GRAUPNER 2201 User manual

72 ft Yacht
Order No.: 2201

2
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Table of contents
Foreword....................................................................................................................................2
Model summary description........................................................................................................3
Intended usage ..........................................................................................................................4
Symbols and their meanings ......................................................................................................4
Warning and safety notices ........................................................................................................4
Conformity declaration................................................................................................................7
Environmental protection notices................................................................................................8
Graupner GmbH & Co KG manufacturer's declaration ...............................................................8
Assembly instructions...............................................................................................................10
Foreword
Thank you for choosing to purchase the Graupner model "72 ft Yacht", order no. 2201. Graupner
models stand for high quality. We pay great attention to stability at the key points in series
production. Due to extensive prefabrication, including motor and rudder system, as well as the high
degree of detail made possible by the CNC processing, this model replicates the original yacht very
closely.
It is quite important that these instructions are read completely prior to assembly and
first-time use of the model. The safety rules stated in these instructions must be
followed during trial runs as well as initial use and thereafter.

3
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Model summary description
This 72 ft yacht the result of a yacht study made by the Munich designer Jochen Kinder. It
was introduced in 2012 at the yacht exhibition in Dubai. J. Kinder Designs has been
successfully designing high-tech products for the international maritime market as well as
premium consumer products for over 25 years.
•This is one of the models in the GRAUPNER PREMIUM product line series, the series of
particularly high quality finished models offering a degree of detail previously unachieved
on the market.
•In order to achieve such high-quality results, the hull is made of stable GRP material, the
superstructure and deck are made of laser-formed ABS parts and many small parts made
of metal are already attached. The hull, superstructure parts, the masts and fittings are
spray painted and the decorative items are attached. Thanks to its many details and
fitting parts, this model gives a particularly authentic impression of the original.
•Installation of the RC components is made simple by the generously sized openings in
the deck. Their installation can be accomplished quickly. Only the installation of the RC
components and rechargeable battery as well as some minor soldering work are
necessary to make the model operable.
Technical data
Length, about 1007 mm
Breath, about 270 mm
Total height, about 500 mm
Total weight, about 7 kg
Scale, about 1:20
•Delivered items: GRP hull, deck, superstructure parts and ship stand made of laser-
formed ABS, railing and other small parts made of metal, two motors, rudder system, pre-
attached trim decals, instructions in German, English and French.

4
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Intended usage
This model is designed to be a ship model for operation on bodies of water which meet the
stipulations described in these instructions and is only suitable for this purpose. No
guarantee or liability is accepted for any improper handling outside the scope of these
stipulations.
Symbols and their meanings
Attention!
This symbol calls attention to the injury risks associated with operating a propeller which must absolutely be observed
by the user! Any disregard for the adjacent notices can lead to severe injuries for the operator.
Attention!
This symbol calls attention to the injury risks associated with operating a propeller which must absolutely be observed
by the user! Any disregard for the adjacent notices can lead to imbalance of the propeller, can severely damage the
model and can produce most severe injuries for persons in the vicinity as a consequence of hurled parts.
Attention!
This symbol calls attention to the following notices which must absolutely be observed by the user! Any disregard for
the adjacent notices can impair safe operation and even endanger the operator.
Attention!
This symbol calls attention to bans which must absolutely be observed by the user! Any disregard for the adjacent bans
can impair the model's functionality and endanger the operator.
This symbol calls attention to notices which must absolutely be observed by the operator to ensure safe operation of a
device.
This symbol calls attention to notices about care of the model which must absolutely be observed to ensure its long
service life.
Warning and safety notices
This is a model that – together with appropriate accessories – can become a functional RC model.
GRAUPNER cannot monitor adherence to the assembly and operating instructions for the model nor
can GRAUPNER supervise the installation, operation or maintenance of the model and its
components. Therefore GRAUPNER accepts no liability whatsoever for losses, damage or costs that
arise from improper operation, improper behavior or which are associated with same in any manner.
Unless mandated by prevailing law, the obligation of the GRAUPNER company to provide damage
compensation arising from the use of the model, regardless of the grounds, is excluded (this
exclusion includes personal injury, death, damage to buildings or structures as well as sales and
business losses, consequential damage for business interruption or other direct and indirect
consequential damages).
Total liability under all circumstances and in each case is limited to the amount actually paid for this
model.

