Gewa UP 360 G User manual

USER MANUAL
GEWA Digital Piano UP 360 G
Bedienungsanleitung | User manual | Mode d’emploi | Manual de instrucciones
www.gewakeys.com
Read these operating instructions before use and observe the
safety information!
Keep the instruction manual for future reference.

Manufacturer:
GEWA music GmbH
Werkstraße 1
08626 Adorf
GERMANY
www.gewamusic.com
Version 1.0
Last update: 11.04.2019

3
1 SAFETY INFORMATION ................................................................................................................. 5
1.1 Key ......................................................................................................................................... 5
1.2 Intended use .......................................................................................................................... 6
1.3 Improper use ......................................................................................................................... 6
1.4 Precautions ............................................................................................................................ 7
1.5 CE mark ................................................................................................................................. 8
1.6 Disposal ................................................................................................................................ 8
2 DELIVERY........................................................................................................................................ 9
3 ASSEMBLY INSTRUCTIONS ....................................................................................................... 10
3.1 Opening the keyboard lid ..................................................................................................... 11
3.2 Use with a keyboard stand ................................................................................................... 12
4 FIRST STEPS ................................................................................................................................ 12
4.1 Control elements of your digital piano ................................................................................ 12
4.1.1 Function Keys............................................................................................................... 13
4.1.2 Pedals .......................................................................................................................... 14
4.2 Keyboard Connections ....................................................................................................... 15
5 OPERATING USE ......................................................................................................................... 17
5.1 Switching on ........................................................................................................................ 17
5.2 DEMO function .................................................................................................................... 17
5.3 Sound selection ................................................................................................................... 18
5.3.1 Sound combination: Dual Sound ............................................................................... 19
5.3.2 Sound combination: Split Sound.................................................................................. 20
5.3.3 Sound combination: 4Hand Mode .............................................................................. 21
5.4 Effects ................................................................................................................................. 22
5.4.1 Reverb ........................................................................................................................ 22
5.4.2 Chorus and other effects ............................................................................................ 23
5.5 Metronome .......................................................................................................................... 24
5.6 Player ................................................................................................................................... 25
5.6.1 USB Player ................................................................................................................. 25
5.6.2 Lessons ...................................................................................................................... 26
5.6.3 DEMO function ........................................................................................................... 26
6 FUNCTIONS MENU ...................................................................................................................... 26
6.1 Table of Settings ............................ ..................................................................................... 27
6.2 General Settings ................................................................................................................... 28
6.2.1 Brilliance ...................................................................................................................... 28
6.2.2 Key Transpose ............................................................................................................ 28
6.2.3 Tuning ......................................................................................................................... 28
6.2.4 Max Phones Volume .................................................................................................... 29
6.2.5 Input Volume ............................................................................................................... 29
6.2.6 Input Reverb ................................................................................................................ 29
6.2.7 Start-Up Settings ......................................................................................................... 30
6.2.8 Piano Information ......................................... .............................................................. 30
CONTENTS

4
CONTENTS
6.3 Piano Settings ....................................................................................................................... 31
6.3.1 Keyboard Response ................................................................................................... 31
6.3.2 Damper Pedal ............................................................................................................. 32
6.3.3 Una Corda Level ......................................................................................................... 32
6.3.4 Sympathetic Resonance ............................................................................................. 32
6.3.5 Temperament .............................................................................................................. 33
6.3.6 Root Note .................................................................................................................... 33
6.4 USB ........................................... ........................................................................................... 34
6.5 System ................................................................................................................................. 34
6.5.1 Display Settings ......................................................................................................... 35
6.5.2 Auto Power Off ........................................................................................................... 35
6.5.3 Registrations Restore ................................................................................................. 35
6.5.4 Default Restore ........................................................................................................... 35
6.6 MIDI Settings ....................................................................................................................... 36
6.6.1 MIDI Transmission Channel ....................................................................................... 36
6.6.2 Local Control .............................................................................................................. 36
6.6.3 Program Change ........................................................................................................ 37
6.6.4 Piano Mode ................................................................................................................ 37
7 USER SETTINGS ......................................................................................................................... 38
7.1 Registration of settings ........................................................................................................ 38
7.2 Applying registrations ......................................................................................................... 38
8 RECORDER AND PLAYBACK .................................................................................................... 39
8.1 Recording songs ................................................................................................................. 39
8.1.1 Recording with metronome support............................................................................. 39
8.2 Playing back recordings ..................................................................................................... 40
8.3 Editing recordings ............................................................................................................... 40
8.4 Loop .................................................................................................................................... 40
9 KEYBOARD USER CALIBRATION ............................................................................................. 41
9.1 Entering the calibration mode ............................................................................................... 41
9.2 Creating a user calibration ................................................................................................... 41
9.3 Comparing factory and user calibration .............................................................................. 42
9.4 Saving and deleting the user calibration ............................................................................. 42
9.5 Exiting the calibration mode ................................................................................................. 42
10 CONNECTING EXTERNAL DEVICES ......................................................................................... 43
10.1 Connecting Headphones .................................................................................................... 43
10.2 Connecting a playback device ........................................................................................... 43
 10.3 Connectinganamplier ...................................................................................................... 43
10.4 Connecting to PC ................................................................................................................ 43
10.5 Bluetooth Audio ................................................................................................................... 44
11 USEFUL INFORMATION ............................................................................................................... 45
11.1 INDEX .................................................................................................................................. 45
11.2 Warranty .............................................................................................................................. 46
12 TROUBLESHOOTING .................................................................................................................. 46
13 TECHNICAL SPECIFICATIONS ................................................................................................... 47

