GPO MEMPHIS User manual
V3 | OCT 2020
USER MANUAL
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 1GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 1 04/11/2020 14:2204/11/2020 14:22
2
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 2GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 2 04/11/2020 14:2204/11/2020 14:22
3
Content
English 5
German 17
French 31
Dutch 45
Spanish 59
Italian 73
Portuguese 87
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 3GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 3 04/11/2020 14:2204/11/2020 14:22
4
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 4GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 4 04/11/2020 14:2204/11/2020 14:22
5
English
5
1
2
3
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 5GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 5 04/11/2020 14:2204/11/2020 14:22
6
2
3
4
27
9
1122
24
8
1023
12
16 15
14
13
21 20 19 17
28 29 30
18
5
6
1
7
26
25
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 6GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 6 04/11/2020 14:2204/11/2020 14:22
7
PARTS / BUTTONS
Before use, detach the stylus guard (white plastic cover) by pulling it
straight off the front of the cartridge in the direction of the arrow.
1. Turntable platter 20. AUX IN
2. 45 rpm adapter 21. Record button
3. Lift lever (use this lever 22. Function button
to lift the tonearm) 23. Volume control
4. Tonearm 24. CD door
5. Speed selector 25. Power indicator
6. Tonearm rest 26. IR sensor
7. Display 27. Auto-stop (ON/OFF)
8. Speakers selector
9. Open/Close button 28. Line out socket
10. Tuning control knob 29. FM antenna
11. FM/FM stereo selector 30. AC power cord
12. Mode button (Programme,
Repeat 1, Repeat Album,
Repeat All)
13. BBS button
14. Skip + button
15. Skip - button
16. SD/MMC card slot
17. Stop/CD/USB/SD button
18. USB port
19. Play/Pause button
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 7GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 7 04/11/2020 14:2204/11/2020 14:22
8
OPERATING THE RADIO
FM TUNER
1. Set the FUNCTION button (22) to the RADIO position.
2. Tune in to the desired radio station by turning the Tuning control
knob (10).
3. Adjust the volume (23) to the desired level.
4. Set the FUNCTION button (22) to the OFF position to turn o
ff the radio.
Antenna
Extend the wire to obtain the best reception. You may need to turn or
change the position of the unit to improve reception.
FM Stereo and Mono Reception
When an FM signal is tuned to the FM stereo (11) position it can be
received in stereo. The FM Stereo indicator will appear on the LCD
display (7).
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 8GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 8 04/11/2020 14:2204/11/2020 14:22
9
OPERATING THE TURNTABLE
Before use, please make sure to: Lift the dust cover.
Release the tonearm clamp and remove the stylus protector.
Listening to records
1. Set the FUNCTION button (22) to the PHONO position.
2. Place a record on the turntable, over the central spindle. Place the
EP adapter over the central spindle when playing 17cm EP records.
3. Set the Speed selector (5) to 33, 45 or 78 rpm depending on the
record.
4. Release the tonearm clamp and remove the stylus protector.
5. Lift the tonearm from the tonearm rest by using the Lift lever.
6. Place the tonearm on the desired position of the record.
7. Gently lower the tonearm onto the record to start playing.
8. When the record is nished the tonearm will automatically stop. Lift
the tonearm from the record and put it back on the rest.
9. To stop manually, lift the tonearm from the record and return
it to the rest.
10. Set the Auto-stop (ON/OFF) selector to the ON position to use the
auto-stop function.
In the ON position, 33 rpm records will automatically stop when the end
of the record is reached.
45 and 78 rpm records can play the whole song when the auto-stop
function is OFF.
Note: Do not stop or turn the platter manually.
Moving or jarring the turntable without securing the tonearm clamp
could result in damage to the tonearm.
Replace the protective cap on the stylus when not in use.
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 9GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 9 04/11/2020 14:2204/11/2020 14:22
10
LINE-OUT CONNECTION
You can connect the unit to external speakers (4 ohm) via the Speaker
output L, R sockets (external speakers are not included).
Note: Sound will still come from the original built-in speakers even
after the external speakers are connected.
SELECTING THE SOURCE -
Stop/CD/USB/SD (17) button
Press this button and hold for 3 seconds to switch between CD, USB or
SD mode.
Remark: Please note that only the USB keys with format FAT32 and
under a capacity of 32Gb can be read by the unit.
LISTENING TO COMPACT DISCS
1. Set the FUNCTION button (22) to the CD position.
2. Press the PLAY/PAUSE button once to start playing the CD from the
rst track. “Play” will appear on the display.
3. Press the PLAY/PAUSE button once again to pause playback.
“Pause” will appear on the display and the track number will ash.
