golmar VESTA SE GB2/H User manual

Code 50121960 TVESTA SE G 2 EN7 B REV.0419
VESTA SE GB2 M7 ONITOR
USER MANUAL
VESTA SE G 2/H M7 B ONITOR
Camera
/Door Light Intercom Playback SetupDivert

INTRODUCTION
Our commitment to achieving the satisfaction of customers like you is manifested through our ISO-9001 certification
and the manufacture of products like the one you have just purchased.
First of all, we thank and congratulate you for purchasing this product.
Its advanced technology and strict quality control will ensure that customers and users enjoy the numerous features
that this device offers. To get the most out of them and ensure proper operation from day one, we recommend that you
read this instruction manual.
CONTENTS
2
SAFETY PRECAUTIONS
- before installing or making modifications to the device.Always disconnect the power supply
- The fitting and handling of these devices must be carried out by authorised personnel.
-Avoid overtightening the screws of the monitor connector.
-All of the wiring must run at least 40cm away from any other wiring.
- Do not place in humid, dusty or smoky locations, or near sources of heat.
- Install the monitor in a dry protected location free from the risk of dripping or splashing water.
- Before connecting the device check the connections between the door panel, power supply, distributors and monitors.
-Always follow the instructions contained in this manual.
Description and communication with hearing aids (Vesta7 SE GB2/H monitor only)..................................................... 8
Installing the monitor in a wall mounting connector..........................................................................................................6
Installing the monitor in an embedding box......................................................................................................................7
Operation..........................................................................................................................................................................
1.5Answering a call from the door panel and showing cameras (DQ-CAM-GB2 module required)..............................10
1.1 ........................................................................................................................8Receiving a call from the door panel
User direct access functions.........................................................................................................................................12
1. .............................................................................................................12-13Displaying door panel/camera images..
1.3 ............................................................................................................................9Ending a call from the door panel
Monitor screen and volume settings menu (brightness, colour, contrast and communication volume)............................11.
1.6 ...................................................................... 10'Doctor mode' function (automatic opening of the main door)..........
1.2 .......................................................................................................... 9Call not answered (missed call)....................
1.4 .......................................................................................................................9Answering a call from the door panel
6. Settings (ringtone, ringtone volume, default settings, about and language selection)........................................ 22-25
Cleaning the monitor.................................................................................................................................................... 25
...................................................................................................................................................16Accessing the menu
3. .................................................................................................................... 18-19Intercom between apartments......
2. .....................................................................................................................................13Activating the outdoor light.
User menu........................................................................................................................................................................
1. ..................................................................................................................17Displaying door panel/camera images..
5. ........................................................................................... 20-22Playback (M-IP-GB2 module required)..................
4. ................................................................................................................................................ 19Divert (no function).
2. ......................................................................................................................................18Activating the outdoor light
4. ............................................................................................................14-15Intercom within an apartment.................
3. .............................................................................................................................. 14Activating 'do not disturb' mode
.................................................................................................................................4Function and menu buttons.........
............................................................................................................5Setting the monitor's address codes.................
................................................................................................................................................4Connection terminals...
.................................................................................................................................4Configuration DIP switch.............
Contents.........................................................................................................................................................................2
Introduction............................................................................................................................................................. .......2.
Safety precautions......................................................................................................................................................... 2.
Characteristics............................................................................................................................................................... 3.
System operation................ ............................................................................................................................................ 3
Description of the monitor..................................................................................................................................................
Descrip n........................................................................... .......................................................................................4tio .
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

