GRAVOGRAPH LS100 IQ Operating instructions

OPERATING AND MAINTENANCE MANUAL
LS100 IQ - LS100 EX -
LS100 ENERGY
LS100 EX ENERGY
ENGRAVING LASER / CUTTING LASER
M_LS100IQ EX Energy_EN_C - Last updated: 01/2018 - Translation of the French original document

Table of contents
M_LS100IQ EX Energy_EN_C 2
A. Foreword ...................................................................................................................................................6
1. Appreciation ...........................................................................................................................................6
2. Information .............................................................................................................................................6
B. Legal notices ............................................................................................................................................7
C. Regulation observance ............................................................................................................................8
D. Required safety labels .............................................................................................................................9
E. Introduction ............................................................................................................................................11
1. Presentation .........................................................................................................................................11
2. Identi󰘰cationofthemarkingequipment................................................................................................11
3. Workstationsafety...............................................................................................................................11
Air extraction system .........................................................................................................................11
Water chiller - only for ENERGY machines .......................................................................................12
Handling the machine ........................................................................................................................13
F. Unpacking ...............................................................................................................................................14
1. Unpacking ............................................................................................................................................14
2. Packagecontents.................................................................................................................................16
Packagecontents-Machine .............................................................................................................16
Toolbox: Content ...............................................................................................................................16
Packagecontents-Waterchiller-onlyforENERGYmachines .......................................................17
Cardboard box: Content - only for ENERGY machines .....................................................................17
G. Laser safety ............................................................................................................................................18
1. Recommendations and safety regarding laser devices ........................................................................18
Personnel safety ................................................................................................................................18
2. Workstationsafety...............................................................................................................................19
Proposed warning label at the entrance to the laser controlled zone ................................................19
General Instructions ...........................................................................................................................20
Wearing safety glasses ......................................................................................................................20
3. optical components ..............................................................................................................................21
Safety precautions .............................................................................................................................21
Protective measures in the event of thermal decomposition or scored or scratched lenses .............21
Protectivemeasuresintheeventofabrokenlens............................................................................21
Arrangements for disposal .................................................................................................................22
4. Potentialhazardsrelatedtomaterialsworkedwith..............................................................................23
Fumes and toxic particles ..................................................................................................................23
Examplesofsecondaryradiationrisks ..............................................................................................24

M_LS100IQ EX Energy_EN_C 3
5. High voltage safety - (only for ENERGY machines)..............................................................................24
H. Description of the machine ...................................................................................................................25
1. Front view of the machine ....................................................................................................................25
Engraving table ..................................................................................................................................25
2. Rear view of the machine .....................................................................................................................26
3. Water chiller (only for ENERGY machines)...........................................................................................27
Front view ..........................................................................................................................................27
Rear view ...........................................................................................................................................27
I. Recommendations for installation .......................................................................................................28
1. Physical installation ..............................................................................................................................28
2. Water chiller (only for ENERGY machines)...........................................................................................29
3. Air extraction system (optional) ............................................................................................................29
4. Air assist (option: Air compressor) ........................................................................................................30
5. ITrequirements ....................................................................................................................................31
6. Software compatibility ..........................................................................................................................31
7. Connecting/disconnectingthewaterchiller-Fillingthetank(onlyforENERGYmachines).................32
Initial installation (if necessary)...........................................................................................................32
Fillingthetank....................................................................................................................................33
Disconnecting the water chiller (shipping position).............................................................................34
8. Electrical installation .............................................................................................................................35
J. Connections - Installation .....................................................................................................................36
1. Power supply connection Water chiller (only for ENERGY machines)..................................................36
Switching on the chiller ......................................................................................................................36
Resolution of the problems: Water chiller ..........................................................................................37
K. Connections - Installation .....................................................................................................................38
1. Power supply connection - Machine .....................................................................................................38
Using the PLC function (User standard inputs/outputs)......................................................................39
Switching on the machine ..................................................................................................................42
Resolution of the problems ................................................................................................................42
Power down: Machine - Water chiller ................................................................................................43
Restarting ..........................................................................................................................................43
2. Machine / PC connection .....................................................................................................................44
Machine / PC connection (USB connection).......................................................................................44
L. Operating instructions for the machine ...............................................................................................45
1. Control panel ........................................................................................................................................45
Indicator light(s) .................................................................................................................................47
2. Description of the human-machine interface ........................................................................................47
Joystick ..............................................................................................................................................47
Accesstothedi󰘯erentmenus ...........................................................................................................48

