GXV3000 Video SIP Phone Quick Installation Guide
Part Number: 418-02006-10
Document Version Number: 1.0
Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA
Tel: [phone], FAX: [phone]
www.grandstream.com
Last updated on April 1, 2008
1

GXV3000 IP Video Phone Quick Installation Guide
WARNING: Please DO NOT power cycle the GXV when LED lights are flashing during system boot
up or firmware upgrade. You may corrupt firmware images and cause the unit to malfunction.
WARNING: Use only the power adapter included in the GXV package. Using an alternative
non-qualified power adapter may possibly damage the unit.
Overview
The GXV3000 IP Video Phone is a next generation IP video phone based on SIP standard and
H.264/H.263/H.263+ video codec, the codec of choice for high-quality video. The GXV3000 supports
real-time (up to 30fps) high-quality video at very modest bandwidth level (as low as 32kbps, up to 1Mbps).
The phone allows nearly all viewing angles via a large 5.6 inch TFTP adjustable LCD screen and a VGA
camera, delivering a high quality visual communication experience.
Equipment Packaging
Unpack and check all accessories
1. One GXV3000 Main Case
2. One Handset
3. One Phone Cord
4. One Universal Power Adaptor
5. One Ethernet Cable
6. Two Wall Mount Sustaining Brackets
7. Quick Installation Guide
Connect the GXV3000 Video Phone
Please use the equipment included in the packaging. Using any other power source may damage the
product.
1. Connect the handset and main phone case with the phone cord.
2. Connect the LAN port of the phone to the RJ-45 socket of a hub/switch or a router (LAN side of the
router) using the Ethernet cable.
3. Connect the 12V DC output plug to the power jack on the phone; plug the power adapter into an
electrical outlet.
4. The LCD will display provisioning or firmware upgrade information. Before continuing, wait for the
date/time display to show up.
5. Using the phone embedded web server or keypad configuration menu, you can further configure the
phone using either a static IP or DHCP.
Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA
Tel: [phone], FAX: [phone]
www.grandstream.com
Last updated on April 1, 2008
2

Configuring the GXV3000 using a Web Browser
1. If DHCP is enabled in your network, the phone’s IP address will be displayed.
2. Type the phone’s IP address in your PC browser.
3. The default administrator password is “admin”; the default end-user password is “123”.
You will need the following information to configure the GXV via the web browser:
1. IP address, subnet mask and gateway IP if using static IP.
2. SIP server and/or Outbound Proxy FQDN or IP address.
3. User subscriber information: User ID, Authentication ID, Password (provided by your VoIP service
provider).
4. GXV3000 supports “Plug-n-Call” if your ITSP (Internet Telephony Service Provider) provides this automatic
provisioning service. Ensure the phone has an internet connection (either DHCP or static IP in your internet
ready network), then power up the phone.
5. Please contact your ITSP for additional settings that may be necessary to configure the phone.
Configure the GXV using the Keypad
1. Make sure the phone is idle.
2. Press the “OK” button to enter the keypad MENU to configure the phone.
3. Follow MENU options to configure the basic features of the phone – for example: the IP address if
using a static IP. For details, please check GXP Series User Manual.
Using the Keypad
1. To select/confirm a selection on the LCD, press the OK key.
2. To browse the menu on the LCD, use the UP and DOWN arrow keys.
3. To select an input, uses the LEFT and RIGHT arrow keys to move the cursor then select input.
4. To delete a selection, move the cursor to the appropriate selection then use the MUTE/DEL key.
GXV3000 Quick Key Pad Configuration Menu
Config
Displays configuration sub-menu, such as Network, SIP
account, audio/Video codec, Upgrade, Factory Reset.
Phone Book Displays the phonebook information.
Call History Displays histories of incoming, dialed and missed calls.
Web Browser Start general purpose HTML web browser.
RTSP Video Streaming Start RTSP video streaming.
Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA
Tel: [phone], FAX: [phone]
www.grandstream.com
Last updated on April 1, 2008
3

Direct IP call Displays the IP-call options menu.
Preference
Displays user preference sub-menu, like ring tone, ring
volume, customized XML idle screen or logo
Status
Displays the network status, account statuses, software
version and MAC-address of the phone.
Turn Off LCD Turns off LCD display.
Factory Functions Extra diagnostic tools reside here.
Reboot Makes the phone reboot itself.
About Displays product information.
Exit Exit from this menu.
Grandstream Networks, Inc. Corporate Headquarters
www.grandstream.com
[e-mail]
1297 Beacon Street, 2nd Floor,
Brookline, MA USA 02446
Tel : [phone] – 9300
Fax: [phone] – 1987
About Grandstream Networks
Grandstream Networks, Inc. is an award-winning designer and manufacturer of next generation IP voice & video
products for broadband networks. Grandstream’s products deliver superb sound and picture quality, rich telephony
features, full compliance with industry standards, and broad interoperability with most service providers and 3rd
party SIP based VoIP products. Grandstream is consistently recognized in the VoIP industry for their innovation,
affordability and superior value in their products. Grandstream Networks is a private company headquartered in
Brookline, MA with offices in Los Angeles, Dallas and China. For more information, please visit
www.grandstream.com.
Declaration of Conformity for GXV3000
Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA
Tel: [phone], FAX: [phone]
www.grandstream.com
Last updated on April 1, 2008
4