CHARACTERISTICS
- DIP switches for setting the monitor address (call code) and end of line.
- LED of button in 'do not disturb' mode fixed / 'doctor mode' LED slow blink.
- Different ringtones to identify the origin of the call (door panel, intercom or apartment door).
- Input for call from the apartment door.
- SAR-12/24 auxiliary call repeater output (12Vdc/50mAmaximum).
- 'Doctor mode' function (automatic door opening).
- Hands-free monitor.
- 7” TFT colour screen.
- Enabling the menu to be viewed when the B is busy.US
- Settings: Ringtone, ringtone volume, default settings (restore), about and language.
(Accessed through the 'About' option in the user menu)Installer menu: .
- Indicating the number of door panels (up to 4 access panels).
- Monitor as master or slave 1, slave 2 or slave 3. Up to 4 monitors per apartment.
(during auto switch-on or communication).Screen and volume settings menu:
- Indicating the number of cameras (up to 4 CCTV cameras, DQ-CAM-GB2 module required).
-Activating intercom between apartments.
-Activating the outdoor light.
- The Vesta7 SE GB2/H monitor interacts with hearing aids equipped with T-mode, making conversation between
apartment and door panel easier.
- Playback (M-IP-GB2 module required).
- Capacitive function buttons to access and select menu functions:
- Intercom calls between apartments.
- Displaying camera pictures (DQ-CAM-GB2 module required).
- Monitor with simple installation (non-polarised 2 wire BUS).
User menu:
- Displaying door panel images.
- Lock release button 2 / in standby, it activates/deactivates the 'do not disturb' function.
- Intercom within an apartment button.
- Brightness.
- Menu access button.
- Contrast.
- Start/stop communication button and, in standby mode, it displays the image from the door panel.
- Colour.
- Monitor speaker volume (communication).
- Lock release button 1 / in standby, it activates the outdoor light.
SYSTEM OPERATION
If the call is not answered within 40 seconds, LED will turn off and the channel will be freed.
- To establish communication, press button on any monitor in the apartment. Door panel LED will turn on.
- The call lasts for 40 seconds and, when received, the image appears on the master monitor without the visitor
knowing. To view the image on a slave monitor, this function needs to have been enabled on the monitor. House kit
application: the image appears on the monitor (with code 0 'house 1' or monitor with code 16 if the call is in 'house 2')
when receiving the call without the visitor being alerted.
- To make a call, the visitor must press the button of the apartment; an audible sound indicates that the call is being
made and LED will turn on. If vocal synthesis is enabled, a 'Call is in progress' message appears indicating that a
call is being made. At this moment, the apartment's monitors receive the call. If another apartment is called by
mistake, press the button for the correct apartment and the first call will be cancelled.
- Communication will last for one and a half minutes or until button or is pressed again. When communication
has finished, LEDs and will turn off and the channel will be freed. If vocal synthesis is enabled, a 'Communication
is finished' message will indicate that the call is over.
- To open door 1 or 2, press the corresponding button / during the call or communication processes: one press
will activate the lock release for five seconds and LED will also turn on for five seconds. If vocal synthesis is
enabled, a 'Door open' message will be indicated on the door panel.
If the monitor is a Vesta7 SE GB2/H with icon on the front, make sure that the hearing aid is 20cm away from the
monitor to ensure maximum audio quality during communication with the door panel.
-Adescription of the function buttons can be found on page 4.
3
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

