Gewa DP300G User manual

USER MANUAL
GEWA Digital Piano DP 300 G
Bedienungsanleitung | User manual | Mode d’emploi | Manual de instrucciones
www.gewakeys.com
Read these operating instructions before use and observe the
safety information!
Keep the instruction manual for future reference.

2
Manufacturer:
GEWA music GmbH
Werkstraße 1
08626 Adorf
GERMANY
www.gewamusic.com
Version 1.0
Last update: 10.04.2019

3
1 SAFETY INFORMATION ................................................................................................................. 5
1.1 Key ......................................................................................................................................... 5
1.2 Intended use .......................................................................................................................... 6
1.3 Improper use ......................................................................................................................... 6
1.4 Precautions ............................................................................................................................ 7
1.5 CE mark ................................................................................................................................. 8
1.6 Disposal ................................................................................................................................ 8
2 DELIVERY........................................................................................................................................ 9
3 ASSEMBLY INSTRUCTIONS ....................................................................................................... 10
4 FIRST STEPS ................................................................................................................................ 12
4.1 Control elements of your digital piano ............................................................................... 12
4.2 Control buttons and pedals ................................................................................................. 13
4.3 Keyboard / Connections panel / Back.................................................................................. 15
5 OPERATING USE ......................................................................................................................... 17
5.1 Switching on ........................................................................................................................ 17
5.2 DEMO function ................................................................................................................... 17
5.3 Choice of sounds ................................................................................................................ 17
5.3.1 Dual Mode .................................................................................................................. 18
5.4 Reverb and Chorus ............................................................................................................. 18
5.4.1 Reverb ........................................................................................................................ 18
5.4.2 Chorus and other effects ............................................................................................ 19
5.5 Metronome .......................................................................................................................... 19
5.5.1 Metronome - switching on/off ..................................................................................... 19
5.5.2 Metronome - changing speed ................................................................................... 20
5.5.3 Changing time signature ........................................................................................... 20
5.5.4 Metronome - volume adjustment ................................................................................ 20
6 FUNCTIONS MENU ...................................................................................................................... 20
6.1 Settings ............................................................................................................................... 21
6.2 Transposition ....................................................................................................................... 21
6.3 Fine-tuning the sounds ........................................................................................................ 22
6.4 Touch function / touch sensitivity ........................................................................................ 22
6.5 Balance settings .................................................................................................................. 22
6.6 Brilliance settings . ............................................................................................................... 23
6.7 MIDI transmission channel .................................................................................................. 23
6.8 Local Control ....................................................................................................................... 23
6.9 Program Change function .................................................................................................... 24
6.10 Piano mode ........................................................................................................................ 24
6.11 Changing the tuning ........................................................................................................... 25
6.11.1 Changing the root note ........................................................................................... 25
6.12 Adjusting string resonance ................................................................................................. 25
6.13 Adjusting damper resonance .............................................................................................. 26
6.14 Adjusting LINE IN input volume .......................................................................................... 26
6.15 Auto Power Off ...................................................................................................................... 26
6.16 Layer Pedal ........................................................................................................................... 26
7 RECORDING AND PLAYBACK FUNCTIONS ............................................................................. 27
7.1 Recording music ................................................................................................................. 27
7.2 Playback of recordings ....................................................................................................... 27
7.3 Deleting recordings ............................................................................................................. 27
CONTENTS

4
CONTENTS
8 USER CALIBRATION OF THE KEYBOARD .................................................................................28
8.1 Selecting the calibration mode ........................................................................................... 28
8.2 Creating a user calibration .................................................................................................. 28
8.3 Comparing factory and user calibration ............................................................................. 29
8.4 Exit calibration mode ........................................................................................................... 29
9 CONNECTING EXTERNAL DEVICES (ACCESSORIES) ........................................................... 30
9.1 Connecting headphones ..................................................................................................... 30
9.2 Connecting a playback device .......................................................................................... 30
 9.3 Connectinganamplier ...................................................................................................... 30
9.4 Connecting to PC ................................................................................................................ 30
10 USEFUL INFORMATION .............................................................................................................. 31
10.1 INDEX .................................................................................................................................. 31
10.2 Warranty .............................................................................................................................. 32
11 TROUBLESHOOTING .................................................................................................................. 33
12 TECHNICAL SPECIFICATIONS ................................................................................................... 34

