Golden Technologies GA 541 User manual

Avenger Owner’s Manual Revised 09/29/09
Model GA 541
Y O U R L I F E I N M O T I O N
401 Bridge Street, Old Forge, PA 18518
Tel: [phone] Fax: [phone]
www.goldentech.com

Avenger Owner’s Manual Revised 09/29/09
Your Avenger™package should include the following items. If your package
arrived without any of the following items, please contact us right away!
1) Owners Manual
2) Battery Charger
3) Batteries (If ordered)
4) Seat Arm Rests
5) Keys
6) Avenger™Scooter
7) Basket
DISCLAIMER
Golden Technologies, Inc. is not and cannot be held responsible for any damage
or injury incurred due to improper or unsafe use of the Golden Avenger™scooter.
Golden Technologies Inc. specifically disclaims responsibility for any bodily injury
or property damage that may occur during any use that does not comply with
applicable federal, state, or local laws or ordinances.

Avenger Owner’s Manual Revised 09/29/09
CONTENTS
________________________________________
I. Introduction…………………………………………………… 4
II. Safety………………………………………………………….. 6
III. EMI/RFI………………………………………………………… 9
IV. Your Golden Avenger™…….………………………………...10
V. Operation………………………………………………………12
Hand Controls
Seat Controls
VI. Riding Your Avenger™………………………………………...16
Mounting
Basic Driving
Control Through Tight Spots
VII. Disassembly……………………………………………………. 20
VIII. Assembly………………………………………………………...25
IX. Transporting Your Avenger™………………………………… 27
X. Diagnostics………………………………………………………28
XI. Care and Maintenance………………………………………… 29
Main Circuit Breaker
Wheels and Tires
If your Avenger™does not operate
Lubrication
Charger and Batteries
Battery Maintenance
Battery Cable Installation
Cleaning your Avenger™
XII. Warranty………………………………………………………….35

Avenger Owner’s Manual Revised 09/29/09
Congratulations on the purchase of your new Golden Avenger™scooter! The
Avenger™combines cutting edge technology with attractive designs that are also
highly functional in today’s world. We at Golden Technologies know that you
have chosen a scooter that will give you years of dependable operation and will
also enhance the quality of your life by providing you with the mobility to
experience a more active daily lifestyle.
Please read, understand and follow all of the instructions and suggestions in this
manual before you operate your Avenger™for the first time. The safe use of
your new scooter is very important and starts with you. Your new Avenger™is
user-friendly and designed for maximum maneuverability in even the tightest
spaces.
If you feel uncomfortable with your new Avenger™or do not understand the
instructions presented in this owner’s manual, or if, for any reason, you do not
feel capable of performing the activities necessary to assemble, disassemble,
operate, or maintain your Avenger™, please contact the home health care dealer
you purchased this scooter from or contact Golden Technologies technical
support services at 800-624-6374.
Golden Technologies, Inc. cannot be held responsible for personal injury or
property damage resulting from the unsafe or the improper use of any of our
broad range of health and personal mobility products.
Please fill out and mail the enclosed warranty registration card. We at Golden
Technologies Inc, would appreciate hearing about your experience with your new
Avenger™scooter!
Please mail your warranty card to:
Golden Technologies Inc
Warranty Registration Office
401 Bridge Street
Old Forge, PA 18518
Phone: [phone]
Fax: [phone]
Stop by our website 24 hours a day!!!
www.goldentech.com