M_LS100IQ EX Energy_EN_C 4
3. Control panel: Water chiller (only for ENERGY machines)...................................................................49
Reset .................................................................................................................................................49
Temperature alarm function ...............................................................................................................50
Flow alarm function ............................................................................................................................50
General parameters ...........................................................................................................................50
Advanced parameters ........................................................................................................................52
M. Using the machine .................................................................................................................................53
1. Switching on the PC / Switching on the machine .................................................................................53
2. Creating the composition ......................................................................................................................53
3. Setting the driver properties .................................................................................................................53
4. Transferringthe󰘰le ..............................................................................................................................54
5. Positioning the object to be engraved ..................................................................................................54
6. Focusing ...............................................................................................................................................54
Autofocus ...........................................................................................................................................54
7. Start-up engraving ................................................................................................................................55
8. Removing and reloading material .........................................................................................................55
N. Adaptable accessories ..........................................................................................................................56
1. Cylinder attachment .............................................................................................................................56
2. Cuttingoutkit .......................................................................................................................................56
3. Compressorkit(Airassist) ....................................................................................................................57
4. Honeycomb cutting table ......................................................................................................................57
O. Preventive maintenance ........................................................................................................................58
1. General maintenance ...........................................................................................................................58
2. Accessories provided ...........................................................................................................................58
3. Cleaning the system .............................................................................................................................59
Engraving table ..................................................................................................................................59
Guides/belts .......................................................................................................................................59
Fume extraction outlets .....................................................................................................................59
4. Optics maintenance ..............................................................................................................................60
Mirror(s) / Lens(es) ............................................................................................................................60
5. Removing and cleaning the Z Auto sensor ..........................................................................................61
6. Autofocus adjustment ...........................................................................................................................62
7. Setting point zero (Origin) .....................................................................................................................65
P. Technicalspeci󰄈cations........................................................................................................................ 66
1. Physical characteristics - LS100 IQ / LS100 ENERGY.........................................................................66
2. Physical characteristics - LS100 EX / LS100 EX ENERGY..................................................................66
3. Engraving characteristics .....................................................................................................................67
4. Noise emission of the machine (ISO 11201 standard)..........................................................................67
5. Environment .........................................................................................................................................67
6. Laser characteristics ............................................................................................................................67
7. Electrical characteristics .......................................................................................................................68
8. Connections and cabling ......................................................................................................................68

M_LS100IQ EX Energy_EN_C 5
9. Firmware characteristics - driver ..........................................................................................................68
10.Characteristics of the water chiller (only for ENERGY machines).........................................................69
Q. Appendix: Engraving menu ................................................................................................................... 70
1. "Parameters" sub-menu .......................................................................................................................71
2. "File" sub-menu ....................................................................................................................................71
3. "Info" sub-menu ....................................................................................................................................71
4. "Con󰘰guration"sub-menu ....................................................................................................................71

M_LS100IQ EX Energy_EN_C 6
A. Foreword
1. Appreciation
ThankyouforchoosingLS100IQEXEnergy-Gravograph.
Gravotech is pleased to count you among the users of its engraving and traceability solutions.
For help, contact Gravotech.
For more information on products, visit www.gravograph.com website.
2. Information
To ensure security and productivity, read this manual before starting-up the equipment.
It provides details about the installation and use of the equipment.
Keep this manual in case you need to refer to it.
Fortheattentionofusershavinganindividualcardiacassistdevice󰄈tted:
Our equipment is designed and manufactured with the greatest care in order to
guarantee their compliance with the EMC Directive currently in force. This means
that the levels of electromagnetic emissions produced by this equipment when in
operationarelimitedanddonotexceedthethresholdsde󰄈nedbytheDirective.
However, multiple factors make it impossible to guarantee the total absence of risk
forusershavingacardiacassistdevice󰄈tted.Consequently,itisrecommendedthat
standing for a prolonged period within less than 1 m (3.281 ft) of an operating machine
should be avoided.

