Getac S410-G4 User manual

Getac S410-G4
Self-Maintenance Manual

2 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Content
Handle (P/N 344876800018)
Side door (P/N 340876800006)
Rear door (P/N 340876800007)
Main SSD canister (P/N 581191770002)
Keyboard (P/N 531091770001)

3 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Handle (P/N 344876800018)
1. Remove the four screws (342830700019), then remove the cover.
2. Remove the Handle.
To install:
Reverse the removal procedure to install the new part.

4 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Side door (P/N 340876800006)
1. Remove the four screws (371102010066) that secure the door to S410G4.
2. Detach the door from S410G4.
To install:
Reverse the removal procedure to install the new part.

5 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Rear Door (P/N 340876800007)
1. Remove the three screws (371102010066) that secure the door to S410G4.
2. Detach the door from S410G4.
To install:
Reverse the removal procedure to install the new part.

6 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Main SSD canister (P/N 581191770002)
1. Remove one screw (370102010421), and then remove the SSD canister.
2. Remove one screw (371102010432), and then remove the cover., you can find below parts.

7 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Main SSD canister (P/N 581191770002)
3. Paste the Mylar onto the new SSD.
4. Paste the thermal pad onto the other side of the SSD.

8 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Main SSD canister (P/N 581191770002)
5. Insert the SSD into the connector.
6. Assemble the SSD cover and fix the cover using the one screw (371102010432).
Attention: The hook needs to be clamped tightly.

9 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Main SSD canister (P/N 581191770002)
7. Paste the Mylar onto the SSD canister.
Attention：You can choose if you want to paste this Mylar or not.

10 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Keyboard (P/N 531091770001)
1. Remove two screws (371102010432) lock the keyboard cover.
2. Remove seven screws (371102010432) lock the keyboard cover and hinge cover. Then remove the
keyboard cover and hinge cover.

11 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Keyboard (P/N 531091770001)
3. Remove two screws (371102010432) lock the keyboard cover.
4. Remove four screws (370102010416) lock the keyboard bracket cover, then remove the keyboard bracket
cover.

12 Copyright © 2018 Getac Technology Corporation and/or any of its affiliates. All Rights Reserved.
｜
Keyboard (P/N 531091770001)
5. Disconnect the keyboard FPC, then remove the keyboard.
To install:
Reverse the removal procedure to install the new part.
