Graywind 58509 User manual

Version: 1.0 Date: 4, May, 2023
58509
SMART BLINDS
USER GUIDE

WHY GRAYWIND？
We are a group of seekers for perfect life, looking for
inspiration from the purest light and shadows.
What we want to share is not only window decoration,
but also technology, art and customization.
We are committed to bringing convenient,
pleasant and elegant life experience to every customer.
Graywind embraces technology and persists
in continual innovation as well as creating
a brand new smart life experience,
bringing our user a more convenient,
safer and more enjoyable living environment.
Ultra Smart Life
Graywind represents the harmony between
light and shadows, which grants the space
graceful versatility and artistical sight.
Our users can seek for the beauty of life and
enjoy happiness.
Explore Pure Beauty
Graywind refuses to be mediocre and releases
unique true self.
We offer stylish designed product to our users.
They can delight themselves, show themselves
and release themselves without restriction
of rule and enjoy from the freedom.
Enjoy Freedom
SOCIALIZE WITH US

DISSATISFIED
SATISFIED
If your motorized blinds are running without any issues,
we invite you to activate product warranty.
1. Search graywindblinds.com or scan QR code to
visit our website.
2. Register and click account to enter personal page.
3. Choose Product Activation tab, fill in info & order id,
then submit.
4. Activation done.
We will pre-program and double check before shipment.
For battery motors, please charge them for 8-10 hours
before first use.
If the parcel you received isn't in good condition,
please take photos and confirm whether they still work.
Any after-sales questions, please scan the QR code
and contact us. We are always at service 24/7.
Customer Service:
[email protected]

CONTENTS
PARAMETERS
AA-1. Motor
A-2. Remote Control
4
5
Install The Battery
Parameters
1-2
3
Zigbee & Bluetooth Battery Motor
Wifi Hardwired Motor
INSTALLATION
BB-1. Preparation 6
7
B-2. Accessories
8-9
10-12
13-14
15-16
B-3. Installation Of Blind With Valance
Inside Mount
Outside Mount
Inside Mount
Outside Mount
B-4. Installation Of Blind Without Valance
17B-5. Take Down The Blind
REMOTE CONTROL PROGRAMMING
DD-1. Sleep Mode 26-27
D-2. Enter Setting Mode 28
29-41
D-3. Motor Programming
APP CONTROL
C18-23C-1. Zigbee Battery Motor
24
C-2. Bluetooth Battery Motor
25
C-3. Wifi Hardwired Motor

Reset Button
LED Light
Charging Port
Signal Receiver
A. PARAMETERS
A-1 MOTOR
ZIGBEE & BLUETOOTH BATTERY MOTOR
The motor is in non-signaled state when received.
Please remove the blocker to wake it up.
Signal
Blocker
Type-C Cable x1 Extension Cord x1
78.7”(2m) 78.7”(2m)
(Optional)
1

Orange Light Flashing
Out of power:
Under Charging:
Blue Light Flashing
Fully Charged:
Solid Blue
Solar Panel
(Optional)
Charger
(Not included)
5V2A
1. Please fully charge the motor for more than 8 hours
before the first use.
2. Once fully charged, it can be used for 3-6 months
depending on the frequency of use.
2

Signal Receiver
100-240V 50/60Hz
Reset Button
WIFI HARDWIRED MOTOR
Extension Cord x1
59”(1.5m)
(Optional)
3

A-2 REMOTE CONTROL
Magnetic
Holder
s x2
CR2450(3V)
4
+
Lithium Cell
CR2450
3V
Your blind has been programmed,
please control it after installation.
INSTALL THE BATTERY
+
Lithium Cell
CR2450
3V
+
Lithium Cell
CR2450
3V
+
Lithium Cell
CR2450
3V

5
PARAMETERS
BACK
FRONT
+
Lithium Cell
CR2450
3V
+
Lithium Cell
CR2450
3V
Set Key T Set Key P
Stop
Group icon:
Group “1-6”
Up
Down
- Channel
Favorite
Position
Channel+
Channel “ ”:
Group control all blinds
00
Control max 16 blinds
separately
Channel “1-16”:

6
B-1 PREPARATION
5m
* Drilling hole size 6mm
Recommended size of drill bit: 15/64''
B. INSTALLATION

7
B-2 ACCESSORIES
WITH VALANCE
NO VALANCE
f xn
v
v
Motor Side
b1x1 b2x1
2.75”
(70mm)
1.77”
(45mm)
1.1”
(27mm)
|------------|
|----|
|----------------
|
2.75”
(70mm)
1.77”
(45mm)
1.1”
(27mm)
|------------|
|----|
|----------------
|
f xn
b xn
2.4”
(60mm)
1.38”
(35mm)
1.5”
(38mm)
|-----------------------|
|-------------|
|-------------|

8
B-3 INSTALLATION OF BLIND
WITH VALANCE
INSIDE MOUNT
5”
(127mm) 5” (127mm)
5”
5”
b
b
1
2
b
f
Mark punch positions.
Drill holes & install mounting brackets.

9
3
4
5
b b
Your blind has been programmed,
please use directly.
Install the blind.
Remove paper seal.

10
OUTSIDE MOUNT
5”
(127mm) 5” (127mm)
1
2
b
b
b b
b
Clamp mounting brackets on the valance.
Mark bracket positions.

11
3
4
5
b
b
5”
＞
3.2”
(81mm)
(127mm)
b
bf
f
b
b
Take down mounting brackets.
Mark punch positions.
Drill holes & install mounting brackets.

12
6
b b
b b
7
8
Your blind has been programmed,
please use directly.
Install the blind.
Remove paper seal.

13
*Charging port
facing outward
1
2
3
INSIDE MOUNT
b1b1
b1
b2
b2
f
f
Mark punch positions.
Drill holes & install mounting brackets.
Install the side where the motor is located.
b2
B-4 INSTALLATION OF BLIND
WITHOUT VALANCE

14
4
KA!
5
6
Install the other side.
Remove paper seal.
b1b1
Your blind has been programmed,
please use directly.

15
1
2
4
5
OUTSIDE MOUNT
3
b
1
b
2
Put mounting brackets on both sides of the blind.
Mark bracket positions
Remove mounting brackets.
Mark punch positions.
Drill holes & install mounting brackets.
b1
b1
b2
b2

16
6
7
b2
KA!
b1
8
9
Install the side where the motor is located.
Install the other side.
Remove paper seal.
*Charging port
facing outward
Your blind has been programmed,
please use directly.
