Size:W530xD180xH108.5cm
BERGEN THREE TIER SHOE CABINET.
Page 1 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
Page 2 of 12
Batch No.WMI 17056(PO#2991)
The product is intended for a maximum load of 15 kg spread evenly thorough the storage
compartments . Do not exceed this weight .
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
Page 3 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
3
4
1
2
5
3
4
1
2
5
3
4
1
2
5
8
9
12
10
12
11
13
14
6
7
Description: RIGHT DRAWER BRACKET
QTY:3pcs
Dimension:236x158x9mm
Description:LEFT DRAWER BRACKET
QTY:3pcs
Dimension:236x158x9mm
Description:DRAWER BOTTOM PANEL
QTY:3pcs
Dimension:450x65x9mm
Description:DRAWER BACK PANEL
QTY:3pcs
Dimension:450x130x9mm
Description:DRAWER FRONT PANEL
QTY:3pcs
Dimension:470x320x15mm
Description:LEFT SIDE PANEL
QTY:1pc
Dimension:1070x176x14mm
Description:RIGHT SIDE PANEL
QTY:1pc
Dimension:1070x176x14mm
Description:TOP PANEL
QTY:1pc
Dimension:530x181x15mm
Description:BACK PANEL
QTY:1pc
Dimension:438x314x3mm
Description:BACK PANEL
QTY:1pc
Dimension:438x314x3mm
Description:BACK PANEL
QTY:1pc
Dimension:438x365x3mm
Description:SUPPORT PANEL
QTY:2pcs
Dimension:472x30x15mm
Description:SUPPORT PANEL
QTY:1pc
Dimension:472x35x15mm
Description:SUPPORT PANEL
QTY:1pc
Dimension:472x30x14mm
Page 4 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
Page 5 of 12
Batch No.WMI 17056(PO#2991)
BOLT
BARREL NUT
DOWEL
SCREWS
DOOR AXIS
DOOR STOPPER
CAM BOLT
CAM LOCK
SCREWS
K
LSCREWS
Fixings
Fixings (Not to scale)
36
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
10 20 30 40 50 60 70
WALL STRAP
WALL ANCHOR
Page 6 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
Page 7 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
1: Right Drawer Bracket x3
2: Left Drawer Bracket x3
3: Drawer Bottom Panel x3
4: Drawer Back Panel x3
5: Drawer Front Panel x3
D: Screws x12
E:Door Axis x6
3: Drawer Bottom Panel x3
4: Drawer Back Panel x3
D: Screws x24
STEP 1 PARTS REQUIRED
STEP 2 PARTS REQUIRED
x3
Page 8 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
6: Left Side Panel x1
12: Support Panel x2
13: Support Panel x1
14: Support Panel x1
A: Bolt x4
B: Barrel Nut x8
C: Dowel x4
STEP 3 PARTS REQUIRED
9: Back Panel x1
10: Back Panel x1
11: Back Panel x1
F: Door Stopper x3
STEP 4 PARTS REQUIRED
6
(i)
(ii)
Page 9 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
STEP 5 PARTS REQUIRED
STEP 6 PARTS REQUIRED
C: Dowel x2
7: Right Side Panel x1
A: Bolt x4
C: Dowel x2
F: Door Stopper x3
Page 10 of 12
Batch No.WMI 17056(PO#2991)
BERGEN THREE TIER SHOE CABINET ASSEMBLY INSTRUCTIONS
STEP 7 PARTS REQUIRED
8: Top Panel x1
G: Cam Bolt x4
l: Wall Strap x1
J: Screws x1
STEP 8 PARTS REQUIRED
H: Cam Lock x4