Konformitätserklärung gemäß dem Gesetz über Funkanlagen und
Telekommunikationsendeinrichtungen (FTEG) und der Richtlinie 1999/5/EG (R&TTE)
Declaration of Conformity in accordance with the Radio and Telecommunications Terminal
Equipment Act (FTEG) and Directive 1999/5/EC (R&TTE Directive)
Hersteller /Verantwortliche Person / The manufacturer / responsible person
Manufacturer: Grandstream Networks, Inc.
5th Floor, R2-A Building,
South District of Hi-Tech Industrial Park,
Shenzhen, P.R.China, P.C. 518057
Responsible Laboratory: Bay Area Compliance Lab Corp. ShenZhen
Suite C, 41-D Electronics Science & Technology Building,
No. 2070 Shennanzhong Rd ShenZhen,
Guandong 518031, P.R. China
Tel: [phone]
Fax: [phone]
erklärt, dass das Produkt/ declares that the product:
Series: GXV 3000
Model: GXV 3000
Attestation Number: RSZ06030301-1, RSZ06030301-2
Date of Issue: March 29, 2005
Type (ggf. Anlagenkonfiguration mit Angabe der Module):
Type (if applicable, configuration including the modules)
[X] Telekommunikations(Tk-)endeinrichtung [ ] Funkanlage
Telecommunications terminal equipment Radio equipment
Telecommunication via Voice over IP (VoIP) ............................................
Verwendungszweck Geräteklasse
Intended purpose Equipment class
bei bestimmungsgemäßer Verwendung den grundlegenden Anforderungen des § 3 und den
übrigen einschlägigen Bestimmungen des FTEG (Artikel 3 der R&TTE) entspricht.
complies with the essential requirements of §3 and the other relevant provisions of the FTEG
(Article 3 of the R&TTE Directive), when used for its intended purpose.
Gesundheit und Sicherheit gemäß § 3 (1) 1. (Artikel 3 (1) a))
Health and safety requirements pursuant to § 3 (1) 1. (Article 3(1) a))
Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA
Tel: [phone], FAX: [phone]
angewendete harmonisierte Normen ... Einhaltung der grundlegenden Anforderungen auf
www.grandstream.com
Last updated on April 1, 2008
5

Harmonised standards applied... andere Art und Weise (hierzu verwendete
Standards/Spezifikationen) ...
Other means of proving conformity with the
essential requirements (standards/specifications
used)...
Schutzanforderungen in Bezug auf die elektromagn. Verträglichkeit § 3 (1) 2, Artikel 3 (1) b))
Protection requirements concerning electromagnetic compatibility § 3(1)(2), (Article 3(1)(b))
angewendete harmonisierte Normen Einhaltung der grundlegenden
Harmonised standards applied... Anforderungen auf andere Art und Weise
(hierzu verwendete
EN 55022: 1998+A1: 2000+A2: 2003 Standards/Spezifikationen)...
EN 55024: 1998 +A1:2001 + A2: 2003 Other means of proving conformity with the
essential requirements
(standards/specifications used)...
Maßnahmen zur effizienten Nutzung des Funkfrequenzspektrums
Measures for the efficient use of the radio frequency spectrum
Non-applicable
Luftschnittstelle bei § 3 Funkanlagen gemäß (2) (Artikel 3(2))
Air interface of the radio systems pursuant to § 3(2) (Article 3(2))
angewendete harmonisierte Normen Einhaltung der grundlegenden Anforderungen auf
Harmonised standards applied andere Art und Weise (hierzu verwendete Standards/
Schnittstellenbeschreibungen)...
Non-applicable Other means of proving conformity with the essential
requirements (standards/interface specifications used)...
Anschrift/Address
Grandstream Networks, Inc.
1297 Beacon St 2nd Flr
Brookline, MA 02446 USA
+ TK-Nr./Phone, fax, e-mail
Tel: [phone] x 804
Fax: [phone]
[email protected]
Ort, Datum Name und Unterschrift
Place & date of issue Name and signature
Grandstream Networks, Inc., 1297 Beacon St., 2nd Flr, Brookline, MA 02446 USA
Tel: [phone], FAX: [phone]
Brookline, MA, USA August 20, 2007 Bruce G. MacAloney, Vice President