DESCRIPTION OF THE MONITOR
Connection terminals and DIP switch:
( ):WHITE HZ+
( ):GREEN HZ-
Configuration DIP switch:
The switches set to OFF have a zero value.
DIP 1 to DIP 5: To set the monitor address (addresses 0 to 31).
L1, L2: Bus connection (non-polarised).
CALL REPEATER, GND: Auxiliary call repeater connection
(SAR-12/24). (12Vdc/50mA maximum).
DIP 6: Configures the end of line. Leave in the ON position in
monitors where the bus cable terminates. Set to OFF in
intermediate monitors only.
The values of the switches set to ON are shown in the table below.
HZ+, HZ-: Door bell connection.
The monitor code is the sum of the values of the switches set to
ON.
Connection terminals:
123
ON DIP
456
L1
L2
(RED): CALL REPEATER
( ):BLACK GND
(YELLOW): DO NOT USE
Menu entry and user settings button. On menu screen: Display door panel image.
On menu screen: Intercom function between
apartments.
Menu buttons:
4
123
ON DIP
4 5 6
E : 0 + 0+4+0+16 = 20xample
Switch number: 1 2 3 4 5
ON: 1 2 4 8 16Value when
Table of values
On menu screen: Divert (no function).
Menu entry and selection button.
a. 7” TFT colour screen.
b. Microphone.
c. Start/stop communication button.
In standby: Display door panel image.
d. Door release button 1. In standby: Activation of outdoor
light / Press for 6 seconds to activate/deactivate the
'doctor mode' function (function code [9018] must be
activated).
e. Lock release button 2. In standby: 'do not disturb' mode,
a 3-second press activates/deactivates 'do not disturb'
mode. If the mode is activated, icon illuminates.
In standby: Intercom function in the apartment.
In auto spy/auto switch-on: Select other door panel(s),
camera(s) in descending mode and in carousel (if any).
g. In standby: Enter menu.
f. End call/communication button.
In auto spy/auto switch-on: Select other door panel(s),
camera(s) in ascending mode and in carousel (if any).
In standby: If there is a missed call, the LED blinks and
when you press you access the 'playback' menu.
k. Configuration DIP switch.
In call/communication: Select camera(s) in ascending
mode and in carousel (if any).
h. In standby: Enter menu.
j. Connector fixings.
Video activated: Screen and communication volume
settings.
i. Vertical wiring entries.
n. Communication with hearing aids (Vesta7 SE GB2/H
only). et the hearing aid switch to T-mode, see p. 8.S
l. Connector.
m.Bus connection terminals.
On menu screen: Activate outdoor light.
123
ON DIP
456
cfg
deh
l
m
j
k
b
a
1 2 3
ON DIP
4 5 6
i
j
i
n
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
(continued)

5
DESCRIPTION OF THE MONITOR
Setting the monitor's address codes (addresses 0 to 31):
DIP 6: Configures the end of line. Leave in the ON position in monitors where the video cable terminates. Set to OFF in
intermediate monitors only.
1 2 3
ON DIP
4 5 6
C 0 / 32ode
123
ON DIP
4 5 6
C 01ode
123
ON DIP
4 5 6
C 02ode
123
ON DIP
4 5 6
C 03ode
123
ON DIP
4 5 6
C 04ode
123
ON DIP
4 5 6
C 05ode
123
ON DIP
4 5 6
C 06ode
123
ON DIP
4 5 6
C 07ode
1 2 3
ON DIP
4 5 6
C 08ode
123
ON DIP
4 5 6
C 09ode
123
ON DIP
4 5 6
C 10ode
123
ON DIP
4 5 6
C 11ode
123
ON DIP
4 5 6
C 12ode
123
ON DIP
4 5 6
C 13ode
123
ON DIP
4 5 6
C 14ode
123
ON DIP
4 5 6
C 15ode
123
ON DIP
4 5 6
C 16ode
123
ON DIP
4 5 6
C 17ode
123
ON DIP
4 5 6
C 18ode
123
ON DIP
4 5 6
C 19ode
123
ON DIP
4 5 6
C 20ode
123
ON DIP
4 5 6
C 21ode
123
ON DIP
4 5 6
C 22ode
123
ON DIP
4 5 6
C 23ode
123
ON DIP
4 5 6
C 24ode
123
ON DIP
4 5 6
C 25ode
123
ON DIP
4 5 6
C 26ode
123
ON DIP
4 5 6
C 27ode
123
ON DIP
4 5 6
C 28ode
123
ON DIP
4 5 6
C 29ode
123
ON DIP
4 5 6
C 30ode
123
ON DIP
4 5 6
C 31ode
DIP 1 to DIP 5: To set the monitor address (addresses 0 to 31).
123
ON DIP
4 5 6
DIP 6 to ON DIP 6 to OFF
123
ON DIP
4 5 6
( )
**
( )
** Important:
-In door panel systems with call buttons, the first address on the monitor is 'Code 0'.
-In coded panel systems (N3301/GB2), 'Code 0' is 'Code 32', which means that when a call is made to
a monitor with 'Code 0' (DIP 1 to DIP 5 set to OFF), needs to be entered on the N3301/GB2
numeric keypad.
-In the software (Address Manager GB2), 'Code 0' is also shown as 'Code 32'.
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
23

