GV-RK1352 Config AP earlier in this
installation guide.
After GV-RK1352 Config AP is started, you have to enable the external controls and set the
GV-R1352 to be slave.
1. Start the GV-RK1352 Config AP. Type the barcode number and the COM port of GV-
R1352. The barcode number is on the rear panel of GV-R1352. Refer to Defining ID
Numbers of Readers earlier in this installation guide on how to determine the COM port
of GV-R1352.

June 15, 2011
9
2. To enable external control of Beeper or LED, select Beeper, Green LED or Red LED.
 Beeper: Enables the external control of Beeper.
 Green LED: Changes the standby color from blue to green.
 Red LED: Changes the standby color from blue to red.
3. Select Slave from the Master / Slave drop-down list and select an ID number for the
reader. The ID number is ranging from 0 to 7.
4. Click Setup GO. The settings are sent to GV-R1352.
After the above settings, you need to connect the Beeper, Red LED and Green LED wires
from GV-R1352 to GV-AS Controller.
6.2 Wiring the Beeper and LED to GV-AS Controller
To wire the beeper and LED to GV-AS Controller, follow these steps. We will use GV-AS400
Controller as an example. Connect the control wires of GV-R1352’s Beeper, Red LED or
Green LED to any of outputs 9 ~ 16 on GV-AS400 Controller. The following diagram is an
example on connecting the beeper wire of GV-R1352 to GV-AS400 Controller.
Wire Color
Function
Black GND
Yellow Beeper

June 15, 2011
10
6.3 Configuring the Beeper and LED Settings for Each Door/Gate
After connecting the wires for Beeper or LED, specify the Beeper or LED settings for each
door/gate on the GV-AS Web interface. Here we use GV-AS400 Controller as example.
1. On the GV-AS400 Web interface, click Output Setting. The page below appears.
2. From outputs 9~12, select a door and select Beeper, Green LED, Red LED or Invert
Red LED. Click Submit.
 Beeper: Enables the external control of Beeper.
 Green LED: Changes the standby color to blue. When a card is read, the LED
flashes green.
 RED LED: Changes the standby color to red. When a card is read, the LED flashes
blue.
 Invert Red LED: Changes the standby color to blue. When a card is read, the LED
flashes red.

June 15, 2011
11
7. Firmware Upgrade
GeoVision will periodically release the updated firmware on the website. The new firmware
can be simply loaded into GV-R1352 by using Update Utility included in the Software CD.
Important Notes before You Start
Before you start updating the firmware, please read these important notes:
1. While the firmware is being updated, the power supply must not be interrupted.
2. Do not turn the power off within 10 minutes after the firmware is updated.
WARNING: The interruption of power supply during updating causes not only update
failures but also damages to the device. In this case, please contact your sales
representative and send your device back to GeoVision for repair.
To upgrade firmware:
1. Insert the Software CD, and select Run Firmware Update Utility. This dialog box
appears.
2. Select the COM port of GV-R1352.
3. Click the Browse button to locate the firmware file (.img) saved at your local computer.
4. Click Update.
5. The LED indicator should flash purple during the process of firmware upgrading. When
the process is complete, GV-R1352 will be sounded twice and the LED indicator will
change to green.

June 15, 2011
12
8. Specifications
CPU 8 bit microprocessor
Frequency 13.56 MHz for ISO14443A (Mifare DESFire, Mifare
Plus and Mifare Class)
Wiegand Interface Wiegand 26 / 34 bit, distance 30 m / 98.43 ft
RS-485 9,600 bps, connect up to 8 GV-R1352 units
Power DC 7.5V – 12V
LED Red, Green and Blue LED
Beeper Buzzer
Reader Color Black
Operating Temperature -20 °C ~ 60 °C / -4 °F ~ 140 °F
Operating Humidity 10% ~ 90% (no condensation)
Dimensions (W x H x D) 65.80 x 115.6 x 20.5 mm / 4.6 x 2.6 x 0.8 in
Weight 120 g / 0.26 lb
Certification IP66, CE, FCC, RoHS
9. The number of GV-R1352 supported by GV-AS
Controllers
GV-R1352 Interface
GV-AS Controller Model Wiegand RS-485
GV-AS100 11
GV-AS110 / 120 1 Not support
GV-AS100 / 110 / 120 with GV-ASBox 24
GV-AS100 / 110 / 120 with GV-ASNet Not support 2
GV-AS400 88