M_LS100IQ EX Energy_EN_C 7
B. Legal notices
Last updated: 10/15
The purpose of this document is to provide users (hereinafter the User(s)) with information and to ensure their safety. It has no contractual
value and Gravotech group (hereinafter Gravotech) reserves the right, at any time and without notice, to make such changes or
improvementsasitdeems󰘰ts,ortosubstituteanynewequipmentand/ormaterialand/orpartand/orimagetoitsequipment,software
and/or associated manuals or documentation (hereinafter the Product(s)).
This manual, including texts, images, photos, graphics, design, or any compilation, digital conversion or data contained in it, is subject to
copyright. This manual shall not be reproduced, disseminated, transmitted, transcribed, translated or stored electronically, on any medium
whatsoeverregardlessofitsformatwithouttheexpressandwrittenpermissionofGravotech,totheexceptionofsoftwarebackupcopies
as provided by law.
TheintellectualpropertyrightsrelatingtotheProductsandtothismanual,including-butnotlimitedto-patents,trademarks,models,
copyright, domain names and also the know-how, trading name or company name, are owned by Gravotech Marking S.A.S or any
company of the Gravotech group. Under no circumstances does the transmission of this manual or the supply of Products or services
constitute an assignment of or any express or tacit license for any intellectual property right owned by Gravotech.
To the extent permitted by law, Gravotech provides hereby no warranty (in particular no warranties of performance, non-infringement,
merchantabilityor 󰘰tnessfor aparticularpurpose)relating tothesupplyofitsProducts,otherthanthoseconferredupontheUserby
Gravotech's general terms and conditions of sale or any contractual document agreed between Gravotech and the User. Nor does
Gravotechguaranteethecompatibilityofitssoftwarewithanysoftwarepackagenotsuppliedbyit,oranydefectinassembly,adaptation,
design, compatibility and operation with any or part of a combination created by the User.
Gravotech shall not be liable for any damages, that the User or its property, a third party or the Product itself may su󰘯er, caused
bytheProductandarisingfromanyinappropriateuseormisuseoftheProduct,negligence,carelessness,inadequatesupervisionor
maintenance, failure to observe the safety or usage instructions described herein or otherwise communicated to the User, the use of poor-
qualityornon-recommendedlubricants,󰘱uidsandadditivesorwherethereisfaultonthepartoftheUserorathirdparty.Asprovidedin
this manual, the User shall furthermore (i) observe the normal conditions of use, (ii) not exceed the recommended maximum number of
hoursduringwhichtheequipmentmaybeoperatedonand(iii)refrainfromproceedingtoanyProduct'srepairormakeitproceedbyany
unquali󰘰edthirdparty,orwithouttheappropriatepersonalprotectiveequipment.
TheProduct'sspeci󰘰cationsarealteredby(i)anyProduct'smodi󰘰cationoralteration,(ii)anyadaptationandinstallationofaccessories
that are not recommended by Gravotech, (iii) the integration of a control system and (iv) the connection to an external device. Such
speci󰘰cations' alterations may lead to the non-compliance of the Product with applicable rules and standards. Shall the Product be
non-compliant,thepersoninchargeoftheProduct'sinstallationshallberesponsibleofthe󰘰nalworkstation'scompliance.Innoevent,
Gravotech shall be liable for any damages arising from such non-recommended or unauthorized Product's alterations. It is precised that
the warranty shall not apply in such case.
UndernocircumstancesshallGravotechbeheldliableforanyindirect,incidental,special,consequentialpunitiveorothersimilardamages,
includinganyeconomicloss,lossofpro󰘰t,lossofdataoropportunity,whetherornotforeseeablebyorcommunicatedtoGravotech,
caused by this manual or the supply of Products or services concerned by the said manual.
To the widest extent permitted by law, Gravotech shall only be held liable for direct damage arising from personal injury caused by a fault
proven in its Product (including this manual).
Gravotech®-Type3®-Propen™-Technifor™-Gravograph®is(are)aused,pendingorregisteredtrademark(s)ofGravotechgroupor
one of its subsidiaries.
The products and names of third party companies which appear in this manual are used solely for the necessary purposes of reference,
andinparticularforissuesofcompatibility.Allthetrademarksmentionedinthismanualremainthepropertyoftheirrespectiveowners.
Windows®is(are)aused,pendingorregisteredtrademark(s)ofMicrosoftCorporation.Postscript®is(are)aused,pendingorregistered
trademark(s)ofAdobeSystemsIncorporated.