5
Level of danger Symbol Importance Denition
Severe injury WARNING Severe to fatal injuries if
disregarded
Severe injury through
electric shock WARNING Additional symbol for danger of
electric shock
Slight injury and property
damage CAUTION
Slight injury and / or property
damage can occur if the safety
instructions are disregarded.
Note NOTE
Crucial information
concerning the handling of
the device
Tip TIP Application tips
SAFETY INFORMATION
KEY
Dear Customer,
Thank you for choosing a digital piano from GEWA music!
You have chosen a high-quality digital piano that will give you an impressive sound
experience and lots of fun.
Additional functions extend the capabilities of your digital piano far beyond piano
playing.
Your safety is very important to us!
Please read the safety information carefully and pay close attention to it. Retain this
manual and hand it over to the respective user.
1SAFETY INFORMATION
The manufacturer is not liable for personal injury or property damage resulting from
improper use of the device!
Only use your digital piano as directed!
1.1 KEY
The following symbols are used in this operating manual to identify hazards and notes.
NOTE

6
1.2 INTENDED USE
The digital piano is intended for use in dry rooms.
• Devices for audio playback (as input or output) or for data communication can be
connected.However,therespectivetechnicalspecicationsmustbecompliedwith
(see the section “Technical data“).
• The electrical connection may only be made to correctly installed power supplies,
fulllingtherespectiveregulations.Themainsvoltageontheidenticationplatemust
correspond to the mains voltage of the country of use.
• The digital piano is only to be used in the original delivery condition described below.
Conversions of any kind are not permitted and cause the immediate loss of the warranty
claim.
• The digital piano must be placed on securely fastened and weight-suitable, stable and
leveloorsorplatforms.
1.3 IMPROPER USE – EXAMPLES:
• Use outdoors or in rain
• Use in damp rooms
• Connection to incorrect supply voltage or improperly installed electrical power supplies.
• Use in close proximity to electrical or electronic equipment such as stereos, televisions,
radios or mobile phones.
• These devices may cause interference and affect the sound quality.
• Electrical leads that are too long can also affect sound quality.
• Transport and installation in places or vehicles with strong vibration, dust and strong heat
e.g. direct sunlight.
The manufacturer accepts no liability for damage for the following reasons:
• Disregard of the safety instructions
• Improper handling
• Use with devices that are not compatible with the technical data listed below
NOTE
SAFETY INFORMATION
INTENDED USE

7
SAFETY INFORMATION
PRECAUTIONS
1.4 PRECAUTIONS
Please follow the the precautions listed here. Disregard of precautionary measures can
have serious consequences:
• Severe injury or even fatal accidents
• Electric shock
• Short circuit
• Damage
• Fire
Other threats are conceivable; this is not an exhaustive list.
WARNING Fatal electric shocks
• Even low electrical currents can lead to serious injuries and death.
• Never open the digital piano’s casing.
• Never use damaged power cables.
• Lay the power cable in such a way that it can not be damaged.
  •Neverplacecontainers(vases,glassesetc)lledwithwateroruidsonthepiano.
• Never pour water or liquids on to the digital piano or keyboard.
• Never clean the digital piano with a wet cloth.
• Never plug in or pull out the mains plug with wet hands. Never pull on the cable; it can
cause damage.
• If liquid accidentally gets into the digital piano, immediately unplug the power.
Then have your digital piano checked by your GEWA service representative.
WARNING Unusual circumstances
• Turn off the digital piano or unplug the power cable if:
- There is a sudden loss of sound while using the digital piano
- The digital piano generates an unusual smell or smoke
• Be sure to have the digital piano checked by your GEWA service representative
 WARNING Protectionagainstre
  •Openamessuchascandlesortealightscantipoverandcauseare
  •Neverplaceobjectswithopenamesonthedigitalpiano!