4. To stop playback, press the Stop/CD/USB/SD button.
In CD mode, this unit can read CD, CD-R and CD-RW discs. This unit
cannot play MP3 CDs, but it can play MP3 les on a USB ash drive.
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 10GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 10 04/11/2020 14:2204/11/2020 14:22
11
SKIPPING TRACKS
Selecting a different track during playback
1. Press the SKIP +/ SKIP - buttons (14, 15). The track number ap-
pears on the display.
2. Press the PLAY/PAUSE button to start playing the selected track.
REPEAT CD PLAY
1. When playing a CD, if you wish to listen to the same track repeated-
ly, press the MODE button (12) on the unit.
2. To play the entire disc over and over again, press the MODE button
twice. “REP ALL “ will be displayed.
3. To cancel repeat play, press the STOP button or press the MODE
button repeatedly until the repeat indicator disappears.
Note: The “REP ALL” function affects both normal and programmed
playback.
PROGRAMMED DISC PLAY (CD)
You cannot enter programs while playing a CD. Press the STOP button
(17) and then follow the instructions below.
1. Press the unit’s MODE button (12) and select PROGRAMME. The
information is displayed on the LCD display.
2. Press the unit’s SKIP +/SKIP - buttons (14, 15) to select the location
in which the track should be stored i.e. track 03.
3. Press the MODE button (12) and select PROGRAMME. The rst
programmed selection is now stored in the programme memory.
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 11GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 11 04/11/2020 14:2204/11/2020 14:22
12
Listening to programmed tracks
Press the PLAY/PAUSE button (19). The CD will start playing at the
beginning of the rst programmed track.
To clear the programmed memory:
If the disc is playing, press the STOP button (17) to stop the disc.
Turn off the device or use the FUNCTION button (22) to exit CD mode.
USING A USB / SD CARD
1. Insert the USB ash drive into the USB port (18) or the SD card into
the SD card slot (16).
2. Press the Stop/CD/USB/SD button (17). The total number of tracks
will be shown on the display and play automatically. NOTE: Only
MP3 format les are supported.
Not all USB ash drive brands are supported.
Playing the entire USB or SD card
When inserting a USB ash drive or SD CARD, playback will start auto-
matically with the rst track. The current track number is displayed.
1. To stop playback, press the PLAY/ PAUSE button (19) . The time
elapsed will ash.
2. To continue playback, press the PLAY/ PAUSE button again.
3. To stop playback, press the STOP button (17).
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 12GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 12 04/11/2020 14:2204/11/2020 14:22
13
RECORDING AND STORING FROM CD
You can record your favourite CD songs in MP3 format and store them
on a memory device via the USB port (18) or SD/MMC card slot (16).
1. Set the FUNCTION button (22) to CD mode.
2. Press the SKIP +/SKIP - buttons (14, 15) to select the song or track
you wish to record and then press the PLAY/PAUSE button (19).
3. Insert the USB ash drive into the USB port (18). Press the RE-
CORD button (21) to start synchronized recording. “>USB” will be
displayed indicating the track is being recorded to USB.
4. Insert the SD/MMC card into the SD/MMC slot (16). Press the
RECORD button (21) to start synchronized recording. “>SD” will be
displayed indicating the track is being recorded to SD or MMC.
5. Press the STOP button (17) to stop recording.
6. If you insert the USB ash drive and SD/MMC card into the unit at
the same time: press the RECORD button (21) to start synchronised
recording; “USB or CARD” will ash on the display. Then press the
SKIP +/SKIP - buttons (14, 15) to select recording to USB or card
and press the RECORD button to conrm.
7. Press the STOP button (17) to stop recording.
8. Note: CD recording must be synchronised. Press the STOP button
to conrm.
Attention: Some original CDs may not be recordable as they are
copy-protected.
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 13GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 13 04/11/2020 14:2204/11/2020 14:22
14
RECORDING AND STORING FROM
TURNTABLE
You can record you favourite vinyl songs in MP3 format and store them
on a memory device via the USB port (18) or SD/MMC card slot (16).
1. Set the FUNCTION button (22) to PHONO mode.
2. Insert the USB ash drive into the USB port (18). Press the RE-
CORD button (21) to start synchronized recording. “>USB” will be
displayed indicating the track is being recorded to USB.
3. Insert the SD/MMC card into the SD/MMC slot (16). Press the
RECORD button (21) to start synchronized recording. “>SD” will be
displayed indicating the track is being recorded to SD or MMC.
BASS BOOST
Press the BASS button (13) once to the ON position to enjoy a more
powerful Bass sound.
REMOTE CONTROL
1. Remove the battery cover from the back of the remote control.
2. Insert a CR2025 (3V) battery (included) making sure that the + and
symbols on the battery match those on the battery compartment.