M_LS100IQ EX Energy_EN_C 8
Last updated: 12/2017
EC declaration of conformity or declaration of incorporation supplied with the machinery
Type of machine Directives - Standards
Dotpeenmarking:Machine
XF500p, XF500m, Impact p, Impact eZ p, Impact m, Impact eZ m
P5000PN, P5000EM
Scribingmarking:Machine
M10 Jewel, M20 Pix, B-Engraver
RingCube, TagCube
Sharpening by grinding: Machine
CG30
Bevelling: Machine
B4, B6
Engraving by milling: Machine
IM3
M20, M20 Jewel, M20 ABC, M20 Pen, M20 Energy, M20 Beauty Cube
M40, M40G, M40 ABC
IS200, IS400, IS400 Volume
IS6000, IS7000, IS8000 - XP - XP Milling
Hot foil stamping: Machine
M20 Artfoil
Dotpeenmarking:Transportablemachinery-Partlycompletedmachinery
XF530p, XF530m, XE320Cp
Dotpeenmarking:Partlycompletedmachinery
XF510Cp-Sp-Dp, XF510Cm-Sm-Dm, XE310Cp-Sp
Scribingmarking:Partlycompletedmachinery
XF510Cr-Sr-Dr, SV510
CCU,Rack,TouchPad
UC500, UC500 SV, UC300, UC Laser
RacksIS
Laser fume extractor
ES10, ES20, ES30, ES40, ES50
LE120HP, LE140HP, LE150HP, LE190HP, LNI900
Accessory: Partly completed machinery
APF Rotary, APF Laser
PFD500
TAG3500
Cylinder attachment
DMC15, DMC25, DMC25PN, DP3500, DP4500, DP4500PN
RD1, RD2, RDM
- Low voltage: 2014/35/EU
- EMC: 2014/30/EU
- RoHS 2: 2011/65/EU
Dotpeenmarking:Portablemachine
XM700 - Low voltage: 2014/35/EU - EMC: 2014/30/EU
- RoHS 2: 2011/65/EU
- Cells and batteries: 2006/66/EC
CO2,Yagand󰘰berlasermarking:Machine(gantry)
LS100 Energy, LS100 Ex Energy, LS900 Energy
LS100, LS100 Ex, LS900, LS900 XP, LS1000XP
LS100 Ex Fibre, LS900 Fibre
LS900 Edge
CO2,Yagand󰘰berlasermarking:Machine(galvo)
LW1, LW2
Laser Solution Hybrid-Series (Energy), Laser Solution Green-Series
(Energy), Laser Solution CO2-Series (Energy)
- Machinery: 2006/42/EC
- Low voltage: 2014/35/EU
- EMC: 2014/30/EU
- RoHS 2: 2011/65/EU
-Safetyoflaserproducts-Part1:Equipmentclassi󰘰cationand
requirements:EN60825-1:2008
- Safety of laser products - Part 4: Laser guards: EN 60825-4+A1+A2:2006
CO2,Yagand󰘰berlasermarking:Partlycompletedmachinery(galvo)–
Class 4
Laser Solution Fiber-Series (Energy)
- Low voltage: 2014/35/EU
- EMC: 2014/30/EU
- RoHS 2: 2011/65/EU
-Safetyoflaserproducts-Part1:Equipmentclassi󰘰cationand
requirements:EN60825-1:2008
- Safety of laser products - Part 4: Laser guards: EN 60825-4+A1+A2:2006
C.Regulation observance