5
Level of danger Symbol Importance Denition
Severe injury WARNING Severe to fatal injuries if
disregarded
Severe injury through
electric shock WARNING Additional symbol for danger of
electric shock
Slight injury and property
damage CAUTION
Slight injury and / or property
damage can occur if the safety
instructions are disregarded.
Note NOTE
Crucial information
concerning the handling of
the device
Tip TIP Application tips
SAFETY INFORMATION
KEY
Dear Customer,
Thank you for choosing a digital piano from GEWA music!
You have chosen a high-quality digital piano that will give you an impressive sound
experience and lots of fun.
Additional functions extend the capabilities of your digital piano far beyond piano
playing.
Your safety is very important to us!
Please read the safety information carefully and pay close attention to it. Retain this
manual and hand it over to the respective user.
1SAFETY INFORMATION
The manufacturer is not liable for personal injury or property damage resulting from
improper use of the device!
Only use your digital piano as directed!
1.1 KEY
The following symbols are used in this operating manual to identify hazards and notes.
NOTE

6
1.2 INTENDED USE
The digital piano is intended for use in dry rooms.
• Devices for audio playback (as input or output) or for data communication can be
connected.However,therespectivetechnicalspecicationsmustbecompliedwith
(see the section “Technical data“).
• The electrical connection may only be made to correctly installed power supplies,
fulllingtherespectiveregulations.Themainsvoltageontheidenticationplatemust
correspond to the mains voltage of the country of use.
• The digital piano is only to be used in the original delivery condition described below.
Conversions of any kind are not permitted and cause the immediate loss of the warranty
claim.
• The digital piano must be placed on securely fastened and weight-suitable, stable and
leveloorsorplatforms.
1.3 IMPROPER USE – EXAMPLES:
• Use outdoors or in rain
• Use in damp rooms
• Connection to incorrect supply voltage or improperly installed electrical power supplies.
• Use in close proximity to electrical or electronic equipment such as stereos, televisions,
radios or mobile phones.
• These devices may cause interference and affect the sound quality.
• Electrical leads that are too long can also affect sound quality.
• Transport and installation in places or vehicles with strong vibration, dust and strong heat
e.g. direct sunlight.
The manufacturer accepts no liability for damage for the following reasons:
• Disregard of the safety instructions
• Improper handling
• Use with devices that are not compatible with the technical data listed below
NOTE
SAFETY INFORMATION
INTENDED USE

7
SAFETY INFORMATION
PRECAUTIONS
1.4 PRECAUTIONS
Please follow the the precautions listed here. Disregard of precautionary measures can
have serious consequences:
• Severe injury or even fatal accidents
• Electric shock
• Short circuit
• Damage
• Fire
Other threats are conceivable; this is not an exhaustive list.
WARNING Fatal electric shocks
• Even low electrical currents can lead to serious injuries and death.
• Never open the digital piano’s casing.
• Never use damaged power cables.
• Lay the power cable in such a way that it can not be damaged.
  •Neverplacecontainers(vases,glassesetc)lledwithwateroruidsonthepiano.
• Never pour water or liquids on to the digital piano or keyboard.
• Never clean the digital piano with a wet cloth.
• Never plug in or pull out the mains plug with wet hands. Never pull on the cable; it can
cause damage.
• If liquid accidentally gets into the digital piano, immediately unplug the power.
Then have your digital piano checked by your GEWA service representative.
WARNING Unusual circumstances
• Turn off the digital piano or unplug the power cable if:
- There is a sudden loss of sound while using the digital piano
- The digital piano generates an unusual smell or smoke
• Be sure to have the digital piano checked by your GEWA service representative
 WARNING Protectionagainstre
  •Openamessuchascandlesortealightscantipoverandcauseare
  •Neverplaceobjectswithopenamesonthedigitalpiano!

