Gestetner CS210 User manual

1. Basics
How to Make a Copy........................................................................
2. Area Editing Example (Only for Edit type)
Filling a Background Area with a Color ............................................
3. Area Editing Summary (Only for Edit type)
Other Area Editing Functions ...........................................................
4. Color Balance Adjustment
Adjusting the Color Balance .............................................................
5. Image Overlay (Only for Edit type)
Making a Leaflet...............................................................................
6. Front & Back Cover
Copying Front and Back Covers ......................................................
7. Summary
Features at a Glance........................................................................
Some limitations may apply to functions—for details please refer to the Operating Instructions.
The copy samples in this guide differ somewhat from actual copies due to printing effects.
page.2
page.4
page.6
page.8
page.10
page.12
page.14
This machine comes in two models which are referred to in this manual as Basic type and Edit
type.
Check the inside front cover of the Operating Instructions for the model you have before
reading this guide.

2
In this situation... Use this function...
You wish to make a copy in the same color
and the same size as your original.
Basics
This machine has the following functions:
• Auto Color Select
Selects a suitable color automatically.
• Auto Original Type Select
Selects a suitable original image type au-
tomatically.
• Auto Paper Select
Selectsasuitablepaper sizeautomatically.
How to Make a Copy
Set the
original.
Make sure that
following functions
are selected:
• [Auto Color Select]
• [Text / Photo]
• [Auto Paper Select]
• [Full Size]
*Auto Color Select and Auto Original Type Select
cannot be set together.

3
Tip
On the exposure glass(platen glass) In the document feeder
To check the number
ofcopiesmadesofar,
press the Counter
key .
Face down
Press the
Start key.
Face up

4
In this situation... Use this function...
You wish to fill the specified background of
your original with a selected color.
Area Editing Example (Only for Edit type)
The Color Background function inArea Ed-
itingmakescopieswith the designatedarea
filled in a selected color.
Filling a Background Area with a Col
Set the original
on the exposure glass
(platen glass).
*For information on other Area Editing features, see page 6 and 7.
Press the
[Area Editing]
key.
Select the
area shape,
then designate
the area.

5
h a Color
Select [Color
Creation] , then press the
[Color Background] key.
Select the
desired color,
then press the
[OK] key twice.
Press the
Start key.
Press the
[Confirm Selection]
key.
Press the
[Area Edit] key.

6
Area Editing Summary (Only for Edit type)
Other Area Editing Functions
Objective Area Selection Edit the Area Copy Result
Color Conversion
I wish to change the
color of an area.
GCARE10E
햲Select Rectangle .
햳Mark the first point with the editor
pen or your finger.
햴Mark the diagonally opposite cor-
ner of the area you wish to select.
햵Press the [Area Edit] key.
햶Press the [Color Creation] key.
햷Pressthe[Color Conversion] key.
햸Pressthecolor youwishtochange.
햹Press the color you wish to use.
햺Press the [OK] key.
햻Press the [OK] key.
Delete Area
I wish to delete an area. 햲Select R.A.Polygon .
햳Mark the first point with the editor
pen or your finger.
햴Mark the points.
햵Press the [Area Edit] key.
햶Press the [Delete Area] key.
햷Press the [OK] key.
Color Erase
I wish to remove color
from an area.
햲Select Polygon .
햳Mark the first point with the editor
pen or your finger.
햴Mark the points.
햵Press the [Area Edit] key.
햶Press the [Color Creation] key.
햷Press the [Color Erase] key.
햸Press the color you want to erase.
햹Press the [OK] key.
햺Press the [OK] key.
Save Area
I wish to blank out all ar-
eas except the selected
area.
햲Select R.A.Polygon .
햳Mark the first point with the editor
pen or your finger.
햴Mark the points.
햵Press the [Area Edit] key.
햶Press the [Save Area] key.
햷Press the [OK] key.

7
s
Objective Area Selection Edit the Area Copy Result
Paint
I wish to fill an area with
a selected color.
햲Select Closed Loop .
햳Touch on a point inside a closed
loop.
햴Press the [Area Edit] key.
햵Press the [Color Creation] key.
햶Press the [Paint] key.
햷Select the color you want to use.
햸Press the [OK] key.
햹Press the [OK] key.
Multi-Closed Loop
I wish to fill an area but
leaveaninternal partleft
unfilled.
햲Select Multi-Closed Loop .
햳Touch on a point inside a closed
loop.
햴Touch onapoint thatyou don’twant
to paint.
햵Press the [Area Edit] key.
햶Press the [Color Creation] key.
햷Press the [Paint] key.
햸Select the color you want to use.
햹Press the [OK] key.
햺Press the [OK] key.
Line
I wish to add a line. 햲Select Frame/Line,then selectLine
.
햳Mark the first point with the editor
pen or your finger.
햴Mark the last point.
햵Press the [Area Edit] key.
햶Select the color you want to use.
햷Select the line width.
햸Press the [OK] key.