D. Requiredsafetylabels
Last updated: 12/2017
Required safety labels
Shared labels
Warning: Laser beam
Warning: Electricity
LS100
LS100 Ex
LS100 Energy
LS900
LS900 XP
LS1000 XP
Warning:
Flammable
materials
Warning: Hot
surface
LS100 Ex Fibre
LS900 Fibre
Warning:
Flammable
materials
Warning: Hot
surface
LS900 Edge
Laser Solution
Fiber-Series
(Energy)
Laser Solution
Hybrid-Series
(Energy)
Laser Solution
Green-Series
(Energy)
9
M_LS100IQ EX Energy_EN_C

Required safety labels
Laser Solution
CO2-Series
(Energy)
LW1 - LW2
(LaserTop 2000)
M_LS100IQ EX Energy_EN_C 10
Requiredsafetylabels

11
M_LS100IQ EX Energy_EN_C
E. Introduction
1. Presentation
TheLS100IQ/EXisanengraving,markingandcuttingmachineequippedwithaCO2lasersource.Thelaser
sources are air cooled.
TheLS100ENERGY/EXENERGYisanengraving,markingandcuttingmachineequippedwithaCO2laser
source with a high voltage supply and a water-cooled glass tube. A water chiller is supplied.
Thistypeoflasero󰘯ersveryhighqualitymarkingonawiderangeofmaterials.
2. Identi󰘰cationofthemarkingequipment
Themarkingequipmentisidenti󰘰edby:
• 1identi󰘰cationplateontherearface
HavethemodelandserialnumberoftheequipmentavailablewhencontactingGravotech.
3. Workstationsafety
• Turno󰘯themachinebeforebeginninganycleaning,maintenanceorrepairprocedure.
• Never operate the machine without the protective covers properly mounted.
• Never operate the machine if the doors are damaged or do not close properly.
Air extraction system
• Neveroperatethemachinewithoutafumeandgasextractionsystemthatisproperlycon󰄈gured,
installed and maintained in good working order.
• The gases and fumes from the marking process must be extracted from the machine and discharged
outside.

12
M_LS100IQ EX Energy_EN_C
Introduction
Water chiller - only for ENERGY machines
Never operate the LS100 ENERGY/EX ENERGY machine without a properly operating water
chillerthatiscorrectlycon󰄈gured,installedandmaintainedingoodworkingorder.
In order to protect the chiller pump, it is strictly prohibited to operate it without
demineralisedwaterinthetank.Toavoiddamagingthepump,itisimportantto󰄈llthe
tankbeforeusingitforthe󰄈rsttime.
• Itisimportanttocheckthatthedemineralisedwaterlevelisalwaysadequate.Coolingcapacitybeginsto
decline when the demineralised water level falls below the green area (NORMAL) on the gauge.
• Neverdrainthewatertankwhilethechillerisinoperation.
• Ensurethattheairintakeandairoutletarewellventilated.Theremustbeaclearanceofatleast8cm
(3.150in)attheairintakeandof30cm(11.811in)attheairoutlet.
• Beware of water condensation. In areas of higher ambient humidity and when the temperature of the water
is below room temperature, condensation forms on the water pipes and cooled components. In this event,
it is advisable to increase the water temperature or to warm up the pipes and cooled components.