8
SAFETY INFORMATION
CE MARK
CAUTION Damage to the digital piano
• Inappropriate electrical voltages can damage the digital piano.
• Only operate the digital piano in the permissible voltage range (as indicated on the
respectiveidenticationplate).
• Only use the supplied power cable.
• Never place the power cable near to sources of heat, such as radiators or freestanding
heaters.
• Do not bend or kink the power cable, or damage it in any other way.
• Lay the power cable so that nobody can step on it, trip on it or roll over it.
• Do not place objects on the power cable.
• Regularly check the power cable and remove any dust or dirt that may be present.
CAUTION Damage to the digital piano through thunderstorms
• Thunderstorms can generate electrical surges that can damage electrical equipment.
• In the event of a thunderstorm or long periods of non-use (such as travel), unplug the
appliance from the mains.
1.5 CE MARK
CE MARK
This device complies with EU directive requirements: Directive 2014/53/EU
EN55020:2007+A11:2011
EN55024:2010
EN55032:2012
EN61000-3-2:2014
EN61000-3-3:2013
EN301489-17:V2.2.1
EN301489-17:V3.2.0
EN62479:2010
EN300328:V2.1.1
 TheconformitywiththeregulationslistedaboveisconrmedbytheCEsignonthedevice.
The declaration of conformity can be viewed at the following address:
GEWA music GmbH, Werkstraße 1, 08626 Adorf, GERMANY
1.6 DISPOSAL
To dispose of the old device, please take it to your local waste management authority
(e.g. disposal company or recycling centre).
The adjacent symbol indicates that the device must be disposed of separately from
household waste. In accordance with the Electrical and Electronic Equipment Act, owners
of old appliances are legally required to dispose of old electrical and electronic appliances
at a separate and designated waste disposal point.
Please help in contributing to protect the environment by not disposing of the old device
in household waste.

9
ITEMS SUPPLIED
2PARTS SUPPLIED WITH THE PIANO
Check the content of the package for completeness before starting with the assembly.
Pos. Description Pcs.
1 Keyboard 1
1A Music desk 1
1B Rollable keyboard lid 1
2 Rear panel 1
3 Pedal board 1
4 Left side panel 1
5 Right side panel 1
6 Power cable 1
7a Phillips screw M6 x 16 5
7b Phillips screw M6 x 30 4
8 Phillips wood screw 3.5 x 30 10
9 Headphone hanger 1
10 Quick Start Guide 1
11 Adjustment screw 1
not
shown
Cable clips 2

10
3ASSEMBLY INSTRUCTIONS
In this section we will show you how to easily set up your GEWA digital piano.
For the assembly you need:
• size 2 Phillips screwdriver
• second assisting person
Do not rmly tighten the recessed head screws until all parts of your digital piano are
aligned. Make sure you assemble your digital piano on level ground.
Now lets start assembling your GEWA digital piano:
1. Unfold the pedal cable (not shown) and screw the adjustment screw ( 11 ) into the
pedal board ( 3 ).
2. By using the phillips screws ( 7b ), connect the side panels ( 4 and 5 ) to the pedal
board.
3. Then attach the rear panel (2) with phillips wood screws (8).
4. Now place the keyboard onto the base from above. Make sure that the angels of the
side panels are guided into the millings of the keyboard. Then secure the keyboard with
4 screws ( 7a ).
5. Now screw the headphone hanger (9) onto the left underside of the keyboard by using
a phillips screw ( 7a ).
6. Then align your digital piano and tighten all of the screws.
NOTE
ASSEMBLY INSTRUCTIONS

11
7. Place your digital piano at the desired location and make sure that the adjustment
 screw(11)touchestheoorasshownbelow.
8. Insert the pedal cable true to side into the pedal cable socket on the underside of the
keyboard ( 1 ). It should slide easily into the socket. Then plug the power cable ( 6 )
into the power socket which is also located on the underside (not shown).
9. Set up the music desk as shown below.
3.1 OPENING THE KEYBOARD LID
Please make sure to always use both hands to open or close the lid.
To open the lid please follow below drawing. In the opposite way the lid can then be
closed again
CAUTION
ASSEMBLY INSTRUCTIONS
Pedal cable
Pedal connector