Avenger Owner’s Manual Revised 09/29/09
Your Golden Avenger™is a battery-operated personal mobility vehicle. Please
exercise caution and consideration when you are operating it. Driving your
Avenger™carefully and thoughtfully will help ensure your personal
safety and the safety of other people.
Note: Before learning to operate your Avenger™, have your Golden
Technologies, Inc. representative determine if it is advisable for you to practice
getting on and off your Avenger™and operating it in the presence of an
attendant.
BEFORE GETTING ON YOUR AVENGER™
•Check to be certain that the power is turned off. See “Operation” section
in this manual. This will eliminate the possibility of accidentally activating
the thumb lever controls and causing injury to you or to others.
•Check to be certain that your Avenger™brake handle is in the engaged
position. See the “Disassembly” section in this manual.
•Flip up the armrests.
WARNING: WHEN GETTING ON OR OFF YOUR AVENGER™, DO NOT PUT MOST OR ALL
OF YOUR WEIGHT ON THE EDGE OF THE DECK. DOING SO MAY CAUSE THE SCOOTER
TO TIP.
GETTING ON YOUR AVENGER™
•Position the seat for safe and easy mounting. See: “Operation” section.
•Carefully place one foot on the approximate center of the deck and seat
yourself comfortably and securely on the seat.
•Fasten the lap belt, if your scooter is so equipped.
•Flip down the armrests.
GETTING OFF YOUR AVENGER™
•Make certain that the power is turned off and key is removed!
•Flip up the armrest.
•Unfasten the lap belt, if your scooter is so equipped.
•Carefully place one foot on the ground, transfer your weight to that leg,
and slowly come to a standing position.
•Step away from the scooter.
MAXIMUM WEIGHT
Your Avenger™has been rated to a maximum payload (includes operator and
any other carry on baggage) of 500 pounds. Exceeding the maximum weight
rating will void the warranty.
WARNING: EXCEEDING THE MAXIMUM WEIGHT RATING MAY ALSO RESULT IN INJURY
TO YOURSELF AND TO OTHERS.

Avenger Owner’s Manual Revised 09/29/09
SAFETY
DRIVING ON AN INCLINE
•For maximum stability, lean forward in your Avenger™seat while
proceeding up ramps, slopes, curbs, or any low rise.
•Drive with caution when attempting to negotiate any incline, even
handicap access ramps.
•Always climb or descend a gradient by driving straight up or straight down
the face of the slope.
•Do not traverse or drive across the face of a gradient.
•Do not attempt to negotiate an incline that is covered with snow, ice, cut or
wet grass, leaves, or any other potentially hazardous material.
•Do not back down an incline.
•Try to keep your Avenger™moving when climbing an incline. If you do
come to a stop, restart and accelerate slowly and carefully.
•Do not try to descend or climb a slope whose gradient is greater than
recommended. See “Specifications” section.
WARNING: IF, WHILE YOU ARE DRIVING DOWN A SLOPE, YOUR SCOOTER STARTS TO
MOVE FASTER THAN YOU FEEL IS SAFE, RELEASE THE THUMB LEVER AND ALLOW
YOUR AVENGER™TO COME TO A STOP. WHEN YOU FEEL THAT YOU AGAIN HAVE
CONTROL OF YOUR SCOOTER, PUSH THE THUMB LEVER FORWARD AND CONTINUE
SAFELY DOWN THE REMAINDER OF THE SLOPE.
DRIVING DOWN AN INCLINE
•Whenever it is safely possible, drive forward down any ramp, low rise, or
incline.
Golden Technologies Inc. does not recommend that you drive your scooter in
reverse down any incline, ramp, curb, or low rise. Backing down any slope may
create a very hazardous situation.
If it is necessary to back down a slope follow one of two procedures.

