Global Fire Equipment VALKYRIE CS User manual

TECHNICAL SPECIFICATIONS
SUPPLY VOLTAGE
CURRENT - SOUNDER/BEACON ACTIVE
SOUNDER OUTPUT
CABLE SIZE
RESET/START-UP TIMES
COLOUR / CASE MATERIAL
OPER. TEMPERATURE / MAX. HUMIDITY
PROTECTION
DIMENSIONS / WEIGHT
20 V to 30 V DC
10 mA - 280 mW @ 28 V DC
97.5 dB (@ 1 meter - 30 V DC)
0.5-2.5 mm²
20 seconds max.
White or Red / ABS & PC - Flame Retardant rating UL 94 V2
o o
-10 C to 55 C / 95% RH Non-Condensing
Type A - Indoor Use IP21C
110 (D) x 85 (H) mm included base / 254 g inc. base
Minimum A-weighted sound level (dB) at 1m distance
Angle of radiation (º)
TONE "00"
TONE "01"
TONE "10"
TONE "11"
15
80,5
75,6
76
73
º45
82,3
76,7
78,9
78,2
º75
86
80,9
79,2
80,9
º105
87,1
80,7
83,8
82,7
º135
86,9
80,8
82,8
82,6
º165
73,5
73,6
70
71,1
º
15
83,8
72,9
78,9
77,1
º45
82,7
77
80
78,5
º75
87
79,5
77,3
80,3
º105
87,9
81,3
82,8
82,3
º135
85,6
80,8
82,3
80,8
º165
79,1
73,1
74,7
74,9
º
ORDER CODE | DESCRIPTION | CERTIFICATE
Angle of radiation (º)
TONE "00"
TONE "01"
TONE "10"
TONE "11"
A-weighted sound level (dB) 20V DC – Horizontal plane
A-weighted sound level (dB) 20V DC – Vertical plane
Horizontal
Plane
Vertical
Plane
0º
180º
0º
180º
(Base top view)
CONVENTIONAL WALL SOUNDER
GLOBAL FIRE EQUIPMENT S.A.
Sítio dos Barrabés, Armazém Nave Y, Caixa Postal 908-Z, 8150-016 São Brás de Alportel - PORTUGAL |
Email: [e-mail] | Technical Support: [email protected] | www.globalfire-equipment.com
Tel: [phone]
MANUAL 210729
MADE IN PORTUGAL - EU
VALKYRIE CS
For EN54-13 compliance, please check the control panel manual specifications.
1328-CPR-0287
1328-CPR-0287
1328-CPR-0287
1328-CPR-0287
VALKYRIE CS-WHITE
VALKYRIE CS-RED
VALKYRIE CSB-WHITE
VALKYRIE CSB-RED
CONVENTIONAL WALL SOUNDER-WHITE
CONVENTIONAL WALL SOUNDER-RED
CONVENTIONAL WALL SOUNDER/BEACON-WHITE
CONVENTIONAL WALL SOUNDER/BEACON-RED

SOUNDER BASE - LOOP CONNECTIONS
Please note that this device is polarised.
BASE LOCK
Terminals
2. Positive Supply - OUT
3. Negative Supply - Pulsing Output
4. Positive Supply - IN
1. Negative Supply - Continuous Tone
NOTE:
Only last device in Sounder Circuit should have e.o.l (end of line)
fitted across + and - terminals.
OUT
To next device
in Sounder Circuit
Tone - Pulsing
TONE SELECTION
To lock beacon remove pin
available at terminal 4 on the
underside of the beacon using
a small screwdriver.
To unlock beacon from its base
push provided unlock key
through hole available on the
base side wall as shown.
ALTERNATING
HIGH-FREQUENCY TONE
2.7 Khz - 3.2 Khz
CONTINUOUS TONE
800 Hz
SWEEPING TONE
800-1000 Hz
ALTERNATING
LOW-FREQUENCY TONE
800-1000 Hz
OFF (0)
ON (1)
Earth connection
available on base
for shielded cable
Tone - Continuous
IN
PANEL
Sounder
Circuit
MORE INFO >> WWW.GLOBALFIRE-EQUIPMENT.COM