12
3.2 USE WITH A KEYBOARD STAND
It is also possible to use a keyboard stand instead of the supplied rack. In this case place
the keyboard stand on level ground and position the piano centrally on top. If possible,
the speakers on the bottom of the piano should not be covered or partly touched by the
stand. For the connection with a standard sustain pedal you can use the 6.3mm jack socket
labeled ‘sustain’ on the rear panel.
NOTE
4GETTING STARTED
Now let‘s have a look on to the controls of your GEWA digital piano
4.1 THE CONTROLS OF YOUR DIGITAL PIANO
Your GEWA digital piano features the following controls:
Music desk
Control panel Volume switch
Power On/off
Speakers
Pedals
Headphone sockets
USB Port
Headphone hanger LED Indicator
ASSEMBLY INSTRUCTIONS / GETTING TO KNOW YOUR INSTRUMENT
CONTROLS / CONSOLE

13
4.1.1 FUNCTION KEYS
Diagram A 1 Display
Provides settings and status information.
NOTE: The current activated menu is always displayed
with a black background.
2 Soft buttons
These allow you to select functions that are shown in the
display.
3 Cursor buttons
Navigation to and within functions and function groups
Recording related buttons
4 play/stop
Start / Stop for recorded pieces of music.
5 record
This sets your GEWA Digital Piano to record standby mode
6 Metronome and metronome functions
With this button the metronome can be switched on/off
and edited.
7 Reverb button
Turns the reverb on/off and, when longer depressed,
enters the edit mode
8 Chorus and other effects
Turns the Chorus and other effects on/off and, when
longer depressed, enters the edit mode
9 User settings
In this section you can save and reload your individual
settings.
10 Sound selection switches
These switches allow you to select and play the different
sounds on your GEWA digital piano.
11 Power On/Off
This switch turns your GEWA digital piano on or off. Press
and hold the switch for about 3 seconds to turn off your
digital piano.
NOTE: The switch does not engage. Light pressure is
enough.
12 Volume switch
This switch determines the volume of your GEWA digital
piano.
NOTE: Before switching on, it is advisable to set this
control to the middle.
11
on/off
12
volume
GETTING STARTED
FUNCTION KEYS

14
Diagram B
4.1.2 PEDALS
GETTING TO KNOW YOUR INSTRUMENT
PEDALS
Sustain Pedal (right side)
The Sustain- or Damper Pedal on an acoustic grand piano
lifts up all the dampers that sit on the strings. Thereby all
played notes continue to sustain after the keys are released.
Furthermore, all the other strings can freely resonate, so their
frequencies contribute to a richer sound.
All this is simulated by the pedal of your Gewa piano. It is also
possible to play with half pedal, which means the simulated
dampers are only lifted slightly, so that the sustaining notes
are decaying faster than with the pedal fully depressed.
Piano Pedal (left side)
When the Piano- or Una Corda Pedal is being operated, the
Gewa Piano simulates shifting the keyboard action slightly
to the right. The altered striking line of the imaginary piano
hammers results in a differently colored tone and a slightly
softer volume.
Sostenuto Pedal (middle position)
The Sostenuto Pedal resembles the Sustain Pedal. The only
difference is that only those notes are sustaining whose keys
were being depressed at the moment of actuating the pedal.
All the other notes are dampened as usual.

15
4.2 KEYBOARD CONNECTIONS
A
B
C
General View
Speaker Speaker
A1 USB IN/OUT Connect a USB stick or another USB device here.
A2 Headphone sockets Connect one or two sets of headphones here.
B Pedal cable socket Connect the pedal cable here.
B
Diagram A Diagram B
A1
A2
GETTING TO KNOW YOURINSTRUMENT
KEYBOARD CONNECTIONS

16
GETTING TO KNOW YOURINSTRUMENT
KEYBOARD CONNECTIONS
C1 C2 C3 C4 C5 C6
Diagram C
C1 LINE IN This port is for external sound source playback (e.g. MP3
players) through the speaker system via a 3.5mm jack
socket (-> page 29).
C2 SUSTAIN You can connect a standard sustain pedal to this 6.3mm
jack socket, if you want to use your digital piano with an
external stand.
C3 LINE OUT L/R This connection is split into the stereo channels L(eft) and
R(ight). Using 6.3mm jack cables, you can connect these
  outputs to a receiver, e.g. an amplier or a recorder
(-> page 43).
C4 MIDI IN/OUT Connect MIDI devices here (-> pages 36 and 37).
C5 USB-B Connection Connect your digital piano with your PC via this connection
(-> page 43).
C6 Power Supply Connect your digital piano to the power supply here, using
the power cable.