Avenger Owner’s Manual Revised 09/29/09
SAFETY
Note: When using either of the following procedures to back down a slope,
Golden Technologies strongly advises that you have the assistance of another
person. Procedure 1
1. Set the key switch to the “Off” position. See “Operation” section.
2. Dismount your Avenger™.
3. Put your scooter in the freewheel mode. See “Disassembly” section.
4. While standing alongside the scooter, carefully manually maneuver it
down the slope.
5. When you have reached a level surface at the bottom of the slope,
position the free-wheel lever in the engaged position. See “Disassembly”
section.
6. Carefully remount your Avenger™and resume normal operation.
WARNING: WHEN YOUR SCOOTER IS IN FREEWHEEL MODE, THE BRAKE IS RELEASED.
THE WEIGHT OF THE SCOOTER ON A SLOPE MAY CAUSE YOU TO LOSE CONTROL OF
THE SCOOTER. IF YOU DO NOT FEEL CAPABLE OF MANUALLY CONTROLLING YOUR
SCOOTER DOWN THE SLOPE, REQUEST ASSISTANCE OR DO NOT ATTEMPT TO USE
THIS PROCEDURE. Procedure 2
1. Set the key switch to the “Off” Position. See “Operation” section.
2. Dismount your Avenger™
3. Set the key switch to the “On” position. See “Operation” section.
4. While standing alongside your scooter, carefully operate the controls at
the lowest speed setting. See “Operations” section.
5. Slowly and carefully back your scooter down the incline.
6. When you have reached a level surface at the bottom of the slope,
position the free-wheel lever in the engaged position. Carefully remount
your Avenger™and resume normal operation.
MEDICATION
Always check with your physician to determine if any of the medications you are
taking may affect your judgment and / or your ability to operate your Avenger™.
Also check with your physician concerning your physical ability to operate a
scooter.
WARNING: DO NOT CONNECT OR ALLOW ANYONE EXCEPT AN AUTHORIZED GOLDEN
TECHNOLOGIES REPRESENTATIVE TO CONNECT ANY ELECTRICAL OR MECHANICAL
DEVICE TO YOUR AVENGER. UNAUTHORIZED ACCESSORIES WILL VOID THE
WARRANTY AND MAY CAUSE INJURY.
Please use your Golden Avenger
™ scooter often and allow it to expand the horizons of your daily
life. But as with all things, especially motor operated vehicles, observing a few rules and safety
considerations will help ensure safe scooter operation. So please follow the rules below.
Note: Please remember that while on your Golden Avenger
™ , you are a motorized pedestrian.
You must observe and obey all pedestrian rules and regulations for the locale in which you are
riding.

Avenger Owner’s Manual Revised 09/29/09
SAFETY
RULES FOR USE AND OTHER SAFETY CONSIDERATIONS
•Read completely and understand this owner’s manual before assembling,
operating, transporting, or disassembling your Golden Avenger™.
•Always operate your Golden Avenger™with thought, care and safety.
•Do not attempt to use your Avenger™on an escalator. Always use in an
elevator.
•Do not carry passengers under any circumstances.
•Do not mount or dismount your Golden Avenger™unless the brake is
engaged.
•Make certain that the key switch is set to “off” before mounting or
dismounting your scooter.
•Do not back your Golden Avenger™down an incline or across an uneven
surface.
•Do not turn your scooter suddenly at full speed.
•Make certain that the seat is locked in the forward position before
operating your Avenger™.
•Always come to a full stop before changing direction from forward to
reverse or from reverse to forward.
•Do not operate your Avenger™where you could not safely or legally walk.
•Do not climb ramps or curbs that exceed your scooter’s capacity.
•Always approach curbs and inclines straight on.
•Be aware of and careful near mechanical pinch points (for example, when
mating the rear carriage to the front frame, especially when assembling
and disassembling your scooter. See Assembly/Disassembly section.
•Never sit on your Avenger™when it is being transported.
•When your Avenger™is being transported, make certain that it is securely
fastened down with an approved tie-down system.
•Do not operate your vehicle if it is not functioning properly.
•Use caution when driving on soft or uneven surfaces such as grass and
gravel.
•Also use caution on decks where there is no railing.
•Never drive on the roadway, except when you must cross the street.
•Do not attempt to drive your Avenger™up or down a step or curb that is
higher than three inches.
•Never back up or down a step or curb.
•Never operate your Avenger™while you are under the influence of alcohol
or any other controlled substance.
WARNING: TURNING TOO SHARPLY AROUND A CORNER CAN CAUSE THE SCOOTER
TO TIP. AVOID THIS DANGER AT ALL TIMES BY STEERING A WIDE ARC AROUND
CORNERS AND OBSTACLES. ALSO, TO AVOID THE RISK OF TIPPING, REDUCE SPEED
BEFORE NEGOTIATING ANY TURNS.

