Global Fire Equipment JUNO NET User manual

The IR Keypad is typically the most convenient method to program the system. The sensor for the IR
Keypad is just below the SOUND ALARMS button on the Main Panel and on a Repeater. Each time a
key is pressed on the IR Keypad the Main Panel will beep.
If no beeps are audible then check the batteries in the IR Keypad.
The IR Keypad uses 2 x AAA batteries.
To access the characters in , first press the SHIFT KEY. To return to the characters in BLACK press
the SHIFT KEY again.
Each time a key press is received by the panel the panel emits a beep. The beeps when SHIFT is on
are of a higher pitch than when SHIFT is off.
0-9 are used to input numbers
and are used to select items
B-SP and are often used to change fields (move the cursor)
+/- are often used to select the loop
ENTER is used to select items and to store changes
ESC is used to abort changes and exit
HOME is often used to go back to the start of a function
Pressing both EXIT keys exits programming mode.
Where possible help is displayed automatically. However additional help is sometimes available if you
press the help key ‘:’ the colon.
The first press will display help for 7 seconds, a second press will ensure the help is displayed for 20
seconds. Pressing any key whilst help is displayed will clear the help but this key press will be ignored.
The IR Keypad Keys
Help
RED
JUNO-NET
Getting started
GLOBAL
FIRE EQUIPMENT
DEFAULT ACCESS CODE: 35427

Getting Into Programming Mode
When the Main Panel is powered up it will be necessary to enter the panel programming mode.
Familiarize yourself with this section before proceeding to the next section in the manual and powering
up the panel.
Programming mode is accessed via the miniature infra-red keypad (IR Keypad) or by connecting a PC
(PS2) keyboard to the Main Panel. It is also possible to upload and download settings to a PC but to
do this you must first enter the panel programming mode.
INFRA-RED KEYPAD
JUNO-NETCOMMISSIONING
0
A
4
E
8
I
1
B
5
F
9
J
2
C
6
G
K
3
D
7
H
L
MN
/[]
.,
'"+-
:
*&
OP
QRST
UVWX
Y
HOME SHIFT
ENTER
B-SP
ZSPACE
ESC EXIT
HOME: Return to first loop, zone, device etc.
ENTER: Accept current selection
B-SP: Backspace
ESC.: Reject. (ESCape from current selection)
EXIT: Press both keys simultaneously to stop programming
SHIFT: Toggle this keypad to switch from alpha-numeric
to numeric
GLOBAL
FIRE EQUIPMENT

Logging In
To enter programming mode you need to log in.
The Main Panel must be powered up and must have initialized itself i.e. NOT be showing the
‘INITIALIZING’ message.
Press ENTER on the IR Keypad (or keyboard). You must now input your unique customer access code
(supplied with the panel). You have unlimited attempts but if code entry is not started within 10
seconds then the panel will revert back to it’s default screen. While entering the code you are allowed
up to 5 seconds between key presses.
The programming functions are arranged using a menu system.
To select a function or sub-menu use either and ENTER or 0-9 and ENTER.
HOME takes you to "1-Review".
ESC takes you up a menu level.
Any number presses (0-9) will append a digit to what you see unless :
1) You are at the very top (1- Review) then the first press selects the first digit.
2) You are at the bottom then the press replaces the last digit.
The top level menus are:
1 Review Historic Log
2 Text Descriptions & Names
3 Zones - Disable & Assign
4 Sounders - Disable & Assign
5 Input/Output - Disable & Assign
6 Device Set-up
7 Monitor Device Counts & Test
8 General
Most functions operate in a consistent manner using the standard keys. The item that is being
changed is usually highlighted with a flashing cursor.
Function Selection
JUNO-NETCOMMISSIONING
GLOBAL
FIRE EQUIPMENT

USER & INSTALLER DEFAULT ACCESS CODES
FRONT PANEL KEYPAD KEY'S FUNCTIONS
To enter both codes use the arrow keys and when finished press .
User Access Code and then press key to confirm entry.
Installer Access Code and then press to confirm entry.
OK
OK
OK
Used to confirm entry of any data or selection. Same function as the ENTER key on IR remote
control.
Used to increase selection or number. Equivalent function as UP arrow key on IR remote control.
Used to decrease selection or number. Equivalent function as UP arrow key on IR remote control.
Escape key. Used to exit a particular function. Equivalent function as ESC arrow key on IR remote
control.
Note: It is not possible to introduce text for labels using the front panel keypad.
OK
ESC