13
M_LS100IQ EX Energy_EN_C
Introduction
Handling the machine
• Never move or lift the machine without the assistance of lifting rings and an appropriate vehicle. Serious
injurycanoccurifincorrectliftingtechniquesareused.
• The head must be handled with the greatest care.
• In the event of an extended period of non-use, unplug the power cable and protect the machine.
• Never move the head manually unless the machine is jammed mechanically.
• Neverpourorspillliquidonthemachine(drinks,cleaningproducts,etc.)exceptwhererecommendedby
Gravotech (example: lubrication).

14
M_LS100IQ EX Energy_EN_C
F. Unpacking
The machine should be carried in its packaging using a lifting system that can lift 300 kg
(661.387 lb) or more.
1. Unpacking
Only for ENERGY machines:
1. Cut and remove the straps holding the 2 parcel(s) together (water chiller)- (LS100 ENERGY/EX
ENERGY).
1. Water chiller
2. LS100 ENERGY/EX ENERGY
2. Separate the 2 parcel(s).
1. Water chiller
2. LS100 ENERGY/EX ENERGY
1
2
12

15
M_LS100IQ EX Energy_EN_C
Unpacking
For all machines:
3. Cut and remove the packaging straps.
1. Mounting screw(s)
2. Wooden board(s)
4. Removethe󰄈xingscrewsandthetwowoodenboardsfrombothsidesofthepackaging.
5. Remove the cardboard.
1
2
4
3
1. Strap(s)
2. LS100 IQ - LS100 EX - LS100 ENERGY - LS100 EX ENERGY
3. Water chiller - only for ENERGY machines
4. Protection(s)
6. Release and remove the strap.
7. Remove all the protective elements.
8. Remove the machine from the packaging (1 person(s) on each side).
9. Remove the water chiller from the packaging (1 person(s) on each side) (only for ENERGY machines)
Check that nothing is missing from the parcel. If anything is missing, contact Gravotech.
Keepthepackaginginordertomovethemachinesafely.Thispackagingisdesignedtoprotectthemachine
during shipping (return for repair...).
ThepackagingcomplieswithEuropeanrecyclingstandards.
2
2
1

16
M_LS100IQ EX Energy_EN_C
Unpacking
2. Packagecontents
Packagecontents-Machine
1
2
345
1. Machine: LS100 IQ - LS100 EX - LS100 ENERGY - LS100 EX ENERGY
2. 1 CD-ROM with user manual
3. Toolbox
4. Power cable
5. USB cord
Toolbox: Content
1
2
3
45
6 7 8 9 10 11
1. 1 bottle(s) of cleaning solution
2. 1packet(s)oflenscleaningwipes
3. 1packet(s)ofcottonbudsformirrors
4. Driver
5. Ball-tiphexkey
6. Brush
7. Setof6keys
8. Compressed air hose for air assist (Length: 100 mm (3.937 in) - Tube diameter: 4 mm (0.157 in))
9. Autofocus adjustment gage - LS100 IQ - LS100 EX
10. Autofocus adjustment gage - LS100 ENERGY - LS100 EX ENERGY
11. Barb󰘰tting-LS100ENERGY

17
M_LS100IQ EX Energy_EN_C
Unpacking
Packagecontents-Waterchiller-onlyforENERGYmachines
1 2
1. Water chiller
2. Cardboard box
Cardboard box: Content - only for ENERGY machines
1 2 3
4 5
1. Power cable
2. Water hose(s)
3. Outlet connector
4. 2 Hose clamp(s)
5. O ring