Avenger Owner’s Manual Revised 09/29/09
EMI / RFI
The rapid development of electronics, especially in the area of communications,
has saturated our environment with electromagnetic (radio) waves that are
emitted by television transmitters, cellular phones, citizen’s band radios (CBs)
amateur radios (AM radios), wireless computers links, microwave transmitters,
paging transmitters, etc. These electromagnetic (EM) waves are invisible and
increase in strength the closer one gets to the source of transmission. When
these energy waves act upon electrical devices and cause them to malfunction or
to function in an erratic or uncontrolled manner, they are referred to as
Electromagnetic Interference (EMI) or Radio Frequency Interference (RFI).
EMI / RFI AND YOUR AVENGER™
All electrically powered vehicles, including scooters are susceptible to EMI / RFI.
This interference could result in abnormal, or unintended movement of your
Golden Avenger™.
WARNING: UNINTENDED MOVEMENT OR BRAKE RELEASE COULD CAUSE AN
ACCIDENT OR INJURY.
The FDA has determined that each make and model of scooter can resist EMI /
RFI to a certain level. The higher the level of resistance, the greater the degree
of protection from EMI / RFI – measured in volts per meter (V/M). The FDA has
also determined that current technology is capable of providing 20 V/M of
resistance to EMI/RFI, which would provide useful protection against common
sources of interference. The resistance level of the Golden Avenger™is not
known.
EMI / RFI RECOMMENDATIONS
•Do not turn on or use hand-held personal electronic communication
devices such as cellular phones, walkie-talkies, or CB radios while your
scooter is turned on.
•Be aware of any nearby transmitters (radio, television, microwave, etc.) on
your intended route and avoid operation your of scooter close to any of
those transmitters.
•Turn off the power if your Avenger™is going to be in a stationary position
for any length of time.
•Be aware that adding accessories or components or modifying your
scooter may make it more susceptible to EMI / RFI.
•If unintended movement or brake release occurs, turn your scooter off as
soon as it is safe to do so.
•Report all incidents of unintended movement or brake failure to your
Golden Technologies representative or to Golden Technologies.
WARNING: TURN OFF YOUR SCOOTER AS SOON AS IT IS SAFELY POSSIBLE IF
UNINTENDED OR UNCONTROLLABLE MOTION OCCURS OR IF UNINTENDED BRAKE
RELEASE OCCURS.

Avenger Owner’s Manual Revised 09/29/09
SCOOTER INSTRUCTIONS
FOR YOUR RECORDS:
Please fill in your Avenger™information below. This information will be useful in
the event that you ever need to contact Golden Technologies concerning your
scooter.
Model _____________________ Serial Number _____________________
Date of Purchase _________________ Body Color _____________
Options______________________________________________________
Your Golden representative or dealer
Name________________________________________________________
Company _____________________________________________________
Address ______________________________________________________
_____________________________________________________________
Please remember to fill in and return your warranty registration card.
Tiller Adjustment Knob
Ad
j
ustable Seat Pos
t
Wi
g
-Wa
g
Control
Ke
y
Circuit Breaker
Reset

Avenger Owner’s Manual Revised 09/29/09
TECHNICAL SPECIFICATIONS INFORMATION
Specification Name Three-wheel model Four-wheel model
Length 51.5” 57.5”
Width 24.5” 24.5”
Tires Pneumatic Pneumatic
Front 10”x3.5” 13”x4”
Rear 13”x4” 13”x4”
Weight Capacity 500 pounds 500 pounds
Maximum Speed 7.5 mph 7.5 mph
Ground Clearance 5” 4.5”
Operating Range 10-15 miles 10-15 miles
Turning Radius 41” 48”
Batteries (2) 12 VDC – 55AH Nf22 12 VDC – 55Ah Nf22
Weight
Seat 62.5 pounds 62.5 pounds
Seat w/o arms pounds pounds
Front half 45.5 pounds 70 pounds
Rear half 54.4 pounds 58.4 pounds
Freewheel mode Yes Yes
Maximum incline 8 degrees 8 degrees
Electronic speed control Yes Yes
Brakes Electro-mechanical Electro-mechanical
Charger Off board 5 amp Off board 5 amp
Rear wheel drive Sealed transaxle,
motor 24 VDC 4-pole Sealed transaxle, motor 24 VDC 4-pole
Controller 110 amp
programmable P/G
S Drive
110 amp/programmable P/G
S Drive
Flashers/Turn indicators Rear flashers/turn
indicators Forward and rear flashers/turn indicators
Warranty – Motor /
Electronics 2 Years 2 Years
Electronics warranty
excludes batteries
Warranty – Frame Limited Lifetime Limited Lifetime