5
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Attention!
Never reach into a running propeller or attempt to hold the propeller by hand when it is operating. This leads to hand
injuries. Rotational forces can readily cause the propeller to get out of control.
Attention!
Never put objects/foreign materials into a running propeller. Always ensure that objects/foreign materials cannot get
into the propeller when it is running. If this does happen, the propeller's sudden imbalance can cause heavy damage to
the model. Persons in the vicinity can be severely injured by parts hurled through the air.
Attention!
Never dwell in front or back of a propeller. Improper assembly or unforeseen circumstances can cause the propeller to
come off of its shaft. Stop the propeller if unusual noises are heard.
Attention!
The propeller must be securely attached. Do not direct the propeller toward persons or animals, do not test the
propeller in the hand. Never dwell in front of a propeller. Unforeseen circumstances can cause the propeller to come off
of its shaft. Persons in the vicinity can be severely injured by parts hurled through the air.
Attention!
Do not touch any part of the drive train (i.e. motor + propeller + shaft) while it is operating as this can lead to injuries.
Allow the motor, shaft, regulator and battery time to cool off after operation before touching any of these parts!
Warning!
Operating the model while under the influence of medication, alcohol, drugs, etc. is forbidden.
Attention!
Ensure that the operation of model boats is permitted on the given body of water.
Attention!
The operator of a model ship must be aware of the legal stipulations before putting a model ship into operation because
a model ship is subject to applicable laws. Applicable laws are always to be followed in every case. In this respect, pay
attention to the laws applicable in the given country. Before operating the model for the first time, check if your private
liability insurance provides coverage for model ships of this type. If this is not the case, obtain special liability insurance
coverage for RC models.
Warning!
Any deviation from the model's instructions can have an effect on the model's functionality and operational safety. This
must be avoided under all circumstances.
Warning!
The model has been designed for operation on water and is only suitable for this purpose. Any other use can lead to
property damage and/or personal injuries. You are responsible for safe operation of the model and the safety of other
persons and animals.
Attention!
The model may only be operated with accessories which we recommend as otherwise functionality cannot be
guaranteed.
Attention!
The commissioning and operation of the model is solely at the risk of the operator. Only cautious, considered handling
during operation of the model will prevent personal injuries and property damage.
Attention!
This model is not suitable for children under 14 years of age.
Attention!
Protruding model parts can be sharp and the antennas and masts can cause eye injuries.
Attention!
Pay attention to the potential dangers associated with the tools that are used.

6
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Attention!
Never operate the model in saltwater.
Attention!
Never operate the model when persons or animals are in the water! Persons and animals are exposed to substantial
injury hazards due to this model's relatively high speed capability.
Attention!
Do not operate the model in nature reserves, landscape protection areas or water conservation areas. Ask local
authorities about the water bodies where operating model ships is permitted.
Attention!
Never operate the model in adverse weather conditions like rain, storms, strong wind, high waves or strong water
currents.
Attention!
Comply with the recommendations and notices associated with the remote control set and accessories.
Attention!
Check the model for reliable response to the remote control unit and all plug-in connections for secure connection
before operating the model.
Attention!
Never attempt to recharge any primary cell batteries used as a power supply. Only secondary cell batteries (i.e.
rechargeable) may be charged.
Attention!
The remote control unit's effective range must be checked prior to operation of the model. To check this, switch the
model on then walk with it away from the transmitter as far as about 100 m while a helper operates various controls on
the transmitter. All model functions must be performed by the model to successfully complete this check.
Attention!
Check if the radio channel to be used is free. Never operate the model if it is not sure that the radio channel is free.
Attention!
Pay attention to radio devices or transmitters which could substantially affect the model's functionality. Try to ensure
that such devices are not operated in the vicinity while the model is being operated.
Attention!
Do not exceed the recommended power supply voltage. Higher voltage can lead to motor and/or speed regulator
overheating or melt wiring conductors. This can destroy the model.
Attention!
Pay attention to the smooth, free movement of all drive components. This is particularly applicable while the model is
operating because leaves and other materials in the water can get caught up in drive components. If this should happen,
the motors and/or speed regulator can be destroyed by overload conditions.
Attention!
Batteries must never be short-circuited or come into direct contact with water.
Attention!
Never operate the model on strongly moving water (e.g. a river) as the model may drift away if it becomes disabled.
Attention!
Never endanger yourself or others in an attempt to recover the model.