INSTALLING THE MONITOR IN A WALL MOUNTING CONNECTOR
The top of the connector must be positioned at a height of 1.60m. The minimum distance between the sides of the
connector and the closest object must be 5cm.
Positioning the wall mounting connector:
Fix the monitor's wall mounting connector to the wall by drilling two 6mm diameter holes and using the screws and plugs
supplied with the monitor.
Fixing the monitor's wall mounting connector to the wall:
Positioning the monitor:
1 2 3
Avoid dusty or smoky environments or locations near sources of heat.
6
Connect the cables to the monitor (see p. 4), position the monitor in front of the wall mounting connector, ensuring that
the holes in the base of the monitor line up with those on the connector , and then move the monitor downwards
until the monitor is securely fixed to the connector .
.
Remember to remove the protective covering from the front of the monitor once installation is complete.
12
3
1.60m
x4 30
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

INSTALLING THE MONITOR IN AN EMBEDDING BOX
Make a hole in the wall to position the top of the universal embedding box at a height of 1.60m from the ground. The
minimum distance between the sides of the embedding box and the closest object must be 5cm.
Location of the embedding box:
1.60m
Pass the cable through the hole made in the embedding box. Embed the box and ensure that it is level and flush.
Fix the wall mounting connector of the monitor to the embedding box with the screws supplied.
Positioning the embedding box and fitting the wall mounting connector:
Avoid dusty or smoky environments or locations near sources of heat.
Screws supplied with
the embedding box.
7
Positioning the monitor:
1 2 3
Connect the cables to the monitor (see p. 4), position the monitor in front of the wall mounting connector, ensuring that
the holes in the base of the monitor line up with those on the connector , and then move the monitor downwards
until the monitor is securely fixed to the connector .
.
Remember to remove the protective covering from the front of the monitor once installation is complete.
12
3
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

OPERATION
When a call is received, the monitor(s) will play a melody, the LEDs will illuminate (the LED of button will blink
rapidly) and the image from the door panel will be displayed on the master monitor without the visitor knowing. If the
call is not answered within 40 seconds the monitor returns to standby mode. If there is an M-IP-GB2 memory module,
it will automatically take a photo or record a video (for video, a 16GB Class 10 MicroSD card is required, not supplied)
and the LED of button will blink indicating that a photo/video is pending viewing.
1.1 Receiving a call from the door panel:
Monitor description when receiving a call and during communication:
To open door 1, press the door release
button during the call: one press will activate
the lock release for 5 seconds.
8
Continued overleaf
DS-1
00:30
01
Start/stop communication.
Call: LED blinks rapidly.
Communication: LED blinks slowly.
Door panel that made the call/CCTV
camera selected.
Call/communication time elapsed.
In call.
Screen settings: brightness, colour,
contrast and monitor volume.
Select CCTV camera(s) image.
(DQ-CAM-GB2 module required).
End call/communication.
Activate lock release 2.
Activate lock release .1
In communication.
In call/communication LEDs illuminated.
00:30
01
To open door 2, press the door release
button during the call: one press will
activate the lock release for 5 seconds.
Communication with hearing aids.
Set the hearing aid switch to
T-mode. (Vesta7 SE GB2/H only).
Note:
T
Communication with hearing aid (Vesta7 SE GB2/H monitor only):
Make sure that the hearing aid is 20cm away from the
monitor to ensure maximum audio quality during
communication with the door panel.
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
In call automatic image recording.
(M-IP-GB2 memory module required).