Avenger Owner’s Manual Revised 09/29/09
AVENGER™OPERATION
TruCharge Meter
Emergency Flashers
(Reverse) Thumb Lever (Forward)
Hand Controls
Speed Adjustment Dial
The speed adjustment dial allows you to pre-select the maximum top speed of
your Golden Avenger™.
•Turn the dial completely counterclockwise to operate your scooter at the
lowest top speed.
•Turn the dial clockwise to increase the operational speed of your scooter.
We recommend that you select a speed setting at which you feel comfortable,
safe, and in control of your Avenger™.
Key Switch
This switch turns the power of your Avenger™on and off.
•Insert the key into the key hole and turn clockwise. Notice the TruCharge
volt meter/ diagnostics gauge will illuminate. Once illuminated, your
scooter is powered On.
Note: Always make certain that the key is removed from the key switch before
getting on or off your Golden Avenger™.
Speed Adjustment
Knob
Headlight Switch
Turn Indicator
Switch
Key
Horn Button

Avenger Owner’s Manual Revised 09/29/09
OPERATION
When the power to your Avenger™is turned on the TruCharge volt meter/
diagnostics gauge will illuminate. This gauge is used for battery condition and
diagnosing operational problems that may arise. See “Diagnostics” section.
Horn Button
Press this button to sound the horn.
Thumb Lever Control
This self-centering lever system controls your Avenger™speed (up to the
maximum speed set by the speed adjustment dial) as well as the forward and
reverse direction. This control system is also called the “Wig-wag”.
To drive forward:
•Please your hands on the handgrips.
•Use your thumbs to operate the control lever.
•Use your right thumb to press lightly on the “F” (forward motion) lever to
move your scooter forward.
•Increase the pressure applied by your thumb to increase your forward
speed.
•To stop your Avenger™, release all pressure on the lever. The lever will
automatically return to the center (neutral) position and your scooter will
come to a gradual stop.
Note: Always bring your Avenger™to a full stop before changing direction from
forward to reverse, or from reverse to forward.
To drive in reverse:
•Place your hands on the handgrips.
•Use your thumbs to operate the control levers.
•Use your left thumb to press lightly on the “R” (reverse motion) lever to
move your scooter in reverse.
•Increase the pressure applied by your thumb to increase your reverse
speed.
•To stop your Avenger™, release all pressure on the lever. The lever will
automatically return to the center (neutral) position and your scooter will
come to a gradual stop.

Avenger Owner’s Manual Revised 09/29/09
OPERATION
The TruCharge volt meter/ diagnostics gauge.
This meter shows the amount of voltage in your Avenger™batteries and is also
the diagnostics gauge.
•10 bars lit indicates full battery charge.
•6 or 7 bars lit, charge your batteries.
Note: Your scooter will automatically turn itself off if the battery output falls to 18
V DC or lower.
Tiller Adjustment
The tiller on your Avenger™scooter employs an adjustment lever to provide you
with infinite tiller angle settings. To set the tiller to your liking, follow these
directions:
•Use one hand to grasp a handgrip.
•Use your other hand to loosen the adjustment lever.
•Position the tiller to a comfortable driving position.
•Tighten adjustment lever.
NOTE: The length of your Avenger tiller can be extended by the removal of tiller
plastic, removal of 2- 6mm machine screws. The tiller can be lengthened by 3”
and the replacement of 1 of the 6mm machine screws. (Picture not shown)
WARNING: BE SURE THE TILLER ADJUSTMENT LEVER IS FULLY TIGHTENED BEFORE
OPERATING THE SCOOTER.
Adjustment
Lever

Avenger Owner’s Manual Revised 09/29/09
OPERATION
SEAT CONTROLS
Armrest Height Adjustments can be made by removing the 2
screws on the back of the armrest and raising to a comfortable
position and resetting the screws. The armrest can be raised 3”
and by replacing only 1 screw. You can raise the armrest and
replace both screws. You will require a 6mm allen wrench for this
task.
Armrest Width Adjustment
To adjust the armrest width:
1. Loosen the (2) 6mm adjustment screws at the rear of
each arm. Slide each arm to the desired width and tighten
the screws.
Seat Height Adjustment (Picture Not Shown)
To adjust the seat height: Lift up on seat rotate lever and turn
seat either left or right, lift seat straight up. Holding rotate
lever in the up position while lifting seat may make this task
easier. Remove 17mm machine screw and place seat post
at the desired height and re-insert screw.
Seat Rotation Lever
The seat can be rotated through 360°and locked at any
90°position.
1. Pull up on the seat rotate lever and rotate the seat
to the desired position.
2. Release the handle to lock the seat at any 90°position.
WARNING: DO NOT ATTEMPT TO DRIVE YOUR AVENGER
IN ANY SEAT POSITION OTHER THAN FULLY FORWARD.
Flip-Up Armrests
Pull up on the end of either armrest to flip it up for easy
transfer on and off your Golden Avenger™.
Seating
The Golden Avenger™seat is available only in gray vinyl.

