Getac V110 User manual

Rugged Mobile Computing Solution
V110
USER MANUAL

Nov. 2013
TRADEMARKS
All brand and product names are trademarks or registered trademarks of
their respective companies.
NOTE
The information in this manual is subject to change without notice.
For the latest version of the manual, please visit the Getac website at
www.getac.com.

i
Table of Contents
Chapter 1 Getting Started..............................................................1-1
Getting the Computer Running............................................. 1-2
Unpacking ........................................................................... 1-2
Connecting to AC Power.................................................... 1-3
Opening and Closing the Cover......................................... 1-4
Operating in Tablet Mode ................................................. 1-5
Turning On and Off the Computer ................................... 1-7
Taking a Look at the Computer............................................. 1-8
Front Components.............................................................. 1-8
Rear Components ............................................................. 1-10
Right-Side Components.................................................... 1-11
Left-Side Components ...................................................... 1-12
Top-open Components..................................................... 1-13
Bottom Components ........................................................ 1-15
Installing the Accessories...................................................... 1-17
Attaching the Carrying Strap........................................... 1-17
Using the Tether (Optional)............................................. 1-18
Attaching the Handgrip Strap (Optional)....................... 1-19
Chapter 2 Operating Your Computer............................................2-1
Using the Internal Keyboard.................................................. 2-2
Typewriter Keys .................................................................. 2-2
Cursor-Control Keys............................................................ 2-2
Numeric Keypad.................................................................. 2-3
Function Keys...................................................................... 2-4
Fn Key .................................................................................. 2-4
Hot Keys .............................................................................. 2-4
Windows Keys..................................................................... 2-6

ii
Using the Touchpad................................................................ 2-7
Configuring the Touchpad................................................. 2-9
Navigating on the Screen..................................................... 2-10
Using the Touchscreen ..................................................... 2-10
Using the Dual Mode Display (Optional) ........................ 2-13
Using the Network Features................................................. 2-14
Using the LAN ................................................................... 2-14
Using the Wireless LAN .................................................... 2-14
Using the BT Feature ............................................................ 2-16
Turning On/Off the BT Radio........................................... 2-16
Connecting to another BT Device.................................... 2-17
Using the WWAN Feature (Optional).................................. 2-18
Installing a SIM Card......................................................... 2-18
Turning On/Off the WWAN Radio................................... 2-19
Setting up a WWAN Connection..................................... 2-20
Chapter 3 Managing Power ...........................................................3-1
AC Adapter.............................................................................. 3-2
Battery Pack............................................................................. 3-3
Charging the Battery Pack ................................................. 3-3
Initializing the Battery Pack............................................... 3-4
Checking the Battery Level ................................................ 3-4
Battery Low Signals and Actions ....................................... 3-5
Replacing the Battery Pack ................................................ 3-6
Power-Saving Tips ................................................................... 3-8
Chapter 4 Expanding Your Computer...........................................4-1
Connecting an HDMI Display Monitor .................................. 4-2
Connecting a USB Device........................................................ 4-3
Connecting a Serial Device..................................................... 4-4
Connecting an Audio Device.................................................. 4-5
Using Smart Cards ................................................................... 4-6
Using ExpressCards.................................................................. 4-7
Replacing the Hard Disk Drive ............................................... 4-9
System Memory Upgrade ..................................................... 4-10
Chapter 5 Using BIOS Setup...........................................................5-1
When and How to Use............................................................ 5-2
Menu Descriptions .................................................................. 5-3
Information Menu .............................................................. 5-3
Main Menu.......................................................................... 5-3

iii
Advanced Menu.................................................................. 5-4
Security Menu ..................................................................... 5-5
Boot Menu .......................................................................... 5-6
Exit Menu ............................................................................ 5-6
Chapter 6 Using Getac Software ...................................................6-1
OSD Control Panel .................................................................. 6-2
G-Manager .............................................................................. 6-3
Getac Camera (Optional)........................................................ 6-5
Getac Smart Tag (Optional).................................................... 6-6
Chapter 7 Caring for the Computer ..............................................7-1
Protecting the Computer........................................................ 7-2
Using an Anti-Virus Strategy.............................................. 7-2
Using the Cable Lock .......................................................... 7-2
Taking Care of the Computer ................................................ 7-3
Location Guidelines ............................................................ 7-3
General Guidelines ............................................................. 7-4
Cleaning Guidelines............................................................ 7-4
Battery Pack Guidelines...................................................... 7-5
Touchscreen Guidelines...................................................... 7-6
When Traveling....................................................................... 7-7
Chapter 8 Troubleshooting ............................................................8-1
Preliminary Checklist............................................................... 8-2
Solving Common Problems..................................................... 8-3
Battery Problems ................................................................ 8-3
BT Problems......................................................................... 8-3
Display Problems................................................................. 8-4
Hardware Device Problems ................................................ 8-5
Keyboard and Touchpad Problems ................................... 8-5
LAN Problems...................................................................... 8-6
Power Management Problems .......................................... 8-6
Sensor Problems (for Windows 8 Models Only) ............... 8-7
Software Problems ............................................................. 8-8
Sound Problems .................................................................. 8-8
Startup Problems ................................................................ 8-8
Wireless LAN Problems....................................................... 8-9
Other Problems................................................................. 8-10
Resetting the Computer ....................................................... 8-11
System Recovery.................................................................... 8-12

iv
System Restore, Refresh, or Reset (for Windows 8
Models).............................................................................. 8-12
System Recovery (a Tool for Windows 7 Models)........... 8-13
Appendix A Specifications ............................................................... A-1
Appendix B Regulatory Information............................................... B-1
On the Use of the System.......................................................B-2
Class B Regulations .............................................................B-2
ANSI Warning......................................................................B-3
Safety Notices......................................................................B-4
On the Use of the RF Device...................................................B-6
USA and Canada Safety Requirements and Notices.........B-6
European Union CE Marking and Compliance Notices....B-8

Getting Started 1-1
Chapter 1
Getting Started
Congratulations on purchasing this rugged computer.
This chapter first tells you step by step how to get the computer up and
running. Then, you will find a section briefly introducing the external
components of the computer.

1-2 Getting Started
Getting the Computer Running
Unpacking
After unpacking the shipping carton, you should find these standard items:
Notebook computer
Accessories:
−Battery pack x 2
−AC adapter
−AC power cord
−Stylus or digitizer pen (optional)
−Tether (optional)
−Carrying Strap
−AG/AR (anti-glare/anti-reflection) film, which is already attached to
the screen
−Screen cleaning cloth
−Driver disc
−Document(s)
Inspect all the items. If any item is damaged or missing, notify your dealer
immediately.

Getting Started 1-3
Connecting to AC Power
It is suggested that you use AC power when you start up the computer for
the very first time.
1. Plug the DC cord of the AC adapter to the power connector of the
computer ().
2. Plug the female end of the AC power cord to the AC adapter and the
male end to an electrical outlet ().
3. Power is being supplied from the electrical outlet to the AC adapter and
onto your computer. Now, you are ready to turn on the computer.
CAUTION: Use only the AC adapter included with your computer. Using
other AC adapters may damage the computer.
NOTE: When the AC adapter is connected, it also charges the battery pack.
For information on using battery power, see Chapter 3.

1-4 Getting Started
Opening and Closing the Cover
To open the top cover:
1. Pull loose the cover latch () and release the clamp ().
2. Lift up the cover (). You can tilt the cover forward or backward for
optimal viewing clarity.
To close the top cover:
1. Close the display.
2. Lift the cover latch and engage the clamp on the display. Then, push in
the cover latch to click it into place.