7
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Notice!
Remove the battery/batteries from the model when it is not in use.
Notice!
Do not expose the model to strong humidity, hot or cold temperatures or contamination.
Notice!
Do not expose the model for extended periods to strong sunlight or the radiating heat of hot lamps. The different
expansion coefficients of the hull and wooden deck materials can cause cracks.
Notice!
Protect the model and transmitter against damage or slipping while they are being transported.
Notice!
Pay particular attention to the model's water-tightness. A model boat will sink if it takes on too much water. Prior to
every use, check the model for any damage and also ensure the hull is watertight where drive shafts and rudder control
shafts penetrate the hull.
Notice!
Let the model dry off good after it is used.
Notice!
Be sure to check the water-tightness of shaft penetrations through the hull several times during the model's maiden
voyage. If water is intruding, remove the shafts and lubricate the stern tube with sufficient grease (order no. 570).
Notice!
The electric motors built into the model may not be thrown away along with household waste. They must be removed
and turned in at an appropriate disposal facility.
Notice!
If batteries are connected in parallel they may only be so connected when the model is operated as otherwise reciprocal
effects could take place between the batteries and cause them damage. Therefore, connect batteries only just before
running the model and disconnect them again afterward. Batteries must never be stored with connected parallel wiring.
Care!
Clean the model after every use. Remove any water which may have intruded. If water has gotten into RC components,
lay them out to dry then send them to the responsible GRAUPNER service center for inspection.
Care!
Clean the model and transmitter only with suitable cleaning materials. A lint-free cloth is suitable. Never use chemical
cleaning agents, solvents, gasoline, spirits or similar.
Care!
After operating the mode, lubricate drive shafts with a small drop of oil on the bearings. The outer shaft bearings for the
propellers must also be lubricated. To lubricate the drives, use only oil which does not contaminate or pollute water
(e.g. order no. 206). At the end of the operating season, the shafts should be removed and lubricated anew with a
water-neutral grease (e.g. order no. 570).
Declaration of Conformity
CE - Guidelines
The described products meet applicable and mandatory EU directives.

8
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Environmental protection notices
The symbol on this product, its operating instructions or packaging gives notice that this product may not be discarded as
common household waste at the end of its service life. It must be turned over to a recycling collection point for electric and
electronic apparatus.
The materials can be recycled according to their markings. You make an important contribution to protection of the environment by
utilizing facilities for reuse, material recycling or other means of exploiting obsolete equipment.
Batteries must be removed from the unit and disposed of separately at an appropriate collection point. Please inquire with local authorities
about the responsible waste collection locations.
Graupner GmbH & Co KG manufacturer's declaration
Content of the manufacturer declaration
If there should be an evident material or processing defect in one of the objects marketed in the
Federal Republic of Germany and purchased by a consumer (§ 13 BGB) we, the company Graupner
GmbH & Co KG, Kirchheim/Teck, accept responsibility for eliminating the object's defect within the
scope as specified below.
The rights acquired through this manufacturer declaration cannot be asserted by the consumer when
the object's usage impairment is due to natural wear, use under competitive conditions, improper
usage (including improper installation), or external causes.
This manufacturer declaration leaves the legal or contractual provisions for defect claims and the
consumer's rights in the purchase contract with respect to the seller (dealer) unaffected.
Scope of guarantee performance
In the event of a guarantee claim, we reserve the right to choose between a repair or the
replacement of defective goods. Further reaching claims, in particular claims for compensation of
costs in conjunction with the defect (e.g. assembly/disassembly costs) and remuneration for
consequential damages – when legally permitted – are excluded. Claims based on legal regulations,
in particular those associated with product liability law, are unaffected by this.
Prerequisite to guarantee performance
The purchaser must assert claim for guarantee performance in writing, which is to be accompanied
by the original purchase receipt (e.g. invoice, receipt, delivery note) and this guarantee card. The
purchaser must also return the defective goods to the following address at his/her own cost.
Fa. Graupner GmbH & CO KG, Service Department,
Henriettenstr. 94 -96, 73230 Kirchheim/Teck, Germany
The purchaser is to state in the claim the nature of the material or processing defect or the defect's
symptoms specifically enough that a review of our guarantee obligation is possible.