OPERATION
When a call is received, the monitor(s) will play a melody, the LEDs will illuminate (the LED of button will blink
rapidly) and the image from the door panel will be displayed on the master monitor without the visitor knowing. If there
is an M-IP-GB2 memory module, it will automatically take a photo or record a video (for video, a 16GB Class 10
MicroSD card is required, not supplied) and the LED of button will blink indicating that a photo/video is pending
viewing.
1.3 Ending a call from the door panel:
Continued from previous page.
1.2 Call not answered (missed call):
To open door 1, press the door release button
during the call: one press will activate the lock
release for 5 seconds.
9
1.4 Answering a call from the door panel:
Communication will last for one and a half minutes or until button or is pressed again.
When a call is received, the monitor(s) will play a melody, the LEDs will illuminate (the LED of button will blink
rapidly) and the image from the door panel will be displayed on the master monitor without the visitor knowing. If there
is an M-IP-GB2 memory module, it will automatically take a photo or record a video (for video, a 16GB Class 10
MicroSD card is required, not supplied) and the LED of button will blink indicating that a photo/video is pending
viewing. To answer the call, press button (the LED of button will blink slowly). If the monitor is a
Vesta SE GB2/H with icon on the front, make sure that the hearing aid is 20cm away from the monitor to ensure
maximum audio quality during communication with the door panel.
Start/stop communication.
00:30
DS-1
00:30
DS-1
00:30
01
When a call is received, the monitor(s) will play a melody, the LEDs will illuminate (the LED of button will blink
rapidly) and the image from the door panel will be displayed on the master monitor without the visitor knowing. If the
call is not answered within 40 seconds the monitor returns to standby mode.
To open door 2, press the door release button
during the call: one press will activate the lock
release for 5 seconds.
To open door 1, press the door release button
during the call: one press will activate the lock
release for 5 seconds.
To open door 2, press the door release
button during the call: one press will activate
the lock release for 5 seconds.
00:30
DS-1
00:30
DS-1
00:30
01
DS-1
00:30
DS-1
00:30
01
End call.
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
If there is an M-IP-GB2 memory module, it will
automatically take a photo or record a video (for video, a
16GB Class 10 MicroSD card is required, not supplied)
and the LED of button will blink indicating that a
photo/video is pending viewing.

OPERATION
Continued from previous page.
10
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
1. Doctor mode function (automatic door opening):6 ' '
The 'doctor mode' function enables lock release 1 to be activated automatically 7 seconds after making a call from the
door panel without having to establish communication or press door release 1 button . The main monitor will display
the door panel image without alerting the visitor. The call ends after 40 seconds and the channel is free. If there is an
M-IP-GB2 memory module, it will automatically take a photo or record a video 4 seconds after receiving a call from the
door panel (for video, a 16GB Class 10 MicroSD card is required, ) and the LED of button will blink
indicating that a photo/video is pending viewing.
not supplied
Descrip n:tio
Enabling 'doctor mode':
To enable doctor mode, enter function code [9018] in the installer menu (see pp. 22 and 24).
Activating 'doctor mode':
To activate doctor mode, the monitor must be in standby mode. Then press button for 6 seconds, the LED of
button will blink to indicate that the doctor mode function is activated.
Deactivating 'doctor mode':
To deactivate doctor mode, the monitor must be in standby mode. Then press button for 6 seconds, the LED of
button will turn off to indicate that the doctor mode function is activated.
Important:
When deactivating 'do not disturb' mode (with the monitor's 'doctor mode' activated), the status LED will blink and the
'doctor mode' function will be reactivated.
When activating 'do not disturb' mode (with the monitor's 'doctor mode' activated), the status LED will change from
blinking to fixed and the 'doctor mode' function will be cancelled.
1.5 Answering a call from the door panel and showing cameras (DQ-CAM-GB2 module required):
When a call is received, the monitor(s) will play a melody and show the door panel image on the master monitor without
alerting the visitor. If there is an M-IP-GB2 memory module, it will automatically take a photo or record a video (for
video, a 16GB Class 10 MicroSD card is required, ) and the LED of button will blink indicating that a
photo/video is pending viewing. To answer the call, press button . If the monitor is a Vesta2 SE GB2/H with icon
on the front, make sure that the hearing aid is 20cm away from the monitor to ensure maximum audio quality during
communication with the door panel.
not supplied
.
Communication will last for one and a half minutes or until button or is pressed again.
In call or communication: selects from the door panel the image of the camera(s) in ascending mode and in
carousel (DQ-CAM-GB2 module required). Viewing the image of the door panel or camera(s) from the
monitor enables the opening of door 1/2 and audio with the door panel in case of communication.
Note:
DS-1
00:30
DS-1
00:30
01
Start/stop communication.
To open door 1, press the door release button during
the call: one press will activate the lock release for
5 seconds.
To open door 2, press the door release button during
the call: one press will activate the lock release for
5 seconds.
[ ]
9018