3. Replace the battery cover.
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 14GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 14 04/11/2020 14:2204/11/2020 14:22
15
1. PLAY/PAUSE button 8. MODE button
2. RECORD button (Programme, Repeat 1,
Repeat Album, Repeat All)
3. Stop/CD/USB/SD button 9. Folder Up button
4. Skip - button 10. Folder Down button
5. Skip + button 11. Remote sensor
6. OPEN button
7. PROGRAMME button
1
2
3
4
5
6
7
8
9
10
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 15GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 15 04/11/2020 14:2204/11/2020 14:22
16
BATTERY REPLACEMENT
When the battery runs low, the distance at which the remote control will
operate is greatly reduced and you will need to replace the battery.
Remark: In order to save energy when the unit has no sound output
for a while, the unit will be switched to stand-by automatically. It can be
switched ON by using the function selector again.
USING THE REMOTE CONTROL
1. To use the remote control, point it at the remote sensor (11) and
press the button gently but rmly. Since the remote control range is
reduced when the unit is used at an angle, try to aim it directly at
the remote sensor.
2. Do not expose the remote sensor to strong light (direct sunshine or
articial light) and make sure that there are no obstacles between
the remote sensor and the remote control.
SPECIFICATIONS
Power supply: AC 230V - 50Hz
Power consumption: 13W
Radio frequency coverage: FM - 108 MHz
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 16GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 16 04/11/2020 14:2204/11/2020 14:22
17
German
17
1
2
3
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 17GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 17 04/11/2020 14:2204/11/2020 14:22
18
2
3
4
27
9
1122
24
8
1023
12
16 15
14
13
21 20 19 17
28 29 30
18
5
6
1
7
26
25
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 18GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 18 04/11/2020 14:2204/11/2020 14:22
19
TEILE / TASTEN
Entfernen Sie vor der Benutzung den Nadelschutz (wei(l,e Kunststof-
fabdeckung) durch Ziehen in Pfeilrichtung.
1. Plattenteller
2. Adapter fur Drehzahl 45
3. Hubhebel (zum Anheben des
Tonarms)
4. Tonarm
5. Geschwindigkeitswa hler
6. Tonarmsti.itze
7. Display
8. Lautsprecher
9. Taste fur
Offnen/Schlie(l,en
10. Tuning-Drehknopf
11. Umschalter FM/FM Stereo
12. Modus-Taste (Programme,
Titel wiederholen, Album wie-
derholen, Alles wiederholen,)
13. BBS-Taste
14. Nachster Titel
15. Vorheriger Titel
16. Kartensteckplatz SD/MMC
17. Taste Stopp/CD/ USB/SD
18. USB-Anschluss
19. Taste Play/Pause
20. AUX IN
21. Aufnahmetaste
22. Funktionstaste
23. Lautstarkeregler
24. CD-Fach
25. Betriebsanzeige
26. lnfrarotsensor
27. Auto-Stopp (EIN/AUS)
28. Ausgangsbuchse
29. FM-Antenne 30.Netzkabel
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 19GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 19 04/11/2020 14:2204/11/2020 14:22
20
BEDIENUNG DES RADIOS
FM-TUNER
1. Stellen Sie die Funktionstaste (22) auf die Position RADIO.
2. Stellen Sie mit dem Tuning-Drehknopf (10) den gewOnschten Radi-
osender ein.
3. Wahlen Sie mit dem Lautstarkeregler (23) die gewOnschte Laut-
starke .
4. Stellen Sie die Funktionstaste (22) auf die Position AUS, um das
Radio auszuschalten.
Antenne
Verlangern Sie das Kabel, um den besten Empfang zu erhalten. Mogli-
cherweise mOssen Sie das Gerat drehen oder die Position andern, um
den Empfang zu verbessern.
FM-Stereo- und Mono-Empfang
Wenn der FM-Empfang auf der Position FM-Stereo (11) steht, kann
das Signal in Stereo empfangen werden. Auf dem LCD-Display (7)
erscheint die FM-Stereo-Anzeige.
BEDIENUNG DES PLATTENSPIELERS
Var dem Gebrauch stellen Sie bitte Folgendes sicher: Offnen Sie die
Abdeckhaube.
Losen Sie die Tonarmklemme und entfernen Sie den Nadelschutz.
Abspielen von Schallplatten
1. Stellen Sie die Funktionstaste (22) auf die Position PHONO.
GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 20GPO_Memphis_user_Manual EU - Oct 2020_v1.indd 20 04/11/2020 14:2204/11/2020 14:22
Other manuals for MEMPHIS
2
Table of contents
Languages:
Other GPO Turntable manuals