9
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
The transportation of the object from purchaser to us as well as return transportation is at the risk of
the purchaser.
Period of validity
This declaration is only valid during the entitlement period for making claims as stipulated by this
declaration. The entitlement period is 24 months from the item's date of purchase by the consumer
from a dealer in the Federal Republic of Germany (purchase date). If claims are made for defects
after expiration of the entitlement period or the defects in the claim are not substantiated as
required by this declaration or documents are only submitted after expiration of the entitlement
period, then the purchaser is not entitled to rights or claims under this declaration.
Limitation period
To the extent we do not acknowledge liability for a properly submitted claim as specified by this
declaration within the entitlement period, all rights of this declaration have a 6 month period of
limitation from the point in time of claim submission but not earlier than the end of the entitlement
period.
Applicable law
This declaration and all claims, rights and obligations arising therefrom are governed exclusively by
German substantive law without the norms of international private law and under exclusion of
applicability for the UN Convention on the International Sales of Goods.

10
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Assembly instructions
•Unpack the model and the ship's stand carefully.
•To open the model, carefully lift its superstructure upward.
IMPORTANT: The superstructure has many parts that can be damaged when the
superstructure is lifted off so be sure to take the superstructure off carefully. NOTICE: At the end
of these instructions there is a detail picture of the assembled model. That picture can be used as
an orientation aid during assembly.
•The superstructure of the 72 ft Yacht is a single piece and can be removed completely. The
superstructure must be removed to perform maintenance and install RC components.

11
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
•Solder a G3.5 plug onto the regulator's leads (+ is red, - is black). Check the direction of the
motor's rotation when the battery is
connected. The ship's screw should turn in the
direction that would propel the model
forward. NOTICE: The G3.5 connector system is
designed such that the size of the plastic housing
dictates the polarity of connections. When one
complies consistently with this scheme, the
batteries and regulator are exchangeable and
reversed polarity conditions are prevented by this connector system. Follow one of the following
tips to make soldering of the connector pins easier. These tips also reduce the chances of
damaging model details during the soldering process. TIP 1: Remove the regulator. Do this by
disconnecting all connectors. Reassembly is done in exactly the reverse order. TIPP 2: With the
help of a so-called "third hand", the connector can be soldered right next to the model (see
photo).
•Check the screws on the shaft coupling and the propeller to be seated securely (if not already
done) as these could have been loosened during the transport. This can be checked by pulling on
the propeller. If the shaft can be pulled toward the rear then one of the set screws is loose.
Tighten down a loose screw carefully. First remove the superstructure so the stud screw
becomes accessible. NOTICE: Secure a stud screw that has become loose with screw lock lacquer,
e.g. UHU thread-lock fluid (order no. 952), because otherwise vibration could cause it to become
loose again during operation.
•Attach the speed regulator and receiver into the hull with a strip of Velcro or double-sided
adhesive tape.
•Connect the servo and the regulator to the receiver. Use cable ties or adhesive tape to fasten the
cables in place in the hull.
•Route the antenna in the hull near the deck opening and fasten it in place with adhesive tape.
IMPORTANT: To assure good reception, the antenna must be routed as close as
possible to the hull's rim! The GRP hull diminishes reception only very little.

12
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
•Plug in the battery to the speed regulator. Lay the batteries into the model and test the RC
system's functions. It is absolutely necessary to fix the batteries in place so they cannot slide
about while operating the model. Attach a strip of Velcro to each battery and the
complementary strip onto the hull to hold the batteries securely in place.
ATTENTION: Be sure to secure the cover good as otherwise water may intrude into
the model and do irreparable damage or even cause loss of the model.
•Put the superstructure back onto the hull.

13
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
Maiden voyage
Charge all batteries and test the model's functions. Check if all plug-on parts are securely seated.
Now the maiden voyage can begin. Take it easy during the maiden voyage. Take the time to become
familiar with the model's maneuvering behavior. This model travels quite fast, has a large turning
radius and a long braking distance. Therefore it should be operated in a body of water with an
adequate surface area. Do not maneuver too far away from the shoreline.
Now have a lot of fun with your model 72 ft Yacht.
Also necessary (but not in the delivered items)
Order no. Designation
33112 MX-12 COMPUTER SYSTEM GRAUPNER HoTT, 6 channels
9733.3 LiPo battery V-MAXX45C 3/3300 11.1 V G3.5
2970 Plug G3.5 gold-plated (2 pcs.)
2969.K Housing G 3.5
7195 Regulator, VariateurProfi V80R
Order no. 3368 Hook- and loop ribbon (Velcro)

14
GRAUPNER GmbH & Co. KG D-73230 KIRCHHEIM/TECK GERMANY
No liability for printing errors. Technical changes reserved! 03/2012
