GMI DT-Z Series User manual

WORKBENCH ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED FOR ASSEMBLY
Cordless drill with #2 phillips head bit & 18” magnetic extension,
3/8" and 5/16” magnetic socket bit.
BEFORE ASSEMBLING THE WORKBENCH
Read through the assembly instructions to
familiarize yourself with the order in which the
parts are assembled. We suggest that you clear
& vacuum the area where the bench is to be
assembled. It is important that the bench is
assembled in the same sequence as instructed.
HARDWARE & GMI COMPONENTS
All assembly hardware is provided. Full size photos
accompany each step where hardware is needed.
STEP 1
Assemble the modesty panels to the base
cabinets. Use four 1/4-20 x 1/2" Bolts with
the 3/8" magnetic socket for each modesty
panel.
**Your base cabinets may be different than
those shown. Follow the same instructions**
Modesty Panel
STEP 2
Hook the (Optional) wire
management tray over the top
lip of the modesty panel.
For (3) base configuration benches
the assembly process is the same as
shown. The wire tray flange will clip over
the modesty panel flange along the top
edge.
Wire Management Tray
Optional
DT-XXX-Z Configuration
1/4-20 x 1/2”
Flange Head Bolt

STEP 3
Set the top on the assembled base.
Adjust the top to leave no more than a two inch
overhang in the front and even gaps on the left
and right side.
The 14 x 1 drive screws do not require
pre-drilled holes.
Attach the top to each leg pedestal
with six #14 x 1" Lag bolts. Use the 3/8"
magnetic socket. Next attach the cabinet to the
top using four #14 x 1" Lag bolts. Drawer
cabinets will require removal of the drawer to
access the mounting holes in the top of the
cabinet.
Place the work station in the desired
location and level.
STEP 4
Position the risers on the top so there is
1" from the back of the riser to the back
of the worksurface AND 1-1/4" from the
side of the riser to the side of the work-
surface. If assembling a three riser shelf,
position the center riser in the center of the top.
Attach the risers to the top. Use
#14 x 1" Lag bolts. (You will need
the 18" extension and 3/8" magnetic
socket to reach the mounting holes inside).
Set the shelf on the risers. Adjust the shelf so
there is an even distance left-to-right. Use a
straight edge to line up the back of the shelf
with the back of the worksurface.
Attach the shelf to each riser using four
#14 x 1" Lag Screws with the 3/8"
magnetic socket.
Riser
STEP 1
12” to 18”
Riser
STEP 2
#14 x 1”
Lag Bolt
#14 x 1”
Lag Bolt
#14 x 1”
Lag Bolt