SCREEN AND VOLUME SETTINGS MENU
11
To adjust brightness, the monitor must be in communication or auto switch-on mode. Then press button to show
on screen option . Using menu buttons and , select the required brightness level. Press button to change
the following option or press to exit the settings menu.
To adjust the colour, the monitor must be in communication or auto switch-on mode. Then press button
repeatedly until option is displayed on the screen. Using menu buttons and , select the required colour level.
Press button to change the following option or press to exit the settings menu.
.
To adjust the contrast, the monitor must be in communication or auto switch-on mode. Then press button
repeatedly until option is displayed on the screen. Using menu buttons and , select the required contrast level.
Press button to change the following option or press to exit the settings menu.
.
To adjust the communication volume, the monitor must be in communication or auto switch-on mode. Then press
button repeatedly until option is displayed on the screen. Using menu buttons and , select the required
volume level. Press button to return to option or press to exit the settings menu.
00:01
01
5
+
-
-
00:01
01
5
+
-
-
00:01
01
5
+
-
-
00:01
01
6
+
-
-
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

USER DIRECT ACCESS FUNCTIONS
Description of buttons with user direct access functions:
12
Display door panel image.
Activate/deactivate the 'do not disturb' mode
function.
Activate outdoor light.
1. Displaying door panel/camera images:
1.1 To display the image from one of the installed door panels/cameras, press button while the monitor is in
standby. The following screen will display the image from the door panel with address 1, indicating the selected door
panel '01' and the elapsed connection time.
Monitor in standby
00:01
01
Door panel selected
Continued overleaf
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
Activate intercom function within apartment.
If there is a missed call: The LED of button
blinks and when you press you access the
'playback' menu, (see pp. 20-22).
.

Then, using menu buttons and , select the desired door panel/camera (DQ-CAM-GB2 module required, for function
codes, see p. 24) in descending and ascending mode respectively (carousel mode).
During door panel selection, door 1 and 2 can be opened by pressing the corresponding button / : one press
will activate lock release 1 or 2 for five seconds.
The connection will last for 30 seconds or until option is pressed twice if a door panel is selected or once if a camera
is selected.
Continued overleaf
00:01
01
00:01
01
To establish audio and video communication with the selected door panel, press button . The screen will
display symbol . Communication will last for one and a half minutes or until button is pressed again.
During door panel selection, door 1 and 2 can be opened by pressing the corresponding button / during the
image display or communication processes: one press will activate lock release 1 or 2 for five seconds.
Door panel selected
00:01
01
Camera selected
Continued from previous page.
USER DIRECT ACCESS FUNCTIONS
13
2. Activating the outdoor light:
2.1 To activate the outdoor light, press button while the monitor is in standby. The outdoor light (SAR-GB2
module required) activates for 1 minute, see the TSAR-GB2 MLuser manual for how to set other light activation times.
Monitor in standby
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