17
5OPERATING USE
Any settings, except for the volume control setting, will be reset when your digital piano
is turned off. You can change this behaviour and save some of the settings permanently
(-> page 30).
5.1 SWITCHING ON
When switching on, turn the volume switch to the middle position.
1. Press the On/Off switch on the right side of your digital piano.
2. The Reverb and the “Piano“ sound group button light up. In addition, the LED indicator
lights up on the front right side of your digital piano.
3. Your GEWA digital piano is now ready for use.
5.2 DEMO FUNCTION
The DEMO function provides a fantastic overview of the various sounds of your digital
GEWA digital piano.
This is how to activate the DEMO song function:
NOTE
TIP
1. Press the soft button that is assigned to “Player‘‘ in the display.
2. Use the upper/lower cursor keys to navigate to the „Demo“ Menu.
It is highlighted in black when selected.
3. Now press the right cursor key to enter the demo song selection. You can
now choose between the following 12 DEMOs:
4. Use the upper/lower cursor keys to select the desired DEMO.
5. By pressing the Play / Stop button, the DEMO can be played or stopped.
6. You can leave the Menu by pressing the “Exit“ soft button.
1
2/4
5
6
3
OPERATING USE
DEMO-FUNCTION

18
5.3 SOUND SELECTION
Your GEWA digital piano features 40 different sounds.
They are arranged in the following groups:
Press the desired sound selection switch (1) repeatedly or
press the right/left cursor keys (2) to navigate through the
different sounds of the group.
The current selected sound is shown in the display (3).
Piano E-Piano Strings Choir Organ Bass & Guitar Others
Concert Grand Seventy Three Movie Strings Church Organ 1 Acoustic Bass Clavi
Bright Grand 1 E-Piano 1 Strings Church Organ 2 Bass & Cymbal Vibraphone
Mellow Grand 1 FM Piano Slow Strings Draw Bar Organ Finger E-Bass Marimba
Mellow Grand 2 Wurly Pizzicato Jazz Organ 1 Fretless Bass Celesta
Upright Piano Choir Jazz Organ 2 Picked Bass French Accord
Rock Grand Slow Choir Mellow Organ Nylon Guitar
Harpsichord Pop Choir Steel Guitar
Synth Strings
OB Saw
Dark Pad Synth
Synth Bell Pad
Use the demo songs to receive an impression
of the different sounds. Let your own playing
be inspired by experimenting with the versatile
sound groups.
TIP
OPERATION
SOUND SELECTION
2
3
1

19
5.3.1 SOUND COMBINATION (DUAL SOUND)
Your GEWA digital piano can be set to play two simultaneous sounds in a layered mode.
In the following we will show you how to do this:
1. Hold down a sound selection button while selecting a second additional
group (e.g. Piano and Strings & Choir).
2. Choose two sounds by using the cursor keys and the sound selection
switches (-> page 18).
3. If you now play the keyboard you will hear both sounds simultaneously.
This is how you adjust the Dual Mode:
4. Press the Menu softbutton. Navigate through the following settings and
adjust them as desired by using the cursor keys:
• Balance: Here you can change the volume ratio between the two
selected sounds.
• 2_Octave Shift: With this function, you can transpose the second
sound up or down by 1, 2 or 3 octaves.
• 2_Pedal: Here you can decide whether the Damper Pedal should
   sustainbothsounds(On)oronlytherstone(Off).
5. Use the Exit softbutton to leave the menu.
6. Press the Exit softbutton again to deactivate the Dual Mode and to
return to the home menu.
OPERATION
SOUND COMBINATION
1/2
2/4
5/6
4

20
5.3.2 SOUND COMBINATION (SPLIT SOUND)
Your digital piano can be set to play two sounds with a split keyboard (e.g. left part with
a bass and right part with a piano sound).
1. Press the Split softbutton. Your keyboard is split into two zones now.
2. By using the cursor keys, select a sound for each zone (-> page 18).
3. Start playing. You will hear one sound for both zones each.
If you want to adjust the Split Mode, proceed as follows:
4. Press the Menu softbutton. Navigate through the following settings and
adjust them as desired by using the cursor keys:
• Split Point:Hereyoucandenethepointwherethekeyboardis
to be split.
Alternatively, you can dene the Split Point by holding the
“K Sense“ softbutton while pressing the desired key on the
keyboard.
• Balance: Here you can change the volume ratio between the two
selected sounds.
• L_Octave Shift: With this function, you can transpose the sound
chosen for the left side of the split keyboard up or down by 1, 2 or
3 octaves.
• L_Pedal: Here you can decide whether the Damper Pedal should
sustain both sounds (On) or only the one selected for the right
zone of the keyboard (Off).
5. Use the Exit softbutton to leave the menu.
6. Press the Exit softbutton again to deactivate the Split Mode and to
return to the home menu.
TIP
OPERATION
SOUND COMBINATION
2/4
1 5/6
4
2