18
M_LS100IQ EX Energy_EN_C
G.Laser safety
1. Recommendations and safety regarding laser devices
Personnel safety
THIS MACHINE HAS A CLASS 4 LASER BOXED IN A CLASS 1 CASING. THIS MACHINE IS CONSIDERED
AS CLASS 2M DUE TO ITS VISIBLE DIODE LASER (Red).
• The machine is considered as Class 1 when the door is closed. In this case, the security enclosure of the
LS100IQ/EX/ENERGY islocked andsealed against potential Laser radiationemissions undernormal
workingandsafetyconditions.Themodi󰘰cationoflockingsystems,ortheremovalofthesesystemsorlabels
designedforsafety,willresultinexposuretohazardsfromtheLaserbeam.Anymodi󰘰cationisprohibited.
TheLS100IQ/EX/ENERGYisclosed,lockedandlabelledtoensurethatitworksincompletesafety.The
labels and security devices must not be removed or concealed by the operator.
• ThemachineisconsideredasClass2Mwhenthedoorisopened(emissionpowerequaltoorlessthan1
mW).Inthiscase,thesecurityshutterintheLasermoduleclosestoavoidanyriskofLaseremission.The
markingcanonlybecarriedoutifthedoorisclosed.
Ifthemachineisbeingintegrated,theinstallerisresponsibleforensuringthe󰄈nalequipmentconforms
to current legislation. Observe EN 60825-1 standard concerning the controls and signage (access
panels, doors, emergency stops...). Example: application of safety pictograms, installation of suitable
guards, use of the electrical safety channel provided on the equipment (non-exhaustive list).
Only trained personnel aware of the risks posed by the machine are authorized to use it. Only Gravotech
personnel, or persons authorized by Gravotech may service the elements that constitute the marking
machine. Any intervention by unauthorized third party would exclude Gravotech's liability.
Laser radiation is invisible, but exposure, direct or scattered, is hazardous to skin and eyes.
Donotusethismarkingequipmentinanexplosiveenvironment.Noin󰄉ammablematerialshouldbe
locatedwithinthemachineenclosurenearthere󰄉ectedbeam(operator'sshirt,curtains,wallcovering
innon-syntheticmaterial:󰄈rehazard).Forsafetyreasons,neveroperatethemachinewithoutconstant
surveillance.
Thislasercanproducedangerousdi󰓐usere󰄉ections.Itmayleadtoskinandeyeinjuriesaswellas
a󰄈rerisk.Itsuserequiresextremecaution.Fire preventionandprotectionequipmentistheuser's
responsibility. Do not look at the Laser beam continuously when marking, even through the protective
glass. The light intensity may strain the eye.
The ENERGY laser sources must be cooled by means of a water chiller with the capability to control a
minimum󰄉owandamaximumwatertemperature.Donotmodifyordisablethechiller'ssafetydevices.

19
M_LS100IQ EX Energy_EN_C
Laser safety
2. Workstationsafety
Proposed warning label at the entrance to the laser controlled zone
Speci󰄈chygieneandsafetyinstructions-Personnellaserradiationprotection
Concerned industrial use installation:
Use:
Installation:
Restricted area
Theroominwhichthissignispostedisde󰘰nedasarestrictedlaserarea:
in normal production phase (1)
maintenance and setting phase (1)
..........................................................................(1)
Regulation in the restricted area
Access to the restricted laser area is regulated. Only competent personnel having
attended proper training can remain during the operation: this implies medical aptitude
and laser safety training.
Any person authorized access to the restricted area is to observe the rules provided by
the employer.
(1)Tobe󰘰lledinorcrossedout.

20
M_LS100IQ EX Energy_EN_C
Laser safety
General Instructions
Avoid any exposure to laser radiation.
Donotputhandsoranobjectinthelaserbeam'strajectory.
Never stare into the primary laser beam.
Do not direct the beam towards other persons, openings or windows.
Avoid direct eye exposure to diode laser beam.
Do not remove protection hoods or short-circuit the securities.
Electrical interventions on the system can only be carried out by competent LT/HT
personnel.
In the event of an incident or even doubts concerning the functioning of the installation,
inform the person in charge of laser safety.
Wearing safety glasses
Under normal conditions of use, the machine operates at Class 1 - 2M: protective goggles are not necessary.
Laser radiation safety glasses are mandatory whenever in an area where laser radiation
emission exceeds class 3B AEL.
Name and address of the doctor in charge of medical exams for personnel occupying the laser restricted
area:
.................................................................................. Tel:.....................................................................
Name and address of person in charge of the observance of laser security regulation in the restricted area:
.................................................................................. Tel:.....................................................................