3.1 To activate 'do not disturb' mode, press button / on the master monitor for 3 seconds while in standby.
The status LED of button / of the master and secondary monitors in the apartment will illuminate indicating
that the function is activated. The monitors in the apartment will not receive door panel or intercom calls.
Continued overleaf
Continued from previous page.
USER DIRECT ACCESS FUNCTIONS
14
Monitor in standby
3 Activating 'do not disturb' mode:
3.2 To deactivate 'do not disturb' mode, press button / on the master monitor for 3 seconds while in
standby. The status LED of button / of the master and secondary monitors in the apartment will turn off
indicating that the function is deactivated.
4.1 To activate the intercom within an apartment, press button on the monitor while in standby.
The following call screen will be displayed, the status LED of button will blink rapidly and a long audible tone will
confirm that the call is being made or short tones will indicate that a monitor in the apartment is already communicating
with the door panel and the call will not be made. If a call is being made, press button to cancel the call.
Monitor in standby
4 Intercom calls within an apartment:
Make an intercom call
01
( )
*
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

Continued from previous page.
USER DIRECT ACCESS FUNCTIONS
15
If a call is received from another apartment during an intercom process, the intercom call will be cancelled, a melody on
the apartment's monitor will warn that a call is being made and the address of the apartment making the intercom call
will be displayed (see 'Intercom between apartments' on pp. 18-19).
If a call is received from the door panel in the apartment during an intercom process, the intercom call will be cancelled,
a melody on the apartment's monitor will warn that a call is being made and an image will appear on the master
monitor. To establish communication with the door panel, press button on the monitor. If there are slave monitors
in the apartment, press button on any of them.
The ringtones vary depending on where the call is being made from, enabling the user to identify its origin (door panel,
intercom or apartment door).
On the other monitors in the apartment, the status LED of button will blink rapidly and a melody will indicate that an
intercom call is being made. Press button to accept the call and establish communication, the status LED of
button will blink slowly, or press button to cancel it. If the call is accepted, communication will last for one and a
half minutes or until button is pressed again.
Receive an intercom call
01
In communication
01
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR

USER MENU
To access the menu, the monitor must be in standby. Then press menu button or to display the options screen
of the main menu.
16
Continued overleaf
Description of the menu buttons:
Menu entry and user settings button. Display door panel image.
Intercom function between apartments.
No 'Divert' function.
Menu entry button and 'Image memory'.
Activate outdoor light.
Camera/
Door Light Intercom Divert Setup
Monitor in standby
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
Playback
Main menu screen
Camera/
Door Light Intercom Playback SetupDivert
10:26
26/11/2019
Tue.
10:26
26/11/2019
Tue.
Note: The date and time is only displayed if an M-IP-GB2 memory module is installed.
( )
*
( )
*

USER MENU
17
1. Displaying door panel/camera images:
To display the image from one of the installed door panels/cameras, press button .
The following screen will display the image from the door panel with address 1, indicating the selected door panel '01'
and the elapsed connection time. Then, using menu buttons and , select the desired door panel/camera (for
camera, a DQ-CAM-GB2 module is required, for function codes, see p. 24) in descending and ascending mode
respectively (carousel mode).
The connection will last for 30 seconds or until option is pressed twice if a door panel is selected or once if a camera
is selected.
During door panel selection, door 1 and 2 can be opened by pressing the corresponding button / : one press
will activate lock release 1 or 2 for five seconds.
Continued overleaf
Continued from previous page.
Main menu screen
00:01
01
00:01
01
To establish audio and video communication with the selected door panel, press button . The screen will
display symbol . Communication will last for one and a half minutes or until button is pressed again.
During door panel selection, door 1 and 2 can be opened by pressing the corresponding button / during the
image display or communication processes: one press will activate lock release 1 or 2 for five seconds.
Door panel selected
00:01
01
Camera selected
Start/stop communication.
To open door 1, press the door release button
during the call: one press will activate the lock
release for 5 seconds.
To open door 2, press the door release button
during the call: one press will activate the lock
release for 5 seconds.
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
Camera/
Door Light Intercom Playback SetupDivert
10:26
26/11/2019
Tue.