8
SAFETY INFORMATION
CE MARK
CAUTION Damage to the digital piano
• Inappropriate electrical voltages can damage the digital piano.
• Only operate the digital piano in the permissible voltage range (as indicated on the
respectiveidenticationplate).
• Only use the supplied power cable.
• Never place the power cable near to sources of heat, such as radiators or freestanding
heaters.
• Do not bend or kink the power cable, or damage it in any other way.
• Lay the power cable so that nobody can step on it, trip on it or roll over it.
• Do not place objects on the power cable.
• Regularly check the power cable and remove any dust or dirt that may be present.
CAUTION Damage to the digital piano through thunderstorms
• Thunderstorms can generate electrical surges that can damage electrical equipment.
• In the event of a thunderstorm or long periods of non-use (such as travel), unplug the
appliance from the mains.
1.5 CE MARK
CE MARK
This device complies with EU directive requirements: Directive 2014/53/EU
EN55020:2007+A11:2011
EN55024:2010
EN55032:2012
EN61000-3-2:2014
EN61000-3-3:2013
EN301489-17:V2.2.1
EN301489-17:V3.2.0
EN62479:2010
EN300328:V2.1.1
 TheconformitywiththeregulationslistedaboveisconrmedbytheCEsignonthedevice.
The declaration of conformity can be viewed at the following address:
GEWA music GmbH, Werkstraße 1, 08626 Adorf, GERMANY
1.6 DISPOSAL
To dispose of the old device, please take it to your local waste management authority
(e.g. disposal company or recycling centre).
The adjacent symbol indicates that the device must be disposed of separately from
household waste. In accordance with the Electrical and Electronic Equipment Act, owners
of old appliances are legally required to dispose of old electrical and electronic appliances
at a separate and designated waste disposal point.
Please help in contributing to protect the environment by not disposing of the old device
in household waste.

9
DELIVERY
2DELIVERY
Check that the contents of the package is complete before commencing with assembly.
No. Description Quantity
1 Keyboard and keyboard lid 1
1a Music desk 1
2 Rear panel 1
3 Pedal board 1
4 Left side panel 1
5 Right side panel 1
6 Connecting cable power supply 1
7a Phillips screw M6 x 16 4
7b Phillips screw M6 x 35 4
8a Phillips wood screw 3.5 x 18 4
8b Phillips screw M4 x 10 with washer and spring washer 2
9 Quick Start Guide 1
10 Adjustment screw 1

10
8
8
8
8
7
7
7
7
7
7
7
7
7
7
ASSEMBLY INSTRUCTIONS
3ASSEMBLY INSTRUCTIONS
This section tells you how to correctly set up your digital piano. For assembly you will
need:
• A size 2 phillips screwdriver
• Another person
Do not tighten the phillips screws until all parts of your digital piano have been pre-
assembled and aligned.
How to assemble your digital piano:
1. Unfold the pedal cable (not shown) and screw the adjustment screw ( 10 ) into the
pedal board ( 3 ).
2. Connect the side panels (4 and 5) with the pedal board using the phillips screw (7b)
3. Attach the rear panel ( 2 ) with the 4 phillips wood screws ( 8a ) to the pedal board. Then
connect it to the side panels by using the phillips screws ( 8b ).
 4.Thenyoucanplacethekeyboardonthetop.Ensurethatitisttedtothemetalangleof
the side panels. 4 phillips screws (7a) must be screwed into the keyboard from below.
5. Then align your digital piano and tighten all of the screws.
NOTE