Avenger Owner’s Manual Revised 09/29/09
RIDING YOUR AVENGER™
MOUNTING
Note: For you first driving sessions, make certain that your Golden Avenger™
starts out on a level surface and that you will continue driving on a level surface.
To get on Your Avenger™
1. Stand behind your Avenger™
2. Make certain that the brake handle is in the “Forward” position.
3. Pull up on the seat rotate lever.
•This lever is normally located on the right-hand side of the seat.
•Pull the lever up, and position the seat in a comfortable position
for seating.
•Release the lever to lock the seat into one of the four preset
locking positions.
WARNING: BE SURE YOUR SEAT IS LOCKED IN THE FORWARD POSITION BEFORE
OPERATING.
•Make certain that the seat is positioned for safe and easy
mounting.
•Position yourself in the seat.
•Use the seat rotate lever to position the seat in the fully forward
direction.
•Fasten your lap belt, if your Avenger™is so equipped.
BASIC DRIVING
1. Make certain that you are seated safely and properly on your Avenger™.
2. Turn the speed control dial fully counterclockwise to its slowest setting.
NOTE: Reverse movement of the scooter may not occur when the speed control
dial is set fully counterclockwise at it’s slowest setting.
3. Insert the key into the keyhole.
4. Push the key all the way into the key receptacle and turn clockwise to
power the scooter.
5. Place your hands on the handgrips.
a. If you wish to drive forward, position your right thumb on the right
thumb lever and push forward.

Avenger Owner’s Manual Revised 09/29/09
b. If you wish to drive in reverse, position your left thumb on the left
thumb lever and push forward.
6. Press against the thumb lever to gently accelerate your Avenger™.
7. Release the lever to allow your Avenger™to come gently to a full stop.
8.Practice these two basic functions until you feel that you have control of
your scooter.
Steering
Steering your Golden Avenger™is easy and logical.
1. With both hands on the handgrips of the tiller, turn the tiller to the right to
travel to the right.
2. With both hands on the handgrips of the tiller, turn the tiller to the left to
travel to the left.
3. Make certain to maintain sufficient clearance when turning your scooter so
that the rear wheels will clear any obstacle.
WARNING: TURNING TOO SHARPLY AROUND A CORNER CAN CAUSE THE SCOOTER
TO TIP. AVOID THIS DANGER AT ALL TIMES BY STEERING A WIDE ARC AROUND
CORNERS AND OBSTACLES. ALSO, TO AVOIDE THE RISK OF TIPPING, REDUCE SPEED
BEFORE NEGOTIATING ANY TURNS.
Steering in a tight spot
If you must steer in a tight spot, such as entering a doorway or when turning
around:
1. Bring your Avenger™to a full stop.
2. Turn the speed control dial to the slowest setting (Fully counter clockwise)
3. Turn the tiller to the direction in which you wish to drive.
4. Press gently on the appropriate thumb lever and slowly turn your
Avenger™.
For more information on dealing with obstacles and tight spots, see “Control
through Tight Spots” on the next page.
Steering in Reverse
Backing up your Avenger™requires attention to what you are doing
1. Use your left thumb to press against the left thumb lever.
2. Turn the tiller to the left to drive in reverse to the left.
3. Turn the tiller to the right to drive in reverse to the right.
Note: Your Avenger™speed in reverse is fifty percent of the maximum speed set
at the speed control dial.