8
In this situation... Use this function...
Copies are too yellow.
Color Balance Adjustment
The Color Balance function allows you to
control the overall color tone of copies.
Adjusting the Color Balance
Press the
Adjustment/Memory
key.
Set the
original. Adjust the
color tone.

9
Tip
You can alter up to three single colors by mixing them with adjacent
colors in the color circle.
1. Press the Adjustment/Memory key.
2. Press the [Color Adjustment] key.
3. Select the color that you want to adjust from the color circle.
4. Adjust the color with the [ ] or [ ] key.
5. Press the [OK] key.
Press the
[OK] key.
Press the
Start key.

10
In this situation... Use this function...
You wish to superimpose one original im-
age over another e.g. to make a leaflet. The Image Overlay function makes copies with a portion of one original image (the im-
age original) overlayed onto another origi-
nal image (the background original).
Making a Leaflet
Image Overlay
Set the
original on the
exposure glass.
1: Background original
2: Image original
Press the
Area Image Overlay
[Image] key.
1: Foreground image original
2: Background image original
* Select the [Overlay Opacity
Yes] or [Overlay Opacity No]
key.
Press the
[Image Overlay]
key.

11
Tip
When you mark first point in step 5, a rectangle and
leading diagonal appear to show the full size and
scale of the image.
Select the
area of the
foreground
image original.
Then press the
[Confirm Selection] key.
Select the
area of the
background
image original.
Then press the
[Confirm Selection] key.
* To select the area
Mark two diagonally opposite
corners of a rectangle.
* You can select the scale of the
image. For details, see Tip.
Mark second point on the
leading diagonal.
For Proportional scaling
Mark second point off the
leading diagonal.
For Squeeze or strech
Press the
Start key.

12
In this situation... Use this function...
You wish to copy the front and back covers
onto different type (e.g. different color) pa-
per.
Front & Back Cover
UsetheFront&Back Coverfunctionto have
the first and last pages copied onto a differ-
ent kind of paper (e.g. colored) than that
used for the remaining pages.
Copying Front and Back Covers
Set the
originals in the
document feeder.
Select the
[Front & Back Cover]
key.
Press the
[Shift/Book] key.
The optional document feeder is required to use this function.

13
vers
Press the
Start key.
Select the
[Copy] or [Blank]
key.
sfunction.
* The covers are copied in
Thick mode.
Set cover
sheets into the
bypass tray.

14
Summary
Features at a Glance
For details, please see the following pages in the Operating Instructions.
• Color Mode Page 40
• Full Color Copy
• Black & White Copy
• Single Color Copy
• Twin Color Copy
•
Auto Original Type Select
Page 44
*1 Optional 20-bin sorter stapler required.
*2 Optional document feeder required.
*3 Only for Edit type.
• Margin Adjustment
Page 78
• Shift Page 77 • Cover Sheet
Page 82 *2
• Center Erase
Page 81 • Border Erase
Page 81 • Center/Border Erase Page 81
• Color Conversion
Page 85 • Color Erase
Page 87
• Color Background
Page 88 • Type Mask
Page 89
• Outline Image
Page 91 • Mirror Image
Page 96
• Shadow Image
Page 92 • Positive/Negative
Page 101
• Slanted Image
Page 95 • Repeat Image
Page 97
• Auto Paper Select
Page 47
• Auto Reduce/Enlarge
Page 54
UE USA A257

15
• Area Editing Page 139
• Color Conversion
Page 152 *3 • Color Background
Page 152 *3 • Delete Area Page 153 *3 • Full Image Overlay
Page 111 *3
•
Color Erase Page 152
*3 • Paint Page 152 *3 •
Save Area Page 154
*3 • Area Image Overlay Page 115 *3
• Sort Page 102
*1
• Stack Page 103
*1
• Staple Page 104
*1
• Preset R/E Page 59
• Zoom Page 60
• Size Magnification Page 62
•
Directional Magnification(%) Page 63
• Directional Size Magnification(inch) Page 64
• Poster Mode Page 65
• 1 Sided 2 Sided
Page 68 • 2 Sided 2 Sided Page 70 • Book 1 Sided Page 73 • 2 Sided 1 Sided Page 74
• Book 2 Sided
Page 71 • Multi 2 Sided Page 72 • Combine 2 Originals
Page 75 *2 • Combine 4 Originals Page 76 *2

Make copies of this manual and
stick them on the wall.
Set this manual
face down on the
exposure glass.
Press the [Start] key.
Stick the copies on the
wall.
NDCS51EE
A257-8657
UE USA
Printed in Japan
(S1092/G1096)