USER MENU
18
Continued from previous page.
2. Activating the outdoor light: (SAR-GB2 module required)
To activate the outdoor light, press button . The outdoor light (SAR-GB2 module required) will activate for
1 minute. See the TSAR-GB2 MLuser manual for how to set other light activation times.
Main menu screen
IMPORTANT:Activate function codes and on the monitor (see 'Installer menu' p. 22 and p. 24).[9015] [8017]
To access the intercom function between apartments, press button . The following selection screen will be
displayed. Use buttons and to select the apartment to call.
3. Intercom between apartments:
Main menu screen Apartment selection screen
[01]
[02]
[00]
[03]
Then press button to make the call. The following call screen will be displayed indicating the address of the
apartment to call. The status LED of button will blink rapidly and a long audible tone will confirm that the call is
being made or a series of short audible tones will indicate that the unit called is in communication with the door panel or
on an intercom call with another apartment, and the call will not be made. If a call is being made, press option
to cancel the call.
.
Apartment selection screen
[01]
[02]
[00]
[03]
Make an intercom call
01
Continued overleaf
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
Camera/
Door Light Intercom Playback SetupDivert
10:26
26/11/2019
Tue.
Camera/
Door Light Intercom Playback SetupDivert
10:26
26/11/2019
Tue.

USER MENU
19
Continued overleaf
Continued from previous page.
On the monitor(s) of the apartment called, the status LED of button will blink rapidly, a melody will indicate that an
intercom call is being made and the address of the apartment making the call will be shown. Press button to
accept the call and establish communication, the status LED of button will blink slowly, or press button to
cancel it. If the call is accepted, communication will last for one and a half minutes or until button is pressed again.
Receive an intercom call
00
In communication
00
If during the intercom process a call is received from the door panel of another apartment, the intercom process will be
cancelled; the monitor in the apartment will emit a melody to indicate that the call is being made and the image will
appear on the master monitor. To establish communication with the door panel, press button on the monitor. If
there are slave monitors in the apartment, press button on any of them.
The ringtones vary depending on where the call is being made from, enabling the user to identify its origin (door panel,
intercom or apartment door).
4. Divert: (No function)
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
Main menu screen
Camera/
Door Light Intercom Playback SetupDivert
10:26
26/11/2019
Tue.
x

USER MENU
20
Continued from previous page.
5. Playback: (M-IP-GB2 module required)
To display the call photos/videos on the door panel, press button . The following 'Playback' selection screen will
be displayed. Use buttons and to select the photo/video to view (for video, a 16GB Class 10 MicroSD card is
required, , each video is 10 seconds long).not supplied
VESTA7 SE GB2 - VESTA7 SE GB2/H MONITOR
Main menu screen Selection screen
Camera/
Door Light Intercom Playback SetupDivert
10:26
26/11/2019
Tue.
0032 [1/30] 191126_103607.avi
26/11/2019 10:36:09
Delete Delete all Info ExitLast Next
To delete the selected photo/video, press button . Symbol will be displayed above the 'delete' option. Press
button to confirm the deletion and show the next saved photo/video or press to cancel the deletion and
show the next saved photo/video.
button
?
Selection screen
0032 [1/30] 191126_103607.avi
26/11/2019 10:36:09
Delete Delete all Info ExitLast Next
Selection screen
0032 [1/30] 191126_103607.avi
26/11/2019 10:36:09
Delete Delete all Info ExitLast Next
?
To delete all recorded photos/videos, press button . Symbol will be displayed above the 'delete all' option.
Press button to confirm the deletion of all saved photos/videos or press button to cancel the deletion and show
the next saved photo/video.
?
Selection screen
0032 [1/30] 191126_103607.avi
26/11/2019 10:36:09
Delete Delete all Info ExitLast Next
Selection screen
0032 [1/30] 191126_103607.avi
26/11/2019 10:36:09
Delete Delete all Info ExitLast Next
?
Continued overleaf