Avenger Owner’s Manual Revised 09/29/09
RIDING YOUR AVENGER™
Control through tight spots
As you use your Avenger™to increase your mobility, you will undoubtedly
encounter some obstacles that will require practice to negotiate smoothly and
safely. Below are some common obstacles that you may meet during the daily
use of your scooter. Listed with those obstacles are some driving tips that should
help you conquer those obstacles. Learn and follow those tips, and with
surprising ease you will soon be in control of your scooter as you maneuver it
through doors, up and down ramps, up and over curbs, through grass and gravel,
and up and down inclines.
Doors
•Approach any unfamiliar door slowly.
•Notice if the door has a knob or a push bar.
•Determine if the door opens towards you or away form you.
•Do not try to use your own strength to open the door. Learn to use the
power of your scooter to do the majority of the work for you.
If the door opens away from you:
1. Use one hand to turn the doorknob or to operate the push bar.
2. Use your other hand to steer the scooter and to gently press on the thumb
lever that will move your scooter slowly forward.
3. Use your arm to push the door gently open.
4. Drive through the doorway.
5. If it is a self-closing door, it will close behind you.
6. If it is not a self-closing door, stop your scooter when it is clear of the door
and use your hand to push the door closed.
If the door opens towards you:
1. Use one hand to turn the doorknob or to pull the handle.
2. Keep your grip on the knob or on the handle.
3. Use your other hand to steer your scooter and to gently press the thumb
lever that will move your scooter slowly in reverse.
4. Allow the power of your Avenger™to pull the door completely open.
5. When the door is completely open, stop your scooter.
6. Drive through the doorway while keeping your hand on the door to prevent
it from hitting or blocking your scooter.
7. If it is a self-closing door, it will close behind you.
8. If it is not a self-closing door, pull it closed behind you.
Ramps
Because of the American Disabilities Act (ADA), many buildings are fitted with
ramps that provide access for scooters and for other mobility vehicles.

Avenger Owner’s Manual Revised 09/29/09
RIDING YOUR AVENGER™
When proceeding up any ramp, curb, or incline:
•Lean forward in your seat to move your center of gravity forward for
maximum stability and safety.
If the ramp has a switchback, good cornering ability is required.
•Maneuver your scooter so that the front wheels take wide swings around
the corners of the ramp.
•Doing this will allow your scooter’s back wheels to follow a wide arc
around the corner, staying clear of obstacles.
If you must stop your scooter while driving up a ramp:
•Starting up again simply requires that you apply gentle and steady forward
power (pressure to the right-hand thumb lever).
•Accelerate gently after stopping on any incline.
Driving down a ramp:
•Keep your Avenger™speed control dial set fully counterclockwise at the
slowest speed setting.
•If you must come to a stop, release the thumb control lever slowly and
smoothly.
Curbs
•Always use caution when negotiating any curb.
•Go up or down a curb only at a direct angle.
•Approach and negotiate the curb so that both back wheels of your scooter
go over the curb at the same time.
•Never negotiate inclines or curbs by traversing them. Doing so my cause
the scooter to tip over
•Go down a curb slowly to avoid a jarring bump. Use as little power as
possible.
Grass and Gravel
Your Avenger™performs admirably on grass, gravel, and hills, but you must
follow the operational parameters presented in this manual. Refer to the “Safety”
section. If you are unsure about any situation, avoid it. Common sense is your
best protection
•Feel free to use your Avenger™on lawns or in park areas.
•Avoid long or high grass, which may wrap around your scooter’s axles.

Avenger Owner’s Manual Revised 09/29/09
DISASSEMBLY
Your Avenger™scooter is designed to be disassembled in order to be
transported. When disassembling your Avenger™, please be sure to follow these
simple instructions.
Step 1 - Place your scooter on a level surface. You will be disengaging your
brake during disassembly; therefore it is very important to assure that your
scooter will not roll.
WARNING: BE SURE YOUR KEY IS OUT OF THE KEY HOLE BEFORE YOU BEGIN
DISASSEMBLING YOUR AVENGER™.
Step 2 - (Optional) Remove the arms from the seat. This will reduce the weight
of the seat making it easier to lift.
Step 3 - Remove the seat from the scooter – Your seat must be turned to either
the left or right position to be removed out of the post. Grip the seat on opposite
sides and, with a firm grip, pull the seat straight up to remove.
